Quark-Elec QK-AS07 User manual

Disclaimer: This product is designed to aid navigaon and should be used to augment normal navigaonal
procedures and pracces. It is the user’s responsibility to use this product prudently. Neither Quark-elec, nor
their distributors or dealers accept responsibility or liability either to the product user or their estate for any
accident, loss, injury or damage whatsoever arising out of the use or of liability to use this product.
Email: [e-mail]
V1.1(4/20)
QK-AS07 / QK-AS07-C
SET-UP GUIDE
CE, RoHS cered
www.quark-elec.com
QK-AS07
NMEA 2000 GPS SENSOR
GPS, GLONASS AND GALILEO
Please recycle your packaging

This is an overview only. Always familiarize yourself with the product manual and
the manuals of any connecng devices before installaon. Designed to be
connected by an experienced installer.
QK-AS07 /QK-AS07-C
AS07 INSTALLATION
The AS07 connects directly to your NMEA 2000 backbone for power and data transfer. No
other connecons or conguraon is required.
1. Mounng: Consider your locaons
• Sturdy outdoor locaon, with ‘line of sight’ to the sky.
• The AS07 has a standard G3/4 thread and is supplied with a corresponding base.
• If drilling holes for screws and cabling, seal around any holes to prevent damage to your vessel
or equipment.
2. Disconnect all power sources before connecng your equipment!
3. Connect to your NMEA 2000 backbone (12.0V power)
The QK-A032 draws 12.0V power from your NMEA 2000 backbone. You will need a backbone and
2 terminaon resistors (1 on each end), such as NMEA 2000 Starter Kit (www.quark-elec.com/
product/nmea-2000-n2k-starter-kit/).
4. Re-power your NMEA 2000 backbone.
The posional data will now be available to all devices on the NMEA 2000 bus.
USING THE OPTIONAL OUTPUT SWITCH (AS07-C)
QK-AS07 /QK-AS07-C
BEFORE LEAVING HOME:
We recommend pre-installing any needed Conguraon soware or drivers if needed, as you
might not have a CD reader/internet access on site.
Not required for standard NMEA 2000 use with default sengs.
Driver and Conguraon soware are for use with AS07-C, they are oponal and only needed
for specic features.
If using AS07 for conguraon or 0183 use you will need
• Conguraon soware (Windows) required.
• Hardware driver may be required. Driver required for Windows. If using Windows 10, the
driver should install automacally, if not, it is included on the Free CD and at Quark-elec.com.
Driver not required for Mac
Conguraon Soware and specic instrucons are on the FREE CD and at www.quark-elec.com.
The AS07 can be used out of the box, for instant posional data to your NMEA 2000 bus.
Alternavely, the AS07 can be used with the AS07-C Oponal Output Switch (pictured above).
The AS07-C can be used for,
A. Addional conguraon (Windows PC soware),
• Filtering of NMEA 2000 PGN messages, to eliminate unwanted data.
• Adjusng the frequency of NMEA 2000 data. The default seng is 1 Hz (data transferred
once per second) The frequency can be set to 1/2/5/10 per second. 1Hz is the default seng
and is generally recommended. Please note: 10 Hz may cause data overow on the NMEA
2000 system.
B. Backward compability with NMEA 0183 devices.
(The AS07-C (Output Switch) will always require Conguraon. See manual for AS07-C setup.)
