Quoizel RNL9008WT Mounting instructions

1of2
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
2017 QuoizelInc.
Assembly Instruction Sheet #IS-RNL9008WT
For Style RNL9008WT
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-800-645-3184
or visit us on-line at www.quoizel.com
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly
recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal.
Pleasegoto forproductcleaningtips.Gotothe selection.
(1)A21MediumBasebulb150WMaximumor
(1)MediumBaseVintageBulbisrecommendedbutnotsupplied.
20-30minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtoensureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
www.quoizel.com Care + Maintenance
LightSource:
EstimatedAssembly Time:
Preparation:
ToolsRequired: Flathead screwdriver,Phillips screwdriver,pliers, wire cutters, wire strippers, electrical tape, safety glasses.
Package Contents
AMounting Screw
x3
Fixture Body
x1
Glass
Panel
x4
B
C
STEP 1 Remove Cage from Fixture Body-
A. Unlock lock screws on the bottom of the Fixture Body (C) and
remove the cage from the .Fixture Body (C)
C
Cage
Figure 1
Lock Screw
Socket Assembly
STEP 2 Install Glass Panels-
A. Insert the Glass Panel (B) into the
cage. Attach the top edge of the
Glass Panel (B) to the slot in the top
of the cage. Fold tabs in the bottom
edge of the cage to secure Glass
Panels (B).
Figure 2
Slot
Cage
Tab
B
STEP 3 Install the Bulb and Cage-
A. Insert the bulb onto the socket and
screw snugly into place.
B. Place the cage back onto the Fixture
Body (C) and secure with previously
removed lock screws. Hand tighten
until snug.
Socket
Lock Screw
Vintage Bulb
(recommended
but not Supplied)
Figure 3
ReleasedDate:2017-10-17
Cage
2of2
2017 QuoizelInc. ReleasedDate:2017-10-17
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-800-645-3184
or visit us on-line at www.quoizel.com
STEP 4 -Mark the Location for the 3 Mounting Holes
A. Place the light fixture onto the post and mark the location of the 3
mounting holes on the fixture fitter onto the post with the marking
pen.
Fixture
Fitter Marking Pen
Mounting
Hole
STEP 5 M C
EM H
-arking the enter of
ach ounting ole
A. Remove the light fixture. Using
the center punch and hammer
marking the center of each
mounting hole location that is
marked with the marking pen.
Center Punch
Hammer
Marking
Post
Lighting
Post
Post
STEP 6 Drill Holes-
A. Using the 1/16” bit and drill, drill a pilot hole completely through the
post at each (3) locations marked in step 5 above.
1/16” bit and drill
STEP 7 - Wire Connections
A. Use standard wire connectors (not included) to make all wire
connections. Twist connectors until wires are tightly joined together.
Wrap each connection with approved electrical tape and carefully
stuff all the connected wires into the Outlet Box.
White wire
from outlet box White wire
from fixture
Black wire from
outlet box (or Red)
Black wire
from fixture
Bare, or Green
Ground wire
from outlet box
Ground wire
from fixture
Post
Post
STEP 8 Attach the fixture to
the Post Mount
-
A. Place the fixture on the post
lining up the mounting holes
on the fixture fitter with the
holes on the post. Use the
Mounting Screws (A) to
attach the fixture to the post.
Your fixture is now
assembled and ready
to use. Enjoy!
Post
Hole
Fixture
Fitter
Mounting
Hole
Post
Lighting
A
Fixture
Fitter
Figure 4
Figure 5
Figure 6
Figure 7
Figure 8
RNL9008WT
FINISH: WESTERN BRONZE
20”
NOTE: ALL DIMENSIONS ARE ROUNDED UP
TO THE NEAREST 1/4"
8”
8”
