QuietKat 48V Hunter User manual
2
INTRODUCTION
Thank you for purchasing a QuietKat. This is a serious piece of machinery designed for use by adults in fully
controlled and safe environments. As the purchaser/owner of the machine, you are responsible with the task of
keeping the rider(s) safe at all times. If you defer this task to someone else, it is your responsibility to pass this
owner’s manual and all relevant information to whoever will take on this role, and ensure without question that
the rider has a full understanding of how to operate this machine.
Your QuietKat is driven by a powerful electric motor in which the torque is virtually instant. This means that
opening the throttle will propel the machine to the set speed very quickly. In a ‘panic’ situation riders tend to
open the throttle more. This could result in serious injury or death, as well as damage to the machine. Your
QuietKat has great capabilities and can grow with the skills of the rider to high levels, but it is imperative
that the responsible adult is in control during the entire learning process and gives full attention at all times.
QuietKat is designed for off-road use only and must not be used on public roads or sidewalks. Please check
and obey all local laws. QuietKat may only be ridden in safe areas where all laws are being followed and all
required permissions are given. Off Highway Vehicle (OHV) stickers may be required for some areas.
This Owner’s Manual provides important information regarding safety and maintenance of your QuietKat.
Please read through the entire manual prior to operating your machine. If at any time you have questions or
need assistance with the maintenance of your QuietKat please contact us using the contact information below
and throughout the Owner’s Manual.
Thanks again for purchasing a QuietKat and we hope you will enjoy the ride!
Jake Roach.
President - QuietKat
Contact Information
Service & Support - service@quietkat.com
General Info - info@quietkat.com
Sales - sales@quietkat.com
3
INDEX
From Out Of The Box To On The Road ............. 4-6
Warnings & Notices. ........................................... 7-11
Unit Specs. .......................................................... 12-17
Monthly Maintenance Schedule .........................18
Rear Suspension Lock Out ..................................19
Cycle Analyst Basics. ..........................................20
Removing & Changing Front Tire...................... 21
Rear Rack Assembly........................................... 22
Aligning Brake Pads. .......................................... 23
Appendixes .........................................................24
FAQ............................................................................... 25-27
QuietKat on YouTube............................................... 28
Warranty Information...........................................29-30
Battery Maintenance .............................................31-32
FROM OUT OF THE BOX TO ON THEROAD
4
Per QuietKat you’ll receive:
•
QuietKat (assembled)
•
Battery (one per unit)
•
Battery Charger (one per battery)
•
Keys (one set for battery box, one set for optional bag)
•
Owner’s Manual Packet
•
Optional Items
•
Rear Rack (Assembled)
•
Front Handlebar Bag
Prepping Your New QuietKat For Riding:
1.
Flip up Handle Bar in up-right position until it clicks in place *See Pic 1
2.
Push Quick Release Stem into the up-right position with Handle flush against Stem Tube *Pic2
Note: Should be VERY snug
3.
Twist plastic “Lock” clock-wise until Handle is in locking position *Pic 3
4.. Release Quick Release located mid-way up the Folding Stem, adjust Handlebars to desired height
and re-lock Quick Release *Pic 4
Note: Should be VERY snug
*Use grove in stem as a guide to align and straighten the handlebars *Pic 5
Pic 1 Pic 2 Pic 3
FROM OUT OF THE BOX TO ON THEROAD
5
Pic 4 Pic 5
5.
Unlock and open the Battery Box located in the center console *See Pic 6
Note: *Keys are located on the Center Tube Frame zip tied directly in front of Battery Box*
6.
Connect the 2 (two) RED Anderson Connectors *See Pic 7
7.
Close and lock the Battery Box
8.
Turn Handle Bar Igntion to the ON (I) position until Cycle Analyst lights up *See Pic 8
9.
To go forward have the Reverse Switch to the OFF (O) position. To go in reverse have the Reverse Switch
to the ON (I) position.
*If still no power, locate the Main Power Switch on the Motor Controller attached to the underside of
the battery box lid. Make sure the power switch is turned to the ON (I) position
Pic 6 Pic 7 Pic 8
FROM OUT OF THE BOX TO ON THEROAD
6
10.
Twist the throttle and you’re ready to ride *See Pic 9
Note: Should you need further information on riding your QuietKat refer to the “Riding The QuietKat”
video on YouTube. https://www.youtube.com/watch?v=Pelq8ALyZZ0
Pic 9
PRE-RIDE CHECKLIST
Check your wheels - Especially the front wheel with the hub motor. Spokes should be tight
and the wheel should not have play.
Check the frame - The dropouts and connection to the fork should be tight and secure. Look
for paint cracks, blisters, or bulges indicating damage.
Pump up your tires - under-inflated tires can cause serious damage if you bottom-out the rim
on a pothole or curb. But don’t over inflate - too much pressure makes the tires rock-hard.
Recommended PSI of front tires is 25 psi. Recommended PSI of rear tires is 22.5 psi.
Check cables, brakes, & wires - Working brakes are crucial, and the brake cables are an
important part of this. Lift the wheel off the g round and run the throttle, test the brakes and
make sure the wheel stops after applying brakes.
Double-check battery - Make sure it’s fully charged, securely fastened and the connections are
tight
Check components - Seat post, rack, seat, steam handlebars. Make sure nothing is bent of
loose.
Ensure bolts making sure they’re tight and secure. Be aware of any smells or noises and
keep a record of them.
7
WARNINGS & SAFETY INSTRUCTIONS
To ensure optimum performance from your QuietKat and to ensure safe operation, it is
important to fully understand the features of the machine. This manual contains important
information that every owner must fully understand prior to operation.
This Owner’s Manual uses the following symbols and terms to
call your attention to Warnings and Notices:
Meaning: This term calls attention to a Warning. A Warning indicates a potentially
hazardous situation which, if not avoided, could result in bodily injury or
death, in addition to property damage. Read the text accompanying
the Warning to be aware of the specific hazard.
Meaning: This term calls attention to a Notice. The text accompanying a
Notice provides helpful or other important related information.
Please read, understand, and follow all Warnings and Notices on your QuietKat and those
included in this manual. If you do not understand any of this important information
please contact the QuietKat Customer Care at 970-328-2399.
WARNING:
NOTICE:
8
WARNING: ADULT SUPERVISION REQUIRED
QuietKat is intended to be used by an operator 16 years or older. Adult supervision
is required for any operator who is under the age of 18. Never allow a child to alter
the settings or to ride without adult supervision. Instructing and practicing in a
controlled situation will allow the child to learn how to operate the machine safely
and under control. The child’s enjoyment will be greatly enhanced if they feel safe
during the initial learning process. Please follow the instructions contained in this
manual before operating the machine.
It is illegal and hazardous to use a QuietKat on streets and thoroughfares. Use on
streets exposes the rider to hazards from motorists and other vehicles and may lead to
accidents resulting in serious injury, death, and/ or property damage. Check local laws
and regulations to find out where and how you may use this product legally.
•
OPERATOR ONLY! NO PASSENGERS!
•
Long hair, loose clothing, or loose items worn by the rider must be covered to
prevent entanglement in moving parts of the machine
or surroundings while riding.
•
Do not exceed the weight limit. Heavier riders may significantly reduce
performance and/or render the vehicle unstable and/or over-tax the
brakes and other control devices. Exceeding the weight limit
may cause structural damage not covered by the warranty.
•
Do not touch any moving or hot parts.
•
Do not ride at night or under other low visibility conditions.
•
Do not immerse this vehicle in water.
•
Do not ride on steep or uneven surfaces.
•
Do not ride faster than conditions permit for safe operation.
•
The rider should be securely seated on the unit ready to ride
before turning on the vehicle.
WARNING: OFF-ROAD USE ONLY
WARNING: FOLLOW SAFE RIDING PRACTICES
NOTICE: SERVICE/WARRANTY
9
For all questions regarding your QuietKat service/warranty, please contact
QuietKat directly or contact your local retailer/distributor.
See retailer/distributor contact information on the QUIETKAT.COM web site.
Off-road riding presents many hazards such as loose dirt, obstacles, and other
difficult-to-see-and-avoid conditions. Wear approved helmet, gloves, wrist,
knee, elbow and eye protection. Failure to use appropriate safety equipment
greatly increases the risk of serious injury.
Failure to maintain this vehicle in proper operating condition can lead to an accident
resulting in injury, death, and/or property damage. If you have any questions
about the proper care and maintenance of this vehicle, consult your selling dealer/
distributor or contact QuietKat Customer Care at info@quietkat.com or 970-328-
2399. Before each ride make sure that all bolts and nuts are fastened securely, the
tires are properly inflated, and the throttle and brake controls are operating freely.
The QuietKat is designed to operate with the included 48-72 volts batteries only.
Use of any battery voltage higher than 72 volts will result in motor failure. QuietKat
considers such modifications and/or changes to its products to be a material
alteration of any such products, thereby voiding any warranties and/or guarantees
in their entirety and will not be responsible for any and/or all injuries, death and/or
other damage(s) caused by any such modifications.
WARNING: WEAR PROTECTIVE EQUIPMENT
WARNING: PROPER MAINTENANCE
OF THIS VEHICLE IS REQUIRED
WARNING: BATTERY SYSTEM
10
WARNING: UNPACKING AND ASSEMBLY
Failure to properly assemble and adjust your QuietKat prior to use may result in
an accident resulting in serious injury, death and/or property damage. If you are
uncertain about any aspect of the assembly and adjustment of your QuietKat,
seek help from a qualified mechanic or the QuietKat Customer Service Department.
There are no user serviceable elements incorporated into the motor, motor controller,
battery, battery charger, throttle, or wiring harness of your QuietKat. DO NOT
ATTEMPT TO DISASSEMBLE OR ADJUST ANY OF THESE COMPONENTS.
Doing so may cause extensive damage to these components, will void your
warranty, and may cause a hazardous condition including electrical shock.
If you cannot resolve a problem using this owners manual, contact your
QuietKat Customer Service Department for assistance.
NOTICE: VARIABLE FACTORS
Many factors affect speed and range capabilities. Terrain, average speed, rider
weight, tire pressures, wind, hills, number of batteries, and other variables
all have an impact on the performance and control of the unit
Failure to obey all of the warnings & instructions contained in this manual may
result in serious injury or death and permanent damage to your QuietKat.
Riding in reverse requires adequate knowledge and experience with your QuietKat.
Be careful and go slow, especially in reverse.
WARNING: DISASSEMBLING AND ADJUSTING
WARNING: OBEY ALL WARNINGS
WARNING: RIDING IN REVERSE
11
NOTICE : SAFETY RESPONSIBILITES
Please read, understand, and practice the following guidelines for safe operation of
your QuietKat.
•Supervision: Riders must be supervised by responsible adults at all times. The rider
should never be beyond eye and voice range. An adult must always assess and approve
the riding conditions and the QuietKat preparedness before the unit is ridden. Always
ensure the rider is cautious, maintaining complete control, and riding at a reasonable
speed. Ensure the terrain is suited to the skills of the rider and capabilities of the unit.
•Helmets & Safety Attire: There is no single factor that works better at reducing the
severity of injuries sustained in accidents more than a quality helmet. Please don’t
ever allow your QuietKat to be ridden without one. Riders should also wear suitable
riding gear (gloves, eye protection and boots). Shoe laces, loose clothing, or even
long hair could potentially get caught in wheels.
•One Rider Only: Your QuietKat was engineered to carry one rider and no (0)
passengers. Carrying a passenger would overload the machine and alter thehandling.
•Do not overload the Vehicle: QuietKat trikes are designed for riders under 300lbs.
Exceeding the weight limitations will adversely affect the handling of the machine, and
potentially cause damage not covered by the warranty.
•It’s the law; obey it: Obey all laws. QuietKat trikes are for OFF-ROAD USE
ONLY. QuietKat trikes cannot be used on public roads or sidewalks. The
purchaser, owner and/or riders of this machine are directly responsible to know
and obey all
local, state, and federal laws regarding the riding and use of this machine.
•Weather & Riding Conditions: Please be aware, that in wet conditions, distance to stop
may double or triple over the distance that it takes under dry conditions. Ride more slowly
and anticipate your stops by applying the brakes earlier.
•Night time: Do not ride your QuietKat after dark or in low light conditions.
•Maintenance: Proper maintenance will extend the life of your unit. Thereare
maintenance instructions here in this manual. Check the brakes and the tires
and the tightness of all those important fasteners before each and every ride.
Have your unit checked by a qualified bike shop mechanic at least once a year.
It’s a small investment in the well-being of the rider.
•Batteries: We have equipped your QuietKat with sealed Lithium-Ion battery. As
always, if you have any questions, please don’t hesitate to contact us at970-328-2399.
•Read This Manual Cover To Cover: There is a lot of important informationthat
you need to know. Do not guess how to adjust the machine, charge it or ride it.
We have recommendations that will instruct how to set-up, maintain,
and ride your QuietKat. Please read them thoroughly.
•Call us with questions or problems: We can be reached at the numbers listed on the
back cover of this manual. You can also get assistance from the QuietKatdealers.
Unit Specs - 48V Hunter
12
This KAT is powered by a 48V 20AH Lithium battery pack and charger. The machine is capable of carrying an
additional battery to cover more than 50 miles of range per charge, and produces more than five (5)horsepower,
which equates to over 5000+ watts. This model of QuietKat is recommended for up to a 225 pound rider/
weight load, and is engineered for off road travel. The HUNTER weighs about 120 pounds, is 32” wide and
63” long. Its high grade aluminum frame and quality craftsmanship contribute to its ability to withstand many
years of outdoor use. The HUNTER comes with a QK-TC65 motor *NEW, 18 FET digital controller *NEW,
advanced throttle *NEW, hydraulic disc brakes, digital display and meter.
•
48V 20AH Lithium Battery Pack
•
QK TC65 Motor
•
18 FET Controller
•
Range 20 to 25 Miles with 1 battery
•
Capable up to 50 miles with use of 2nd battery
•
Top Speed is 23 mph
•
Top Power is 5,000 watts (5 horsepower)
•
20” x 4” Knobby Front Tire
•
13” x 4” Knobby Rear Tires
•
Rubber Floor Mats
•
Reverse
QuietKat assembled dimensions: 63”L x 32”W
Minimum collapsed height: 32”
QuietKat assembled weight w/ battery (Hunter Model): 120 lbs.
Recommended load carry for the Hunter Model: Up to 225lbs, rider and gear.
13
Unit Specs - 48V HunterAP
This KAT is powered by a 48V 20AH Lithium battery pack and charger. The AP (all purpose) models include
the front handlebar bag, rear utility rack and rear mud guards. The machine is capable of carrying an additional
battery to cover more than 50 miles of range per charge, and produces more than five (5) horsepower, which
equates to over 5,000+ watts. This model of QuietKat is recommended for up to a 225 pound rider/weight load,
and is engineered for off road travel. The HUNTER AP weighs about 130 pounds, is 32” wide and 65” long.
It’s high grade aluminum frame and quality craftsmanship contribute to its ability to withstand many years of
outdoor use. The HUNTER AP comes with a QK-TC65 motor *NEW, 18 FET digital controller *NEW,
advanced throttle *NEW, hydraulic disc brakes, front mud fairing, front handlebar bag, weight supported rear
rack, rear mud guards, digital display and meter.
•
48V 20AH Lithium Battery Pack
•
QK TC65 Motor
•
18 FET Controller
•
Range 20 to 25 Miles with 1 battery
•
Capable up to 50 miles with use of 2nd battery
•
Top Speed is 23 mph
•
Top Power is 5,000 watts (5 horsepower)
•
20” x 4” Knobby Front Tire
•
13” x 4” Knobby Rear Tires
•
Weight Supporting Rear Utility Rack
•
Rear Mud Guards
•
Front Handle Bar Bag
•
Rubber Floor Mats
•
Reverse
QuietKat assembled dimensions: 65”L x 32”W
Minimum collapsed height: 32”
QuietKat assembled weight w/ battery (Hunter AP Model): 130 lbs.
Recommended load carry for the Hunter Model: Up to 225lbs, rider and gear.
14
Unit Specs - 60V Prowler
This KAT is powered by a 60V 20AH Lithium battery pack and charger. The machine is capable of carrying an
additional battery to cover more than 40 - 50 miles of range per charge, and produces more than six (6) horse-
power, which equates to over 6000+ watts. This model of QuietKat is recommended for up to a 275 pound
rider/weight load, and is engineered for off road travel. The PROWLER weighs about 125 pounds, is 32” wide
and 63” long. Its high grade aluminum frame and quality craftsmanship contribute to its ability to withstand
many years of outdoor use. The PROWLER comes with a QK-TC65 motor *NEW, 18 FET digital controller
*NEW, advanced throttle *NEW, hydraulic disc brakes, digital display and meter.
•
60V 20AH Lithium Battery Pack
•
QK TC65 Motor
•
18 FET Controller
•
Range 20 to 25 Miles with 1 battery
•
Capable up to 50 miles with use of 2nd battery
•
Top Speed is 27 mph
•
Top Power is 6,000 watts (6 horsepower)
•
20” x 4” Knobby Front Tire
•
13” x 4” Knobby Rear Tires
•
Rubber Floor Mats
•
Reverse
QuietKat assembled dimensions: 63”L x 32”W
Minimum collapsed height: 32”
QuietKat assembled weight w/ battery (Prowler Model): 125lbs.
Recommended load carry for the Prowler Model: Up to 275lbs, rider and gear.
15
Unit Specs - 60V ProwlerAP
This KAT is powered by a 60V 20AH Lithium battery pack and charger. The AP (all purpose) models include
the front handlebar bag, rear utility rack and rear mud guards. The machine is capable of carrying an additional
battery to cover more than 40-50 miles of range per charge, and produces more than six (6) horsepower, which
equates to over 6,000+ watts. This model of QuietKat is recommended for up to a 275 pound rider/weight load,
and is engineered for off road travel. The PROWLER AP weighs about 135 pounds, is 32” wide and 65” long.
It’s high grade aluminum frame and quality craftsmanship contribute to its ability to withstand many years of
outdoor use. The PROWLER AP comes with a QK-TC65 motor *NEW, 18 FET digital controller *NEW,
advanced throttle *NEW, hydraulic disc brakes, front mud fairing, front handlebar bag, weight supported rear
rack, rear mud guards, digital display and meter.
•
60V 20AH Lithium Battery Pack
•
QK TC65 Motor
•
18 FET Controller
•
Range 20 to 25 Miles with 1 battery
•
Capable up to 50 miles with use of 2nd battery
•
Top Speed is 27 mph
•
Top Power is 6,000 watts (6 horsepower)
•
20” x 4” Knobby Front Tire
•
13” x 4” Knobby Rear Tires
•
Weight Supporting Rear Utility Rack
•
Rear Mud Guards
•
Front Handle Bar Bag
•
Rubber Floor Mats
•
Reverse
QuietKat assembled dimensions: 65”L x 32”W
Minimum collapsed height: 32”
QuietKat assembled weight w/ battery (Prowler AP Model): 135lbs.
Recommended load carry for the Prowler Model: Up to 275lbs, rider and gear.
16
Unit Specs - 72V Rancher
This KAT is powered by a 72V 30AH Lithium battery pack and charger. The machine is capable of 30 -50
miles of range per charge and produces more than seven (7) horsepower, which equates to over 7000+ watts.
This model of QuietKat is recommended for up to a 325 pound rider/weight load, and is engineered for off road
travel. The RANCHER weighs about 135 pounds, is 32” wide and 63” long. Its high grade aluminum frame
and quality craftsmanship contribute to its ability to withstand many years of outdoor use. The RANCHER
comes with a QK-TC65 motor, 18 FET digital controller, advanced throttle *NEW, hydraulic disc brakes,
digital display and meter.
•
72V 30AH Lithium Battery Pack
•
QK TC65 Motor
•
18 FET Controller
•
Range 30 -50 Miles with 1 battery
•
Top Speed is 32 mph
•
Top Power is 7,000 watts (7 horsepower)
•
20” x 4” Knobby Front Tire
•
13” x 4” Knobby Rear Tires
•
Rubber Floor Mats
•
Reverse
QuietKat assembled dimensions: 63”L x 32”W
Minimum collapsed height: 32”
QuietKat assembled weight w/ battery (Rancher Model): 145lbs.
Recommended load carry for the Rancher Model: Up to 325lbs, rider and gear.
17
Unit Specs - 72V RancherAP
This KAT is powered by a 72V 30AH Lithium battery pack and charger. The AP (all purpose) models include
the front handlebar bag, rear utility rack and rear mud guards. The machine is capable of 30 -50 miles of range
per charge and produces more than seven (7) horsepower, which equates to over 7,000+ watts. This model of
QuietKat is recommended for up to a 325 pound rider/weight load, and is engineered for off road travel. The
RANCHER AP weighs about 135 pounds, is 32” wide and 65” long. It’s high grade aluminum frame and
quality craftsmanship contribute to its ability to withstand many years of outdoor use. The PROWLER AP
comes with a QK-TC65 motor, 18 FET digital controller, advanced throttle *NEW, hydraulic disc brakes, front
mud fairing, front handlebar bag, weight supported rear rack, rear mud guards, digital display and meter.
•
72V 30AH Lithium Battery Pack
•
QK TC65 Motor
•
18 FET Controller
•
Range 30 - 50 Miles with 1 battery
•
Top Speed is 32 mph
•
Top Power is 7,000 watts (7 horsepower)
•
20” x 4” Knobby Front Tire
•
13” x 4” Knobby Rear Tires
•
Weight Supporting Rear Utility Rack
•
Rear Mud Guards
•
Front Handle Bar Bag
•
Rubber Floor Mats
•
Reverse
QuietKat assembled dimensions: 65”L x 32”W
Minimum collapsed height: 32”
QuietKat assembled weight w/ battery (Rancher AP Model): 145 lbs.
Recommended load carry for the Rancher Model: Up to 325lbs, rider and gear.
MONTHLY MAINTENANCE SCHEDULE
18
•
Wash your unit thoroughly
•
Check tread wear on all tires. Use tire slime for preventative maintenance of your tires.
•
Observe any smells or noises that come from your QuietKat and record them.
•
Observe any rubbing of brake lines, wires, & cables. Organize and re zip-tie wires & cables as needed.
•
Tighten all bolts and screws on your QuietKat:
-
Axel Bolts
-
Brake Caliper Bolts (front & rear)
-
Fork Bolts
-
Handlebar Bolts
-
Headset Bolts
-
Rotor Bolts
•
Inflate tires to recommended PSI
-
Front Tire = 25 PSI
-
Rear Tire = 22.5 PSI
•
Center and align brake pads to rotors *See Page 23*
•
Check electrical connections making sure they are all secure. Use electrical tape to secure any
loose connections or worn insulation.
•
Straighten & tighten handlebars.
•
Discharge & re-charge battery *See Storage section of the Lithium-Ion Battery manual*
•
Spray brake cleaner on brake pads and brake rotors ensuring they are clean free of any debris.
19
REAR SUSPENSION LOCK-OUT
*Your unit is assembled and shipped with the Suspension in the Fully Locked Position
There are 3 (three) Lock-Out positions. Use a 9/16” socket to remove or install Rear Suspension
Bolts on the Swingarm to engage or disengage the following Lock-Out positions
1.
Fully Locked: All 3 (three) bolts are installed and fastened on the Swingarm *See Pic1
Note: Fully Locked position is most stable at slower speeds
2.
Medium Flex: 2 (two) outer bolts are removed, leaving 1 (one) middle bolt is installed
and fastened on the Swingarm. *See Pic 2
Note: Medium Flex position enables suspension to better contour in turns giving more control
3.
Full Lean: 0 (zero) bolts are installed and fastened on the Swingarm *See Pic 3
Note: Full Lean position is the most active setting allowing full articulation of the suspension
giving the rider additional control on rougher riding surfaces.
Pic 1 Pic 2 Pic 3
20
V3 CYCLE ANALYST BASICS
The below directions are intended for basic use only. For further directions on the V3 Cycle Analyst refer to the
link provided in the appendixes or call our customer service department at 970-328-6629
Main Navigation:
1.
While in the main screen, hold the left button until you see “Enter Setup”, then release the button and it will
say “Setup Spdometer” indicating the Speedometer Setup.
2.
Tap the left or right buttons to move through the menus
3.
When you get to the menu you want, hold the right button until it say “OK”, and then release, now you are in
that menu.
4.
Tap the right button to move through the entries until you get to the one you want to change.
5.
Hold the right button until the number is blinking. You will be able to change it one digit at a time usingthe
left button to lower the number and the right to raise it.
6.
Hold the right button after you get the correct number, and it will move right to the next digit and repeatthe
process with each digit until it stops blinking.
7.
Tap the right button to continue through the entries until you get back to the original menu screen where you
can navigate to the next menu.
8.
When finished, tap the right button until it says leaving setup. From here you can drive again.
9.
If you turn off the Cycle Analyst during this process, turn it back on and you will return to the originalscreen
with all the changes saved.
To change the modes from Economy, Off Road, and Unlimited:
1.
Press and hold the left button and then tap the right to move through them.
Low Medium High
2.
Release the buttons when you are finished.
This manual suits for next models
5
Table of contents
