Service Manual
SERVICE PARTS & DIAGRAMS
This guide is a troubleshooting reference used for maintaining and
servicing your Bend Pak product. It provides comprehensive information
on identifying serviceable parts and components and assists in
troubleshooting problems and performing assembly /disassembly
procedures.
QUICKJACK
7000TL - 110V
PRODUCT SKU
5175640
DRAWING Nº
5175356
CATEGORY
QuickJack
REV
Version A
DATE
11.01.2022

DIMENSIONS ARE IN MM
☺
7
6
2
5
1
4
9
3
8
155.0
1872.0
425.0
ITEM NO
PART
NUMBER
DESCRIPTION QTY REV
1 5910009 7000TL PACKAGING BOTTOM BOX 1 C
2 5215921 7000TL FRAME ASSEMBLY, R.H. 1 E
3 5601108 QUICKJACK HANDLE WELDMENT 1 D
4 5930189
6000ELX/7000TL FRONT BOTTOM STYROFOAM
PACKAGING
1 C
5 5930188
6000ELX/7000TL REAR BOTTOM STYROFOAM
PACKAGING
1 B
6 5930191 6000ELX/7000TL TOP STYROFOAM PACKAGING 2 B
7 5910002
PACKAGING TOP BOX; 7000TL BOX 2-RIGHT,
ENGLISH-FRENCH
1 C
8 5940059 PLYWOOD INSERT, 1832 x 345 x 6mm 2 B
9 5930575 .50" PLASTIC STRAPPING 10 -
WHERE USED
7000TL
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
C
ADDED 5905756, UPDATED TITLE TO REFLECT
MARKETING, UPDATED BOM REVISION
12/23/2020 CA 01237
D UPDATED BOM REVISION 01/20/2021 TM 01265
OBSO REPLACED WITH 5216102 11/11/2021 TM 01362
E
UNOBSOLETE FOR PRODUCTION, REPLACED
LABELS WITH COLORS & GRAPHICS NOTE,
UPDATED BOM REVISION
03/14/2022 CA 01402
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
E
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5215930
7000TL VER E
PACKAGING, BOX 2
ENGLISH-FRENCH
04/21/2020
DO NOT SCALE DRAWING
1:15
SCALE:
THIRD ANGLE PROJECTION
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
