Quoizel MC1426TWT User manual

Part Description Quantity
A1 pc.
1 pc.
1 pc.
1 pc.
B
C
D
Finial
Stem with Knurled Nut
Package Contents
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone [phone]
Fax [phone]
www.quoizel.com
Tools Required: None
Estimated Assembly Time: 15-20 minutes
Preparation: Identify and inspect all parts before beginning installation. Check package
content list and diagrams below to be sure all parts are present. If any parts are missing
or damaged, do not attempt to assemble, install, or operate the fixture. Contact customer
service for replacement parts.
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Assembly Instruction Sheet #IS-MC1426TWT
For Style MC1426TWT
A
B
C
D
1of3
Bulb Recommended: (2) Medium Base 60W Maximum
Shade
Base
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2012QuoizelInc.
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
June2012

MC1426TWT
FINISH: WESTERN BRONZE
PART NUMBER
(2) 60W Medium
Base Bulbs
(Not Supplied) NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION REQ.
NO.
1
2of3
16”
7.5”
21.5”
7” Dia.
2S1409MC
11426TWTMC
MICA SHADE 15.5"D X 8"H
BASE WESTERN BRONZE MC1426TWT
1
1
1
2

3of3
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2012 QuoizelInc.
Figure 1
Assembly Instruction Sheet #IS-MC1426TWT
For Style MC1426TWT
STEP 1 Install the Stem-
A. Screw the beaded end of the Stem with Knurled Nut (A)
into the Coupling on the top center of the Base (B).
Hand tighten until snug.
Base
Harp
Coupling
June2012
STEP 2 -Attach Shade
A. Adjust the Knurled Nut on the top end of the Stem (A) to
proper location for the Shade (D) and the Finial (C).
B. Place the Shade (D) onto the top end of the Stem (A).
Secure by threading the Finial (C) onto the Stem (A).
Hand tighten until snug.
Finial
Figure 2
Stem
Shade
STEP 3 Install Bulb-
A. This fixture uses standard bulb with medium base .
Maximum 60 watts.
B. Insert bulb and screw snugly into place.
Figure 3
Bulb
Socket
Knurled Nut
