Quadra-Fire CASTILE-MBK-B User manual

1 7021-154J May 12, 2017
CASTILE-B PELLET APPLIANCE
Model(s):
CASTILE-MBK-B CASTILE-CWL-B
CASTILE-CSB-B CASTILE-PMH-B
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
Installation Manual
Installation & Appliance Set-Up
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT DISCARD THIS MANUAL
O-T L
Tested and
Listed by
Portland
Oregon USA
OMNI-Test Laboratories, Inc.
CUS
WARNING
If the information in these instruc-
tions is not followed exactly, a
re could result causing property
damage, personal injury, or death.
• Donotstoreorusegasolineorotheram-
mablevaporsandliquidsinthevicinityof
thisoranyotherappliance.
• Donotoverre-Ifapplianceorchimney
connectorglows,youareoverring.Over
ringwillvoidyourwarranty.
• Complywithallminimumclearancesto
combustiblesasspecied.Failureto
complymaycausehousere.
HOT SURFACES!
Glassandothersurfacesarehot
 duringoperationANDcooldown.
Hot glass will cause burns.
• Donottouchglassuntilitiscooled
• NEVERallowchildrentotouchglass
• Keepchildrenaway
• CAREFULLY SUPERVISE children in same room as
replace.
• Alertchildrenandadultstohazardsofhightemperatures
• High temperatures may ignite clothing or other
ammable materials.
• Keep clothing, furniture, draperies and other ammable
materialsaway.
WARNING
CAUTION
Testedandapprovedforwoodpelletsorshelledcornonly.
Burningofanyothertypeoffuelvoidsyourwarranty.
NOTE
ToobtainaFrenchtranslationofthismanual,pleasecontact
yourdealerorvisitwww.quadrare.com
Pourobtenirunetraductionfrançaisedecemanuel,s’ilvous
plaîtcontactervotrerevendeurouvisitezwww.quadrare.com
CAUTION
Checkbuildingcodespriortoinstallation.
• InstallationMUSTcomplywithlocal,regional,stateandna-
tionalcodesandregulations.
• Consultlocalbuilding,reofcialsorauthoritieshavingjuris-
dictionaboutrestrictions,installationinspection,andpermits.

2 7021-154J May 12, 2017
CASTILE FREESTANDING
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicatesahazardoussituationwhich,ifnotavoidedwillresultindeathorseriousinjury.
• WARNING!Indicatesahazardoussituationwhich,ifnotavoidedcouldresultindeathorseriousinjury.
• CAUTION! Indicatesahazardoussituationwhich,ifnotavoided,couldresultinminorormoderateinjury.
• NOTICE:Indicatespracticeswhichmaycausedamagetotheapplianceortoproperty.
1 Important Safety Information............3
A.ApplianceCertication......................................................3
B.BTU&EfciencySpecications........................................3
C.GlassSpecications.........................................................3
D.ElectricalRating................................................................3
E.MobileHomeApproved.................................................... 3
2 Getting Started ...................................4
A . Design,Installation&LocationConsiderations..........................4
B.ThermostatWallControlLocation......................................5
C.ToolsAndSuppliesNeeded..............................................5
D.InspectApplianceandComponents.................................5
E.InstallChecklist..................................................................6
3 Dimensions and Clearances.............7
A.ApplianceDimensions......................................................7
B.ClearancestoCombustibles(ULandULC).......................8
C.HearthPadRequirements(ULandULC)..........................8
D.Alcove..............................................................................9
4 Vent Information...............................10
A.VentingTerminationMinimumRequirements...................10
B.AvoidingSmokeandOdors..............................................11
C.NegativePressure............................................................11
D.Draft ..............................................................................12
E.ChimneyandExhaustConnection..................................12
F.VentingTerminationRequirements...................................12
G.EquivalentFeetofPipe...................................................13
H.PipeSelectionChart........................................................13
I.PelletVentingCharts..........................................................14
5 Venting Systems ..............................15
A.ThroughTheWall.............................................................15
B.VerticalintoExistingClassAChimney.............................16
C.ThroughTheWall&Vertical-Exterior..............................16
D.Vertical-Interior-TypicalInstallation................................16
E.Masonry............................................................................17
F.AlternateMasonry.............................................................17
6 Appliance Set-Up .............................18
A.OutsideAirKitInstructions................................................18
B.TopVentAdapterInstallation............................................19
C.RearVent&RearVenttoTopVentAdapterInstallation...19
D.LegLevelingSystem........................................................19
E.OptionalLogSetPlacementInstructions..........................20
F.ThermostatInstallationandOperation..............................20
7 Mobile Home Installation.................22
8 Accessory List .................................23

May 12, 2017 7021-154J 3
CASTILE FREESTANDING
Model CastilePelletAppliance
Laboratory OMNITestLaboratories,Inc.
Report No. 061-S-77d-6.2
Type SolidFuelRoomAppliance/PelletFuel
BurningType
Standard ASTME1509-04,ULCS627-00and
ULC/ORD-C1482-M1990RoomAppli-
ancePelletFuelBurningtypeand(UM)
84-HUD,MobileHomeApproved.
FCC ComplieswithPart15ofFCCRules.
Operationissubjecttothefollowing
twoconditions:(1)thisdevicemaynot
causeharmfulinterference,and(2)this
devicemustacceptanyinterference
received,includinginterferencethatmay
causeundesiredoperation.
1 Important Safety Information
NOTE:Hearth&HomeTechnologies,manufacturerof
thisappliance,reservestherighttoalteritsproducts,their
specicationsand/orpricewithoutnotice.
Improper installation, adjustment, alteration, service or
maintenancecancauseinjuryorpropertydamage.
Forassistanceoradditionalinformation,consultaqualied
installer,serviceagencyoryourdealer.
Quadra-FireisaregisteredtrademarkofHearth&Home
Technologies.
• Installationanduseofanydamagedappliance.
• Modicationoftheappliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installationand/oruseofanycomponentpartnotapprovedby
Hearth&HomeTechnologies.
• Operatingappliancewithoutfullyassemblingallcomponents.
• Operating appliance without legs attached (if supplied with
appliance).
• DoNOTOverre-Ifapplianceorchimneyconnectorglows,
youareoverring.
Anysuchactionthatmaycausearehazard.
WARNING
Fire Risk.
Hearth&HomeTechnologiesdisclaimsany
responsibilityfor,andthewarrantywillbevoidedby,
thefollowingactions:
C. Glass Specications
Thisapplianceisequippedwith5mmceramicglass.
Replaceglassonlywith5mmceramicglass.Pleasecon-
tactyourdealerforreplacementglass.
D. Electrical Rating
115VAC,60Hz,Start4.1Amps,Run1.1Amps
E. Mobile Home Approved
• Thisapplianceisapprovedformobilehomeinstalla-
tionswhennotinstalledinasleepingroomandwhen
anoutsidecombustionairinletisprovided.
• Thestructuralintegrityofthemobilehomeoor,ceil-
ing,andwallsmustbemaintained.
• The appliance must be properly grounded to the
frameofthemobilehomeanduseonlyListedpellet
ventClass“L”or“PL”connectorpipe.
• OutsideAirKit,partOAK-ACCmustbeinstalledina
mobilehomeinstallation.
NOTICE: Thisinstallationmustconformwithlocalcodes.In
theabsenceoflocalcodesyoumustcomplywiththeASTM
E1509-04, ULC S627-00, (UM) 84-HUD and ULC/ORD-
C-1482.
A. Appliance Certication
B. BTU & Efciency Specications
The Quadra-Fire Castile PelletAppliance meets the U.S.
EnvironmentalProtectionAgency’semissionlimitsforpellet
appliancessoldafterMay15,2015.
Thispelletapplianceneedsperiodicinspectionandrepairfor
properoperation.Itisagainstfederalregulationstooperate
thispelletapplianceinamannerinconsistentwithoperating
instructionsinthismanual.
EPACertication#: 940-14
EPACertiedEmissions: 1.8gramsperhour
*LHVTestedEfciency: N/A
**HHVTestedEfciency: N/A
***EPABTUOutput: 8,500to28,200/hr.
****BTUInput: 11,600to38,700/hr.
VentSize: 3or4inches,LorPL
HopperCapacity: 40lbs.+/-5lbs.
Fuel WoodPellets
*WeightedaverageLHVefciencyusingdatacollectedduring
EPAemissionstest.
**WeightedaverageHHVefciencyusingdatacollectedduring
EPAemissionstest.
***ArangeofBTUoutputsbasedonEPADefaultEfciencyand
theburnratesfromthelowandhighEPAtests.
****Based on the maximum feed rate per hour multiplied by
approximately 8600 BTU’s which is the average BTU’s from a
poundofpellets.

4 7021-154J May 12, 2017
CASTILE FREESTANDING
Install Guide
2 Getting Started
Marginal Location:
• Below peak
Location NOT recommended:
• Not the highest point of the roof
• Wind loading possible
Multi-level Roofs
Windward
Leeward
Recommended:
Outside Air Intake
on windward side
NOT recommended:
Outside Air Intake
on leeward side
Recommended Location:
• Above peak
Recommended:
• Insulated exterior chase
in cooler climates
Recommended Location:
• Above peak
• Inside heated space
Location NOT recommended:
• Too close to tree
• Below adjacent structure
• Lower roof line
• Avoid outside wall
Marginal Location:
• Wind loading possible
Figure 4.1
A . Design, Installation & Location Considerations
1. Appliance Location
NOTICE: Check building codes prior to installation.
• InstallationMUSTcomplywithlocal,regional,stateand
nationalcodesandregulations.
• Consult insurance carrier, local building inspector, re
ofcialsorauthoritieshavingjurisdictionoverrestrictions,
installationinspectionandpermits.
Itisagoodideatoplanyourinstallationonpaper,usingexact
measurements for clearances and oor protection, before
actuallybeginningtheinstallation.Locationoftheappliance
andchimneywillaffectperformance.
Considerationmustbegivento:
• Safety,convenience,trafcow
• Placementofthechimneyandchimneyconnectorandto
minimizetheuseofchimneyoffsets.
• Placetheappliancewheretherewillbeaclearpassage
foraListedchimneythroughtheceilingandroof(vertical)
orthroughexteriorwall(horizontal).
• Installingtherequiredoutsideairkitwillaffectthelocation
oftheventtermination.
Whenlocatingventandventingtermination,theidealloca-
tionistoventaboverooflinewhenpossible.Thisminimizes
theaffectsofwindloading.
Since pellet exhaust can contain ash, soot or sparks, you
mustconsiderthelocationof:
• Windows
• AirIntakes
• AirConditioner
• Overhang,softs,porchroofs,adjacentwalls
• Landscaping,vegetation
• Horizontalorverticalventtermination
2. Floor Support
The supporting oor under the appliance must be able to
handletheweightoftheappliance,fuelloadandtheweight
ofthechimney.
Ensure that your oor will support these weights prior to
installation. Add sufcient additional support to meet this
weightrequirement priorto installation.The weightof the
applianceis258lbs.
WARNING
Fire Risk.
Damagedpartscouldimpairsafeoperation.Do
NOTinstalldamaged,incompleteorsubstitute
components.

May 12, 2017 7021-154J 5
CASTILE FREESTANDING
•  Installation and use of any damaged
appliance.
•Modicationoftheappliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installationand/oruseofanycomponentpartnotapproved
byHearth&HomeTechnologies.
• Operatingappliancewithoutfullyassemblingallcomponents.
• Operatingappliancewithoutlegsattached(ifsupplied with
appliance).
• DoNOTOverre
Or any such action that may cause a re hazard.
WARNING
Hearth&HomeTechnologiesdisclaimsany
responsibilityfor,andthewarrantywillbe
voidedby,thefollowingactions:
ReciprocatingSaw  ChannelLocks
Hammer  PhillipsScrewdriver
TapeMeasure  PlumbLine
1/4”Self-TappingScrews FramingMaterial
Hi-tempCaulkingMaterial Gloves
SafetyGlasses  FramingSquare
ElectricDrill&Bits(1/4”) Level
Mayalsoneed:
VentSupportStraps  VentingPaint
Tools and building supplies normally required
for installation, unless installing into an existing
masonry replace:
C. Tools And Supplies Needed
B. Thermostat Wall Control Location
The thermostatwallcontrol’slocationwillhavesomeaffect
on the appliance’soperation.
• Maximumwirelengthfromapplianceis100feet(30.48m)
with continuous non-spliced wire.  Recommended 20
gaugewire,solidcopper.
• When located close to the appliance, it may require a
slightlyhighertemperaturesettingtokeeptherestofthe
housecomfortable.
• Whenlocatedinanadjacentroomoronadifferentoor
level,youwillnoticehighertemperatures near the appli-
ance.
D. Inspect Appliance and Components
• Opentheapplianceandremoveallthepartsandarticles
packedinsidetheComponentPack.Inspectalltheparts
andglassforshippingdamage.
• Reporttoyourdealeranypartsdamagedinshipment.
• Alllabelshavebeenremovedfromtheglassdoor.
• Platedsurfaceshavebeenwipedcleanwithasoftcloth,
ifapplicable.
• Read all the instructions before starting the installation.
Follow these instructions carefully during the
installation to ensure maximum safety and benet.
• Follow pipe manufacturer instructions for installation
and air clearance requirements.
WARNING
Fire Risk.
Damagedpartscouldimpairsafeoperation.
DoNOTinstalldamaged,incompleteor
substitutecomponents.

6 7021-154J May 12, 2017
CASTILE FREESTANDING
E. Install Checklist
Appliance Install
Appliance is leveled and connector is secured to appliance.
Hearth extension size/height decided.
Outside air kit installed.
Floor protection requirements have been met.
If appliance is connected to a masonry chimney, it should be cleaned and
inspected by a professional. If installed to a factory built metal chimney, the
chimney must be installed according to the manufacturer’s instructions and
clearances.
Chimney
Chimney installed, locked and secured in place with proper clearance.
Chimney meets recommended height requirements (14-16 feet).
Terminations installed and sealed.
Clearances
Combustible materials not installed in non-combustible areas.
Mantels and wall projections comply with installation manual requirements.
Protective hearth strips and hearth extension installed per manual requirements.
Appliance Setup
All packaging and protective materials removed.
All labels have been removed from the door.
All packaging materials are removed from inside/under the appliance.
Manual bag and all of its contents are removed from inside/under the appliance
and given to the party responsible for use and operation.
ATTENTION INSTALLER:
Follow this Standard Work Checklist
This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual.
Customer: __________________________________________________________________________
Date Installed: __________________________________________________________________________
Lot/Address: __________________________________________________________________________
Location of Appliance: ______________________________________________________________
Installer: __________________________________________________________________________
Dealer/ Distributor Phone #: ______________________________________________________________
Serial #: __________________________________________________________________________
Model : __________________________________________________________________________
WARNING! Risk of Fire or Explosion!
Hearth & Home Technologies recommends the following:
• That this checklist remain visible at all times on the appliance until the installation is complete.
Comments: Further description of the issues, who is responsible (Installer/Builder/Other Trades, etc.) and corrective action needed:
Comments communicated to party responsible by on
(Builder/Gen. Contractor) (Installer) (Date)
YES IF NO, WHY?

May 12, 2017 7021-154J 7
CASTILE FREESTANDING
Figure 7.2- Front View
Figure 7.1 - Top View
Figure 7.3 -Side View Figure 7.4 - Side View with Top Vent Adapter
24 in. (609mm)
24-5/8 in.
(626mm)
12 in.
(305mm)
24 in. (609mm)
28-9/16 in.
(725mm)
15-15/16 in.
(405mm)
22-7/8 in.
(582mm)
17 in.
(431mm)
16-5/16 in.
(414mm)
28-3/4 in.
(730mm)
5 in.
(126mm)
27-7/8 in.
(708mm)
3 in.
(76mm)
3 Dimensions and Clearances
A. Appliance Dimensions

8 7021-154J May 12, 2017
CASTILE FREESTANDING
Straight Back Against Wall Inches Millimeters
ABackWalltoAppliance 2 51
BSideWalltoAppliance 6 152
Corner Installation Inches Millimeters
CWallstoAppliance 2 51
Vertical Installation Inches Millimeters
DBackWalltoFluePipe 3 76
ESideWalltoAppliance 6 152
FBackWalltoAppliance 7 178
Corner Installation Inches Millimeters
GSideWalltoAppliance
Corner
2 51
Installations with:
3 to 3 inch Top Vent Adapter and
3 to 6 inch Offset Adapter Kit
NOTE:
•IllustrationsreecttypicalinstallationsandareFORDESIGNPUR-
POSESONLY.
• Illustrations/diagramsarenotdrawntoscale.
• Actualinstallationmayvaryduetoindividualdesignpreference.
Hearth Pad Requirements Inches Millimeters
KSides 2 51
L* Back 2 51
MFront 6 152
*L Exception for Horizontal Installations:
USA INSTALLATIONS: A non-combustible oor protec-
tion is recommendedextendingbeneaththeuepipewhen
installed with horizontal venting or under the Top Vent
Adapterwithverticalinstallation.
CANADA INSTALLATIONS:A non-combustibleoorpro-
tectionextendingbeneaththeuepipeis required withhor-
izontalventing orunder theTopVent Adapterwith vertical
installation.
C
C
A
B
D
E
F
G
GH
H
L*
K
K
M
Must extend 2 inches (51mm) beyond each
side of pipe (shaded area)
Dimension to Corner Inches Millimeters
IFlueCenterLine 10-3/8 264
JBackofTopVentAdapter 9-1/8 232
J
I
C
L
HSideWalltoFluePipe 3 76
Alcove Installation Inches Millimeters
MinimumAlcoveHeight 43 1092
MinimumAlcoveSideWall 6 152
MinimumAlcoveWidth 38 965
MaximumAlcoveDepth 36 914
B. Clearances to Combustibles (UL and ULC)
C. Hearth Pad Requirements (UL and ULC)
Use a non-combustible oor protector, extending beneath
applianceandtothefront, sidesandrearasindicated.Mea-
surefrontdistance“M”fromthesurfaceoftheglassdoor.
Fire Risk.
Complywithallminimumclearancestocombustibles
asspecied.Failuretocomplymaycausehousere.
WARNING

May 12, 2017 7021-154J 9
CASTILE FREESTANDING
A
C
B
D
NOTE:
• IllustrationsreecttypicalinstallationsandareFOR
DESIGNPURPOSESONLY.
•Illustrations/diagramsarenotdrawntoscale.
• Actualinstallationmayvaryduetoindividualdesign
preference.
D. Alcove
Figure 9.1
*Allminimumslistedaretoacombustiblesurface.
Minimum* Maximum
Inches Millimeters Inches Millimeters
AHeight 43 1092 n/a n/a
BWidth 38 965 n/a n/a
CDepth n/a n/a 36 914
DToSideWall 6 152 n/a n/a

10 7021-154J May 12, 2017
CASTILE FREESTANDING
4 Vent Information
A. Venting Termination Minimum Requirements
J or K
X
V
M
I
H
A
V
G
B
V
V
A
B
V
FV
C
B
B
E
L
V
D
V
Electrical
Service
V
N
VN
V
N
N
V
Inside Corner
FIXED
CLOSED
OPEN
OPEN
FIXED
CLOSED
VX
G
G
Termination Cap Air Supply Inlet Gas Meter Restricted Area
O
P
Figure 10.1
A12in. AboveFinishGrade(thegradesurface
mustbeanon-combustiblematerial
B48in.noOAK Opendoororwindow:belowortotheside
B12in. Opendoororwindow:above
C6in. Permanentlyclosedwindow:above,below
ortotheside
D36in.noOAK Verticalclearancetoaventilatedsoft
locatedabovetheterminalwithinahori-
zontaldistanceof2ftfromthecenter-line
oftheterminal
E12in. Clearancetounventilatedsoft
F12in. Clearancetooutsidecorner
G12in. Clearancetoinsidecorner
H36in. Abovegasmeter/regulatormeasuredfrom
horizontalcenter-lineofregulator
I36in.USA
72in.Canada
Clearancetoserviceregulatorventoutlet
J48in.noOAK Clearancetonon-mechanicalairsupply
inlettothebuildingorthecombustionsair
inlettoanyotherappliance
K10fthorizontal
3ftvertical
Clearancetomechanicalairsupply
L7ft. Abovepavedsidewalk,paveddriveway
locatedonpublicproperty
M12in. Underanopenveranda,porch,deckor
balcony
NSeeNote
below*
Electricservice:above,belowortothe
side(locationmustnotobstructorinterfere
withaccess)
O24in. Adjacentbuilding,fencesandprotruding
partsofthestructure
P12in. Clearanceaboverooflineforvertical
terminations
All minimum clearances are listed with an Outside Air Kit (OAK) installed, unless otherwise noted in table below.
24in. Abovegrass,topofplants,woodoranyothercom-
bustible
36in.noOAK Clearancefromanyforcedairintakeofotherappli-
ance
12in. Clearancehorizontallyfromcombustiblewall
15in. Venteddirectlythroughawall,minimumlengthof
horizontalpipe
6in.horizontal
12in.vertical
Minimumhorizontalorverticalterminationsmust
protrudefromwall
*NOTE: Consultlocalbuilding,reofcialsorauthoritieshavingjurisdic-
tion.Localcodesorregulationsmayrequiredifferentclearances.
NOTICE:
Do NOT Terminate Vent:
• Inanylocationthatwillallowuegasesorsootfromen-
teringorstainingthebuilding
• Inanylocationwhichcouldcreateanuisanceorhazard
• Inanyenclosedorsemi-enclosedareasuchasacarport,
garage, attic, crawl space, under a sun deck or porch,
narrowwalkway
• Closely fenced area, or any location that can build up
a concentration of fumes such as a stairwell, covered
breezeway,etc.
NOTICE:
Termination must exhaust above air inlet elevation.
• Itisrecommendedthatatleast60inches(1.52m)ofvertical
pipebeinstalledwhenapplianceisventeddirectlythrougha
wall.Thiswillcreateanaturaldraft,whichwillhelpprevent
thepossibilityofsmokeorodorventingintothehomeduring
apoweroutage.
• Itwillalsokeepexhaustfromcausinganuisanceorhazard
byexposingpeopleorshrubstohightemperatures.
• Thesafestandpreferredventingmethodistoextendthevent
verticallythroughtherooforabovetheroof.
