Quadrone Maximus User manual

Instruction Manual

Notice
•All instructions, warranties and other collateral documents are subject
to change at the sole discretion of our company.
Introduction
Table of Contents
•Thank you for choosing Quadrone! This is a four-axis aircraft that can
fly outdoors, in order to make it easier to control the aircraft. Please
carefully read this manual before operating your Quadrone. Please
keep this manual for future reference.
•Before your first flight, please take the time to carefully read this
manual containing important flight information which will help your first
flight go more smoothly.
Introduction 1
Table of Contents 1
Notice 1
Warning 2
Additional Warnings and Precautions 2
Safety Notes 2
Included 3
Quadrone Diagram 4
Remote Controller Diagram 4
Remote Controller Battery Installation 4
Charging Your Drone 5
Assembling the Drone 5
Installing the Camera 5
Syncing the Quad and Remote 6
Flight Controls 6
Practice Tips 8
Trimming the Quad 8
Flips and Rolls 9
Photo/Video 9
Speed Selection 10
Headless Mode 10
One Key Return 10
Changing the Blades 11
Troubleshooting 12
Safety Guidelines 13
Limited 90-Day Warranty 14
1

Warnings
Safety Notes
Additional Warnings and Precautions
•All instructions, warranties and other collateral documents are subject
to change at the sole discretion of our company.
• If this is your first time flying a quadcopter read the manual carefully.
Seek the help of an experienced pilot to help you fly. These safety
instructions are intended not only for the protection of your Quadrone
but also to protect your own safety. Improper operation can cause
injury or property damage.
• This product is suitable for indoor and outdoor use. Please make sure
you choose a flight area with no obstacles and maintain a safe
distance from people and pets. Do not operate near power lines.
• Read the ENTIRE instruction manual to become familiar with the
features of the product before operating. Failure to operate the
product correctly can result in damage to the product, personal
property or cause serious injury. This is a sophisticated hobby
product. It must be operated with caution and common sense, and
requires some basic mechanical ability. Failure to operate this product
in a safe and responsible manner could result in injury or damage to
the product or property. This product is not intended for use by
children without direct adult supervision. This manual contains
instructions for safety, operation and maintenance. It is essential to
read and follow all the instructions and warnings in this manual, prior
to assembly, set up or use, in order to operate correctly and avoid
damage or serious injury.
1. Age Recommendation: Not for children under 14 years of age. This is
not a toy.
2. Always operate in open spaces away from obstacles, people, and
hazards.
3. Always follow directions and warnings for this and any optional
equipment carefully. (chargers, rechargeable battery packs, etc)
4. Always keep small parts and electrical parts out of the reach of
children.
5. Always avoid water exposure to all equipment not specifically
designed and protected for this purpose. Moisture can cause damage
to electronics.
6. Never place any portion of the model in your mouth as it could cause
serious injury or even death.
7. Never operate your model with low batteries.
•Thank you for choosing Quadrone! This is a four-axis aircraft that can
fly outdoors, in order to make it easier to control the aircraft. Please
carefully read this manual before operating your Quadrone. Please
keep this manual for future reference.
•Before your first flight, please take the time to carefully read this
manual containing important flight information which will help your first
flight go more smoothly.
• RC models are composed of many precise electrical components. It is
important to keep the model and associated equipment away from
moisture and other contaminants. The introduction of exposure to
water or moisture in any form can cause the model to malfunction
or crash. Do not operate or expose to rain or moisture.
• To avoid a potential fire hazard from batteries, do not short, reverse
polarity, or puncture batteries. Battery charging should be done under
adult supervision at all times, at a location out of reach of children. Do
not mix Ni-Cad and Alkaline batteries.
• Make sure the batteries are installed correctly to ensure correct
polarity. If you do not plan to use your Quadrone for an extended
period of time, remove the batteries from the controller to avoid
battery leakage which may damage the controller. Please dispose
depleted batteries according to local laws and ordinances.
• Li-Polymer batteries have higher operational risks compared to other
batteries. It is imperative to follow proper operational guidelines. The
manufacturer and dealer assume no liability for accidental damages
caused by improper usage. Do not use any other charger other than
the supplied charger included in this packaging in order to avoid
potential fire or explosion. Do not crush, disassemble, burn,
or reverse polarity.
• RC models are made from various forms of plastic very susceptible to
damage or deformation due to extreme heat and cold temperatures.
Make sure not to store the model near any heat source or
adverse temperatures.
2

Crash Guards X4
Extra Blade A X2
Extra Blade B X2
USB Charger X1 Battery X1
Quadrone Maximus X1 Remote Control X1
Camera X1
Included
• If this is your first time flying a quadcopter read the manual carefully.
Seek the help of an experienced pilot to help you fly. These safety
instructions are intended not only for the protection of your Quadrone
but also to protect your own safety. Improper operation can cause
injury or property damage.
• This product is suitable for indoor and outdoor use. Please make sure
you choose a flight area with no obstacles and maintain a safe
distance from people and pets. Do not operate near power lines.
• Read the ENTIRE instruction manual to become familiar with the
features of the product before operating. Failure to operate the
product correctly can result in damage to the product, personal
property or cause serious injury. This is a sophisticated hobby
product. It must be operated with caution and common sense, and
requires some basic mechanical ability. Failure to operate this product
in a safe and responsible manner could result in injury or damage to
the product or property. This product is not intended for use by
children without direct adult supervision. This manual contains
instructions for safety, operation and maintenance. It is essential to
read and follow all the instructions and warnings in this manual, prior
to assembly, set up or use, in order to operate correctly and avoid
damage or serious injury.
1. Age Recommendation: Not for children under 14 years of age. This is
not a toy.
2. Always operate in open spaces away from obstacles, people, and
hazards.
3. Always follow directions and warnings for this and any optional
equipment carefully. (chargers, rechargeable battery packs, etc)
4. Always keep small parts and electrical parts out of the reach of
children.
5. Always avoid water exposure to all equipment not specifically
designed and protected for this purpose. Moisture can cause damage
to electronics.
6. Never place any portion of the model in your mouth as it could cause
serious injury or even death.
7. Never operate your model with low batteries.
• RC models are composed of many precise electrical components. It is
important to keep the model and associated equipment away from
moisture and other contaminants. The introduction of exposure to
water or moisture in any form can cause the model to malfunction
or crash. Do not operate or expose to rain or moisture.
• To avoid a potential fire hazard from batteries, do not short, reverse
polarity, or puncture batteries. Battery charging should be done under
adult supervision at all times, at a location out of reach of children. Do
not mix Ni-Cad and Alkaline batteries.
• Make sure the batteries are installed correctly to ensure correct
polarity. If you do not plan to use your Quadrone for an extended
period of time, remove the batteries from the controller to avoid
battery leakage which may damage the controller. Please dispose
depleted batteries according to local laws and ordinances.
• Li-Polymer batteries have higher operational risks compared to other
batteries. It is imperative to follow proper operational guidelines. The
manufacturer and dealer assume no liability for accidental damages
caused by improper usage. Do not use any other charger other than
the supplied charger included in this packaging in order to avoid
potential fire or explosion. Do not crush, disassemble, burn,
or reverse polarity.
• RC models are made from various forms of plastic very susceptible to
damage or deformation due to extreme heat and cold temperatures.
Make sure not to store the model near any heat source or
adverse temperatures.
3
Card Reader x1
4GB SD Card x1

Quadrone Diagram
Remote Controller Diagram
Remote Controller Battery Installation
1. Use the included screw driver to open the battery cover. Rotate
counter clockwise to loosen screw.
2. Insert 6 AA batteries into the remote. Make sure the batteries are
installed in the correct polarity as indicated in the controller. Do not
mix old and new batteries or batteries with different chemistries.
3. Reattach battery cover.
• RC models are composed of many precise electrical components. It is
important to keep the model and associated equipment away from
moisture and other contaminants. The introduction of exposure to
water or moisture in any form can cause the model to malfunction
or crash. Do not operate or expose to rain or moisture.
• To avoid a potential fire hazard from batteries, do not short, reverse
polarity, or puncture batteries. Battery charging should be done under
adult supervision at all times, at a location out of reach of children. Do
not mix Ni-Cad and Alkaline batteries.
• Make sure the batteries are installed correctly to ensure correct
polarity. If you do not plan to use your Quadrone for an extended
period of time, remove the batteries from the controller to avoid
battery leakage which may damage the controller. Please dispose
depleted batteries according to local laws and ordinances.
• Li-Polymer batteries have higher operational risks compared to other
batteries. It is imperative to follow proper operational guidelines. The
manufacturer and dealer assume no liability for accidental damages
caused by improper usage. Do not use any other charger other than
the supplied charger included in this packaging in order to avoid
potential fire or explosion. Do not crush, disassemble, burn,
or reverse polarity.
• RC models are made from various forms of plastic very susceptible to
damage or deformation due to extreme heat and cold temperatures.
Make sure not to store the model near any heat source or
adverse temperatures.
Canopy
Motor
Blade
4
Antenna
Power Indicator
Directional Joystick
Throttle Joystick
Aileron Trim Buttons
Power Button
Speed Selection
Flip Button
Forward/Backward
Trim Buttons
Unlock/Emergency Stop
Auto Land/Auto Take-off
Headless Mode
One Key Return
Shoot Photo
Shoot Video

Assembling the Drone
Charging Your Drone
Installing the Camera
1. Use the included screw driver to open the battery cover. Rotate
counter clockwise to loosen screw.
2. Insert 6 AA batteries into the remote. Make sure the batteries are
installed in the correct polarity as indicated in the controller. Do not
mix old and new batteries or batteries with different chemistries.
3. Reattach battery cover.
1. Before installing the camera to the drone, make sure the SD card is
properly inserted into the camera.
2. After the SD card is inserted, plug the camera’s plug into the
drone’s port as shown in the image.
3. Insert the camera’s plug into the drone’s spcketto connect the two.
5
1. To install the landing gear, simply insert the
landing gear into the bottom of the drone. The
landing gear will snap in when fully inserted.
2. To install the crash guards, insert them into the
slots at the end of each arm. Use the provided
screw and screwdriver to secure the guard
in place.
1. Ensure the drone is powered OFF. 2. Open the battery compartment. 3. Unplug the battery and
remove it from the drone.
4. Connect the battery to
the included USB charger.
5. Plug the USB charger into
any USB port. The light on the
charger will flash green to
indicate the battery is charging.
When the light stops blinking and
stays on, charging is complete.
*The drone’s battery will take up to 3 hours to fully charge.
6. Reinsert the battery into the
drone and close the cover.

Flight Controls
1. Turn on your Quadrone by changing the switch on the back of the
drone from OFF to ON. Place it on a flat surface. The lights on the
Quadrone will begin to flash. Do not move the Quadrone during the
syncing process to ensure the gyroscope stays balanced.
2. Turn on your Remote controller, you will hear the remote beep.
(If the batteries of remote are low, your remote will keep on beeping and
the power indicator light will flash. Replace the batteries for your
remote.)
3. Push the throttle joystick up and then down. The lights on the drone will
turn on indicating the remote and the drone are now paired. You are
now ready to fly.
• If you are not going to use your Quadrone for an extended period of
time, please take out the batteries in your remote controller. Potential
battery leakage could occur and possibly damage the remote or create
a fire hazard.
Syncing the Quad and Remote
1. Before installing the camera to the drone, make sure the SD card is
properly inserted into the camera.
2. After the SD card is inserted, plug the camera’s plug into the
drone’s port as shown in the image.
3. Insert the camera’s plug into the drone’s spcketto connect the two.
• Before flying your Quadrone, it is highly recommended that you
familiarize yourself completely with its controls. Read through the
instruction manual completely before attempting your first flight.
6
Power Button

1. Turn on your Quadrone by changing the switch on the back of the
drone from OFF to ON. Place it on a flat surface. The lights on the
Quadrone will begin to flash. Do not move the Quadrone during the
syncing process to ensure the gyroscope stays balanced.
2. Turn on your Remote controller, you will hear the remote beep.
(If the batteries of remote are low, your remote will keep on beeping and
the power indicator light will flash. Replace the batteries for your
remote.)
3. Push the throttle joystick up and then down. The lights on the drone will
turn on indicating the remote and the drone are now paired. You are
now ready to fly.
• If you are not going to use your Quadrone for an extended period of
time, please take out the batteries in your remote controller. Potential
battery leakage could occur and possibly damage the remote or create
a fire hazard.
To start the motors, press the
Unlock Button. When you press
this button, the blades on the
drone will start to spin.
To start your flight, press the Auto Take Off. The drone will slowly start to
ascend.
Push up on the throttle
joystick. The Quadrone will
begin to ascend.
Pull down on the throttle
joystick. The Quadrone will
begin to descend.
Elevation
Push the directional
joystick to forward. The
Quadrone will fly forward.
Push the directional
joystick to the left. The
Quadrone will turn to left.
Forward/Backward
Push the directional
joystick to the right. The
Quadrone will fly to the
right.
Push the directional
joystick to the left. The
Quadrone will fly to left.
Aileron
Push the throttle joystick to
the right. The Quadrone will
turn to right.
Push the throttle joystick to
the left. The Quadrone will
turn to left.
Turning
7
Unlock
Auto
Take Off

Practice Tips
Trimming the Quad
• Use these recommended practice exercises to become a better
Quadrone pilot:
• If your Quadrone is leaning to or favoring a side, you may need to use
the trim feature to balance it out so it flies straight.
Elevation: Raise the Quadrone using the throttle joystick. Gradually
lower the Quadrone so it lands softly to the ground.
Direction: Move the Quadrone in a cross pattern using the directional
joystick. Move forward, backward, left, right, and back to
its original position.
Turning: Turn the Quadrone in a throttle joystick. Turn left and right
repeatedly, and back to its original position.
Flying: Once you have mastered the previous three exercises,
draw a circle on the ground. Practice flying within the
confines of the circle. Narrow the circle as your skills
progress.
When you are done flying, press the Auto Land button. The drone will slowly
land itself to the ground and turn the motors off.
In case of an emergency, press the Emergency Stop button. The blades will
immediately stop and the drone will fall to the ground.
Aileron If the Quadrone leans to
the right, press the Left
Aileron Trim button until it
straightens out.
If the Quadrone leans to
the left, press the Right
Aileron Trim button until it
straightens out.
8

Forward/Backward If the Quadrone leans
backward, press the
Forward Trim button until it
straightens out.
If the Quadrone leans
forward, press the
Backward Trim button until
it straightens out.
* If the trim buttons do not correct the
problem, you will have to recalibrate
your drone. To do so, land the quad on
a flat surface. Hold the joysticks in the
down and out position. The light on the
remote will flash. Hold this position
then release. The remote lights will
stop flashing and recalibration
is complete.
9
Flips and Rolls
• Your Quadrone can perform impressive flips and rolls in midair. In
order to do this, press the flip button on your remote during flight.
Move the directional joystick in any direction and the aircraft will
perform a coinciding flip.
Photo and Video
• To take a photo with your drone, press the Photo
button. The lights on the drone will blink once, indicating
you took a video.
• To take a video with your drone, press the Video
button. The lights on the drone will blink. indicating the
drone is recording. To stop recording, press the Video
button again. The lights on the drone will stop blinking.
Video

Speed Selection
• Your Quadrone can fly at four speeds. To select a speed, simply
press the Speed Selection button on your remote change the speed.
The remote will beep each time the speed changes. The default speed
is 25% full speed.
10
Headless Mode
• When in Headless Mode, no matter what direction
the quadcopter faces, it will respond according to
the direction pushed on the remote. (Forward on
the remote will make the quadcopter fly forward,
even if it is pointing in another direction.) To enter
Headless Mode, simply press the Headless Mode
button on your remote. The remote will begin to
beep and the lights on quadrone begin to flash to
indicate you have now entered Headless Mode. To exit Headless
Mode, simply press the button again. The remote will beep again and
all lights will remain on and return to normal.
25% Speed: 1 Beep
50% Speed: 2 Beeps
75% Speed: 3 Beeps
100% Speed: 4 Beeps
One-Key Return
• When in One-Key Return, no matter what direction
the quadrone faces, the pilot will simply have to
press the One-Key Return button and the
quadrone will fly back to the remote. To use
One-Key Return, the drone must already be in
Headless Mode. Simply press the One-Key Return
button. The remote will give a single beep, and the
quadrone will fly back towards the remote. To exit
One-Key Return, you can push One-Key Return button, or move the
directional joystick and you will return to Headless Mode.

Changing the Blades
• Your Quadrone can fly at four speeds. To select a speed, simply
press the Speed Selection button on your remote change the speed.
The remote will beep each time the speed changes. The default speed
is 25% full speed.
B
A B
A
A
11
•If a blade breaks or falls off your Quadrone during a crash, it will be up to you to repair it.
Use the screwdriver included in the package to remove the screw, detaching the
Propeller from the Drone. Rotate counter-clockwise to loosen. Remove the damaged
blade from the motor. You can now attach a new blade. It is important for the correct
blade to be put on the correct motor or the drone will not fly correctly. A letter is marked
on each blade to indicate which motor it should go on.
See diagram below:
Once you have mounted the new blade, you can refasten it with the screw.
Rotate clockwise to tighten.

DGL TOYS™ is an innovative division of DGL Group, Ltd.
Other trademarks and trade names are those of their respective owners.
DGL TOYS,
195 Raritan Center Parkway, Edison, NJ 08837.
Specifications, colors and contents may vary from illustrations.
Conforms to safety requirements of ASTM, FCC, & CPSIA.
WARNING:
CHOKING HAZARD-Small parts.
Not for children under 3 years.
Tested to comply with FCC standards.
FOR HOME OR OFFICE USE.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
BATTERY WARNING:
• Do not mix alkaline, standard (carbon zinc), rechargeable (nickel hydride) batteries.
• Do not mix old and new batteries.
• Non-rechargeable batteries should not be recharged.
• Rechargeable batteries should be removed from the appliance before being charged.
• Rechargeable batteries should be charged under adult supervision only.
• Exhausted batteries should be removed.
• The supply terminals should not be short-circuited.
• Only batteries of the same or equivalent type are recommended to be used.
• Batteries should be inserted with the correct polarity.
Problem Cause Solution
Drone’s LED lights blink continuously
for more than 4 seconds after quad is
turned on. No response to controller.
No response after quad is turned on.
1. Replace batteries.
2. Reinstall batteries at correct
polarity.
Recharge quad battery.
Motor does not respond to throttle.
Motor spins but doesn’t take off.
Quad is making a loud vibration
noise.
Quad still wanders forward after trim
adjustment. Forward trim is too high. 1. Lower forward trim. 2. Recalibrate drone.
Cannot fly after crash. 1. Motor fell out.
2. Gear loosened.
1. Reinstall motor.
2. Tighten gear.
Bent or damaged rotor blades.
1. Remote batteries have been
depleted.
2. Batteries are installed at
incorrect polarity.
1. Bent rotor blades.
2. Quad battery is depleted.
1. Replace damaged blade.
2. Recharge battery.
Replace damaged blade.
Battery has been depleted.
Unable to sync to
remote controller.
Repeat power
sequence and re-sync.
(See pg. 5)
Troubleshooting
•If a blade breaks or falls off your Quadrone during a crash, it will be up to you to repair it.
Use the screwdriver included in the package to remove the screw, detaching the
Propeller from the Drone. Rotate counter-clockwise to loosen. Remove the damaged
blade from the motor. You can now attach a new blade. It is important for the correct
blade to be put on the correct motor or the drone will not fly correctly. A letter is marked
on each blade to indicate which motor it should go on.
See diagram below:
Once you have mounted the new blade, you can refasten it with the screw.
Rotate clockwise to tighten.
12
FCC ID: XXX
Manufactured in
XXX
Batch Ref: XXX
Model Number: XX-XXX-XXX

• Follow community-based safety guidelines, as developed by organizations
such as the Academy of Model Aeronautics (AMA).
• Fly no higher than 400 feet and remain below any surrounding obstacles
when possible.
• Keep your drone in eyesight at all times, and use an observer to assist
if needed.
• Remain well clear of and do not interfere with manned aircraft operations,
and you must see and avoid other aircraft and obstacles at all times.
• Do not intentionally fly over unprotected persons or moving vehicles, and
remain at least 25 feet away from individuals and vulnerable property.
• Contact the airport or control tower before flying within five miles
of an airport.
• Do not fly in adverse weather conditions such as in high winds or
reduced visibility.
• Do not fly under the influence of alcohol or drugs.
• Ensure the operating environment is safe and that the operator is competent
and proficient in the operation of the drone.
• Do not fly near or over sensitive infrastructure or property such as power
stations, water treatment facilities, correctional facilities, heavily traveled
roadways, government facilities, etc.
• Check and follow all local laws and ordinances before flying over
private property.
• Do not conduct surveillance or photograph persons in areas where there is
an expectation of privacy without the individual’s permission.
WARNING!
To reduce the risk of fire or burns:
Do not disassemble, crush, puncture, or short external connectors contacts.
Use only with specified charger and player.
Do not dispose of in fire or water.
Do not expose to high temperature above 140° F (60° C).
Store between 32° F (0 ° C) and 140° F (60° C).
Keep away from children.
See operating instructions of this battery or product.
Batteries should be recycled or disposed of as per State and Local guidelines.
Safety Guidelines
Battery Disposal Guidelines
Li-ion Battery
Must Be Disposed
Of Properly
13

Limited 90-Day Warranty
IMPORTANT NOTICE!
DO NOT ATTEMPT TO SHIP YOUR PRODUCT BACK WITHOUT
FIRST CONTACTING OUR WARRANTY DEPARTMENT AT:
DGL Group. Ltd.
WARRANTY REPLACEMENT DEPARTMENT
TEL: [phone]
[email protected]
REPAIR/REPLACE PRODUCT
PREPARATION FOR SHIPPING YOUR PRODUCT
DGL Group, Ltd. warrants to the original consumer that this product is free from
any electrical or mechanical defects for a period or 90 DAYS from the date of
purchase. If any such defect is discovered within the warranty period, DGL
Group, Ltd. will repair or replace the unit free of charge upon receipt of the unit,
shipped postage prepaid and insured to our warranty center. The warranty
covers normal consumer use and does not cover damage that occurs in
shipment of failure that results from alterations, accident, misuse, abuse, neglect,
wear and tear, inadequate maintenance, commercial use or unreasonable use of
the unit. Removal of any parts/components voids all warranties. This warranty
does not cover cost of repairs made or attempted outside by third-party individu-
als and fitness, are hereby limited to 90 DAYS from the date or purchase.
Consequential or incidental damages resulting from a breach of any applicable
express or implied warranties are hereby excluded. Some states do not allow
limitations on the duration of implied warranties and do not allow exclusion of
incidental or consequential damages, so the above limitations and exclusions in
these instances may not apply.
If your product begins to malfunction or stop working, immediately call or email
our warranty center at the phone/email listed below. If it is determined that a return
is necessary, our warranty department will issue you an RMA number/form and an
address to the nearest return center to ship the product to. IMPORTANT NOTICE:
We will reject all returns that are not accompanied by an issued RMA form and
number so make sure to contact our warranty center before attempting to return
your product!
Please repack your product in a durable box, preferably in the original carton, and
send it prepaid, and adequately insured. Include the RMA form that was issued by
our warranty department along with your daytime telephone number and email
address (if available) inside the shipping carton. If your warranty has expired,
contact our warranty center for charged service. For further information please
send all inquiries to [email protected]
14

15
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. if this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.
