Quadbeam Technologies MXD73 User manual

MXD73
Quick Start Guide
23 mm 134 mm
25 mm Min
For Cables
And Connectors
Screw Clamp x 4
Gasket Seal
Output Option Card Connection Details
NO3 C3 NC3 NO4 C4 NC4 C6 NO6C5 NO5
Output Option Connector
A B C
Relay 3
Normally
Open
Contact
Relay 3
Common
Contact
Relay 3
Normally
Closed
Contact
Relay 4
Normally
Open
Contact
Relay 4
Common
Contact
Relay 4
Normally
Closed
Contact
Relay 5
Normally
Open
Contact
Relay 5
Common
Contact
Relay 6
Normally
Open
Contact
Relay 6
Common
Contact
Modbus A
Connection
(Inverting)
(Rx-/Tx-)
Modbus C
Connection
(0V Reference)
Optional
Modbus B
Connection
(Non-Inverting)
(Rx+/Tx+)
Modbus and 4 Relays Output Option Card Connection Details
NO3 C3 NC3 NO4 C4 NC4
Output Option Connector
E F
Relay 3
Normally
Open
Contact
Relay 3
Common
Contact
Relay 3
Normally
Closed
Contact
Relay 4
Normally
Open
Contact
Relay 4
Common
Contact
Relay 4
Normally
Closed
Contact
Current
Output B “+”
Current
Output “-”
(Common)
Current
Output “-”
(Common)
Current
Output C “+”
Current
Output E “+”
Current
Output F “+”
Current
Output “-”
(Common)
Current
Output D “+”
5 Current Outputs 2 Relays Output Option Card Connection Details
I-
-
-I-
-
-I-
-
-
B C D
NO3 C3 NC3 NO4 C4 NC4 C6 NO6C5 NO5
Output Option Connector
B C D
Relay 3
Normally
Open
Contact
Relay 3
Common
Contact
Relay 3
Normally
Closed
Contact
Relay 4
Normally
Open
Contact
Relay 4
Common
Contact
Relay 4
Normally
Closed
Contact
Relay 5
Normally
Open
Contact
Relay 5
Common
Contact
Relay 6
Normally
Open
Contact
Relay 6
Common
Contact
Current
Output B “+”
Current
Output D “+”
Current
Output C “+”
Current
Output “-”
(Common)
Output Option Card Connection Details.
Available Relays and Current Outputs Vary Depending On CardType
I-
-
-
Digital Input Connection Details
Digital Input Connector
G12345678
Digital Input Connection Details
SD CARD
DIGITAL INPUTS
OUTPUT OPTION
CH3
CH2
CH1
C
CC
H
HH
1
23
A
B
C
CONDUCTIVITY G12345678
PH / REDOX ECS CONDUCTIVITY
A A B B G E C
-
E E R R
++ -
A A B B A A B B -R R D D+ + -
I- B+ C+D+
0/4 - 20mA
-
-
I- B+ C+ D+
-
-
NO3 C3 NC3 NO4 C4 NC4 C6 NO6C5 NO5
85-250V A
-+
L
+
N
-
1 2 0/4-20
mA
I-E E E A+
-
-
NO1 C1 NC1 NO2 C2 NC2
Power &
Standard Outputs
Connector
Output
Option
Channel 2 Channel 3
Channel 1 Digital
Inputs
SD Card
Slot
89 mm Sq
Recomended Panel Cut-Out
Should be 92mm X 92mm
Exact Instrument Conguration Depends
Upon Ordered Specication
MXD73 Instrument Dimensions
The MXD73 Panel Mount Instrument is designed to be ushed mounted and sealed in a
square cut-out in a panel, and is held in place with the four screw clamps provided
PO Box 1142
Pukekohe
Auckland
2340
New Zealand
Power & Standard Outputs Connection Details
CAUTION!
Always remove the main power from the system
before any alterations to the wiring. Ensure that
both power lines are isolated. Make sure that the
power cannot be switched on by accident whilst the
instrument is being connected. For safety reasons
an earth connection must be made to the earth
terminal of this instrument.
Local wiring and safety regulations should be strictly
adhered to when installing this instrument. If the
installation methods and cable types recommended
in this guide are followed, then the instrument will
achieve the levels of EMC protection as specied in
the accompanying CD manual.
Consult the serial label on the side of the
instrument for supply voltage requirements.
Fitted Options- Power Supply: 24V Output Option Card: 1-Current 2-Relays Channel1: Cond Channel2: Cond Channel3: Cond
Mains 3-Current 0-Relays pH/Redox pH/Redox pH/Redox
3-Current 4-Relays ECS ECS ECS
5-Current 2-Relays DO DO DO
Modbus 4-Relays Aux mA IP Aux mA IP Aux mA IP
SS SS SS
Telephone: [phone]
email: [email protected]
Web: www.quadbeam.co.nz
Power + Basic Outputs Connector
Relay 1
Normally Open
Contact
Relay 1
Common
Contact
Relay 1
Normally Closed
Contact
Relay 2
Normally Open
Contact
Relay 2
Common
Contact
Relay 2
Normally
Closed
Contact
NO1 C1 NC1 NO2 C2 NC2
Current
Output “-”
(Common)
Current
Output A ”+”
I- A+
-
-
Standard Outputs Connection Details
Power Supply
“Live”I n
Power Supply
“Live”Out
(For Daisy Chaining)
Power Supply
“Neutral In
Power Supply
“Neutral” Out
(For Daisy Chaining)
Protective Earth
(Must Be
Connected)
Earth Earth
Power + Basic Outputs Connector
85V-265V AC/DC Power Supply
Connection Details
Power Supply
“+” In
Power Supply
“+”Out
(For Daisy Chaining)
Power Supply
“-” In
Power Supply
“-” Out
(For Daisy Chaining)
Protective Earth
(Must Be
Connected)
Earth Earth
Power + Basic Outputs Connector
18V-32V AC/DC Power Supply
Connection Details
MON 1 JUN 2009
09:56 CH1: 517.2 µS/cm TEMP1: 12.3°C CH2: 9.64 pH
CH3: 23.3% TEMP2: 25.0°C TEMP3: 28.0°C
MAIN MENU
DIGITAL INPUTS
CHANNELS


EXIT
4-20mA OUTPUTS
CALIBRATION
SETPOINT / RELAYS

CONFIGURATION
CURSOR
FURTHER MENU
PAGES BELOW

INSTRUMENT
READINGS
CURRENT
DATE / TIME
UNIT STATUS
FURTHER MENU
PAGES ABOVE
MON 1 JUN 2009
09:56 CH1: 517.2 µS/cm TEMP1: 12.3°C CH2: 9.64 pH
CH3: 23.3% TEMP2: 25.0°C TEMP3: 28.0°C
SETPOINT 1 SETUP
INPUT SOURCE:
RANGE:
TRIGGER:
HIGH VALUE:
MODE:
CHANNEL:

SENSOR
0 to 9.999 mS/cm
HIGH
7.500mS/cm
ON/OFF

EXIT
CHANNEL 1 (COND)

LOW
BAND
LATCH HIGH
TRIGGER
HIGH
LATCH LOW 

CURSOR
ADDITIONAL
OPTIONS BELOW
OPTION POP-UP
MON 1 JUN 2009
09:56 CH1: 517.2 µS/cm TEMP1: 12.3°C CH2: 9.64 pH
CH3: 23.3% TEMP2: 25.0°C TEMP3: 28.0°C
CHANNEL 1 SETUP
UNITS:
CELL CONSTANT:
RANGE:
TEMP INPUT SENSOR:
TEMPERATURE UNITS:
MODE: SIEMENS(S/cm)
1.000
AUTO
PT1000
°C

EXIT



ON-LINE
SECURITY CODE
CODE
ENTER ACCESS
* * *
0
User Interface Overview
Scrolling Menu Layout
Front Layout
Main Menu Layout
Pop-Up Option Layout
Security Access Pop-Up
To protect the instrument setup
from unauthorised or accidental
tampering, a security access code
system is present. This is
implemented via the instrument’s
menu system which operates in two
modes, “locked” as indicated by a
padlock symbol and “unlocked” as
indicated by a key symbol.
