Quoizel MHE9010K Mounting instructions

Part Description Quantity
A
1pc.
3 pcs.
B
Package Contents
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
A
B
Mounting Screw
Assembly Instruction Sheet #IS-MHE9010
For Styles MHE9010K and MHE9010VN
1of5
Fixture Loop
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
C
D
1pc.
2 pcs.
C
D
Fixture Hood
Lock Screw
E
F
4 pcs.
1pc.
E
F
Panel
Fixture Body
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Pleasegoto forproductcleaningtips.Gotothe selection.
(3)CandelabraBase60WMaximum
20-30minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagrams
belowtobesureallpartsarepresent.Ifanypartsaremissingordamaged,donotattempttoassemble,install,or
operatethefixture.Contactcustomerserviceforreplacementparts.
www.quoizel.com Care+Maintenance
LightSource:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:Flatheadscrewdriver, Phillips screwdriver,pliers,wirecutters,wirestrippers,electricaltape,safety
glasses.
2015 QuoizelInc. June2015

MHE9010K
2of5
FINISH: MYSTIC BLACK
9” Sq.
10” Sq.
21.5”
9.5”
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION REQ.
NO.
1
(3)60W Candelabra
base bulbs
(not Supplied)
G3780PA CLEAR SEEDY GLASS PANEL 4
1
MHE9010VN
FINISH: VENETO

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
3of5
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
Figure 1
STEP 1 Attach panel to Cage-
A. Insert Panels (E) into the Slot inside of the Cage then
fold the Tabs in the top of the Cage to secure the Panels
(E).
Cage
Tab
Panel
Slot
Bulb
Figure 2
STEP 2 -Install Bulb
A. standard bulb with a candelabra screw
base 0
This fixture uses
. Maximum 6 watts.
B. Insert bulb and screw snugly into place. Socket
STEP 3 -Attach Cage with Panels to Fixture
Body
A. Align the Hole on the Fixture Hood with the Mounting Hole
on the Cage, secure by thread Lock Screw (D) into the
Mounting Hole. Tighten until sung.
Figure 3
Cage
Lock
Screw
Fixture Hood
Hole
Mounting
Hole
Assembly Instruction Sheet #IS-MHE9010
For Styles MHE9010K and MHE9010VN
2015 QuoizelInc. June2015

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
4of5
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
Fixture Loop
STEP 4 -Install Fixture Loop
A. Thread Fixture Loop (B) onto the Fixture Hood (C), hand
tighten until sung. Fixture Hood
STEP 5 Drill Pilot Holes on Post-
A. Carefully fit the Post Fitter over the end of the Post (not
supplied), making sure the Post Fitter is fully seated.
B. Mark the drill point for the (3) Mounting Screws, using
(3) Mounting Holes as reference. After marking hole
locations, remove fixture from post and drill 1/16” pilot
holes for screws.
Post
Figure 5
Post Fitter
Figure 4
Assembly Instruction Sheet #IS-MHE9010
For Styles MHE9010K and MHE9010VN
2015 QuoizelInc. June2015

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
5of5
Figure 7
STEP 6 Make Wire Connections-
A. Use standard wire connectors to make all wire
connections. (Connectors are not included with fixture.)
Strip and prepare wire ends according to instructions
supplied with connectors.
B. Connect White Supply Wire from the Post to White Wire
from fixture.
C. Connect Black (or Red) Supply Wire from the Post to
Black Wire from fixture.
D. Connect Ground Wire from the Post to Ground Wire from
fixture.
E. Twist connectors until wires are tightly joined together.
F. Wrap each connection with approved electrical tape and
carefully stuff all the connected wires into the Post.
Figure 6
White wire from supply White wire from fixture
Black wire from supply
(or Red)
Black wire from fixture
Ground wire from supply Ground wire from fixture
Post
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
STEP 7 -Attach Fixture Body to Post
A. Coat the top 1” of the Post with Clear Silicone Caulk
(not supplied) and position the Post Fitter onto the Post.
Be sure to seat it completely, aligning the holes in the
Fitter with the 1/16” Pilot Holes drilled into the Post.
B. Secure the Fixture to Post with (3) Mounting Screws.
Your lamp fixture is now assembled and ready to use.
Enjoy!
Mounting Screw
Post
Figure 8
Post Fitter
Mounting
Hole
Assembly Instruction Sheet #IS-MHE9010
For Styles MHE9010K and MHE9010VN
2015 QuoizelInc. June2015
