Quoizel Q1072TPN Mounting instructions

Part Description Quantity
A1pc.
1pc.
B
Socket Assembly
Package Contents
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone [phone]
Fax [phone]
www.quoizel.com
ToolsRequired:None
EstimatedAssemblyTime:15-20minutes
Preparation:Identify andinspect allparts beforebeginning installation.Check package
contentlist anddiagrams belowto besure allparts arepresent. Ifany partsare missing
ordamaged, donot attemptto assemble,install, oroperate thefixture. Contactcustomer
servicefor replacementparts.
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Assembly Instruction Sheet #IS-Q1072TPN
For Style Q1072TPN
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
1of4
BulbRecommended: (1) MediumBase (3-Way) 100WMaximum
Base
A
B
1pc.
CFinial
Shade
C
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
D
1pc.
D
Harp
E
1pc.
E
2012 QuoizelInc. April2012

Q1072TPN
1
2of4
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REQ.
1
1
NO. REPLACEMENT PART DESCRIPTION
SHADE CREAM 10.5” X 15” X 8”
BASE Q1072TPN
PART NUMBER
S1335CR
11072TPNQ
FINISH: PALLADIAN BRONZE
(1) 100W Medium
Base (3-Way) Bulb
(Not Supplied)
2
2
1
15” Dia.
10”
14”
26”
7” Dia.

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2012 QuoizelInc.
3of4
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
STEP 1 Install Socket Assembly-
A. Thread the end of the Socket Assembly (A) onto the top
end of the Base (B). Hand tighten until snug.
Figure 1
Base
Socket
Assembly
STEP 2 Install the Harp-
A. Install the Harp (E) by pressing the ends of the Harp (E)
into the Harp Clips as shown.
Base
Harp
Figure 2
Harp Clip
Assembly Instruction Sheet #IS-Q1072TPN
For Style Q1072TPN
April2012

STEP 4 Install Bulb-
A. This fixture uses standard bulb (3-Way) with medium
screw base. Maximum 100 watts.
B. Insert bulb and screw snugly into place.
Your fixture is now assembled and ready to use. Enjoy!
Figure 4
Bulb
Socket
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2012 QuoizelInc.
4of4
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
STEP 3 Install Shade-
A. Place the Shade (D) over the top end of the Harp (E)
and secure with the Finial (C). Hand tighten until snug.
Figure 3
Harp
Shade
Assembly Instruction Sheet #IS-Q1072TPN
For Style Q1072TPN
Finial
April2012
