Dynamic DX
Finger Steering Control
Basic Operation Instructions
WARNING!
USE ONLY IN DRY
CONDITIONS

2 Basic Operation Instructions Finger Steering Control
Copyright © 2001
Pride Mobility Products Corporation
This manual describes basic operation for the Dynamic DX Finger teering
Control only and must be read in conjunction with the owners manual
supplied with your power chair. Please read both manuals in their entirety
before operating the Dynamic DX Finger teering Control or your power
chair.
This manual is intended as a supplement to the in-service training provided
by your authorized provider. If you have any questions or problems regarding
the Dynamic DX Finger teering Control, please contact your authorized
provider.
IMPORTANT NOTICE

Finger Steering Control Basic Operation Instructions 3
TABLE OF CONTENTS
INTRODUCTION ................................................................................ 4
Dynamic DX Finger teering Control ....................................................... 4
ACTIVE/STANDBY MODES ........................................................... 6
witching Modes ....................................................................................... 6
Active Mode Operation ............................................................................. 6
Actuator Control ........................................................................................ 7

4 Basic Operation Instructions Finger Steering Control
INTRODUCTION
Welcome to Quantum Rehab, a Division of Pride Mobility Products
Corporation. Quantum Rehab is dedicated to the customization of power
chairs for users with advanced rehabilitation and mobility issues. Quantum
Rehab also expands possibilities for enhanced healthcare attendant control
over power chair functions to provide a secondary level of support for our
customers where necessary.
Dynamic DX Finger Steering Control
The Finger teering Control is a DX compatible secondary remote control
operated by sensors which detect the position of the users finger and translate
the position into an executable command.
This manual is designed to explain basic operation of the Finger teering
Control. Figure 1 provides information on the Finger teering Control
components. Use this diagram to familiarize yourself with the function and
location of each component before using the Finger teering Control.

Finger Steering Control Basic Operation Instructions 5
Status LEDs
Green indicates fault codes;red indicates
whether the Finger Steering Control is in
Active Mode or Standby Mode.
Finger Steering Control
Detects the position of the user's finger
and translates that into an executable
command.
Anti-StaticWrist Band and GroundWire
Safety feature intended to prevent static from
damaging the control.
Active/Standby Switch
Toggles between Active and Standby Modes
and scrolls through drive programs and
actuators.
WARNING!
USE ONLY IN DRY
CONDITIONS
Figure 1. Finger Steering Control Components

6 Basic Operation Instructions Finger Steering Control
Figure 2. Finger Area Positioning
NOTE: The Finger Steering Control should only be used in dry conditions
or where sufficient protection from moisture can be maintained. Allow the
control to dry thoroughly if it has been e posed to moisture.
ACTIVE/STANDBY MODES
The Finger teering Control utilizes two modesActive and tandby. Active
Mode allows the user to drive the power chair, while tandby Mode does not.
Switching Modes
To switch from Active Mode to tandby Mode, touch the Active/ tandby
witch. ee figure 1. When in tandby Mode, the Red tatus LED will blink.
To return to Active Mode, touch the Active/ tandby witch for less than 1.5
seconds. When in Active Mode, the Red tatus LED will remain constantly
lit. To scroll through and select the available drive programs and actuators in
Active Mode, hold your finger on the Active/ tandby witch.
NUETRAL
Active Mode Operation
The Finger teering Control detects
the position of your finger and
translates that into a proportional
speed. If your finger is in the neutral
position, the power chair will remain
stationary. When you move your
finger to the outer limits of the finger
area, the chair will drive. The further
away your finger is from the neutral
position, the faster the speed. ee
figure 2.
NOTE: If required, a metal rod or other conductive material can be used to
operate the control. This alternate device must make constant contact with
the user to be operational.

Finger Steering Control Basic Operation Instructions 7
Actuator Control
While in Active Mode, hold your finger on the Active/ tandby witch to
scroll through the drive programs and actuators. When you reach the actuator
you wish to adjust, take your finger off of the switch. Place your finger in the
neutral position of the finger area, then slide your finger down to extend the
actuator or up to retract the actuator.

8 Basic Operation Instructions Finger Steering Control
Exeter, PA
Quantum Hotline: [phone]
Visit the Rehab Zone at:
www.quantumrehab.com
INFMANU1745/A/MAY 2001
