QuickJack™ Portable Car Jack
Setup and Operation Manual
Manual P/N 5900263 —Manual Revision B6 — ReleasedSeptember 2023
Models:
•3500SLX
•6000ELX
•5000TL
•5000TLX
•7000TL
•7000TLX
Avideo of how to set up your QuickJack is available online.
Always check for the latest revision of the QuickJack Setup and Operation Manual at quickjack.com.
QuickJack is designed and engineered by BendPak Inc. in Southern California, USA. Made in China.
⚠
DANGER
I
MPORTANT
S
AFETY
I
NSTRUCTIONS
, S
AVE
T
HESE
I
NSTRUCTIONS! Read the entire contents
of this manual before installing, operating, servicing, or maintaining this lift. Failure to follow the
instructions and safety precautions in this manual can result in severe injury or death. Make sure all other
operators also read this manual. Keep the manual near the product for future reference. By proceeding
with setup and operation, you agree you fully understand the contents of this manual and
assume full responsibility for product use.
A
video of
how to set up your
QuickJack
is available online
Original instructions in the English language.

Manual. QuickJack™ Portable Car Jack, Setup and Operation Manual, P/N 5900263, Manual Revision B6, Released
September 2023.
Copyright. Copyright © 2023 by BendPak Inc. All rights reserved. You may make copies of this document if you agree that:
you will give full attribution to BendPak Inc., you will not make changes to the content, you do not gain any rights to this
content, and you will not use the copies for commercial purposes.
Trademarks. BendPak and the BendPak logo are registered trademarks of BendPak Inc. QuickJack and JackPak are
trademarks of BendPak Inc. All other company, product, and service names are used for identification only. All trademarks
and registered trademarks are the property of their respective owners.
Limitations. Every effort has been made to ensure complete and accurate instructions are included in this
manual. However, product updates, revisions, and/or changes may have occurred since this manual was
published. BendPak reserves the right to change any information in this manual without incurring any
obligation for equipment previously or subsequently sold. BendPak is not responsible for typographical
errors in this manual. The latest version of the manual for this product is available on
www.quickjack.com/support/downloads/ or by scanning the QR code.
Warranty. The QuickJack warranty is more than a commitment to you: it is also a commitment to the value
of your new product. For full warranty details and to register your new QuickJack product, contact your nearest QuickJack
dealer or visit quickjack.com/warranty.
Safety. Your new product was designed and manufactured with safety in mind. Your safety also depends on proper training
and thoughtful operation. Do not set up, operate, maintain, or repair the unit without reading and understanding this manual
and the labels on the unit.
Owner Responsibility. In order to maintain your product properly and to ensure operator safety, it is the responsibility of
the product owner to read and follow these instructions:
• Follow all setup, operation, and maintenance instructions.
• Make sure product setup conforms to all applicable local, state, and federal codes, rules, and regulations, such as state
and federal OSHA regulations and electrical codes.
• Consult a qualified person or organization to address any special regional structural and/or seismic requirements
specified by any other agencies and/or codes. The QuickJack must be installed on a flat surface which can support the
load of the vehicle being lifted without subsidence or movement.
• Read and follow all safety instructions. Keep them readily available for operators.
• Make sure all operators are properly trained, know how to safely operate the unit, and are properly supervised.
• Do not operate the product until you are certain that all parts are in place and operating correctly.
• Carefully inspect the product on a regular basis and perform all maintenance as required.
• Service and maintain the unit only with approved replacement parts.
• Keep all instructions permanently with the product and make sure all labels are clean and visible.
Only use this product if it can be used safely!
Unit Information. Enter the Model Number, Serial
Number, and the Date of Manufacture from the label
on your unit. This information is required for part or warranty
issues.
Model:
Serial:
Date of Manufacture:

QuickJack™Portable Car Jack 3P/N 5900263 —Rev. B6 —September 2023
Table of Contents
Introduction 3Operation 36
Shipping 5Maintenance 48
Safety 5 Troubleshooting 51
Components 8Wiring Diagrams 55
Accessories 10 Labels 56
Specifications 11 Parts Sheets 59
FAQ 13 Declaration of Conformity 67
Setup Checklist 14 Maintenance Log 69
Setup 15 ALI Store 71
Introduction
This manual covers all models of the QuickJack portable car jack, which makes Vehicle maintenance
in your garage or at the track fast and easy.QuickJack models include:
•3500SLX: Raises Vehicles up to 3,500 lbs. / 1,588 kg on a short frame.
•5000TL:Raises Vehicles up to 5,000 lbs. / 2,267 kg on a standard frame.
•7000TL: Raises Vehicles up to 7,000 lbs. / 3,175 kg on a standard frame.
•5000TLX: Raises Vehicles up to 5,000 lbs. / 2,267 kg on an extended frame.
•7000TLX: Raises Vehicles up to 7,000 lbs. / 3,175 kg on an extended frame.
•6000ELX: Raises Vehicles up to 6,000 lbs. / 2,721 kg on a super long frame.
This manual is mandatory reading for all QuickJack users, including anyone who sets it up,
operates it, maintains it, or repairs it. You can always find the latest version of the Manual
on the QuickJack Website.Scan this QR Code for up-to-date information and videos
on the QuickJack.
⚠DANGER Be careful when setting up, operating, maintaining, or repairing your unit; failure to
do so could result in property damage, product damage, injury, or (in very rare
cases) death. Make sure only authorized personnel operate the unit. An authorized
technician must perform all repairs. Do not make modifications to the unit; this
voids the warranty and increases the chances of injury or property damage. Make
sure to read and follow the instructions on the labels on the unit.
Keep this manual on or near your QuickJack so that anyone who uses or services it can read it.
For technical support, visit quickjack.com/support or email QuickJack Technical Support at
[email protected]. You can also request parts (be sure to have the serial and model
numbersof your unit available).

QuickJack™Portable Car Jack 4P/N 5900263 —Rev. B6 —September 2023
IMPORTANT!
PLEASE READ
Only raise your QuickJack Frames
with a Vehicle on them!
The QuickJack is designed and engineered to be used with the weight of a Vehicle on it. You
should only raise the QuickJack Frames with the weight of a Vehicle on them, even the very
first time you use them (with the exception of bleeding the Hydraulic Cylinders). There is
simply no reason to raise your QuickJack Frames unless there is a Vehicle on them.
Why are we telling you to do it this way? Because your QuickJack Frames may occasionally
become stuck up in the air if you raise them without the weight of a Vehicle.There is nothing
wrong with them if this happens, and the issue can be quickly and easily fixed, it is just that
they are designed and engineered to work with the weight of a Vehicle.Only raise your
QuickJack Frames with a Vehicle on them.
And since we have your attention…
Do not remove your Vehicle’s tires then lower the QuickJack to the ground.
The QuickJack requires space between the ground and your Vehicle to build up enough force
to raise a Vehicle. It cannot raise a full load from a completely flat starting position.
Do
Not
Do
This!
This is not a problem in normal operation, as the Vehicles you want to raise are being held well
above the ground by their tires. The problem generally happens when people lower the
QuickJack to a completely flat position with the Vehicle’s tires removed.
What do you do if either of these problems happens to you? Refer to Troubleshooting.

QuickJack™ Portable Car Jack 5P/N 5900263 — Rev. B6 —September 2023
Shipping
Your QuickJack was carefully checked before shipping. Nevertheless, you should thoroughly inspect
the shipment before you sign to acknowledge that you received it.
When you sign the bill of lading, it tells the carrier that the items on the invoice were received in good
condition.
To protect yourself, do not sign the bill of lading until after you have inspected the
shipment. If any of the items listed on the bill of lading are missing or are damaged, do not accept the
shipment until the carrier makes a notation on the bill of lading that lists the missing and/or damaged
goods.
If you discover missing or damaged goods after you receive the shipment and have signed the bill of
lading, notify the carrier at once and request the carrier to make an inspection. If the carrier will not
make an inspection, prepare a signed statement to the effect that you have notified the carrier (on a
specific date) and that the carrier has failed to comply with your request.
It is difficult to collect for loss or damage after you have given the carrier a signed bill of lading. If this
happens to you, file a claim with the carrier promptly. Support your claim with copies of the bill of
lading, freight bill, invoice, and photographs, if available. Our willingness to assist in helping you
process your claim does not make us responsible for collection of claims or replacement of lost or
damaged materials.
Safety
Refer to ANSI/ALI ALIS Standard (current edition) Safety Requirements for Installation and Service of
Automotive Lifts for more information about safely installing your QuickJack.
Important Before proceeding any further, we suggest checking the QuickJack Website to
ensure you have the latest version of the manual for your QuickJack.
⚠WARNING California Proposition 65: This product can expose you to chemicals including
styrene and vinyl chloride which are on the list of over 900 chemicals identified by
the State of California to cause cancer, birth defects or reproductive harm. Always
use this product in accordance with BendPak’s instructions. For more information,
visit www.p65warnings.ca.gov.
Important Safety Instructions
When using your QuickJack, basic safety precautions should always be followed, including:
1. Read all instructions.
2. Do not touch hot parts; you could be burned. Always use care with the equipment.
3. Do not operate equipment with a damaged cord or if the equipment has been dropped or
damaged — until a qualified service person has examined it.
4. Do not let a cord hang over the edge of a table, bench, or counter or come in contact with hot
manifolds or moving fan blades.
5. If an extension cord is necessary, a cord with a current rating equal to or greater than that of the
equipment should be used. Cords rated for less current than the equipment may overheat. Care
should be taken to arrange the cord so that it will not be tripped over or pulled.

QuickJack™ Portable Car Jack 6P/N 5900263 — Rev. B6 —September 2023
6. Always unplug equipment from electrical outlet when not in use. Never use the cord to pull the plug
from the outlet. Grasp plug and pull to disconnect.
7. Let equipment cool completely before putting it away. Loop cord loosely around equipment when
storing.
8. To reduce the risk of fire, do not operate equipment in the vicinity of open containers of flammable
liquids (gasoline).
9. Adequate ventilation should be provided when working on operating internal combustion engines.
10. Keep hair, loose clothing, fingers, and all parts of your body away from moving parts.
11. To reduce the risk of electric shock, do not use on wet surfaces or expose to rain.
12. Use only as described in this manual. Use only manufacturer’s recommended attachments.
13. Always wear safety glasses. Everyday glasses only have impact resistant lenses, they are not
safety glasses.
14. To reduce the risk of injury, close supervision is necessary when this product will be used around
children.
15. To reduce the risk of injury, never overload the drawers or shelves. Refer to loading instructions.
16. To reduce the risk of electric shock or fire, never overload receptacles. Refer to markings for the
proper load on receptacles.
Save these instructions!
QuickJack Safety Information
Please note the following:
•The product is a portable car jack. Use it only for its intended purpose.
•Read this manual thoroughly before installing, operating, servicing, or maintaining your QuickJack.
•The product should only be operated by authorized personnel.
•Do not make any modifications to the product.
•QuickJack is approved for indoor installation and use only. Outdoor installation is
prohibited. Your QuickJack is portable, however, so if you end up taking it outdoors, remember to
protect it from the weather (for example, from falling dirt, rain, sleet, and snow).
•Never exceed the rated capacity of the jack.
•Make sure all operators read and understand this Setup and Operation Manual. Keep the manual
near the device at all times.
•Do not use the product while tired or under the influence of drugs, alcohol, or medication.
•Make a visual inspection of the product before using it each time. Check for damage or missing
parts. Do not use the product if you find any of these issues. Instead, stop using it, then contact
QuickJack at quickjack.com/support or [e-mail].
•Make a thorough inspection of the product at least once a year. Replace any damaged or
severely worn electrical cables, Hydraulic Hoses, decals, or warning labels. Do not use the product
until damaged or worn items have been replaced.
•You must always wear OSHA-approved (publication 3151) personal protective equipment when
installing, using, maintaining, or repairing the QuickJack: leather gloves, steel-toed work boots, eye
protection, back belts, and hearing protection.
•Remove all jewelry while working with the product. Dangling jewelry can get caught in moving
parts; metal jewelry can conduct electricity. Avoid wearing loose-fitting clothing.

QuickJack™Portable Car Jack 7P/N 5900263 —Rev. B6 —September 2023
•While handling a Hydraulic Cylinder or a Hydraulic Hose, also wear gloves. In rare cases, a needle-
like stream of hydraulic fluid (even at low pressure) can penetrate fingers, hands, or arms; such a
puncture can feel like a bite, electric shock, or a prick. While it may seem like a minor issue, any
amount of Hydraulic Fluid injected into the human body is a serious issue. Anyone suffering such a
puncture wound should be immediately taken to a hospital emergency room to determine the
extent of the injury. Explain the circumstances of the injury to the attending physician, including
what kind of Hydraulic Fluid was involved. Do not assume a puncture wound that could have been
caused by Hydraulic Fluid is a minor issue; it could be life threatening.
•Floor surface must be dry, flat, and have a minimum compressive strength of 500 PSI. The Lift
must not sink into the ground or crack the surface under the weight of the Vehicle.
•Avoid using an extension cord; they can overheat. If you must use an extension cord, make sure it
is No. 14 AWG / 2.5mm2minimum.
•Exercise caution in locating the electrical cable and Hydraulic Hoses; do not drive over or step on.
•Clear the area if a Vehicle is in danger of falling off the jack.
•Make sure both Lock Bars are engaged before nearing an elevated Vehicle.
•As an added precaution, you must always use auxiliary safety stands under the Vehicle while
elevated on both QuickJack Frames.
Symbols
Following are the symbols used in this manual:
⚠DANGER Calls attention to an immediate hazard that will result in death or severe injury.
⚠WARNING Calls attention to a hazard or unsafe practice that could result in death or severe
personal injury.
⚠CAUTION Calls attention to a hazard or unsafe practice that could result in minor personal
injury, product, or property damage.
Tip Calls attention to information that can help you use your QuickJack better.
Liability Information
BendPak assumes no liability for damages resulting from:
•Use of the equipment for purposes other than those described in this manual.
•Modifications to the equipment without prior, written permission from BendPak.
•Injury or death caused by modifying, disabling, overriding, or removing safety features.
•Damage to the equipment from external influences.
•Incorrect operation of the equipment.

QuickJack™Portable Car Jack 8P/N 5900263 —Rev. B6 —September 2023
Components
The following image shows the main components of a QuickJack.
Not all components shown. Not drawn to scale.
QuickJack components include:
•Two QuickJack Frames. The Frames, working together, raise and lower Vehicles.
The two Frames are not interchangeable. The Lock Bars, described below, must be on the
outside when you orient the Frames.
•Eight rubber Lift Blocks. Four are medium height (2 inches) and four are tall (3 inches high).
The Lift Blocks can be placed in different locations in the Receiver Trays, allowing you to contact
the factory-recommended Lifting Points on a wide variety of Vehicles. Always use Lift Blocks; do
not raise a Vehicle on just the QuickJack Frames.
Note:You can stack one medium and one tall block together, but not more than that.
If you have a Vehicle with a unibody/pinch-weld frame, QuickJack recommends ordering optional
Pinch-Weld Blocks, available on the QuickJack website.If you have an SUV or truck, there
is an SUV and Light Truck Adapter available for these Vehicles, also on the QuickJack website.
If you are going to be raising Vehicles with very low ground clearance, low-profile Lift Blocks are
available as Accessories.

QuickJack™Portable Car Jack 9P/N 5900263 —Rev. B6 —September 2023
•One Power Unit (includes Pendant Control). Not shown. Provides power to the QuickJack
Frames. There are three Power Units available: 110 VAC, 220/240 VAC, CE-approved 220 VAC.
CE/UKCA approved Power Units part numbers 5585360 / 5585760 / 5585739.
•Parts Bag. Holds the components used during setup; includes the Hydraulic Fittings.
•Two Power Unit Quick-Connect Fittings. One end connects to the Long Hydraulic Hose,
while the other end connects to a Hydraulic Port on the Power Unit.
•Two Male Quick-Connect Fittings. One end connects to the Short Hydraulic Hose, and the
other end connects to the Long Hydraulic Hose.
•Four Female Quick-Connect Fittings. One goes on each end of the Long Hydraulic Hose.
Two per each Long Hydraulic Hose.
•Two Short Hydraulic Hoses. Connect one end to the Hydraulic Cylinder on each Frame and
on the other end to one of the Long Hydraulic Hoses. Note that the Short Hydraulic Hoses must
be routed under the bottom of the Frame, never over the Frame.
•Two Long Hydraulic Hoses. Connect one end to the Power Unit and on the other end to one
of the Short Hydraulic Hoses.
Tip To move your QuickJack components: disconnect the Long Hydraulic Hoses either
at the Power Unit or at the Short Hydraulic Hoses. This is easier than trying to move
the QuickJack with all components connected.
•Two Frame Positioning Handles. Used to easily move the QuickJack Frames, usually to
position the Frames under the Vehicle’s factory-recommended Lifting Points.
•Lock Bars. The two Lock Bars, one on each QuickJack Frame, hold the Frames in position when
they are raised.
Only leave the QuickJack either fully lowered or engaged on a Locking Position.
•Hydraulic Cylinder and Auxiliary Pneumatic Spring. Each QuickJack Frame has one
Hydraulic Cylinder and one Pneumatic Spring. The Hydraulic Cylinder receives Hydraulic Fluid from
the Power Unit, which is used to move the Frames up and down. The Pneumatic Spring acts like a
spring to assist in lowering the Frames.
•Wheels. The two Wheels on the non-sticker end of each QuickJack Frame allow you to easily
move the Frame to a different location. Note that the Wheels and the weight of the Frame can
leave marks on some floors, so be careful using them.
•Handles. On the sticker end of each QuickJack Frame is an opening that can be used as a
Handle when you are moving the Frame. To pick up a Frame by its Handle, with one hand raise the
Frame just off the ground under the large yellow sticker, then put the other hand in the Handle and
continue to raise the Frame.
⚠DANGER Pinch and crush hazard! Keep clear of the QuickJack mechanism as it lowers.
Be careful not to pinch or crush your fingers when lowering the Frame to the
ground.

QuickJack™ Portable Car Jack 10 P/N 5900263 — Rev. B6 —September 2023
Accessories
Note that the following accessories are not ALI-certified.
Crossbeam Adapter
The Crossbeam Adapter lets you contact the Lifting Points with uneven Frames/Lifting Points.
The Crossbeam Adapter components include: one Crossbeam, two Crossbeam Lift Pads, two
Crossbeam Bases, and two Round Lift Pads and Base Adapters. Visit the Accessories page of
the QuickJack website for more information.
SUV and Light Truck Adapter Kit
The optional SUV and Light Truck Adapter Kit increases the service capability of your QuickJack by
providing stackable Lift Blocks that mount inside the Receiver Trays; for 5000TL/TLX and 7000TL/TLX
models.
The Adapter Kit includes: four low-profile, round Contact Pads, four Bases that accommodate the
Contact Pads with Extenders, and four 3-inch Extenders. Visit the Accessories page of the
QuickJack website for more information.
Frame Extension Kit
The Frame Extension Kit is a pair of QuickJack frame extenders that increase the lift-point spread for
5000TL and 7000TL models by 6 inches, for a total lift point spread of 66 inches. They fit snugly
into your QuickJack with no setup required and can be easily taken off and put back on. Visit the
Accessories page of the QuickJack website for more information.
Motorcycle Lift Adapter Kit
The Motorcycle Lift Adapter Kit lets you add a platform on top of your QuickJack Frames, converting it
into a motorcycle lift. This product is not CE certified.
The Adapter Kit includes: a tread plate, heavy-duty tie-down rings, a support axle, a large clamp with
treaded-rubber padding, and an easy-to-use crank for wheel security. Visit the Accessories page
of the QuickJack website for more information.
Ranger RML-1100 Motorcycle Jack
The Ranger RML-1100 Motorcycle Jack is ideal for servicing motorcycles and ATVs up to
1,100 lbs. / 499 kg. It is the perfect accessory for the QuickJack Motorcycle Lift Adapter Kit. This
product is not CE certified. Visit the Accessories page of the QuickJack website for more
information.
JackPak
The portable JackPak lets you add air to the Pneumatic Springs on each QuickJack Frame. It also
includes additional features for roadside assistance and emergencies. Refer to jackpak.com for
more information.

QuickJack™Portable Car Jack 11 P/N 5900263 —Rev. B6 —September 2023
Specifications
Specifications are subject to change without notice.
Model 3500SLX 5000TL 7000TL
Lifting capacity 3,500 lbs. / 1,588 kg 5,000 lbs. / 2,268 kg 7,000 lbs. / 3,175 kg
ALowered height (frame only) 3" / 76 mm 3" / 76 mm 3.5" / 89 mm
BHeight, frame only *16" / 404 mm 20.25" / 512 mm 20.75" / 527 mm
CHeight, small blocks 17" / 431 mm 20.5" / 520 mm 21" / 533 mm
DHeight, tall blocks 18" / 457 mm 21.5" / 546 mm 21.75" / 552 mm
EHeight, stacked blocks 21" / 533 mm 24" / 610 mm 24.5" / 622 mm
FFrame width 10.5"/ 267 mm 11" / 279 mm 12.5" / 318 mm
GMax lifting point spread 50.5" / 1,283 mm 60" / 1,524 mm 60" / 1,524 mm
HMin lifting point spread 27" / 686 mm 37" / 940 mm 37" / 940 mm
IFrame length 62.5"/ 1,588 mm 70" / 1,778 mm 70.75" / 1,797mm
Individual frame weight 60 lbs. / 27 kg 78 lbs. / 35 kg 98 lbs. / 45kg
Power unit weight (no fluid) 50 lbs. / 23 kg 50 lbs. / 23 kg 50 lbs. / 23 kg
Power Unit PRV setting 2,400 psi 2,400 psi 2,400 psi
Maximum Operating Pressure 2,100 psi 2,100 psi 2,100 psi
Sound (when raising/lowering) <70 dBA <70 dBA <70 dBA
Maximum allowed wind speed <60 mph / <96.5 kph <60 mph / <96.5 kph <60 mph / <96.5 kph
Operating Temperature Range +32°F to +104°F (0°C to +40°C)
For power requirements see Connect the Power Unit to a Power Source.
*For reference purposes only; do not raise a Vehicle without Lift Blocks.
Height values may be .25 in / 7 mm different if measurement done with mechanism at full rise or on
top lock. Measurements may be up to 3 percent different based on amount of weight on lift, weight
distribution, and manufacturing tolerances.

QuickJack™Portable Car Jack 12 P/N 5900263 —Rev. B6 —September 2023
Specifications are subject to change without notice.
Model 6000ELX 5000TLX 7000TLX
Lifting capacity per pair 6,000 lbs. / 2,722 kg 5,000 lbs. / 2,268 kg 7,000 lbs. / 3,175 kg
ALowered height (frame only) 3.5" / 89 mm 3" / 76 mm 3.5" / 89 mm
BHeight, frame only *20.75" / 527 mm 20.25" / 512 mm 20.75" / 527 mm
CHeight, small blocks 21" / 533 mm 20.5" / 520 mm 21" / 533 mm
DHeight, tall blocks 21.75" / 552 mm 21.5" / 546 mm 21.75" / 552 mm
EHeight, stacked blocks 24.5" / 622 mm 24" / 610 mm 24.5" / 622 mm
FFrame width 12.5" / 318 mm 11" / 279mm 12.5" / 318 mm
GMax lifting point spread 76" / 1,930 mm 66" / 1,676 mm 66" / 1,676 mm
HMin Lifting point spread 53" / 1,346 mm 43" / 1,092 mm 43" / 1,092 mm
IFrame length 86.75" / 2,203 mm 76" / 1,930 mm 76" / 1,930 mm
Individual frame weight 112 lbs. / 51 kg 81.5 lbs. / 37kg 103lbs. / 47kg
Power unit weight (no fluid) 50 lbs. / 23 kg 50 lbs. / 23 kg 50 lbs. / 23 kg
Power Unit PRV setting 2,400 psi 2,400 psi 2,400 psi
Maximum Operating Pressure 2,100 psi 2,100 psi 2,100 psi
Sound (when raising/lowering) <70 dBA <70 dBA <70 dBA
Maximum allowed wind speed <60 mph / <96.5 kph <60 mph / <96.5 kph <60 mph / <96.5 kph
Operating Temperature Range +32°F to +104°F (0°C to +40°C)
For power requirements see Connect the Power Unit to a Power Source.
*For reference purposes only; do not raise a Vehicle without Lift Blocks.
Height values may be .25 in / 7 mm different if measurement done with mechanism at full rise or on
top lock. Measurements may be up to 3 percent different based on amount of weight on lift, weight
distribution, and manufacturing tolerances.

QuickJack™ Portable Car Jack 13 P/N 5900263 — Rev. B6 —September 2023
Frequently Asked Questions
Question: What kinds of Vehicles can I raise using my QuickJack?
Answer: A wide variety. The two main criteria are: is the curb weight of the Vehicle under the weight
capacity of your QuickJack and do the QuickJack’s Lift Blocks contact the Vehicle’s factory-
recommended Lifting Points? If the answers are yes, and for most Vehicles the answers are yes, then
you can raise the Vehicle.
Q: What if I want to raise a Vehicle that is slightly over the weight capacity of my QuickJack?
A: This is not an intended use of the product. We strongly recommend against trying to raise a Vehicle
that is heavier than the rated capacity of your QuickJack.
Q: Do the QuickJack Frames have a “left” and “right” orientation?
A: Yes. Put your QuickJack Frames next to each other with both Lock Bars on the outside and the
end with the QuickJack Sticker away from you.
Q: Can I use my QuickJack outdoors?
A: No. The QuickJack is approved for indoor installation and use only. Outdoor installation is
prohibited. Your QuickJack is portable, however, so if you end up taking it outdoors, remember to
protect it from the weather (for example, from falling dirt, rain, sleet, and snow).
Q: Can I drive on the QuickJack Frames?
A: A Vehicle can be above your QuickJack Frames (this is normal operation, in fact), but do not drive
a Vehicle on the QuickJack Frames or the Hydraulic Hoses; this damages them.
Q: What happens if I raise a Vehicle on my QuickJack but do not leave it in a locked position?
A: First, do not do this; it is a safety hazard. Second, because the QuickJack is not in a locked
position, the weight of the Vehicle will eventually lower it to the ground. Always follow this rule: if you
raise a Vehicle, engage it on a locking position or lower it back to the ground.
Q: How long can I leave a Vehicle raised on my QuickJack?
A: As long as you want, if it is engaged on a locking position. Once your QuickJack is
engaged on a locking position, gravity holds it in place; a loss of power or leaking Hydraulic Fluid
would not cause the QuickJack to lower.
Q: Anything else I should know about my QuickJack?
A: Two things. First, do not raise your QuickJack Frames to full height with no Vehicle
on it. QuickJack Frames are built to hold the weight of a Vehicle; they may get stuck at full rise if there
is no weight on them. Always raise your QuickJack Frames with a Vehicle on them. Second, do not try
to raise a Vehicle from a no net rise position (meaning if you lower the QuickJack Frames to the ground
while the Vehicle’s tires are removed). QuickJack needs some space to build up enough mechanical
force to raise a Vehicle.

QuickJack™ Portable Car Jack 14 P/N 5900263 — Rev. B6 —September 2023
Setup Checklist
Following are the steps needed to install a QuickJack. Perform them in the order shown.
☐1. Review the Setup Safety Rules.
☐2. Make sure you have the necessary Tools.
☐3. Unpack the Components that came with the QuickJack. Verify all components are present.
☐4. Read the About Thread Sealants section.
☐5. Assemble the Short Hydraulic Hoses.
☐6. Assemble the Long Hydraulic Hoses.
☐7. STOP! Allow 24-Hours for the thread sealant to cure before applying pressure
to the Hydraulic System.
☐8. Install the ORB Hydraulic Fitting on the Hydraulic Cylinders and Attach the Short Hose.
☐9. Select a Setup Site.
☐10. Verify there are adequate Clearances on all sides, above the vehicle and access to electrical
power.
☐11. Locate the Auxiliary Pneumatic Springs and the Hydraulic Cylinders.
☐12. Pressurize the Pneumatic Springs (50 psi / 3.4 bar max.)
☐13. Install the Hydraulic Fittings on the Power Unit.
☐14. Find a location for the Power Unit that allows an unobstructed view of both frames
while lifting.
☐15. Fill the Hydraulic Fluid Reservoir.
☐16. Check the Breather Valve.
☐17. Lubricate Quick-Connect Fittings.
☐18. Connect the Long Hydraulic Hoses between the Power Unit and the Short Hoses on each
Cylinder.
☐19. Connect the Power Unit to a Power Source.
☐20. Bleed the Hydraulic Cylinders.
☐21. Review the Final Checklist.
☐22. Test the QuickJack.
☐23. Leave the Manual for the owner/operator.

QuickJack™Portable Car Jack 15 P/N 5900263 —Rev. B6 —September 2023
Setup
This section describes how to set up your QuickJack.
⚠WARNING Use only the factory-supplied parts that came with your QuickJack. If
you use any attachments, accessories, or configuration modifying components that
are located in the load path and/or affect operation of the Lift, affect the Lift’s
electrical listing, or affect the intended Vehicle accommodation, and if they are not
certified for use with this Lift, then you void the warranty of your QuickJack as well
as compromising the safety of everyone who sets up or uses the Lift. If you are
missing parts, visit quickjack.com/support or contact QuickJack Technical
Support at [email protected], or call [phone] or
[phone].
Your QuickJack is supplied with setup instructions that meet the criteria set by the latest version of the
American National Standard “Automotive Lifts –Safety Requirements for Construction, Testing, and
Validation” ANSI/ALI ALCTV.
Setup Safety Rules
When setting up a QuickJack, your safety depends on proper training and thoughtful operation.
⚠WARNING Always use proper tools, such as a forklift or shop crane, to move heavy
components. Do not install this equipment without reading and understanding this
manual and the labels on the unit.
BendPak recommends referring to the ANSI/ALI ALIS Standard (Current Version) Safety Requirements
for Installation and Service for more information about safely setting up, using, and servicing your
QuickJack.
Always pay attention during setup.Use appropriate tools and equipment. Stay
clear of moving parts. Keep hands and fingers away from pinch points.
⚠WARNING You must always wear protective equipment during setup: leather
gloves, steel-toed work boots, eye protection, back belts, and hearing protection.
Tools
You need the following tools to set up your QuickJack:
• Metric and SAE hex key set
• Metric and SAE socket and ratchet sets
• Metric and SAE Combination wrench set
• 8 or 10-inch Adjustable wrench
• Screwdriver set
Tip Keep a rag handy during setup to clean Hydraulic Fluid spills or leaks.
At some point during setup, you will need to provide some air pressure (up to 50 psi, for the
Pneumatic Springs) and 2.1 quarts / 2 liters of Hydraulic Fluid.
Setup
1
Checklist
Setup
2
Checklist

QuickJack™Portable Car Jack 16 P/N 5900263 —Rev. B6 —September 2023
Unpacking
Open the boxes and arrange the QuickJack components where you will be setting them up.
The components needed to set up a QuickJack:
•Box 1. Includes the Left Frame.
•Box 2. Includes the Right Frame.
•Box 3. Includes the Power Unit (operating voltage chosen at time of purchase), Parts Bag,
Hydraulic Hoses, 4 Medium Lifting Blocks, and 4 Tall Lifting Blocks.
⚠WARNING Your two QuickJack Frames are similar, but they are not interchangeable. Always
line up the Frames parallel to each other as much as the Lifting Points will allow,
with the Lock Bars on the outside, as shown below.
⚠CAUTION Be sure to route the Short Hydraulic Hoses under the QuickJack Frames. If they
are routed over the QuickJack Frames, the QuickJack will not work correctly, and
the Hoses could be damaged.
Setup
3
Checklist

QuickJack™Portable Car Jack 17 P/N 5900263 —Rev. B6 —September 2023
About Thread Sealants
Your QuickJack comes with a bottle of Liquid Thread Sealant. Thread Sealant lubricates and fills the
gaps between the Fitting threads and leaves no residue that could contaminate the Hydraulic Fluid.
When Hydraulic Fittings are assembled and tightened properly, there should be no Hydraulic Fluid
leaks during equipment operation and no internal fluid contamination to disrupt the performance of
your QuickJack.
The same goes for Thread Seal Tape (like Teflon®Tape) or Liquid TPFE (Thread Sealer). Both are
approved Thread Sealants for QuickJack, and if used correctly, there should be no evidence of
Hydraulic Fluid leaks during equipment operation or Hydraulic Fluid contamination that could cause
equipment malfunction.
To apply Liquid Thread Sealant:
1. The ambient temperature when applying thread sealant should be between +46°F and +83°F /
+8°C and +28°C.
2. Verify the Fittings and connectors you are going to use are clean and dry.
If you are adding Thread Sealant to a Fitting or connector that has already been used with a
different sealant, use a wire brush to thoroughly remove the old sealant before adding more.
3. Apply a small amount of Thread Sealant to the first four threads (skipping the first thread) of the
Fitting.
⚠WARNING Make sure to wear the proper protective equipment when handling Thread Sealant.
You only need a small amount because the sealant spreads to the other threads as it is tightened
into place. If you apply too much, the excess liquid will be pushed out when the Fitting is tightened;
use a rag to wipe the excess.
4. Hand tighten the Fitting into the connector, then fully secure by making 2-3 full turns with the
appropriately sized wrench.
5. Allow a minimum of 24 hours curing time, before pressurizing the system.
Liquid Thread Sealant or Thread Seal Tape?
We have found that much QuickJack criticism or
warranty-related claims were caused by Hydraulic
Fluid contamination, with evidence of Thread Seal
Tape particles inside the Power Unit components
and the Reservoir.
To prevent this contamination, QuickJack is supplying a Liquid Thread Sealant in lieu of Thread Seal
Tape. If you want to use Thread Seal Tape over Liquid Thread Sealant, by all means, use what you are
most familiar with. However, you must carefully read and use the following instructions.
Important Notes:
•Thread Seal Tape must wrap Clockwise around the threads for it to work properly. Some
customers incorrectly wrap it backward, resulting in the Tape unwinding as the Fitting is being
tightened.
•Use only 2-3 turns of Thread Seal Tape. Never allow Thread Seal Tape to overlap the
end of the NPT Fitting threads; the overlapping Tape will separate during tightening and
Setup
4
Checklist

QuickJack™Portable Car Jack 18 P/N 5900263 —Rev. B6 —September 2023
enter the Hydraulic System and contaminate the Power Unit components and the Reservoir,
resulting in equipment malfunction.
•As a rule, Fittings with tapered threads should not be assembled to a specific torque, as the
amount of torque varies with thread quality, Port and Fitting materials, sealant used, and other
factors.
•When installing the QuickJack Hose Fittings, hand-tighten the Fittings together, then 2-3 turns after
using a Wrench. Once done, make sure to check all Hydraulic Hoses and Fitting
connections before raising a Vehicle.
Assemble the Short Hydraulic Hoses
To assemble the Short Hydraulic Hoses, you will need from Box 3:
•Two Short Hydraulic Hoses (5570233).
•Two Male Quick-Connect Fittings (5550032).
The following graphic shows the connections to make to the Short Hydraulic Hoses.
To set up and connect the Short Hydraulic Hoses:
1. Locate both Short Hydraulic Hoses and remove their protective caps.
Setup
5
Checklist

QuickJack™Portable Car Jack 19 P/N 5900263 —Rev. B6 —September 2023
2. Prepare the threaded fitting on the male NPT end of each Short Hydraulic Hose with Thread
Sealant.
3. Attach a Male Quick-Connect Fitting to the male threaded end of the Short Hydraulic Hose; make
2-3 full turns using a wrench to securely tighten in place.
⚠CAUTION Allow 24-hours for the thread sealant to cure before applying
pressure to hydraulic components.
Assemble the Long Hydraulic Hoses
To assemble the Long Hydraulic Hoses, you will need from Box 3:
•Two Long Hydraulic Hoses (5570216).
•Four Female Quick-Connect Fittings (5550031).
The following graphic shows the connections to make to the Long Hydraulic Hoses.
To assemble the Long Hydraulic Hoses:
1. Locate both Long Hydraulic Hoses and remove their protective caps.
2. Prepare the Threaded ends with the supplied Thread Sealant.
3. Connect the Female Quick-Connect Fittings to the male threaded connectors on both ends of both
Long Hydraulic Hoses.
To tighten, use one wrench to hold the Male connector in place and a second wrench on the
Female Quick-Connect Fitting to tighten it; make 2-3 full turns using a wrench to securely tighten in
place.
⚠CAUTION Before proceeding, allow 24-hours for the thread sealant to cure
before applying pressure to hydraulic components.
Setup
6
Checklist
Setup
7
Checklist

QuickJack™Portable Car Jack 20 P/N 5900263 —Rev. B6 —September 2023
Installing the ORB Elbow Fittings & Attaching the Short Hoses
You need to install one Hydraulic ORB Elbow Fitting (5550103) on each Hydraulic Cylinder.
Tip O-ring Boss (ORB) fittings benefit from 1-2 drops of hydraulic fluid applied to the O-ring
prior to installing the fitting in the Hydraulic Cylinder. The fluid serves to lubricate the
O-ring and helps prevent damage while tightening the fitting.
Tip Raising the QuickJack Frame and putting a Lift Block under it or manually raising the
Platform to a locking position can provide a little bit of extra room, making it easier to
secure the Hydraulic Elbow Fitting.
To install the Hydraulic Elbow Fittings:
1. Remove the shipping plug from the Hydraulic Cylinder Port using a 6 mm Hex Key.
2. Remove the ORB Hydraulic Elbow Fitting from the Parts Bag and apply a few drops of hydraulic oil
to the O-ring, then attach the ORB end into the Hydraulic Cylinder Port.
Important:Do not use Thread Sealant on either end of the Hydraulic Elbow Fitting.
The figure above details the hydraulic connections to make to the bottom of the Hydraulic Cylinder.
Not all components are shown.
3. Position the threaded fitting end as shown above; accessible but not pointed up.
You want the threaded fitting end accessible but not pointed up, as the Short Hydraulic Hose
would then angle up and could impact the underside of a Vehicle.
4. Turn the Nut until fully snug. The ORB end can be hand-tightened in place, then use a
wrench for an additional half turn to ensure it is snug. Do not use Thread Sealant on the
ORB fitting threads.
5. Perform the same process for the Hydraulic Cylinder on the other QuickJack Frame.
Setup
8
Checklist
