Quantum Q100T User manual

Q100T/Q100TH
Quick Guide
Quantum s.r.l
Via Cadorna, 67 - 20090 Vimodrone (MI)
Www.qtmtv.it

27
2
Index
Warning
Precautions and safety
Remote control
Audio/Video switch
Multimedia
Receiver Menu
Settings
Tv List
Diagnostics
DVB-T First Use
DVB-T Daily Use
DVB-H Mode (*)
DVB-H PayTV (*)
Installation
Installation and Connections
Technical features
Warning
Warranty
EQUIPMENT
Each contains:box
RECEIVER
REMOTE CONTROL
REMOTE INFRARED SENSOR
POWER CAR CABLE
QUICK GUIDE
Page 3
“4
“5
“6
“8
“10
“11
“12
“12
“14
“15
“16
17
19
“20
“24
“25
“26
(*) applicable only to Q100TH version

Warning
!
3
CAUTION
This symbol means impor-
tant instructions. Failure to heed
them can result in serious injury or
death
DO NOT OPERATE ANY
FUNCTION THAT TAKES YOUR
ATTENTION AWAY FROM SAFELY
DRIVING YOUR VEHICLE
Any function that requires your
prolonged attention should only be
performed after coming to a
complete stop.
Always stop your vehicle in a safe
location before performing these
functions. Failure to do so may result
in an accident.
USE THIS PRODUCT FOR MOBILE
12/24 Vcc APPLICATIONS AND
NEGATIVE GROUND
DO NOT DISASSEMBLE OR ALTER
THE UNIT
USE THE CORRECT AMPERE
RATING WHEN REPLACING
FUSES
STOP USE IF A PROBLEM
APPEARS
DO NOT USE OLD BATTERIES
Any misuse that diverts from the
designed application may result in
fire, electric shock or other injury.
Doing so may result in accidents or
injuries.
Failure to do so may result in fire or
electric shock
Failure to do so may cause personal
injury or damage to the product.
When inserting batteries in the
remote control, be sure to observe
proper polarity as instructed.
Rupture or chemical leakage from
the battery may cause malfunction
ing, break or injury.
!
26
IMPORTANT:
Quantum S.p.A. declines all
responsibibty for any errors or omis-
sions in this guide and reserves the
right to make changes without prior
notice.
The information given in this guide
were correct at the time of going to
print.
Warranty
WARRANTY VOUCHER
Model .........................
Serial number .........................
Defect found ...........................................................................
.............................
Customer signature
Date _ _ / _ _ / _ _
To return correctly filled in together with the purchase receipt
DEALER’S STAMP AND SIGN
Warranty
Dear customer,
thank you for choosing our product, which has been designed and manufactured to the highest quality
standards.
› failures caused by carelessness or transport.
› failures caused by installation not in accordance with the instructions
› failures caused by improper, incorrect or not in accordance with the instructions, use of the device
› In the event you require service, during the warranty period, you should fill in and show the present
certificate, together with a valid receipt issued by the dealer, showing the date of purchase of the
product.
• The product is covered by a warranty, for a period of 24 months, which is testified from a delivery document
indicating the date of purchase of the product and the dealer’s name.
• The customer is entitled to the rights provided for by Legislative Decree n° 24/2002
• The warranty covers the replacement or the repair operation of all the parts found to have manufacturing
defects.
• The warranty does not cover:
• The manufacturer cannot be held responsible for accidental damages to persons, pets, or things, as a con-
sequence of non-conformity with all the precautions furnished with the instructions manual.

4
Precautions and Safety !
PRECAUTIONS
TEMPERATURE
Be sure the temperature inside the
vehicle is between +45°C and 0°C
before turning your unit on.
The replacement of the fuses must
be of the same amperage. If one
fuse blows more than once, care-
fully check all electrical connections
to prevent short circuits. Also have
your vehicle’ s voltage regulator
checked.
If you have problems, do not
attempt to repair the unit yourself.
Require assistance at the nearest
retailer or service station.
Installindry,safelocations,away
from dangers and humidity.
Use only in cars with a 12/24 Vcc
negative ground.
Before connecting the device
remove the negative terminal from
the battery to prevent short circuits.
Do not use bolts or nuts related to
any safety system (airbag, etc.), To
make ground connection.
In order to ensure vehicle safety,
the driver’s side screen must be con-
nected to the front video output con-
nector. This will ensure the driver
won’t be able to watch TV while the
vehicle is moving, if the handbrake
wire is properly connected. The
driver will be able to watch TV once
the handbrake is pulled. The rear
passenger screens, connected to
the rear video output connectors,
do not fall under this restriction.
FUSE REPLACEMENT
MAINTENANCE
INSTALL LOCATION
INSTALLATION PRECAUTIONS
VIDEO OUTPUT
SAFETY
CAUTION
WATCHING TV WHILE
DRIVING MAY RESULT IN SERIOUS
ACCIDENTS, INJURIES OR DEATH!
!
25
Warning
!
Q100 series complies with:
CAUTION:
E24: according to ECE R10-03 Regulation
DiGiTVi: specifications D-Book ver.1.0 - June 2004 and following
updates where available
Your receiver is supplied with an operating system and resident programs.
While using the receiver, various software could be downloaded.
You should NOT use improperly any of these softwares wholly or partly for
any reason other than that mentioned in the user manual.
Improper use means: duplication, distribution, tampering. In other words,
that the only allowed usage in the one described in this user manual.

Remote Control
5
i
SCAN
OK
P+
PV+
CHANNEL
12
3
456
78
0
9
EXIT
BACK MUTE
LIST
info
MENU
TV
RADIO
@?!. abc
ghi jkl mno
pqrs tuv
_+ *
wxyz
def
-TV/RADIO - YELLOW
to switch between TV/Radio
listing
SCAN
to start autoscan
-
to select a function or to
confirm the selection
OK
LIST
to view channel list
-
P+/-
zapping channels
-
to view info on a program or
navigation button
UP BUTTON
navigation or volume adjust
button
RIGHT BUTTON
EXIT
to exit from the selected
option
-
0…9
alpha/numerical button
-
BACK
to return to the previous page
(where available)
-
MUTE
to switch on/off the audio
input
-BLUE, GREEN
navigation buttons
DOWN BUTTON
navigation button
LEFT BUTTON
navigation or volume adjust
button
-
STAND-BY
to put the unit on stand-by
and switch to a/v input
to manually search/track a
tuned channel
SEARCH
SEARCH
24
Technical features
Mobile DVB-T signal reception
Autotracking/Autosearch
Favourite Channels List
2 video for separated monitor
1 audio stereo
Audio/video digital quality
Easy and fast plug-and-play installation
output two
output
1 video input
1 audio stereo input
DVB-T
DVB-H (*)
Video Decoding and OSD
Audio Decoding
Connections
ISO/IEC 13818-1 MPEG-2 Transport Stream
ETS 300 744 DVB-T Full Compliance
VHF (Band III) / UHF 21-69
DVB-T COFDM 2k/8k supported
7,8 mhZ bandwidth support
OSF IPDC ESG compliant
UHF bandwith, channels 21-69
COFDM 2k/4k/8k supported
6,8 mhZ bandwidth support
Advanced high definition video decoding
(H264)
Advanced standard definition video decoding
(H264/MPEG2)
Resolution: 720x576 for PAL
16:9/4:3, 3:2 Letterbox and Pan/Scan
65K Colour OSD
Advanced multi-channel audio decoding
(MPEG 1, 2, MP 3, AAC/AAC+)
Stereo / MTS
IR Remote Connector
Antenna-In : Fakra type 2x
Audio stereo Output (RCA L/R) 1x
Composite Video Output (RCA) 2x
Stereo Audio Input (RCA L/R) 1x
Composite Video Input (RCA) 1x
Safety and Reliability
Comsuptions
Mechanical Specification
Operation temperature : -5 C ~ +55 C
Storage temperature : -45 C ~ +85 C
0.7 A in full operation powering two antennas
0.65 A in stand by
500 microA when off (car key off)
Dimensions (WxDxH): 148mm x 107mm x 35mm
(*) applicable only to Q100TH model
-RED (*)
Options list

6
DVB-T First Use
Q100 series is an automotive grade set top box - able to
receive multi-standard DVB digital TV: DVB-T in standard
definition (SD) and high definition (HD) and DVB-H.
By pressing the [Red] button on the remote control, one
could switch from DVB-T mode to DVB-H mode.
vGetting started
following installation instructions on s 19-22
[OK]
searching [EXIT]
› [OK] save
scan phase,
ove-
rall ;
tially the [EXIT], [SCAN] and [OK]
scan phase.
• Please wait until
› press [OK] button
search.
search
At the end of the scan phase, frame will be shown
on the screen.
Be sure that every connection has been correctly set
page
Turn the unit on
frame will be shown on the screen .
press button to the channels in the TV
LIST. The first channel in the up-to-date TV LIST
will be shown on the screen.
If at the end of the frame is shown
on the screen check the connections and the
installation of the receiver then press
sequen buttons
to restart the
to start the automatic channel
It's possible to stop the by pressing EXIT but-
ton. Frame will be shown on the screen. Press
button to confirm stop or the button
to resume it.
SCAN
[OK] to start search - [EXIT] to quit
SCAN
No services found - [EXIT] to quit
0%
TV
0
RADIO
0
50% 100%
SCAN
[OK] to stop - [EXIT] to continue
0%
TV
12
TV
TV
TV
TV
RADIO
RADIO
RADIO
2
50% 100%
SCAN
[OK] to save - [EXIT] to quit
0%
TV
44
TV 1
TV 2
TV 3
TV 4
RADIO 1
RADIO 2
RADIO 3
RADIO 4
RADIO
3
50% 100%
23
Installation and Connections (*)
SIM INSERTION (*)
SIM
In the case of an existing DVB-H PayTV
subscription SIM based, please insert SIM card as
shown in the picture
(*) applicable only to Q100TH model

7
DVB-T First Use
TUNING
[OK] to start search - [EXIT] to quit
TV LIST
ADD FAVOURITE: [OK] to confirm - [EXIT] to quit
SETTINGS DIAGNOSTICS
CREATE SORT DEL.CHAN DEL.LIST
vAutotracking and Autosearch
This innovative automatic function allows the receiver to
follow the selected channel while moving from place to
place.
Typical DTT Networks are Multi Frequency Network (MFN)
that is, each TV channel may be transmitted on different
frequencies depending on the specific geographical area.
Once a specific TV channel has been selected the,
Autotracking and Autosearch functions have the purpose
of tuning, tracking and in some cases automatically
searching for the channel where there is a frequency
change or signal loss due to movement in location, without
the need to start a new search manually..
In order to have the Autotracking and Autosearch function
perform in the best possible way, it is recommended to
carefully the instructions below:
- Tune the available channels in
that specific area
If autosearch does not allow the tuning into of all the
favourite channels, re-start operations by doing point 1
and 2 in an other geographic area.
1.Start an
2.Create a FAVOURITE TV LIST (from menu)
3. Select the FAVOURITE TV LIST as default
AUTOSCAN
by pressing [SCAN] button
- This
enables you to define and organize the list of your
favourite channels
WARNING: channels marked in red are
temporarily not available due to the lack of
network coverage .
WARNING: channels marked in red are
temporarily not available due to the lack of
network coverage .
FAVOURITE TV
1 Channel TV
2 Channel TV
3 Channel TV
4 Channel TV
5 Channel TV
6 Channel TV
7 Channel TV
TV LIST
[GREEN] to change list
FAVOURITE TV
TV LIST
1TV
2
Channel
Channel TV
3 Channel TV
4 Channel TV
5 Channel TV
6 Channel TV
7 Channel TV
[GREEN] to change list
1
1
22
Installation and Connections
vTECHNICAL FEATURES
+ 5V DC PHANTOM POWERED DVB-T
ANTENNAS
Operation frequencies: 174 - 230 (band III)
470 - 866 (bands IV - V)
Gain: 18 dB Max
Cable type: coaxial 75 ohm
Cable lenght: 5 m
Connector: type FAKRA
Power: +5 Vcc
Consumption: 25mA min - 35 mA max
Temperature range : - 40° <> +85° C
Protection class: IP40
Size (L x B x H): 28 x 2,5 x 1,5 cm
TV ANTENNAS
Specifications

8
DVB-T Daily Use
v
v
v
How to switch the receiver on
How to select a channel
Teletext
Depending on the specific car installation, the receiver will
be switched on as soon as the car key turns on the battery.
In case an external a/v source was previously activated,
please use the [ ] button on the remote control to exit
stand-by mode.
A Tv or Radio channel can be selected in three different
modes:
[ ] and [ ] [OK]
INFORMATION BAR will be previewed on the screen
tuning.
DIRECT directly
trough the channels without using the [OK] button.
If the relevant digital service includes Teletext informa-
tion, an OSD emulation of the Teletext home page will be
displayed (page nr.100).
All available pages can be accessed selecting relevant
number (using digits buttons) from the remote control.
(*) applicable only to Q100T model
• DIRECT: select the desired channel by using the numeri-
cal buttons
• ARROWS ZAPPING: select the desired channel by using
the up/down buttons and press to
confirm the selection.
before the channel
• ZAPPING: press [P+] [P-] to browse
56
56
(*)
.
• Press either the [Red] button. The option list will be
displayed
• From the list press [Green] for Teletext OR using the-
up/down buttons [ ] and [ ] select Teletext, press
[OK]
15 Channel TV
rogramP title
TV 12:17
12:00 12:45
SCAN A/V
OK
P+
PV+
CHANNEL
12
3
456
78
0
9
EXIT
BACK MUTE
LIST
info
MENU
TV
RADIO
@?!. abc
ghi jkl mno
pqrs tuv
_+ *
wxyz
def
21
Installation and Connections
TV ANTENNAS
Recommendations
active antennas that are
ly and receiver’s
s. The antenna should be
for the .
v
•
•
•
the is
ed test various positions
s,
• with care
•
INSTALLATION GUIDELINES
Use only amplified
adequate directly powered by the
antenna connector suitable
reception of the Digital Terrestrial signal
Quantum Antennas are manufactured and linked to
the Q100 receiver in order to optimize performance
.
Be sure to position the antennas as far away and
opposing from each other as possible. For exam-
ple, place the first antenna on the right side of the
wind screen of the vehicle and the second one
on the left side of the rear window or on the left
rear vent wing .
Antennas must be installed as far away from the
metal parts (vehicle's roof or vertical borders of
the wind screen/rear vent wing) as possible.
The bonnet or the boot (depending on the vehi-
cle) can influence signal reception. It rec-
ommend to to place the
antenna whether on the higher or the lower part
of the window. The higher part usually guarantees
more protection from noises caused by motorcy-
cles and scooters.
Handle the coaxial cable setting in order
to avoid damages due to vibration or crushing.
Be sure that the connections have been correctly
set and check the screwing of the connectors. Sig-
nal reception problems are often caused by incor-
rect assembly.
WARNING: ONLY use the Quantum antenna
provided. Use of different antenna or other
external power may result in product damage
and might affect the warranty terms

20
DVB-T Daily Use
v
v
v
v
v
v
How to select a channel in a TV/Radio List
How to adjust the volume level
Mute
How to view program info
How to select the audio language
How to select subtitles
• Press [LIST] to show the Tv List
› Press [GREEN] to switch between the general TV LIST
and the FAVOURITE TV LIST if previously preset [see
MENU]
• Press [TV/RADIO] (yellow) to show the RADIO LIST
› Press the same button to switch between the Radio List
and the previously selected TV LIST
• Select the desired channel
:
The volume level can be adjusted by using the [VOL+] [VOL-]
buttons
• Press [MUTE] button to switch on/off the audio output
• Press [info] to view short informations about the selected
program
• Press [BLUE] to get detailed informations about the
selected program
To select the desired language (when more languages are
available):
• Press [info] + [GREEN] and select the desired
language by using the up/down[ ] [ ] buttons
To select the desired subtitle (when available):
• Press [info] + [GREEN] and select the desired subtitle
option by using the up/down[ ] [ ] buttons
WARNING in red
due to lack of network coverage
(*)
channels marked are temporarily not
available
56
56
channels marked are temporarily not
available
FAVOURITE TV
1C TV
2
hannel
Channel TV
3 Channel TV
4 Channel TV
5 Channel TV
6 Channel TV
7 Channel TV
TV LIST
[GREEN] to change list
1
1
SCAN A/V
OK
P+
PV+
CHANNEL
12
3
456
78
0
9
EXIT
BACK MUTE
LIST
info
MENU
TV
RADIO
@?!. abc
ghi jkl mno
pqrs tuv
_+ *
wxyz
def
TV
RADIO
9
Installation and Connections
FRONT PANEL
WARNING:
+5V PHANTOM POWER IS PRESENT
IN ALL “ANTENNA IN” CONNECTORS
+12V/24V KEY - Red
+12V/24V BATTERY - Yellow
BRAKE - Green
GND - Black
VIDEO OUT 1 (FRONT)
VIDEO OUT 2 (REAR)
VIDEO IN
AUDIOOUTR(rigth)
AUDIO OUT L (left)
ANTENNA IN 1
ANTENNA IN 2
IR RECEIVER
TO CAR AUDIO
SYSTEM
RJ11 PORT
AUDIOINR(rigth)
AUDIO IN L (left)
EXTERNAL
AUDIO SOURCE
EXTERNAL
VIDEO SOURCE
FRONT
MONITOR
REAR
MONITOR
(*) applicable only to Q100T model

1910
Audio/Video switch
SCAN A/V
LIST
P+ info
The receiver enables the user to connect an external
audio/video source (e.g. Videogame console, Dvd player,
etc..) to the audio/video input (as shown at page 17) and
to select it through the remote control
Using the Power button of the remote control the user
may switch from digital Tv signal to external source signal
and viceversa.
vAudio/video Inputs
s
How to select audio/video input:
WARNING: FRONT monitor should be enabled only
once the handbrake control is activated.
Installation
WARNING:
Before installing the device
read carefully the following instruc-
tions
!
HAVE THE INSTALLATION DONE BY
QUALIFIED PERSONNEL
DO NOT INSTALL IN LOCATIONS
WITH HIGH MOISTURE OR DUST
MAKE THE CORRECT CONNECTIONS
The installation and wiring of this unit
requires special technical skills and expe-
riences. To ensure safety, always have
the installation done by experts
Route the electrical and audio/video
cables, wiring away from moving parts
and sharp/pointy edges.This will
prevent crimping and damage to the
wires. If wiring is passing through a
metal hole, use of a rubber grommet
can act as a form of insulation
preventing the wires from being cut by
the metal edges of the hole.
Avoid installing the unit in locations with
high levels of moisture or dust.
Prenetration of moisture or dust may
result in product failure.
Failure to make the proper connections
may result in product damage
USE SPECIFIED ACCESSORY PARTS
ARRANGE THE WIRING CORRECTLY
USE ONLY IN CARS WITH A 12 / 24
Vcc NEGATIVE GROUND
BEFORE WIRING DISCONNECT THE
CABLE FROM THE NEGATIVE (-)
BATTERY TERMINALS
DO NOT SLICE INTO ELECTRICAL
CABLES
DO NOT USE BOLTS OR NUTS IN THE
BRAKE OR STEERING SYSTEM TO
MAKE GROUND CONNECTIONS
DO NOT INSTALL IN LOCATIONS
WHICH MIGHT HINDER VEHICLE
OPERATION, SUCH AS THE
STEERING WHEEL OR GEARSHIFT
Be sure to use only the specified acces-
sory parts. Use of accessory parts other
than designed may damage this unit or
cause incorrect functioning of the appli-
ance
Failure to do so may result in fire, electric
shock or other injuries
Failure to do so may result in electric
shock or electric shock injuries.
Never cut away cable insulation to supply
power to other equipment. Doing so will
exceed the current carrying capacity of
the wire and result in fire or electric shock
Bolts or nuts used for the brake or steer-
ing systems (or any other safety-related
system), or tanks should NEVER be used
for installations or ground connections
Doing so may obstruct forward vision or
hamper movement etc., and result in seri-
ous accident

18 11
Multimedia
vMULTIMEDIA
Q100 series is able to support multimedia files stored on a
USB key (ver. 1.1).
Insert USB key in the Q100 USB plug.
Supported format is:
.AVI for video files
.Mp3 for audio files
Max resolution supported is SD (720x576).
• Press [RED] button of the remote control
• Select multimedia option from the list and press OK
• Select Video/Audio option to display Video/Audio
files stored in the USB key.
• From the list of available Video/Audio files, select
one file and press [OK] button. The Video/Audio
player will automatically start playing the file.
Press [INFO] button of the remote to display progress
bar and options, in particular:
[RED] button, to seek back the file
[BLUE] button, to stop playing
[GREEN] button, to pause/play the file
[YELLOW] button, to seek the file
[BACK] button, to go back in the file list
Press [EXIT] button of the remote to quit Multimedia
section and go back to digital TV channels.
v
v
v
How to show the list of multimedia files
How to play a multimedia file
How to quit multimedia section
:vHow to display options
DVB-H PayTV Menu (*)
In case of DVB-H PayTV services, the user may use
the DVB-H menu to have access to the following
options:
- My Subscription info
- Parental control settings
With such option the user may display the list of
subscribed packages (if broadcasted by the DVB-H
Operator).
v
s
v
My Subscription
Parental Control
• press [ME
• select MY SUBSCRIPTION by using the right and
left [ ] [ ] buttons
• press [OK] to confirm the selection or [EXIT] to
cancel.
If available, the list of subscribed packages may be dis-
played.
To access restricted channels a PIN code is needed.
This is provided with the SIM.
The restriction level may be set in the following
way:
• press [ME
• select PARENTAL CONTROL by using the right
and left [ ] [ ] buttons
• press [OK] to confirm the selection or [EXIT] to
cancel.
• browse the list sequentially by using the up and
down buttons [ ][ ]
• press [OK] to confirm the selection or [EXIT] to
cancel.
• Enter PIN code to apply the changes
How to view subscribed package
NU]
NU]
34
34
56
(*) applicable only to Q100TH model
DVB-H
MULTIMEDIA
Video
Audio

1712
Main Menu - SETTINGS
SCAN A/V
OK
P+
PV+
CHANNEL
EXIT
info
MENU
LIST
v
v
MAIN MENU
SETTINGS
.T
The main MENU may be used to see system info and/or set
user’s preferences.
The following options are available:
:
• SETTINGS
• TV LIST
• DIAGNOSTICS
To display main menu press [MENU] of the remote control.
This sub-menu shows the data related to:
• RECEIVER
• RESTORE
• CLOCK
• Press [MENU] to view the main menu on the screen
• Select SETTINGS by using the right and left [ ] [ ]
buttons.
• Press OK to enter this sub-menu and then press it again
till you get the required item
• Select the desired function firstly by using the right and
left buttons [ ] [ ] and then the up and down [ ]
[ ] buttons
• Press [OK] to confirm the selection and to move to
the next function or [EXIT] to cancel the selection
Sub-menus
WARNING: Be careful not to accidentally change
the parameters. this will aid to the misfunctioning
of the device. Default settings are normally used
for standard installation hey can be restored
through the RESTORE function.
How to navigate the Settings Menu
s
34
34 5
6
SETTINGS
Receiver settings: [OK] to confirm - [EXIT] to quit
DIAGNOSTICS
TV LIST
DVB-H PayTV (*)
When using the PayTV option, to have access to
the encoded channels the user must have a valid
subscription with the Operator which is
broadcasting the DVB-H signal.
Once the subscription is in place, the Operator
provides a smart card (SIM card) that will be used
to decrypt channels.
Please refer to page 23 to insert SIM card into the
relevant SIM slot of the unit.
In the case where the SIM card is not related to the
rigth DVB-H Operator or the SIM card is not properly
inserted in the unit’s slot, message (1) may be
displayed.
Please check the SIM card again.
In the case where the subscription has expired or a
new package subscription is required, message (2)
may be displayed.
To renew subscription refer to the displayed message.
The subscribed package may include specific
channels (adult channels) that may require a
Parental PIN code to have full access (3).
Press [OK] and insert PIN code using remote
control digits [1,2,..] then press [OK] again to
confirm.
Please note that PIN code is provided together with
the SIM card.
v
v
Subscription
If a valid subscription is in place, all TV channels
available with that subscription will be accessed
without distinction between free to air and Pay
channels.
PIN Code
(*) applicable only to Q100TH model

13
16
RECEIVER
RESTORE
CLOCK
w
w
w
TV OUT
MENU LANGUAGE
MENU COLOR
RECEIVER DATA
CHANNELS LIST
•
Set tv out mode according your screen type :
› 4:3 pan & scan
› 4:3 letter box
› 16:9
•
To select the menu language
•
To set color of menu
This function enables the user to reset the input data
among the following categories:
•
To reset settings, system and installation parameters
•
To delete all the channels lists
It is possible to make a completely restore the data by
selecting both items.
The receiver's clock will be automatically updated through
the tv signal. It's possible, if desired, to change the time
zone, set at GMT+1 by default
SETTINGS DIAGNOSTICS
TV LIST
CLOCK RECEIVER RESTORE
[OK] to confirm - [EXIT] to quit
Local time 11:23
Greenwich time 09:23
Offset +-01:00
Main Menu - SETTINGS
DVB-H mode (*)
Be sure that every connection has been correctly
set, as shown on page 20
Use P+ and P- buttons of the remote control to zap
the available digital channels.
Press [LIST] to show the TV List (3)
Zapping
and 23.
Once the unit is ON, please use the red button of the
remote control to switch from DVB-T mode to DVB-H
mode and viceversa.
For first time use (after a power off/on) when the
DVB-H mode is entered, the device will automatically
scan UHF bandwith (channels 21-69) to search for the
pre-configured DVB-H listing the user has subscribed
(1).
Once the listing is found (2), the unit will download
related EPG (electronic program guide) and will tune
and displays the first digital TV channel of the list.
Select the desired channel by using the up/down
buttons[ ] e [ ] and press [OK] to confirm the
selection.
Once the TV List is displayed:
If available, press [GREEN] button to view program
guide (4) of the specific channels sorted by time.
Press [BLUE] button to view a new day program
guide
v
v
v
v
Getting started
Channel List
Program Guide
56
(*) applicable only to Q100TH model

14
Main Menu - TV LIST
vHow to manage the Favourite Tv List
It is possible to create a personal favourite Tv List.
TV LIST and RADIO LIST are all the tuned channels so they are
not initially personalize.
• press [MENU]
• select TV LIST and press [OK] to confirm
• select CREATE and press [OK] to confirm
• browse the list sequentially by using the up and down
buttons [ ][ ] , or in groups of six channels by using
right and left buttons [ ][ ] and select the channel
• press [OK] to confirm the selection. A tick signal will be
shown next to the selected channel
• f you want to cancel the selection press again and
the tick will be deleted
Follow the same procedure as shown at the point 1 and
replace CREATE with DELETE.
• press [MENU]
• select TV LIST and press [OK] to confirm
• select SORT and press [OK] to confirm
• browse the list sequentially by using the up and down
buttons [ ][ ] or in groups of six channels by
using the right and left buttons[ ][ ] and select
the channel you want to move
• browse the list in the same way and click on the position
where you want to move the selected
channel. A tick mark will be shown next to the
selected channel
• press [OK] to confirm the new position of the channel
Follow the same procedure as shown at the point 1 and replace
CREATE with ERASE
1. How to create the Favourite Tv List:
2. How to delete a channel from the Favourite Tv List:
3. How to sort the Favourite Tv List:
4. How to delete the Favourite Tv List:
ü
ü
56
34
56
34
3
i [OK]
mark
SCAN A/V
OK
P+
PV+
CHANNEL
EXIT
info
MENU
LIST
[EXIT to quit and save
TV LIST SETTINGS DIAGNOSTICS
CREATE SORT DELETE ERASE
1TV
2
Channel
Channel TV
3 Channel TV
4 Channel TV
5 Channel TV
6 Channel TV
ü
ü
[EXIT] to quit and save
1TV01
2
Channel
Channel TV 02
3 Channel TV 03
4 Channel TV 04
5 Channel TV 05
6 Channel TV 06
3
4
TV LIST SETTINGS DIAGNOSTICS
DELETE ERASE ADD
SORT
Main Menu - DIAGNOSTICS
SCAN A/V
OK
P+
PV+
CHANNEL
EXIT
info
MENU
LIST
v
s
DIAGNOSTICS
NU]
The receiver can provide the following diagnostics
information:
• SIGNAL QUALITY
• RECEIVER INFO
• press [ME
• select DIAGNOSTICS by using the right and left
[ ] [ ] buttons
• press [OK] to confirm the selection or [EXIT] to can-
cel it.
How to view the DIAGNOSTICS:
34
15

This manual suits for next models
1
Table of contents
