Tenor GateKeeper+
• Standalone GateKeeper
• H.323 v3 industry standard compliant
• Advanced call routing and administration
• Up to 800 simultaneous VoIP calls per GateKeeper
• Scalable distributed architecture
• Support for external Remote Management Session Server*
Quintum’s Tenor®GateKeeper+ gives enterprises
and service providers a standalone H.323 compliant
gatekeeper for VoIP networks. The Tenor
GateKeeper+ provides the call routing and
administration for all of the H.323 VoIP endpoints in
your network, including gateways, IP phones and PC
clients.
The Quintum Tenor GateKeeper+ provides the
unique ability to dynamically self configure the VoIP
routing database. It will also support static routing to
provide connectivity to endpoints that are not part of
your VoIP network. The advanced call routing
enables the Tenor GateKeeper+ to provide load
balancing among multiple gateways. The Tenor
GateKeeper+ also provides for authentication/
authorization of all calls in your VoIP network.
With its unique call processing intelligence, the
Tenor GateKeeper+ makes deployment of any size
VoIP network easy and risk-free.
More intelligence means easier network configuration
The Tenor GateKeeper+ dynamically self configures your
VoIP network by collecting routing information during
endpoint registration. The routing database is automati-
cally constructed and shared among all the gatekeepers
in the VoIP network. New endpoints are automatically
added and configured into the network.
More intelligence means greater security
The Tenor GateKeeper+ provides authorization and
authentication for all calls on your VoIP network. This
provides protection against unauthorized calls and
insures proper endpoint identification.
More intelligence means greater connectivity
The Tenor GateKeeper+ supports Location Requests
(LRQs) for gatekeeper to gatekeeper communications.
This allows simple communication among multiple VoIP
networks.
More intelligence means greater scalability
The Tenor GateKeeper+ is software upgradeable up to
800 calls. Multiple Tenor GateKeepers will share routing
information, combining to create a larger distributed
gatekeeper system. The Tenor GateKeeper+ also
supports LRQs, allowing the creation of a tiered network
of gatekeepers.
A more intelligent way to support call management of VoIP network
* Available for an additional cost

GENERAL SPECIFICATIONS
Dimensions (1U High Chassis)
W 17 3/8" x H 1 3/4" x D 10 3/4"
W 44.5cm x H 4.5cm x D 27.6cm
• Maximum weight: 8.25 lbs (3.75kg)
• AC Power: 100-240 Volts AC, 50/60 Hz, 35 watts
• Operating temperature: 40° - 104° F (5° - 40° C)
• Operating humidity: 20% - 80% non-condensing
• EMC: FCC Part 15, EN55022, EN55024
EN61000-2-3, EN61000-3-3
• Safety: UL60950, EN60950, AS/NZS60950
TECHNICAL SPECIFICATIONS
GateKeeper+ Specifications
• H.323 v3 Support: RAS, Fast Start
• Each GateKeeper+ is software upgradeable to a
maximum of 800 VoIP calls
• RADIUS Compliant
• Endpoint access list screening
• Load balancing of VoIP calls among multiple gateways
• Static routing configuration
• LRQ - LCF command for gatekeeper to gatekeeper peering
• Radius/AAA Authentication procedures
IP Network Specifications
• LAN Interface: 10/100 Mbps Ethernet autosensing
• Standard RJ-45 interface (IEEE 802.3) for
10Base-T or 100Base-TX connection
Configuration / Management
• Remote Management
• SNMP v2 Agent
• Command Line Interface
• Remote Telnet Access
• Serial Console Port: RS-232/DB-9
Tenor GateKeeper+
Rev. 5
