USER MANUAL

Before you begin using the vehicle, you must read this i
nstruction manual carefully
Dear Customer,
QUADRO thanks you for choosing this vehicle, and welcomes you as a customer!
You can help to maintain the efficiency, performance and safety conditions of your vehicle with careful
maintenance, performed only by authorised QUADRO dealers or workshops.
Our technicians are committed to producing high quality vehicles, the result of our extensive experience, to
guarantee you the pleasure of safe driving over time.
Please read the owner's handbook supplied with your QUADRO vehicle carefully, and make sure that all routine
and extraordinary maintenance and any technical
servicing is performed exclusively by the specialist staff from our Network of QUADRO Dealers.
To ensure the safety, reliability and value of your vehicle, and to maintain the validity of the warranty, use only
original
QUADRO spare parts and recommended lubricants.

2
INDEX
CHAP.1 INTRODUCTION..................................................................................................................................................... 5
1.1 GENERALIT INFORMATION..................................................................................................................................... 6
CHAP.2 SAFETY PRECAUTIONS AND RECOMMENDATIONS........................................................................................ 9
2.1 ICONS AND INDICATIONS ..................................................................................................................................... 10
2.2 POSITIONING INFORMATIVE STICKERS ............................................................................................................. 12
2.3 GENERAL RECOMMENDATIONS AND REQUIREMENTS ..................................................................................15
2.4 CLOTHING .............................................................................................................................................................. 15
2.5 REFUELLING THE VEHICLE ................................................................................................................................. 16
2.6 SAFE DRIVING ....................................................................................................................................................... 16
2.7 WHEN AT A STANDSTILL ...................................................................................................................................... 19
2.8 - LOAD LIMITS ........................................................................................................................................................ 19
2.9 UNAUTHORISED MODIFICATIONS/ACCESSORIES AND SPARE PARTS ......................................................... 20
2.10 SAFETY INSTRUCTIONS DURING SERVICING AND MAINTENANCE.............................................................. 21
2.11 SAFETY AND REPAIR SYSTEM........................................................................................................................... 22
2.12 RESPONSIBILITIES AND LIMITS OF USE........................................................................................................... 23
CHAP.3 HANDLING AND TRANSPORT ........................................................................................................................... 25
3.1 PRELIMINARY OPERATIONS ................................................................................................................................ 26
CHAP. 4 DESCRIPTION OF THE VEHICLE ...................................................................................................................... 27
4.1 INTENDED USE....................................................................................................................................................... 28
4.2 NOT INTENDED, INCORRECT USE....................................................................................................................... 28
4.3 TECHNICAL DATA .................................................................................................................................................. 30
4.4 COMPONENT LOCATION....................................................................................................................................... 34
4.5 DASHBOARD LEGEND........................................................................................................................................... 35
4.6 INSTRUMENT CLUSTER LEGEND ........................................................................................................................ 35
4.7. INSTRUMENT PANEL FUNCTIONS ...................................................................................................................... 36
4.8 SCHEDULED SERVICING TELL-TALE LIGHT ....................................................................................................... 37

3
4.9 - LEFT-HAND HANDLEBAR MOUNTED CONTROLS............................................................................................ 37
4.10 - RIGHT-HAND HANDLEBAR MOUNTED CONTROLS........................................................................................ 38
4.11 KEYS...................................................................................................................................................................... 38
4.12 STEERING LOCK .................................................................................................................................................. 39
4.13 - KEY-CONTROLLED SWITCH ............................................................................................................................. 40
4.14 PARKING LEVER .................................................................................................................................................. 40
4.15 STORAGE COMPARTMENT BELOW THE SEAT ................................................................................................ 41
4.16 FRONT BOX .......................................................................................................................................................... 42
4.17 LUGGAGE RACK................................................................................................................................................... 42
4.18 IDENTIFICATION................................................................................................................................................... 43
4.19 CENTRAL STAND ................................................................................................................................................. 44
4.20 EXHAUST SYSTEM............................................................................................................................................... 44
4.21 MIRRORS .............................................................................................................................................................. 45
4.22 AUTOMATIC TRANSMISSION.............................................................................................................................. 45
4.23 HTS (HYDRAULIC TILTING SYSTEM) ................................................................................................................. 46
4.24 ADJUSTING THE DAMPERS ................................................................................................................................ 47
CHAP.5 VEHICLE USE ...................................................................................................................................................... 49
5.1 PRELIMINARY CHECKS ......................................................................................................................................... 50
5.2 TYRE PRESSURE ................................................................................................................................................... 51
5.3 FUEL FILLING ......................................................................................................................................................... 52
5.4 START UP................................................................................................................................................................ 54
5.5 STOPPING THE ENGINE........................................................................................................................................ 56
5.6 RUNNING IN ............................................................................................................................................................ 56
5.7 SAFE DRIVING ........................................................................................................................................................ 58
CHAP. 6 VEHICLE MAINTENANCE .................................................................................................................................. 59
6.1 GENERALIT INFORMATION................................................................................................................................... 60
6.2 SAFETY REGULATIONS FOR THE INTERVENTIONS.......................................................................................... 61
6.3 DAILY MAINTENANCE............................................................................................................................................ 62

4
6.4 ENGINE OIL............................................................................................................................................................. 62
6.5 FINAL DRIVE OIL .................................................................................................................................................... 65
6.6 - SPARK PLUG ........................................................................................................................................................ 66
6.7 OIL VAPOUR RECOVERY ...................................................................................................................................... 67
6.8 - BATTERY............................................................................................................................................................... 68
6.9 - FUSES ................................................................................................................................................................... 70
6.10 AIR FILTER ............................................................................................................................................................ 71
6.11 TYRES ................................................................................................................................................................... 73
6.12 COOLANT .............................................................................................................................................................. 73
6.13 BRAKE FLUID........................................................................................................................................................ 75
6.14 FRONT AND REAR DISC BRAKE......................................................................................................................... 76
6.16 REAR LIGHT CLUSTER ........................................................................................................................................ 79
6.17 NUMBERPLATE LIGHT......................................................................................................................................... 80
6.18 SCHEDULED SERVICING .................................................................................................................................... 81
6.19 PERIODIC AND/OR EXTRAORDINARY MAINTENANCE.................................................................................... 86
6.20 SPARE PARTS AND ACCESSORIES................................................................................................................... 86
6.21 TROUBLESHOOTING ........................................................................................................................................... 87
6.22 PUNCTURES ......................................................................................................................................................... 88
6.23 CLEANING ............................................................................................................................................................. 88
6.24 RECOMMENDED PRODUCTS ............................................................................................................................. 91
CHAP. 7 PERIODS OF INACTIVITY .................................................................................................................................. 93
7.1 PERIODS OF INACTIVITY ...................................................................................................................................... 94
CHAP.8 DISMANTLING AND DISPOSAL ......................................................................................................................... 97
8.1 DISMANTLING AND DISPOSAL ............................................................................................................................. 98

CHAP.1 INTRODUCTION

6
Read this manual before use
1.1 GENERALIT INFORMATION
Before you begin using the vehicle, you must read this instruction manual carefully and follow
all instructions it contains precisely.
The vehicle must not be used by persons who have not thoroughly read and understood the instructions contained in
this manual. This manual contains simple and clear descriptions of the operations necessary to understand and use your
vehicle, as well as recommendations for safe use of your vehicle in order to avoid personal injury. It also describes the main
maintenance operations and periodic checks which must be performed on the vehicle.
The guarantee of correct operation and safety of the vehicle strictly requires that all instructions contained in this manual
be applied.
The manual must always accompany the vehicle even when it is resold.
This Owner's Handbook is an integral part of the vehicle and it must therefore be kept in a safe place accessible to all
persons who might need to consult it.
If the manual is lost or damaged, request a new one from your dealer, giving them the vehicle specifications.
This manual is an integral and essential part of your vehicle.
INTRODUCTION

7
INTRODUCTION
QLUMQUA31UK
Quadro3
USE AND MAINTENANCE
Issue 01 of 07/2016
All rights reserved.
The total or partial use of the content of this booklet including reprinting,
storage to disk, reproduction, reprocessing, disclosure or distribution of said
content on any technological platform, medium, electronic network without
QUADRO VEHICLES S.A's prior authorisation in writing is prohibited.
Quadro Vehicles S.A.
Via dei Lauri, 4 - 6833 Vacallo
(Switzerland)
www.quadrovehicles.com

8
INTRODUCTION
Page left intentionally blank

CHAP.2 SAFETY PRECAUTIONS
AND RECOMMENDATIONS

10
SAFETY PRECAUTIONS AND RECOMMENDATIONS
2.1 ICONS AND INDICATIONS
The symbols below are important for thoroughly understanding this booklet: they indicate the sections where it is neces-
sary to pay greater attention. The symbols are different from each other so it is easier to position of the subjects in the
different sectors.
Read this manual before use
DANGER OF BURNS
You might get burnt if you do not observe the
instructions preceded by this symbol.
HAZARD FROM MOVING PARTS
Failure to observe the instructions preceded by
this symbol may cause dragging, crushing and
cutting
BURNING OR ELECTRIC SHOCK
HAZARD
Failure to observe the instructions
preceded by this symbol may
cause burns or electric shocks.
PERSONAL SAFETY
Failure to observe the instructions preceded by
this symbol may be very dangerous for people.
LOOKING AFTER THE VEHICLE
Failure to observe the instructions preceded
by this symbol causes serious damage to the
integrity and/or safety of the vehicle, some-
times even the nullification of the warranty.
PROTECTION OF THE ENVIRONMENT
Instructions preceded by this symbol indicate
proper behaviour so as not to damage the
natural environment.
EXPLOSION HAZARD
Failure to observe the instructions preceded by
this symbol may be very dangerous for people.
RESIDUAL RISKS
This shows the presence of hazards caused by
residual risks that the user must pay attention
to avoid injury or damage.

11
SAFETY PRECAUTIONS AND RECOMMENDATIONS
FLAMMABLE LIQUID HAZARD
Failure to observe the instructions preceded by
this symbol may be very dangerous for people.
PROHIBITION REGARDING THE LUBRICA-
TION OF MOVING PARTS
Failure to observe the instructions preceded by
this symbol may be dangerous people.
OBLIGATION TO USE SAFETY FOOTWEAR
Failure to observe the instructions preceded by
this symbol may be very dangerous for people
FUEL
PROHIBITION ON REMOVING THE GUARDS
Failure to observe the instructions preceded by
this symbol may be very dangerous for people
OBLIGATION TO WEAR APPROPRIATE
GARMENTS
Failure to observe the instructions preceded by
this symbol may be very dangerous for people
OBLIGATION TO USE PROTECTIVE
GLOVES
Failure to observe the instructions preceded by
this symbol may be very dangerous for people

12
SAFETY PRECAUTIONS AND RECOMMENDATIONS
2.2 POSITIONING INFORMATIVE STICKERS
OR
1
2
3
4 5
8
7
6
10 9
Fig. 01 QSI0075

13
SAFETY PRECAUTIONS AND RECOMMENDATIONS
REFER TO FIG-
URE 01
TYPE OF STICKER DESCRIPTION
1 Brake fluid Clean the tank cap before use.
Only use DOT 4 brake fluid from a sealed container
2 General
- Carefully read the Use and Maintenance manual before setting off on the vehicle.
- Before driving off on the vehicle, make sure you have released the parking brake completely.
- Before driving off on the vehicle, make sure that the parking brake tell tale light is off.
- Only use the parking brake when the vehicle is parked.
- Never exceed the payload weight allowed and only use genuine Quadro accessories.
- Carry out a rough check of the functions before driving off.
- Always carry out a scheduled servicing and check once you have reached 1000 km.
3 - Radiator
- Do not open the radiator cap while the engine is still warm.
- Check the level of the tank constantly and top up with a 50 - 50% water/coolant solution.
- Read the quantities in the Maintenance manual.
4 Battery
- Do not use in places with naked flames present. The hydrogen gas generated by the battery could
cause fires and explosions.
- This 12v battery can only be used to start the motor. Do not use for other purposes.
- Keep out of the reach of children and persons who have not learnt the information from the instruction
manual. It may cause serious burns.
- When touching the battery, wear protective goggles and rubber gloves. Sulphuric acid could cause
blindness and serious burns.
- The battery, the poles of the battery, the terminals and the relative components contain lead and
lead compounds and chemical substances that could cause cancer and damage to the reproductive
system.
- The batteries contain other chemical substances that could cause cancer.
- Wash your hands after handling the battery.
5 Fuel Only use unleaded petrol with less than 10% ethanol and with a minimum octane number 95 (RON).
6 Exhaust terminal High temperature exhaust terminal: danger of serious burns if touched.

14
REFER TO FIG-
URE 01
TYPE OF STICKER DESCRIPTION
7 Maximum weight on
the rear rack/pillion
grab rail
Maximum weight limit that can be transported on the rear rack/pillion grab handle. 5 kg
8 Maximum permissi-
ble load
Do not exceed the maximum load limit allowed (260kg -573 lb)
9 Tyres
Front tyre: Rear tyre:
Dimensions 110/80 - 14” M/C 53P 140/70 - 15” M/C 69P
Pressure (just driver) 1,5 bar (21,8 psi) 2,3 bar (33,4 psi)
Pressure (driver + passenger) 1,5 bar (21,8 psi) 2,5 bar (36,3 psi)
Do not use other tyres that are not recommended by Quadro.
10 Safety Carefully read the Use and Maintenance Manual and always use adequate technical clothing
SAFETY PRECAUTIONS AND RECOMMENDATIONS

15
SAFETY PRECAUTIONS AND RECOMMENDATIONS
2.3 GENERAL RECOMMENDATIONS AND REQUIREMENTS
Using Quadro3 requires knowledge of driving techniques for two-wheeled / three-wheeled vehicles.
Ensure you have learnt and practised these techniques with a qualified driving instructor before using the scooter.
Quadro3 has been designed to offer the driver and passenger maximum comfort and safety, however this can only be
obtained through responsible use of the scooter.
When necessary, we recommend practising the scooter functions away from heavily trafficked areas.
Do not drive the vehicle if you do not have a valid driving licence.
Driving while under the influence of alcohol and drugs or medicaments, has a significant negative
effect on reaction times, decision-making and driving abilities in general; it is also generally punished
in accordance with the laws of the country in which you are driving. .
2.4 CLOTHING
The driver and passenger must wear clothing and safety equipment which meets applicable legislation in the country the
vehicle is being driven in and protects them as far as possible in the case of an accident. We recommend always wearing a
type-approved helmet, visor/goggles, gloves, overall and boots; you should always avoid any clothing or accessories which
could get caught in the moving parts of the scooter and/or compromise the driver's view and safety.
Wear adequate technical clothing and safety equipment that is approved and certified and that
guarantees optimal protection to the driver and passenger. You are recommended to always wear
clothing that makes the driver visible to other road users.
While the scooter is being serviced, wear clothes and protective equipment that are suitable for the operation being carried
out.

16
SAFETY PRECAUTIONS AND RECOMMENDATIONS
2.5 REFUELLING THE VEHICLE
While refuelling the scooter, always turn off the engine and check that there are no leaks in order to avoid breathing in
petrol fumes; do not smoke, do not use naked flames and do not use mobile telephones, as these may all ignite the highly
explosive fuel vapour, and check that there are no fuel leaks.
After refuelling, ensure that the fuel filler cap is closed correctly.
Contact a doctor immediately if fuel is swallowed or comes into contact with eyes or skin.
2.6 SAFE DRIVING
Quadro3 has been designed to transport the driver and a maximum of one passenger. Before driving you must perform
a general check on the condition of the scooter, particularly the safety systems, lights and tyres; if you should notice any
serious faults, consult an authorised Quadro dealer immediately.
While driving, the driver must keep both hands on the handlebars and the passenger must hold onto the handles at the
sides of the seat. Both the passenger and driver must keep both feet on the footrest while the scooter is in motion. We
therefore advise you do not transport passengers who are not able to keep their feet firmly planted on the footrest.
Both the driver and the passenger must sit in the right position that allows the driver to control all the functions of the vehicle
and does not involve an unbalancing of the load that could jeopardise the stability of the scooter.
Always transport the passenger on the rear of the seat.
Before setting off, allow the scooter to warm up and anyway do not push it to its maximum.

17
SAFETY PRECAUTIONS AND RECOMMENDATIONS
Fig. 01 QSI0076
When starting off, release the brake lever and turn the throttle handle
slowly in the direction shown by the arrow (Fig. 01); to decelerate, re-
lease the throttle handle accompanying it.
If you open and close the throttle handle abruptly it could cause the vehicle to race forward
suddenly and a possible loss of vehicle control.
Do not attempt to start the vehicle with the throttle open as you might lose control of the
scooter.
Comfortable braking is guaranteed by the gradual and simultaneous use of both the front and rear brake.
Should it be necessary to brake in an emergency, do not let the throttle go abruptly but accompany it
as quickly as possible to the "gas closed" position.

18
SAFETY PRECAUTIONS AND RECOMMENDATIONS
During a long stretch downhill, release the throttle handle and brake gently intermittently. Using the brakes for a long time
continuously could cause them to overheat thus losing braking efficiency.
In order to avoid possible collisions, you should:
• always make yourself visible to other drivers, ensuring you do not drive in their blind spots;
• use appropriate caution when going through road junctions;
• Use the direction indicators to signal a lane change or turning.
Quadro3 has been designed and developed primarily for use on roads; you should therefore avoid long
and/or particularly uneven stretches of unpaved roads.
If the road surface is wet, drive very carefully and never brake abruptly as the wheels might lock as a prevention thereby
increasing the scooter's stopping distance and time. Always drive over bumpier road surfaces such as tram rails or potholes
slowly.
In case of strong gusts of wind, drive the vehicle at a moderate speed.
You should always adapt your speed on the basis of the current road/traffic/atmospheric conditions, and must never in any
case exceed the applicable speed limit.
Do not touch any of the mechanical components, as these can reach high temperatures during operation (for example, the
exhaust pipe).
Do not start the engine in closed and/or poorly ventilated environments.
