Quoizel Style CHI8411IB User manual

Part Description Quantity
A Crossbar 1pc.
1pc.
2 pcs.
2 pcs.
2 pcs.
2 pcs.
B
C
D
E
F
Hex Nut
Lock Washer
Package Contents
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone [phone]
Fax [phone]
www.quoizel.com
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
A
B
C
D
F
E
Mounting Ball
Mounting Screw
Assembly Instruction Sheet #IS-CHI8411IB
For Style CHI8411IB
1of6
ToolsRequired:Flatheadscrewdriver, Phillips screwdriver,pliers,wirecutters,wire
strippers,electricaltape,safetyglasses.
EstimatedAssemblyTime:20-30 minutes
BulbRecommended: (1)MediumBase100WMaximum
Preparation:Identifyandinspectallpartsbeforebeginninginstallation.Checkpackage
contentlistanddiagramsbelowtobesureallpartsarepresent.Ifanypartsaremissing
ordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomer
serviceforreplacementparts.
Fixture Body
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
May2013

2of6
CHI8411IB
1
2
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION REQ.
NO.
GND
2.4mm
13Ga
QUOIZEL R
(1)100W A19
Medium Base Bulb
(Not Supplied)
FINISH: IMPERIAL BRONZE
9465KIT
G2861SH
MTGHARDWAREIMPRBRNZ4"D
SHADE CLEAR WATER GLASS
1
1
11" Dia.
4.5" 13.5"
22.5"
8"
2
1

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
3of6
Assembly Instruction Sheet #IS-CHI8411IB
For Style CHI8411IB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
May2013
Figure 1
STEP 1 Take Cage with Shade apart-
A. Take the Cage with Shade apart by unscrewing Socket
Head Cap Screw. Socket Head
Cap Screw
Cage with
Shade
Fixture Body
STEP 2 Remove PE Foam and Sponge-
A. Take out the Glass by unscrewing Lock Screws and
Tabs. Remove PE Foams and Sponges around the
Glass.
B. Place the Glass back into the Cage and secure with the
Tabs and the Lock Screws..
C. Unscrew the Socket Head Cap Screws from the top
edge of the Cage.
Lock
Screw
PE Foam
(Remove)
Sponge
Figure 2
Tab
Sponge
(Remove)
Glass
Socket Head
Cap Screw
Cage
PE Foam

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
4of6
Assembly Instruction Sheet #IS-CHI8411IB
For Style CHI8411IB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
May2013
STEP 3 Install Cage back Fixture Body-
A. Place the Cage with Shade over the Hood on Fixture
Body (I). Secure by threading the Socket Head Cap
Screws into the mounting holes on the top edge of the
Cage. Hand tighten until snug.
Figure 3
Socket Head
Cap Screw
Cage with
Shade
Fixture Body
Hood
Figure 4
STEP 5 -Attach Crossbar to Outlet Box
A. Attach the Crossbar (A) to Outlet Box and secure by
threading Outlet Box Screws (not supplied) into the
Mounting Holes on the Outlet Box. Tighten until snug.
Figure 5
STEP 4 -Attach Mounting Screws, Lock
Washers and Hex Nuts to Crossbar
A. Line up a set of holes on the Crossbar (A) and Holes on
the backplate of the Fixture Body (F).
B. Thread Mounting Screws (B) into the holes on the
Crossbar (A), pass Lock Washers (C) and thread Hex
Nut (D) onto the Mounting Screws (B). Hand tighten
until snug.
Fixture
Body
Mounting
Screw
Crossbar
Lock Washer
Hex Nut
Crossbar
Outlet Box
Outlet Box
Screw
Mounting Hole

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
5of6
Assembly Instruction Sheet #IS-CHI8411IB
For Style CHI8411IB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
May2013
STEP 6 Make Wire Connections-
A. Use standard wire connectors to make all wire
connections. (Connectors are not included with fixture.)
Strip and prepare wire ends according to instructions
supplied with connectors.
B. Connect White Supply Wire from the Outlet Box to White
Wire from fixture.
C. Connect Black (or Red) Supply Wire from the Outlet Box
to Black Wire from fixture.
D. Connect Ground Wire from the Outlet Box to Ground
Wire from fixture.
E. Twist connectors until wires are tightly joined together.
F. Wrap each connection with approved electrical tape and
carefully stuff all the connected wires into the Outlet Box. Figure 6
White wire from supply White wire from fixture
Black wire from supply
(or Red)
Black wire from fixture
Ground wire from supply Ground wire from fixture
STEP 7 -Attach Fixture Body to Mounting
Screw
A. Place the backplate of the Fixture Body (F) over the
Mounting Screws (B) and secure with Mounting Balls
(E). Hand tighten until snug.
Mounting
Screw
Mounting Ball
Backplate
Figure 8
Figure 7

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
6of6
Assembly Instruction Sheet #IS-CHI8411IB
For Style CHI8411IB
May2013
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
STEP 9 Apply Silicone Sealer to Mounting
Balls
-
A. To prevent moisture from entering the wire
compartment, apply a small amount of silicone sealer
(not included) to the threaded side of the mounting
balls (E) and then install them onto the mounting
screws (B). Wipe off excess caulk.
STEP 10 Apply Silicone Sealer to Backplate-
A. Make sure exterior wall surface and fixture backplate
are free of dirt before applying caulk. Using exterior
grade caulk, start on one side of fixture backplate and
follow contour, where the fixture backplate meets the
exterior wall surface upward. Proceed to caulk over top
of backplate and down other side. Do not caulk bottom
of fixture backplate to ensure proper moisture
drainage.
Your lamp wall fixture is now assembled and ready to
use. Enjoy!
Figure 9
Mounting Ball
Exterior
Grade Caulk
Outdoor Fixture
Backplate
Exterior Wall
Surface
STEP 8 -Install Bulb
A. standard bulb with a medium screw
base 0
This fixture uses
. Maximum 10 watts.
B. Insert bulb and screw snugly into place.
Socket
Bulb
Figure 10
Figure 11
