Quadra-Fire CASTILE-B User manual

108/227021-801F
R
CASTILE-B PELLET APPLIANCE
MODEL(S):
CASTILE-MBK-C
CASTILE-PMH-C
CASTILE-TWL-C
Installation Manual
Installation & Appliance Set-Up
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT DISCARD THIS MANUAL
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
NOTE
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrare.com
Pour obtenir une traduction française de ce manuel, s’il vous
plaît contacter votre revendeur ou visitez www.quadrare.com
Check building codes prior to installation.
• Installation MUST comply with local, regional, state
and national codes and regulations.
• Consult local building, re ofcials or authorities having
jurisdiction about restrictions, installation inspection,
and permits.
CAUTION
WARNING
• Do not store or use gasoline or other ammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not over re - If appliance or chimney connector
glows, you are over firing. Over firing will void
your warranty.
• Comply with all minimum clearances to combustibles
as specied. Failure to comply may cause house re.
If the information in these instructions is
not followed exactly, a re could result
causing property damage, personal injury,
or death.
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down. Hot
glass will cause burns.
WARNING
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room
as replace.
• Alert children and adults to hazards of high temperatures
• High temperatures may ignite clothing or other
ammable materials.
• Keep clothing, furniture, draperies and other ammable
materials away.
Tested and approved for wood pellets only. Burning of
any other type of fuel voids your warranty.
CAUTION

208/227021-801F
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Quadra-Fire is a registered trademark of Hearth & Home Technologies.
1 Important Safety Information
A. Appliance Certication . . . . . . . . . . . . . . . . . . . . . . . . .3
B. BTU & Efciency Specications..................3
C. Glass Specications...........................4
D. Electrical Rating..............................4
E. Mobile Home Approved ........................4
F. Non-Combustible Materials .....................4
G. Combustible Materials .........................4
H. Sleeping Room ..............................4
I. California - Prop65.............................4
2 Getting Started
A . Design, Installation & Location Considerations ..........5
B. Thermostat Wall Control Location ................6
C. Tools And Supplies Needed.....................6
D. Inspect Appliance and Components ..............6
E. Install Checklist ..............................7
3 Dimensions and Clearances
A. Appliance Dimensions.........................8
B. Clearances to Combustibles (UL and ULC) ........10
C. Hearth Pad Requirements (UL and ULC) .........11
D. Alcove ....................................12
4 Vent Information
A. Venting Termination Minimum Requirements.......13
B. Avoiding Smoke and Odors ....................14
C. Negative Pressure ...........................15
D. Draft15
E. Chimney and Exhaust Connection ..............15
F. Equivalent Feet of Pipe........................16
G. Pipe Selection Chart .........................16
5 Venting Systems
A. Through The Wall............................17
B. Vertical into Existing Class A Chimney............18
C. Through The Wall & Vertical - Exterior............18
D. Vertical - Interior - Typical Installation ............18
E. Interior - Rear Vent...........................19
F. Masonry ...................................19
G. Alternate Masonry ...........................19
6 Appliance Set-Up
A. Outside Air Kit Instructions.....................20
B. Top Vent Adapter Installation ...................21
C. Rear Vent & Rear Vent to Top Vent Adapter Installation
21
D. Thermostat Installation and Operation............21
E. Leg Leveling System .........................23
F. Optional Log Set Placement Instructions . . . . . . . . . .23
7 Mobile Home Installation .....................24
8 Reference Materials
A. Service and Maintenance Log . . . . . . . . . . . . . . . . . .25
B. Accessory List ..............................27
= Contains updated information


308/227021-801F
Model Castile Pellet Appliance
Laboratory OMNI Test Laboratories, Inc.
Report No. 061-S-77d-6.2
Type Solid Fuel Room Appliance/Pellet Fuel
Burning Type
Standard
ASTM E1509-04, ULC S627-00 and ULC/
ORD-C1482-M1990 Room Appliance
Pellet Fuel Burning type and (UM) 84-
HUD, Mobile Home Approved.
NOTICE: This installation must conform with local codes. In
the absence of local codes you must comply with the ASTM
E1509-04, ULC S627-00, (UM) 84-HUD and ULC/ORD-
C-1482-M1990.
A. Appliance Certication B. BTU & Efciency Specications
This pellet appliance needs periodic inspection and repair
for proper operation. It is against federal regulations to
operate this pellet appliance in a manner inconsistent with
operating instructions in this manual.
Emissions Report
Number: 0061PM077E
EPA Certication #: 175-19
EPA Certied Emissions: 1.1 grams per hour
*LHV Tested Efciency: 70.4%
**HHV Tested Efciency: 66.1%
***EPA BTU Output: 5,800 to 22,400 / hr.
****BTU Input: 9,300 to 30,600 / hr.
Vent Size: 3, 4 “L” or “PL”, or 6 inches
Hopper Capacity: 45 lbs
Fuel Premium Wood Pellets
* Weighted average LHV efciency using data collected
during EPA emissions test.
**Weighted average HHV efciency using data collected
during EPA emissions test.
***A range of BTU outputs based on HHV and the burn
rates from the low and high EPA tests.
****Maximum BTU input based on the high burn section of
the EPA emissions test.
The Castile is Certied to comply with 2020
particulate emission standards.
11 Important Safety Information

408/227021-801F
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
For assistance or additional information, consult a qualied
installer, service agency or your dealer.
C. Glass Specications
This appliance is equipped with 5mm ceramic glass.
Replace glass only with 5mm ceramic glass. Please
contact your dealer for replacement glass.
D. Electrical Rating
115 VAC, 60 Hz, Start 4.1 Amps, Run 1.1 Amps
E. Mobile Home Approved
• This appliance is approved for mobile home
installations when not installed in a sleeping room and
when an outside combustion air inlet is provided.
• The structural integrity of the mobile home oor, ceiling,
and walls must be maintained.
• The appliance must be properly grounded to the frame
of the mobile home and use only Listed pellet vent
Class “L” or “PL” connector pipe.
• Outside Air Kit, part OAK-ACC must be installed in a
mobile home installation.
F. Non-Combustible Materials
Material which will not ignite and burn, composed of any
combination of the following:
- Steel - Plaster - Brick
- Iron - Concrete - Tile
- Glass - Slate
Materials reported as passing ASTM E 136, Standard
Test Method for Behavior of Metals, in a Vertical Tube
Furnace of 750° C.
G. Combustible Materials
Material made of/or surfaced with any of the following
materials:
- Wood - Plastic
- Compressed Paper - Plywood/OSB
- Plant Fibers - Sheet Rock (drywall)
Any material that can ignite and burn: ame proofed or not,
plastered or non-plastered.
H. Sleeping Room
When installed in a sleeping room it is recommended that
3ft of vertical be installed prior to horizontally exiting the
room and a smoke/CO alarm be installed in the bedroom.
The size of the room must be at least 50ft³ per 1,000 Btu/hr
stove input, if the stove exceeds the room size, out air must
be installed.
I. California - Prop65
This product and the fuels used to operate this product (wood), and the
products of combustion of such fuels, can expose you to chemicals
including carbon black, which is known to the State of California to
cause cancer, and carbon monoxide, which is known to the State of
California to cause birth defects or other reproductive harm. For more
information go to: WWW.P65Warnings.ca.gov
WARNING
NOTE: Hearth & Home Technologies, manufacturer of
this appliance, reserves the right to alter its products,
their specications and/or price without notice.
WARNING
Fire Risk.
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be
voided by, the following actions:
• Installation and use of any damaged appliance.
• Modication of the appliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installation and/or use of any component part not
approved by Hearth & Home Technologies.
• Operating appliance without fully assembling all
components.
• Operating appliance without legs attached (if supplied
with appliance).
• Do NOT Over re - If appliance or chimney connector
glows, you are over ring.
Any such action that may cause a re hazard.

508/227021-801F
Recommended
Location
Marginal
Location
Location
Not
Recommended
Recommended
Location
Location NOT
Recommended
Multi-level Roofs
Windward
Leeward
Outside Air Kit Termination Cap
Figure 5.1
A . Design, Installation & Location Considerations
1. Appliance Location
NOTICE: Check building codes prior to installation.
22 Getting Started
WARNING
Risk of Fire.
Damaged parts could impair safe operation.
Do NOT install damaged, incomplete or
substitute components.
Since pellet exhaust can contain ash, soot or sparks, you
must consider the location of:
• Windows
• Air Intakes
• Air Conditioner
• Overhang, softs, porch roofs, adjacent walls
• Landscaping, vegetation
• Horizontal or vertical vent termination
2. Floor Support
The supporting oor under the appliance must be able to
handle the weight of the appliance, fuel load and the weight
of the chimney.
Ensure that your oor will support these weights prior to
installation. Add sufcient additional support to meet this
weight requirement prior to installation. The weight of the
appliance is 208 lbs.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Consult insurance carrier, local building inspector, re
ofcials or authorities having jurisdiction over restrictions,
installation inspection and permits.
It is a good idea to plan your installation on paper, using
exact measurements for clearances and oor protection,
before actually beginning the installation. Location of the
appliance and chimney will affect performance.
Consideration must be given to:
• Safety, convenience, trafc ow
• Placement of the chimney and chimney connector and to
minimize the use of chimney offsets.
• Place the appliance where there will be a clear passage
for a Listed chimney through the ceiling and roof (vertical)
or through exterior wall (horizontal).
• Installing the required outside air kit will affect the location
of the vent termination.
When locating vent and venting termination, the ideal
location is to vent above roof line when possible. This
minimizes the affects of wind loading.

608/227021-801F
B. Thermostat Wall Control Location
The thermostat wall control’s location will have some affect
on the appliance’s operation.
• Maximum wire length from appliance is 100 feet (30.48m)
with continuous non-spliced wire. Recommended 20
gauge wire, solid copper .
• When located close to the appliance, it may require a
slightly higher temperature setting to keep the rest of the
house comfortable.
• When located in an adjacent room or on a different
oor level, you will notice higher temperatures near the
appliance.
C. Tools And Supplies Needed
Tools and building supplies normally required for
installation, unless installing into an existing masonry
replace:
• Reciprocating Saw
• Channel Locks
• Hammer
• Phillips Screwdriver
• Tape Measure
• Plumb Line
• 1/4” Self-Tapping Screws
• Framing Material
• Hi-temp Caulking Material
• Gloves
• Safety Glasses
• Framing Square
• Electric Drill & Bits (1/4”)
• Level
May also need:
Vent Support Straps
Venting Paint
D. Inspect Appliance and Components
• Open the appliance and remove all the parts and articles
packed inside the Component Pack. Inspect all the parts
and glass for shipping damage.
• Report to your dealer any parts damaged in shipment.
• All labels have been removed from the glass door.
• Plated surfaces have been wiped clean with a soft cloth,
if applicable.
• Read all the instructions before starting the installation.
Follow these instructions carefully during the installation
to ensure maximum safety and benet.
• Follow pipe manufacturer instructions for installation and
air clearance requirements.
Risk of Fire!
• Damaged parts could impair safe operation.
• Do NOT install damaged, incomplete or
substitute components.
WARNING
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be
voided by, the following actions:
WARNING
• Installation and use of any damaged appliance.
• Modication of the appliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installation and/or use of any component part not
approved by Hearth & Home Technologies.
• Operating appliance without fully assembling all
components.
• Operating appliance without legs attached (if supplied
with appliance).
• Do NOT Over re
Or any such action that may cause a re hazard.

708/227021-801F
E. Install Checklist
YES IF NO, WHY?
Verified clearance to combustibles.
Appliance is leveled and connector is secured to appliance.
Hearth extension size/height decided.
Outside air kit installed.
Floor protection requirements have been met.
If appliance is connected to a masonry chimney, it should be cleaned and
inspected by a professional. If installed to a factory built metal chimney, the
chimney must be installed according to the manufacturer’s instructions and
clearances.
Appliance Install
Chimney configuration complies with diagrams.
Chimney installed, locked and secured in place with proper clearance.
Chimney meets recommended height requirements (5 feet minimum vertical).
Roof flashing installed and sealed.
Terminations installed and sealed.
Venting/Chimney
Clearances
Verified all clearances meet installation manual requirements.
Mantels and wall projections comply with installation manual requirements.
Floor protection and heart extensions installed per manual requirements.
Appliance Setup
All protective materials removed.
All labels have been removed from the door.
All packaging materials are removed from inside/under appliance.
Manual bag and all of its contents are removed from inside/under the appliance
and given to the party responsible for use and operation.
WARNING! Risk of Fire or Explosion! Failure to install appliance to these instructions can lead to a fire or
explosion.
Hearth & Home Technologies recommends the following:
Photographing the installation and copying this checklist for your file.
That this checklist remain visible at all times on the appliance until the installation is complete.
Electrical
120 VAC unswitched power provided to the appliance.
Check outlet with multi-meter for proper polarity and voltage (115-120 VAC).
Record voltage reading: _____________
ATTENTION INSTALLER:
Follow this Standard Work Checklist
This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual.
Customer:
Date Installed:
Lot/Address:
Location of Appliance:
Installer:
Dealer/Distributor Phone Number:
Serial Number:
Model Name:
__________________________________________________________________________
______________________________________________________________________
_______________________________________________________________________
________________________________________________________________
___________________________________________________________________________
________________________________________________________
______________________________________________________________________
_______________________________________________________________________
Started appliance and verified that all motors and blowers operate as they should.
Checked draft using a Manometer. Record readings: ______________________
Comments: Further description of the issues, who is responsible (Installer/Builder/Other Trades, ets.) and corrective action needed:
Comments communicated to party responsible __________________________ by ______________________ on ____________
(Builder/Gen. Contractor) (Installer) (Date)
Checked vacuum using a Manometer. Record readings: ____________________

808/227021-801F
Figure 8.1 - Top View
11-7/8 in
(302mm)
11-7/8 in
(302mm)
Figure 8.3 - Top View with TPVNT-6 and 811-0720
5-3/4 in
(146mm) 3-1/2 in
(89mm)
Figure 8.2 - Top View with TPVNT-2 and 812-3570
5 in
(127mm)
11-7/8 in
(297mm) 3 in
(76mm)
1-3/4 in
(44mm)
Figure 8.4 - Top view with TPVNT-2 and 811-0720
3 in
(76mm)
3-1/4 in
(83mm)
A. Appliance Dimensions
33 Dimensions and Clearances

908/227021-801F
Figure 9.1 - Front View
28-1/2 in
(724mm)
24 in
(610mm)
23-5/8 in
(600mm)
15-1/2 in
(394mm)
9-1/2 in
(241mm)
Figure 9.4 - Side View with TPVNT-2 and 811-0720
28-5/8 in
(727mm)
27 in
(686mm)
Figure 9.3 - Side View with TPVNT-6 and 811-0720
24-1/2 in
(622mm)
22-7/8 in
(581mm)
Figure 9.2 - Side View
22-7/8 in
(581mm)
17 in
(432mm)
16-1/4 in
(413mm)
24-5/8 in
(626mm)
Figure 9.5 - Side View with TPVNT-2 and 812-3570
28-3/4 in
(730mm)
26-3/4 in
(679mm)

10 08/227021-801F
Installations with:
3 to 3 inch Top Vent Adapter and
3 to 6 inch Offset Adapter Kit
NOTE:
• Illustrations reect typical installations and are FOR
DESIGN PURPOSES ONLY.
• Illustrations/diagrams are not drawn to scale.
• Actual installation may vary due to individual design
preference.
Horizontal Through the Wall Inches Millimeters
ABack Wall to Appliance 2 51
BSide Wall to Appliance 6 152
Corner Installation Inches Millimeters
CWalls to Appliance 251
C
C
A
B
Vertical Installation Inches Millimeters
DBack Wall to Flue Pipe 3 76
ESide Wall to Appliance 6 152
FBack Wall to Appliance 7 178
Corner Installation Inches Millimeters
GSide Wall to Appliance
Corner
251
HSide Wall to Flue Pipe 3 76
D
E
F
G
GH
H
B. Clearances to Combustibles (UL and ULC)

11 08/227021-801F
USA INSTALLATIONS: A non-combustible oor protection
is recommended extending beneath the ue pipe when
installed with horizontal venting or under the Top Vent
Adapter with vertical installation.
CANADA INSTALLATIONS: A non-combustible oor
protection extending beneath the ue pipe is required
with horizontal venting or under the Top Vent Adapter with
vertical installation.
27-3/4 in.
minimum
28 in.
minimum
6 in
from the fuel door
opening
6 in
USA
15 in
6 in
FUEL DOOR OPENING
Figure 11.1
702MM
minimum
711MM
minimum
152MM
FROM FUEL DOOR
OPENING
381MM
152MM
FUEL DOOR OPENING
CANADA
Must extend 51mm
beyond each side
of pipe (shaded area)
to the wall thimble.
152MM
Figure 11.2
39-1/2 in.
22-5/8 in.
15 in.
33-1/4 in.
6 in.
from the fuel door
opening
USA
Figure 11.3
C. Hearth Pad Requirements (UL and ULC)
EMBER PROTECTION: It is necessary to install a Type I
oor protector.
Floor protector must be non-combustible material, extending
beneath appliance with a minimum of 6 inches (152mm) in
front of glass and 6 inches (152mm) to both sides of the
fuel loading door. Open the door and measure 6 inches
(152mm) from the side edge of the opening in the face of
the appliance.*See exception.
CAUTION
Hearth and Home Technologies does not recommend adhesive
based vinyl ooring due to thermal expansion. Floating-style
ooring (LVP - luxury vinyl plank or LVT – luxury vinyl tile) can be
used, but it will reach temperatures up to 110 °F in a room with
ambient temperature of 70 °F. Consult ooring specications to
ensure compatibility.
When using LVP/LVT ooring, HHT Recommends pellet stove
and inserts have 29 inches of alternative ooring in front of the
stove or insert before using LVP/LVT (luxury vinyl plank/tile
ooring). Whether the stove or insert sits ush on the oor or is
elevated on a raised hearth, 29 inches of alternative ooring is
required in front of the stove or insert.
For all other ooring, continue to follow clearance to combustible
requirements in the installation manual.
NOTICE: Clearances that do not meet the minimum guidelines
could result in damage or buckling to the vinyl ooring and is
done at the installer’s risk.
Fire Risk
Comply with all minimum clearances to
combustibles as specied.
Failure to comply may cause house re.
WARNING

12 08/227021-801F
D
D. Alcove
A
C
BB
Figure 12.2
Minimum* Maximum
Inches Millimeters Inches Millimeters
AHeight 43 1092 n/a n/a
BWidth 38 965 n/a n/a
CDepth n/a n/a 36 914
DTo Side
Wall 6 152 n/a n/a
*All minimums listed are to a combustible surface.
NOTE:
• Illustrations reect typical installations and are FOR
DESIGN PURPOSES ONLY.
• Illustrations/diagrams are not drawn to scale.
• Actual installation may vary due to individual design
preference.
CANADA
Must extend 51mm
beyond each side
of pipe (shaded area)
to the wall thimble.
1603 mm
575 mm
381 mm
844 mm
152 MM
from the fuel door
opening
Figure 12.1

13 08/227021-801F
A. Venting Termination Minimum Requirements
J or K
X
V
M
I
H
A
V
G
B
V
V
A
B
V
FV
C
B
B
E
L
V
D
V
Electrical
Service
V
N
VN
V
N
N
V
Inside Corner
FIXED
CLOSED
OPEN
OPEN
FIXED
CLOSED
VX
G
G
Termination Cap Air Supply Inlet Gas Meter Restricted Area
O
P
A12 in. Above Finish Grade (the grade surface
must be a non-combustible material
B12 in.
48 in. no OAK Open door or window: below or to the side
B12 in. Open door or window: above
C6 in. Permanently closed window: above, below
or to the side
D18 in.
36 in. no OAK
Vertical clearance to a ventilated soffi t
located above the terminal within a
horizontal distance of 2 ft from the center-
line of the terminal
E12 in. Clearance to unventilated soffi t
F12 in. Clearance to outside corner
G12 in. Clearance to inside corner
H36 in. Above gas meter/regulator measured from
horizontal center-line of regulator
I36 in. USA
72 in. Canada Clearance to service regulator vent outlet
J12 in.
48 in. no OAK
Clearance to non-mechanical air supply
inlet to the building or the combustions air
inlet to any other appliance
K10 ft horizontal
3 ft vertical Clearance to mechanical air supply
L7 ft. Above paved sidewalk, paved driveway
located on public property
M12 in. Under an open veranda, porch, deck or
balcony
NSee Note
below*
Electric service: above, below or to the side
(location must not obstruct or interfere with
access)
O24 in. Adjacent building, fences and protruding
parts of the structure
P12 in. Clearance above roof line for vertical
terminations
All minimum clearances are listed with an Outside Air Kit (OAK) installed, unless otherwise noted in table below.
24 in. Above grass, top of plants, wood or any other combus-
tible
12 in.
36 in. no OAK
Clearance from any forced air intake of other appliance
12 in. Clearance horizontally from combustible wall
15 in. Vented directly through a wall, minimum length of
horizontal pipe
6 in. horizontal
12 in. vertical
Minimum horizontal or vertical terminations must pro-
trude from wall
*NOTE: Consult local building, fi re offi cials or authorities
having jurisdiction. Local codes or regulations may require
diff erent clearances.
NOTICE:
Termination must exhaust above air
inlet elevation.
• It is recommended that at least 60 inches (1.52m) of
vertical pipe be installed when appliance is vented
directly through a wall. This will create a natural draft,
which will help prevent the possibility of smoke or odor
venting into the home during a power outage.
• It will also keep exhaust from causing a nuisance
or hazard by exposing people or shrubs to
high temperatures.
• The safest and preferred venting method is to extend
the vent vertically through the roof or above the roof.
NOTICE: Do NOT Terminate Vent:
• In any location that will allow fl ue gases or soot from
entering or staining the building.
• In any location which could create a nuisance or hazard.
• In any enclosed or semi-enclosed area such as a
carport, garage, attic, crawl space, under a sun deck or
porch, narrow walkway.
• Closely fenced area, or any location that can build up
a concentration of fumes such as a stairwell, covered
breezeway, etc.
44 Vent Information

14 08/227021-801F
B. Avoiding Smoke and Odors
Negative Pressure, Shut-Down and Electrical Power
Failure
To reduce the probability of back-drafting or burn-back
in the pellet appliance during power failure or shut down
conditions, it must be able to draft naturally without exhaust
blower operation.
Negative pressure in the house will resist this natural draft if
not accounted for in the pellet appliance installation.
Heat rises in the house and leaks out at upper levels. This
air must be replaced with cold air from outdoors which ows
into lower levels of the house.
Vents and chimneys into basements and lower levels of the
house can become the conduit for air supply and reverse
under these conditions.
Outside Air
An outside air kit is recommended in all installations. The
Outside Air Kit must be ordered separately.
Per national building codes, consideration must be given to
combustion air supply to all combustion appliances. Failure
to supply adequate combustion air for all appliance demands
may lead to back drafting of those and other appliances.
When the appliance is roof vented (strongly recommended):
- The air intake is best located on the exterior wall
oriented towards the prevailing wind direction during
the heating season.
When the appliance is side-wall vented:
- The air intake is best located on the same exterior wall
as the exhaust vent outlet and located lower on the wall
than the exhaust vent outlet.
The outside air supply kit can supply most of the demands of
the pellet appliance, but consideration must be given to the
total house demand.
House demand may consume the air needed for the
appliance. It may be necessary to add additional ventilation
to the space in which the pellet appliance is located.
Consult with your local HVAC professional to determine the
ventilation demands for your house.
Vent Congurations
When installing a pellet appliance with a horizontal vent
conguration the frequency of power outages should be
considered:
• Power outages during operation will cause the appliance
to immediately turn off and may create conditions where
smoke will back draft into the house. In order to reduce
the likelihood of smoke back drafting into the house during
a power outage, Hearth and Home Technologies strongly
suggests:
- Installing the pellet venting with a minimum vertical run
of 5 feet (1.52m).
- Installing the outside air kit at least 4 feet (1.22m) below
the vent termination.
To prevent soot damage to exterior walls of the house and
to prevent re-entry of soot or ash into the house:
• Maintain specied clearances to windows, doors and air
inlets, including air conditioners.
• Vents should not be placed below ventilated softs. Run
the vent above the roof.
• Avoid venting into alcove locations.
• Vents should not terminate under overhangs, decks or
onto covered porches.
• Maintain minimum clearance of 12 inches (305mm)
from the vent termination to the exterior wall. If you see
deposits developing on the wall, you may need to extend
this distance to accommodate your installation conditions.
• DO NOT CONNECT THIS APPLIANCE TO A CHIMNEY
FLUE SERVICING ANOTHER APPLIANCE.
• DO NOT CONNECT TO ANY AIR DISTRIBUTION
DUCT OR SYSTEM.
CAUTION

15 08/227021-801F
C. Negative Pressure
NOTE: The appliance exhaust outlet is designed to
accommodate 3 inch venting. Use of 4 inch venting
requires the use of a 3-to-4 inch exhaust vent increaser
in addition to any other venting components needed, sold
separately.
Negative pressure results from the imbalance of air available
for the appliance to operate properly. It can be strongest in
lower levels of the house.
Causes include:
• Exhaust fans (kitchen, bath, etc.)
• Range hoods
• Combustion air requirements for furnaces, water
appliances and other combustion appliances
• Clothes dryers
• Location of return-air vents to furnace or air conditioning
• Imbalances of the HVAC air handling system
• Upper level air leaks such as:
-Recessed lighting
-Attic hatch
-Duct leaks
To minimize the effects of negative air pressure:
• Install the outside air kit with the intake facing prevailing
winds during the heating season
• Ensure adequate outdoor air for all combustion appliances
and exhaust equipment
• Ensure furnace and air conditioning return vents are not
located in the immediate vicinity of the appliance
• Avoid installing the appliance near doors, walkways or
small isolated spaces
• Recessed lighting should be a “sealed can” design
• Attic hatches weather stripped or sealed
• Attic mounted duct work and air handler joints and seams
taped or sealed
D. Draft
Draft is the pressure difference needed to vent an appliance
successfully. When an appliance is drafting successfully, all
combustion byproducts are exiting the home through the
chimney.
Install through the warm airspace enclosed by the building
envelope. This helps to produce more draft, especially
during lighting and die-down of the re.
Considerations for successful draft include:
• Preventing negative pressure
• Location of appliance and chimney
E. Chimney and Exhaust Connection
1. Chimney & Connector: Use 3 or 4 inch (76-102mm)
diameter type “L” or “PL” venting system. It can be
vented vertically or horizontally.
NOTE: Follow venting manufacturers recommendations
for sealing pipe joints.
NOTICE: Hearth & Home Technologies assumes no
responsibility for the improper performance of the chimney
system caused by:
• Inadequate draft due to environmental conditions
• Down drafts
• Tight sealing construction of the structure
• Mechanical exhausting devices
Risk of Asphyxiation!
Negative pressure can cause spillage of combustion
fumes and soot.
WARNING
2. Mobile Home: Approved for all Listed pellet vent. If
using the 3 inch (76mm) vertical Top Vent Adapter Kit
or the 3 to 6 inch (76-152mm) Top Vent Offset Adapter,
use Listed double wall ue connector. A Quadra-Fire
Outside Air Kit must be used with manufactured home
installations.
3. Residential: The 3 inch (76mm) vertical Top Vent
Adapter Kit and the 3 to 6 inch (76 to 152mm) Top Vent
Offset Adapter are tested to use 24 gauge single wall ue
connector or Listed double wall ue connector to Class
A Listed metal chimneys, or masonry chimneys meeting
International Residential Code standards for solid fuel
appliances.
4. Install vent at clearances specied by the vent
manufacturer.
5. Seal exhaust venting system to the unit with High Temp
500ºF RTV silicone sealant. Secure the venting system
to the unit with at least (3) screws. All pellet vent pipe
must be secured together either by means provided by
the pipe manufacturer or by (3) screws at each joint.
6. DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST
VENTING SYSTEM OF THIS Appliance.
7. DO NOT CONNECT THIS Appliance TO A CHIMNEY
FLUE SERVING ANOTHER APPLIANCE.
USE ONLY RECOMMENDED VENTING COMPONENTS;
OTHERWISE MAKESHIFT PARTS MAY RESULT IN
PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH.
WARNING

16 08/227021-801F
F. Equivalent Feet of Pipe
The table below can help you calculate the equivalent feet
of pipe which is a method used to determine pellet vent size
(Figure 16.1).
Figure 16.2
3 in. or 4 in. (76mm or
102mm) Diameter Pipe
3 in. or 4 in. (76mm or
102mm) Diameter Pipe
Equivalent Pipe
Length In Feet
Equivalent Pipe
Length In Feet
ALTITUDE IN THOUSANDS OF FEETALTITUDE IN THOUSANDS OF FEET
0
20
30
1 2 3 4 5 6 7 8 9 10
4 in. (102mm) Diameter Pipe Only4 in. (102mm) Diameter Pipe Only
10
Example 1Example 1
Example 2
Example 2
Example 1: If the equivalent length of pipe is 23 feet (7m)
with altitude of 8,000 feet (2438m) you must use 4 inch
(102mm) diameter type “L” or “PL” vent.
Example 2: If the equivalent length of pipe is 12 feet (3.7m)
with altitude of 6,000 feet (1829m) you may use 3 or 4 inch
(76 to 102mm) diameter type “L” or “PL” vent.
G. Pipe Selection Chart
The chart will help you in determining proper venting size
according to the equivalent feet of pipe calculated previously
and the altitude above sea level of this installation (Figure
16.2).
1. Locate the calculated equivalent feet of pipe on the
vertical left side of the chart.
2. Move to the right horizontally on the chart until you reach
your altitude above sea level.
3. If you fall below the diagonal line, 3 or 4 inch (76 to
102mm) pipe may be used.
4. If it is anywhere above the diagonal line, a 4 inch
(102mm) diameter pipe is required.
Pellet
Venting
Component
# of
Elbows
Feet
of
Pipe
Multiplied
By
Equivalent
Feet
Components
Equivalent
Feet
90° Elbow or
Tee
3X 5 15
45° Elbow X3
Horizontal
Pipe
7X1 7
Vertical Pipe 2X 0.5 1
Total Equivalent Feet 23
NOTE: This is a generic example and is not intended to represent any specic fuel type.
Example of 3 Elbow-Rear Vent Termination Calculation
2 ft.
2 ft.
3 ft.
2 ft.
Figure 16.1
NOTICE:
• A 90° elbow is 5 times as restrictive to the ow of
exhaust gases under positive pressure as 1 foot
(305mm) of horizontal pipe.
• A foot of horizontal pipe is twice as restrictive as a foot
of vertical pipe.
Vent surfaces get HOT, can cause burns
if touched. Non-combustible shielding or
guards may be required.
WARNING
Risk of Fire!
• Only LISTED venting components may be
used.
• NO OTHER vent components may be used.
• Substitute or damaged vent components may
impair safe operation.
WARNING
Risk of Injury or Property Damage.
• Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage.
• Refer to the owner’s information manual
provided with this appliance.
• For assistance or additional information
consult a qualied installer, service agency
or your dealer.
WARNING

17 08/227021-801F
Figure 17.1
6 in.
(152mm)
Minimum
Non-combustible Hearth Pad
Wall
Thimble Horizontal
Termination
Cap
2 in.
(51mm)
Minimum
6 in.
(152mm)
Minimum
From Glass
Straight Out
45 Degree
Figure 17.2
Wall
Thimble
Illustration shows venting going in both directions.
Choose which one is best for your installation.
2 in. (51mm)
Minimum
2 in.
(51mm)
Minimum
6 in. (152mm)
Minimum
6 in.
(152mm)
Minimum
A. Through The Wall
Horizontal termination cap must be a minimum of 6
inches. (152mm) from the wall. Approved for mobile home
installations. Must use 3 or 4 inch (76-102mm) “L” or
“PL” Listed pellet venting or Listed double wall pipe and a
Quadra-Fire Outside Air Kit in mobile homes.
NOTE: In Canada, where passage through a wall or
partition of combustible construction is desired, the
installation shall conform to CAN/CSA-B365
NOTICE: Please note that while the minimum clearance
for the termination cap is 6 inches (152mm) there is the
possibility of soot build-up around the termination area.
If this occurs we suggest to move the termination further
away from the house to prevent it.
55 Venting Systems
We strongly recommend that you DO NOT DOWNWARD
VENT. The following may occur:
• The appliance will not vent properly
• Smoke spillage in the house
• Excessive sooting
CAUTION

18 08/227021-801F
D. Vertical - Interior - Typical Installation
Figure 18.3
Non-combustible Hearth Pad
Airtight
Clean-out Door
Clean-out cover
Sheathing
3 in. (76mm)
minimum
1 in. (25mm)
clearance
Flashing
Fireclay flue
liner with airspace
Concrete Cap
1 in. (25mm) clearance
with firestop
6 in. (152mm)
minimum
C. Through The Wall & Vertical - Exterior
Figure 18.2
Non-combustible Hearth Pad
Clean-out Cover
Support Bracket
every 60 in. (1.5m)
24 in. (610mm) minimum
Rain Cap
Flashing
2 in. (51mm) minimum
6 in. (152mm)
minimum
Tee
Wall Thimble
Figure 18.1
Firestop
Flashing
Rain Cap
6 in.
(152mm)
Min.
Non-combustible Hearth Pad
3 in. (76mm) Min.
Clean-out Cover
24 in. (610mm) Minimum
Ceiling Support
6 in. (152mm) Flue
Connector
6 in. (152mm) Class A
Chimney Connector
Adapter
3 in. to 6 in.
(76-152mm)
Top Vent Kit
B. Vertical into Existing Class A Chimney We recommend a minimum of 60 inches (1524mm) vertical,
however above the eave is preferred.
All three installations are approved for mobile home
installations. Must use 3 or 4 inch (76 to 102mm) “L” or “PL”
Listed pellet venting or Listed double wall pipe and Quadra-
Fire Outside Air Kit in mobile homes. Single wall pipe is
approved for residential installations only.
NOTE: A chimney connector shall not pass through an
attic or roof space, closet or similar concealed space, or
a oor or ceiling.
*NOTE: Clearance to combustibles are for standard
pellet pipe. If pellet pipe manufacturer allows reduced
clearances to their pipe, reduced clearances are allowed.

19 08/227021-801F
F. Masonry
G. Alternate Masonry
Figure 19.3
Non-combustible Hearth Pad
Airtight
Clean-out Door
Clean-out cover
Sheathing
3 in. (76mm)
minimum
1 in. (25mm)
clearance
Flashing
Fireclay flue
liner with airspace
Concrete Cap
1 in. (25mm) clearance
with firestop
6 in. (152mm)
minimum
Figure 19.4
Non-combustible
Hearth Pad
Airtight clean-out door
Sheathing
2 in. (51mm) minimum
Flashing
1 in. (25mm) clearance
1 in. (25mm) clearance
with firestop
6 in. (152mm) minimum
Fireclay Flue Liner
with airspace
Concrete Cap
Fire Risk.
Inspection of Chimney:
• Masonry chimney must be in good condition.
• Meets minimum standard of NFPA 211
• Factory-built chimney must be a minimum
6 inch (152mm) UL103 HT.
WARNING
E. Interior - Rear Vent
Figure 19.1
Non-combustible Hearth Pad
Wall Thimble
12 in
[305 mm]
Minimum
6 in
[152mm]
Min
3 to 3 in
[76 to 76 mm]
Top Vent Kit
6 in
[152mm]
Min
60 in
[1524 mm]
Recommended
Figure 19.2
Non-combustible Hearth Pad
Wall Thimble
12 in
[305 mm]
Minimum
2 in [51mm] min
6 in
[152mm]
Min
Clean-out Tee
60 in
[1524 mm]
Recommended


20 08/227021-801F
A. Outside Air Kit Instructions
Figure 20.1
Mounting Slots
Pre-cut Hole
Figure 20.2
Align hooks with slots, push up
and slide forward
Attach air channel to stove with 2 screws
Attach collar to air channel with 2 screws
Termination
Cap Assembly
Termination
Cap Assembly
Hose ClampHose Clamp
Trim RingTrim Ring
Flex Hose
Flex Hose
Hose Clamp
Hose Clamp
Collar Assembly
Collar Assembly
Air Intake Channel
(Discard)
Air Intake Channel
(Discard)
Figure 20.3
1. Figure 20.1 shows bottom of convection blower mount
and pre-cut air vent opening for reference only. Air
channel should be mounted with appliance in upright
position.
66 Appliance Set-Up
Never draw outside combustion air from:
• Wall, oor or ceiling cavity
• Enclosed space such as an attic or garage
CAUTION
4. Measure distance from oor to air vent opening in
appliance and mark location on wall. Use saw to cut
opening in wall. Cut a 2-1/2 to 3 inch (64-76mm) opening
on inside wall and a 3 to 3-1/2 inch (76-89mm) opening
on outside of house.
5. Use hose clamp to secure ex pipe to collar assembly.
6. Slide trim ring over ex pipe and run pipe through wall.
7. Attach hose to outside termination cap with second hose
clamp.
8. Secure termination cap to outside surface.
9. Secure trim ring to interior wall.
2. Align hooks in air channel with slots in convection blower
mount and ash box (Figure 20.2). Push up and slide
forward.
3. Secure air channel to appliance with 2 screws and
secure the collar assembly to the air channel with 2
screws (Figure 20.3).
