QuadTech Sentry Plus Series User manual

Sentry Plus Series
Hipot Testers
Instruction Manual
Form 150697/A4
QuadTech, Inc., 2003
5 Clock Tower Place, 210 East
Maynard, Massachusetts, U.S.A. 01754
January 2005
Telephone: [phone]
Sales: 800-253-1230
Facsimile: 978-461-4295
Website: www.quadtech.com
The material in this manual is for informational purposes only and is subject to change, without notice.
QuadTech assumes no responsibility for any error or for consequential damages that may result from the
misinterpretation of any procedures in this publication.
WARNING
Potentially dangerous voltages may be present on front and rear panel terminals. Follow all warnings in
this manual when operating or servicing this instrument. Dangerous levels of energy may be stored in
capacitive devices tested by this unit. Always make sure the high voltage indicator is not on when
connecting or disconnecting the device under test.
!
Product will be marked with this symbol (ISO#3864) when it is necessary for the user to refer to
the instruction manual in order to prevent injury or equipment damage.
Product marked with this symbol (IEC417) indicates presence of direct current.
Product will be marked with this symbol (ISO#3864) when voltages in excess of 1000V are
present.

Page 2 of 85

Page 3 of 85
Contents
Warranty ............................................................................................................5
Specifications............................................................................................................7
Accessories ............................................................................................................11
Safety Precautions....................................................................................................13
Condensed Operating Instructions ........................................................................15
Introduction - Section 1
1.1 Unpacking and Inspection..............................................................................21
1.2 Product Overview ..........................................................................................21
1.3 Controls and Indicators..................................................................................22
1.3.1 Front Panel Controls and Indicators .................................................22
1.3.2 Rear Panel Controls and Connectors ................................................23
1.4 Installation .....................................................................................................24
1.4.1 Dimensions ........................................................................................24
1.4.2 Instrument Positioning.......................................................................24
1.4.3 Power Requirements..........................................................................24
1.4.4 Safety Inspection................................................................................25
Operation - Section 2
2.1 Terms and Conventions .................................................................................27
2.2 Start-Up..........................................................................................................31
2.3 Programming Electrical Safety Tests.............................................................31
2.4 Programming a Ground Continuity Test .......................................................35
2.5 Programming an AC Hipot Test....................................................................37
2.6 Programming a DC Hipot Test......................................................................39
2.7 Programming an Insulation Resistance (IR) Test .........................................41
2.8 Programming a Pause (PA) in Test Sequence ..............................................43
2.9 Storing a Test Setup ......................................................................................45
2.10 Programming a Multi-Step Test.....................................................................47
2.11 PRESET Test Parameters .............................................................................48
2.11.1 AC-V FREQ ......................................................................................48
2.11.2 Software AGC ...................................................................................48
2.11.3 WV AUTO RANGE .........................................................................48
2.11.4 IR AUTO RANGE ............................................................................49
2.11.5 GFI ....................................................................................................49
2.11.6 FAIL RESTART ...............................................................................49
2.12 Instrument Offset ..........................................................................................50
2.13 Connection To Device Under Test ................................................................53
2.14 Measurement Procedure.................................................................................54

Page 4 of 85
Contents (Continued)
2.15 MENU Parameters ........................................................................................56
2.15.1 MEMORY Function .........................................................................57
2.15.2 SYSTEM Function ............................................................................59
2.15.2.1 CONTRAST ...................................................................59
2.15.2.2 BUZZER VOLUME .......................................................59
2.15.2.3 EN 50191 ........................................................................59
2.15.2.4 DC 50V AGC ..................................................................60
2.15.3 OPTION Function .............................................................................60
2.15.4 CALIBRATION Function ................................................................60
2.15.5 KEY LOCK Function .......................................................................61
2.15.6 CHANGE PASSWORD Function ....................................................63
2.15.7 ERROR LOG Function .....................................................................65
2.15.8 ABOUT Function ..............................................................................65
Interface - Section 3
3.1 Remote ..........................................................................................................67
3.2 G16 International Power Strip.......................................................................70
3.3 S07 Power Entry Adapter Cable ...................................................................71
3.4 S03 Corded Product Adapter ........................................................................72
3.5 S05 Foot Switch ............................................................................................73
3.6 S08 Gun Probe ..............................................................................................74
3.7 S50 Plus Ground Bond Tester .......................................................................75
Service & Calibration - Section 4
4.1 General...........................................................................................................77
4.2 Instrument Return ..........................................................................................77
4.3 Calibration......................................................................................................77
4.3.1 Calibration Parameters.......................................................................78
4.3.2 Enable Calibration ............................................................................79
4.3.3 AC Voltage Calibration .....................................................................80
4.3.4 DC Voltage Calibration .....................................................................80
4.3.5 IR Voltage Calibration.......................................................................81
4.3.6 AC Current Calibration......................................................................82
4.3.7 DC Current Calibration......................................................................83
4.3.8 ARC Calibration ................................................................................84
4.3.9 IR Resistor Calibration .....................................................................84
4.3.10 Ground Continuity Calibration .........................................................85
4.3.11 Contrast Calibration ..........................................................................85
4.3.12 Finalize Calibration ...........................................................................85

Page 5 of 85
Warranty
QuadTech warrants that Products are free from defects in material and workmanship and, when
properly used, will perform in accordance with QuadTech’s applicable published specifications.
If within one (1) year after original shipment it is found not to meet this standard, it will be
repaired, or at the option of QuadTech, replaced at no charge when returned to a QuadTech
service facility.
Changes in the Product not approved by QuadTech shall void this warranty.
QuadTech shall not be liable for any indirect, special or consequential damages, even if
notice has been given of the possibility of such damages.
This warranty is in lieu of all other warranties, expressed or implied, including, but not
limited to any implied warranty or merchantability of fitness for a particular purpose.
SERVICE POLICY
QuadTech’s service policy is to maintain product repair capability for a period of at least five (5)
years after original shipment and to make this capability available at the then prevailing schedule
of charges.

Page 6 of 85

Page 7 of 85
Specifications
Dielectric Strength
Sentry 10, 20, & 30 Plus
AC Output Voltage: Range: 0.05 to 5kV AC, in 1V steps
Regulation: ±(1% of setting +5V)
Frequency: 50/60Hz selectable
Voltage Display: Accuracy: ±(1% of reading +5V)
Resolution: 1Volt
AC Current Display: Range: 0.001mA to 20mA AC, in 1µA steps
Accuracy: ±(1.5% of reading + 5 counts) (Total)
Sentry 20 & 30 Plus
DC Output Voltage: Range: 0.05 to 6kV DC, in 1V steps
Voltage Display: Accuracy: ±(1% of reading +5V)
Resolution: 1Volt
DC Current Display: Range: 0.0001mA to 5mA DC
Resolution: 0.1µA
Accuracy: ±(1.5% of reading + 5 counts)
Insulation Resistance
Sentry 30 Plus
Insulation Resistance: Voltage: 50 - 1000V DC in 1V steps
Accuracy: ±(1% of reading + 5V)
Range: 0.1MΩ- 50GΩ(voltage dependent)
Accuracy: 0.1MΩ- 1GΩ, ±(10% + 5counts) <100V
0.1MΩ- 1GΩ, ±(7% + 5counts) <500V
1MΩ- 1GΩ, ±(4% + 5counts) ≥500V
1GΩ- 10GΩ, ±(7% + 5counts) ≥500V
10GΩ- 50GΩ, ±(12% + 5counts) ≥500V

Page 8 of 85
Specifications (Continued)
Safety Features
Ground
Continuity Test: Programmable: 0.1Ωto 5.0Ω±0.2ΩAccuracy, or OFF
Ground Fault
Interrupt (GFI): Shutdown of current imbalance when I > 0.5mA ±0.25mA, or OFF
In-Rush Current: DC Mode: Set detection limit: 0.5uA – 5mA in 0.0001mA increments
The programmable range for In-Rush current is dependent on the
programmed High Limit:
Range: High Limit: In-Rush:
1 0.1µA – 300µA 0.5µA – 300µA
2 0.301mA – 3.000mA 5µA – 3.000mA
3 3.01mA – 5.0mA 50µA – 5.0mA
Fast Output Cutoff: HV output voltage terminated <0.4mS after NG (Fail) result
Fast Discharge: <0.2s (Typical) Discharge of DUT upon termination of HV.
ARC Detection: Detection Current: Range:1mA – 20mA AC and 5mA DC
Pulse Width: Minimum: 10µs
General Features
Time: Test*: 0.1sec – 999 sec, Continuous
Ramp: 0.1sec – 999 sec, OFF
Dwell: 0.1sec – 999 sec, OFF (DC & IR Mode only)
Fall: 0.1sec – 999 sec, OFF
* Test Time is limited ≤60seconds when the voltage and high current limit >100VA.
* Test Time for IR is 0.3sec – 999sec, Continuous
Limits: HI/LO programmable during Test Time
LO can be set to OFF during Hipot Test
HI can be set to OFF during IR Test
Indication: Pass/fail LEDs, audible alarm
Remote Control: Inputs: START, STOP
Characteristics: 24V active low, Pulse width ≅20ms
Outputs: PASS, FAIL, UNDER TEST
Characteristics: Dry contact relay, Closed if true
115V, <100mA
Connector: 9 pin male D-series & Terminal Strip

Page 9 of 85
Specifications (Continued)
General Features
Setup Storage: 60 Memory Locations, 10 steps each
Standard
Interfaces: Remote I/O
Connectors: Front and Rear Connection
HV OUTPUT: Custom Banana Socket
RTN/LOW: Banana Socket
GC (Rear Only): Binding Post/Banana Socket
Front Panel 10 Digit Password with or without setup recall
Lockout: LED Display: LOCK
Mechanical: Bench Mount
Dimensions:(w x h x d): 10.50 x 4.50 x 14.25 inches
262.5 x 112.5 x 356.25 mm
Weight: 25.0 lbs (11.5 kg) net, 28 lbs (13.0 kg) shipping
Environmental: Specifications: 18°C to 28°C, 70% RH
Operating: 0°C to +40
o
C, 80% RH
Storage: -10°C to +60
o
C, 80% RH
Warm-up Time: 15 minutes
Power: • 90 - 130V AC • 50 or 60Hz
• 200 - 250V AC • 300W max
Supplied:
• Instruction Manual • Power Cable
• Calibration Certificate • S02 Test Leads
• Ground Continuity Lead
Safety Agency: CE, TUV
Ordering Description Catalog No.
Information: AC Hipot Tester Sentry 10 Plus
AC/DC Hipot Tester Sentry 20 Plus
AC/DC/IR Hipot Tester Sentry 30 Plus

Page 10 of 85

Page 11 of 85
Accessories
Accessories Included
Item Quantity QuadTech P/N
AC Power Cord 1 4200-0300
Power Line Fuse 3.15A 250V SB 1 520072
Power Line Fuse 1.6A 250V SB 1 520074
High Voltage Lead Set, 1m with alligator clips 1 S02
Ground Continuity Lead 1 700100
Instruction Manual 1 150697
Calibration Certificate 1 N/A
Accessories/Options Available
Item Quantity QuadTech P/N
High Voltage Lead Set, high & low, 1m (std. with unit) 1 S02
Corded Product Adaptor, 115V 1 S03
High Voltage Lead Set, high & low, 2m 1 S04
Foot Switch 1 S05
High Voltage Probe 1 S06
Power Entry Adaptor Cable 1 S07
Gun Probe 1 S08
High Voltage Lead, 1m, unterminated 1 S09
High Voltage Lead, 2m, unterminated 1 S10
Gun Probe with Remote Start 1 S11
Load Box, resistive 1 S12
Load Box, custom resistors 1 S14
Interconnection Cable to Sentry 50 Ground Bond Tester 1 S15
Ground Continuity Lead (standard with unit) 1 700100
International Power Strip 1 G16
Corded Product Adaptor, 240V 1 G25

Page 12 of 85

Page 13 of 85
Safety Precautions
WARNING
The Sentry Plus Series Hipot Tester can provide an output voltage as high as 6000V DC (5000V
AC) to the external device under test (DUT). Although the Sentry Plus unit is designed with full
attention to operator safety, serious hazards could occur if the instrument is used improperly and
these safety instructions are not followed.
1. The Sentry Plus unit is designed for operation with its chassis connected to earth ground.
The instrument is shipped with a three-prong power cord to provide this connection to
ground. This power cord should only be plugged in to a receptacle that provides earth
ground. Serious injury can result if the Sentry Plus is not connected to earth ground.
2. Tightly connect cable(s) to the (blue) RTN/LOW terminal. If this is not done, the
DUT’s casing can be charged to the high voltage test level and serious injury or electrical
shock hazards could result if the DUT is touched.
3. Never touch the metal of the High Voltage probe directly. Touch only the insulated parts
of the lead(s).
4. Never touch the test leads, test fixture or DUT in any manner (this includes insulation on
all wires and clips) when the high voltage is applied and the red DANGER light is ON.
5. Before turning on the Sentry Plus unit, make sure there is no device (DUT) or fixture
connected to the test leads.
6. After each test, press the [STOP] (red) button for safety if there is any concern that HV
may still be applied to the output terminals.
7. When the red DANGER LED is lit or flashing, NEVER touch the device under test, the
lead wires or the output terminals.
8. Before touching the test lead wires or output terminals make sure:
a) The red [STOP] button has been pressed
b) The red DANGER LED is OFF.
9. In the case of an emergency, turn OFF the POWER switch using a “hot stick” and
disconnect the AC power cord from the wall. DO NOT TOUCH THE Sentry Plus
INSTRUMENT.
10. If the DANGER LED does not go off when the [STOP] button is pressed, immediately
stop using the tester. It is possible that the output voltage is still being delivered
regardless of the TEST ON/OFF control signal.
11. When the Sentry Plus instrument is used in remote control mode, be extremely careful.
The High Voltage Output is being turned on and off with an external signal.

Page 14 of 85

Page 15 of 85
Condensed Operating Instructions
WARNING
High Voltage is applied to the white HV Output Terminal anytime the red DANGER LED is ON
or flashing. Always make sure the DANGER LED is OFF when connecting or disconnecting
the device under test (DUT).
General Information
The Sentry Plus Series Hipot Tester is a measuring instrument for direct readout of hipot output
voltage and leakage current and insulation resistance. The voltage applied to the device under
test is adjustable from 50V to 5kV AC and 50V to 6kV DC. The trip current limit is
programmable from 1uA to 20mA AC in 1uA steps and from 0.1uA to 5mA DC in 0.1uA steps.
The output voltage for Insulation Resistance tests is 50V to 1000V DC over a measurement
range of 100kΩto 50GΩ.
Start-Up
The Sentry Plus Series unit can be operated from a power source between 90 and 250VAC at a
power line frequency of 50 or 60Hz. The standard Sentry Plus Series unit is shipped from
QuadTech with a 3.15A fuse in place for AC 90-130V operation. (A 1.6A fuse is included for
200-250V operation). The Sentry Plus unit is shipped with the line voltage selector set for 120V.
Refer to paragraph 1.4.3 for instructions on changing the fuse or line voltage selector.
Connect the Sentry Plus Series unit AC power cord to the source of proper voltage. Operate the
Sentry Plus Series instrument with its chassis connected to earth ground. The Sentry Plus
instrument is shipped with a three-prong power cord to provide this connection to ground. This
power cord should only be plugged into a receptacle that provides earth ground. Serious injury
may result if the Sentry Plus Series instrument is not connected to earth ground.
Press the [POWER] button on the front panel to apply power. To switch the power off, press the
[POWER] button again or if measurements are to be made proceed with the Test Parameter
Setup in Table COI-1. The Sentry Plus Series instrument should warm up for 15 minutes prior to
use.
NOTE
Please read this instruction manual in its entirety before operating this instrument.
These condensed operating instructions are not a substitute for all the information provided in the
remainder of this manual.
NOTE
Refer to paragraphs 2.3 through 2.9 for a full description of programming test parameters and
instruction on how to store the test setup. Test parameters must be set before the Sentry Plus
Series instrument can be zeroed.

Page 16 of 85
Condensed Operating Instructions (Continued)
There are numerous menus within the Sentry Plus Series instruments. Familiarize yourself with
these menus prior to programming a test. Figure COI-1 illustrates the STAND BY display and
lists the functions that can be accessed by pressing the [F1] through [F4] keys.
"STAND BY" or "Power-Up" Display
Function of F1 - F4 Keys
To enter programming mode.
PROGRAM
PRESET
MORE..
MENU
RMT ERROFSTLOCKSTAND BY
1.250kV
3.0s
15.00mA
F1
F4
F3
F2
FALL
RAMP
ARC
LOWAC
STEP 1/1
To view/change preset (initial) settings.
To view/change: memory, system, option,
cal., key lock, pw, error & about.
To view the programmed test setups and
access offset function.
PROGRAM MOREMENUPRESET
F3 F4F2F1
MODE: AC/DC/IR/GC/PA
STEP: 1-10
Soft AGC.
WV Auto Range
AC-V Freq. Memory
Calibration
Option
System
Change Password
Key Lock
Error Log
IR Auto Range
About
View Test Steps (Tabular Format)
OffsetStore
Delete
Recall
Buzzer Volume
Contrast
Multi-Link
High Limit
Voltage EN 50191
DC 50V AGC
Ramp Time
Test Time
Low Limit
Fall Time
ARC Limit
In Rush Current
Manufacturer
Software version
(Need password to enter)
(Need password to enter)
Insert
Delete
NEXT
(Need password to enter)
Instrument
Status
GFI
FAIL Restart
MORE..
: OFF
: OFF
: OFF
: OFF
M1
Dwell Time
(DC)
(DC, IR)
Figure COI-1: Sentry Plus Series Menus

Page 17 of 85
Condensed Operating Instructions (Continued)
With the Sentry Plus Series instrument in “STAND BY” (or power-up display) status, follow the
steps in Table COI-1 to program an AC, DC, IR or GC test or insert a Pause in the test sequence.
Figure COI-2: “STAND BY” and PROGRAM Displays
"STAND BY"
DISPLAY
To enter programming mode.
AC
Display
PROGRAM
PRESET
MORE..
MENU
RMT ERROFSTLOCKSTAND BY
0.000kV
3.0s
0.500mA
F1
F4
F3
F2
FALL
RAMP
ARC
LOWACSTEP 1/1
To move highlighted box around
display to select parameter to change
To exit programming mode.
To toggle choices of highlighted box.
To change value in highlighted box.
UP
DOWN
EXIT
NEXT
RMT ERROFSTLOCKSELECT MODE
F1
F4
F3
F2
FALL
RAMP
ARC
LOWACSTEP 1/1
VOLT
HIGH
TIME
UP
DOWN
EXIT
NEXT
RMT ERROFSTLOCKSELECT MODE
F1
F4
F3
F2
I-RUS
FALL
RAMP
ARC
LOWDCSTEP 1/1
VOLT
HIGH
TIME
DC
Display
IR
Display
GC
Display
To select test mode: AC/DC/IR/GC/PA
To view/change preset (initial)
test parameters.
To view/change system parameters:
memory, system, option, calibration, key
lock, password, error, & about.
To view the programmed test setups and
access offset function.
UP
DOWN
EXIT
NEXT
RMT ERROFSTLOCKSELECT MODE
F1
F4
F3
F2
FALL
RAMP
HIGHIRSTEP 1/1
VOLT
LOW
TIME
UP
DOWN
EXIT
NEXT
RMT ERROFSTLOCKSELECT MODE
F1
F4
F3
F2
LOW
GCSTEP 1/1
CURR
HIGH
DWELL
UP
DOWN
EXIT
NEXT
RMT ERROFSTLOCKSELECT MODE
F1
F4
F3
F2
PASTEP 1/1
PAUSE
UNDER TEST SIGNAL
To select test mode: AC/DC/IR/GC/PA
PA
Display
To select test mode: AC/DC/IR/GC/PA
To select test mode: AC/DC/IR/GC/PA
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
PROGRAM MODE DISPLAYS
0.000kV
0.500mA
3.0s
0.000kV
0.500mA
3.0s OFF
:
:
:
:
:
:
:
:
:
:
:
:: :
:
:
:
:
:
:
:
:3.0s 1.0M Ω
0.000kV
:
:
:
:
:
:
: 0.0A
1.0
Ω
3.0s
:
:OFF PAUSE MODE
:OFFDWELL
DWELL : OFF

Page 18 of 85
Condensed Operating Instructions (Continued)
Table COI-1: Test Parameter Setup
Step Test Parameter AC Hipot DC Hipot IR GC Range
1 To enter
programming mode [F1] = PROGRAM [F1] = PROGRAM [F1] = PROGRAM [F1] = PROGRAM
2 Select Test Step [F1] = UP
[F3] = NEXT [F1] = UP [F3] = NEXT [F1] = UP [F3] = NEXT [F1] = UP [F3] = NEXT 1-10
3 Select Test Mode [F1] = UP
[F3] = NEXT [F1] = UP [F3] = NEXT [F1] = UP [F3] = NEXT [F1] = UP [F3] = NEXT AC, DC, IR, GC, PA
4 Set Test Voltage
Set Current (GC)
[F1] = INC.
[F3] = NEXT [F1] = INC. [F3] = NEXT [F1] = INC. [F3] = NEXT [F1] = INC. [F3] = NEXT 0.05-5kV AC 0.05-6kV DC
0.05-1kV IR
0.1A GC
5 Set High Limit *
Set Low Limit (IR)
[F1] = INC.
[F3] = NEXT [F1] = INC. [F3] = NEXT [F1] = INC. [F3] = NEXT [F1] = INC. [F3] = NEXT 0.001-20mA AC 0.0001-5mA DC
0.1-50000MΩIR
0, 0.1-5ΩGC
6 Set Test Time
Set Dwell (GC) ***
[F1] = INC.
[F3] = NEXT [F1] = INC. [F3] = NEXT [F1] = INC. [F3] = NEXT [F1] = INC. [F3] = NEXT 0, 0.1-999s AC 0, 0.1-999s DC
0, 0.1-999s IR
0.1-1s GC
7 Set Low Limit **
Set High Limit (IR)
[F1] = INC.
[F3] = NEXT [F1] = INC. [F3] = NEXT [F1] = INC. [F3] = NEXT [F1] = INC. [F3] = NEXT 0-20mA AC 0-5mA DC
0-50GΩIR
0-5ΩGC
8 Set ARC Limit [F1] = INC.
[F3] = NEXT [F1] = INC. [F3] = NEXT 1-20mA AC 1-5mA DC
9 Set Ramp Time [F1] = INC.
[F3] = NEXT [F1] = INC. [F3] = NEXT [F1] = INC. [F3] = NEXT 0-999s AC 0-999s DC
0-999s IR
10 Set Dwell Time*** [F1] = INC.
[F3] = NEXT [F1] = INC. [F3] = NEXT 0-999s DC 0-999s IR
11 Set Fall Time [F1] = INC.
[F3] = NEXT [F1] = INC. [F3] = NEXT [F1] = INC. [F3] = NEXT 0-999s AC 0-999s DC
0-999s IR
12 Set In-Rush Current [F1] = INC.
[F3] = NEXT 0, 0.5uA-5mA DC
13aTo program next test
step OR [F1] = NEW OR [F1] = NEW OR [F1] = NEW OR [F1] = NEW OR Program next step OR
13bTo exit
programming mode [F4] = EXIT [F4] = EXIT [F4] = EXIT Exit programming
* High limit decision is made throughout test time.
** Unit will make low limit decision at the end of test.
* ** Limits will be checked at end of dwell time.

Page 19 of 85
Condensed Operating Instructions (Continued)
Offset
After setting your test parameters, zero the Sentry Plus Series instrument by using the automatic
offset. With no device connected, connect the appropriate cable (or other fixture) into the
OUTPUT connectors. Refer to paragraph 2.13 cable connections based on test to be performed.
Return and HV test leads should not be connected together (open circuit) for AC and DC hipot
tests. Return and GC test leads should be connected (short circuit) for a GC test. There is no
offset in an IR test.
NOTE:
If Ground Continuity (GC) is turned ON when performing an offset, the continuity lead must be connected to the
return (RTN/LOW) terminal, otherwise turn the continuity test OFF.
Prior to performing the OFFSET function:
•Allow the instrument to warm up for 15 minutes.
•Connect the Test cables (or fixture) to the front panel OUTPUT and RTN/LOW connectors.
•Program the test steps.
With the instrument in STAND BY status:
•Press [F4] = MORE
•Press [F3] = OFFSET
•Follow instructions on display: i.e.: connect OPEN across OUTPUT terminal.
•Press green [START] button.
•Wait while instrument gets OFFSET value.
•The OFST block at the bottom of the display is now highlighted (back lit).
•Press [F4] = MORE to return to STAND BY status.
OPEN
When ready, press [START] to get offset values
F1
RTN/LOW
F2
OUTPUT
DANGERPASS FAIL
F1
F2
F3
F4
START
STOP
Sentry 30 Plus AC/DC/IR Hipot Tester
01
Q uadTech
!
CAUTION
F4
F3
Max 5kVAC
6kVDC
CAL UPDATE
PRESS START KEY TO GET OFFSET..
1.
2.
Please open the HV output terminal
No offset in IR mode.
+-
Figure COI-3: Zero/Offset OPEN Configuration

Page 20 of 85
Condensed Operating Instructions (Continued)
Connection to Device under Test (DUT)
Figure COI-4 illustrates the connection of the Sentry Plus Series unit to a single DUT using the
S02 1-meter HV cable set that comes standard with the instrument. The custom white banana
plug/red alligator clip is connected between the OUTPUT terminal on the Sentry Plus Series unit
and the high side of the device under test. The black banana plug/alligator clip is connected
between the RTN/LOW terminal on the Sentry Plus Series unit to the low side of the DUT.
DUT
S02
Cable
Set
+-
F1
RTN/LOW
F2
OUTPUT
DANGERPASS FAIL
F1
F2
F3
F4
START
STOP
Sentry 30 Plus AC/DC/IR Hipot Tester
01
Q uadTech
!
CAUTION
F4
F3
Max 5kVAC
6kVDC
CAL UPDATE
1.250kV
STEP 1/5
STAND BY OFST
0.500mA
3.0s
AC LOW: OFF
ARC: OFF
RAMP: OFF
FALL: OFF
PROGRAM
PRESET
MENU
M1
RMT LOCK ERR
MORE..
COI-4: Connection to Device under Test
Measurement Mode
1.
Turn [POWER] ON.
2.
Allow Sentry Plus Series instrument a 15-minute warm up time.
3. Connect S02 Black ground cable to Sentry Plus Series unit RTN/LOW terminal
4. Connect S02 White/red HV cable to Sentry Plus Series unit OUTPUT terminal.
5.
Press [F1] = PROGRAM and enter test parameters. When finished programming, press
[F4] = EXIT to return to STAND BY status.
6.
Press [F4] = MORE to access Offset function. Press [F3] = OFFSET. Follow Offset
instructions. When Offset is complete, press [F4] = MORE to return to STAND BY.
7. Connect device under test (DUT) to test leads.
8.
Press [START].
9. Record measurement.
10.
Press [STOP].
