Scalar i40 and Scalar i80:
Power Supply Filler Plate
Replacement
To maintain proper library cooling, filler plates are required on all empty power
supply slots in the rear of the Scalar®i40 or Scalar i80 library.
To remove a power supply filler plate or to replace the power supply with a filler
plate, refer to the following sections:
•Removing a Power Supply Filler Plate on page 1
•Replacing a Power Supply Filler Plate on page 2
Removing a Power Supply Filler Plate
1Unscrew the two captive thumbscrews (see Figure 1 on page 2).
2Pull out on the thumbscrews so the filler plate is at a slight angle, and the
bottom of the filler plate is still attached in the slot.
3Lift the filler plate up to disengage the catch at the bottom, and pull the
filler plate out of the slot.

Quantum Scalar i40 and Scalar i80: Power Supply Filler Plate Replacement
6-68063-01 Rev A
February 2014
2Replacing a Power Supply Filler Plate
Figure 1 Power Supply Filler
Plates
Replacing a Power Supply Filler Plate
1Hold the filler plate with the thumbscrews at the top.
2Insert the bottom edge of the filler plate into the slot, engaging the bottom
edge of the filler plate in the bottom of the slot.
3Pivot the filler plate up to fit securely in the hole.
4Tighten the thumbscrews.
Single
power
supply
installed
in top slot
Power
supply
filler plate
Captive thumbscrews
