RAB A19-9-E26-9RGB-SS-2P-2/LCB User manual

A19-9-E26-9RGB-SS-2P-2/LCB
Need help? Tech help line: [phone] Email: [email protected] Website: www.rablighting.com
Copyright © 2023 RAB Lighting All Rights Reserved Note: Specifications are subject to change at any time without notice
Page 1 of 4
UPC: 192552025652
Color: White Weight: 0.8 lbs
Project: Type:
Prepared By: Date:
Driver Info
Type N/A
120V N/A
208V N/A
240V N/A
277V N/A
Input Watts 9W
LED Info
Watts 9W
Color Temp Tunable White
2200K - 6500K
Color Accuracy 90 CRI
L70 Lifespan 25,000 Hours
Lumens 800 lm
Efficacy 100
Technical Specifications
Performance
Product Type:
RGBW Starter Kit
Description :
Starter Kit is the ideal introduction to Lightcloud
Blue. Quick to install and easy to setup in minutes.
No Gateway or Hub required.
The Kit includes:
(2) RGBW A19 lamps (A19-9-E26-9RGB-SS)
(1) Remote (LCBLUEREMOTE/W)
(1) Nano (NANO/LCB)
Wattage Equivalency:
60W Incandescent
Input Wattage:
8W (per lamp)
Lumens (Nominal):
800lm (per lamp)
Efficacy:
100lm/W (per lamp)
L70 Lifespan:
25,000-Hour LED lifespan based on IES LM-70 results
(lamps only)
Lightcloud
Lightcloud Blue:
Lightcloud Blue is a Bluetooth mesh wireless lighting
control system that allows you to control RAB's
various compatible devices. With RAB's patent-
pending Rapid Provisioning technology, devices can
be quickly and easily commissioned for residential
and large commercial applications using the
Lightcloud Blue mobile app. Each device in a system
can communicate with any other device, eliminating
the need for a Gateway or Hub and maximizing the
control system's reach.
DLC system - N1XMLOEATBA
Learn more at www.lightcloud.com
Gateway Required:
No
Communication Protocol:
Bluetooth Mesh
SmartShift:
SmartShift is the most advanced - yet easiest to use -
circadian lighting system, which syncs white color
tuning with the local sunrise and sunset.
Range:
Up to 60 feet between standard building materials.
Up to 200 feet clear line of sight.
Wi-Fi Connection (GHz):
The Nano must be connected to a 2.4 GHz Wi-Fi
network. The Nano and the mobile device that it is
pairing with must be on the same Wi-Fi network.
Max # of Devices to Control:
LCBLUEREMOTE/W
Wireless Remote can control up to 3 Areas (up to 600
devices)
NANO/LCB
Nano can manage up to 16 Areas or 600 devices

A19-9-E26-9RGB-SS-2P-2/LCB
Need help? Tech help line: [phone] Email: [email protected] Website: www.rablighting.com
Copyright © 2023 RAB Lighting All Rights Reserved Note: Specifications are subject to change at any time without notice
Page 2 of 4
Technical Specifications (continued)
Factory Reset:
Method 1: Delete from App (all devices)
Open the app and access the device settings for the
paired device. Be sure that the device is online and
select 'Delete'. The device will flash on/off 5 times
and return to full brightness.
Method 2a: Manual (lamps only)
Power the device off and on 5x consecutively. Do
not allow less than 4s to elapse from switching off to
on. Do not allow more than 2s to elapse from
switching on to off. The device will flash 3x, then
reset to 100% brightness at default CCT.
Method 2b Manual: (Remote)
Press and hold "On/Off" button and "Function 1" (..)
buttons at the same time for 5 seconds until you see
a slow flashing red light at the top left corner on the
face of the Remote.
Method 2c Manual: (Nano)
Press and hold the center button on the Nano for 10
seconds. A flashing red light will appear to indicate
the Nano has been reset and then revert to a
flashing blue light indicating the Nano is ready to
pair to the App.
Method 3: Rapid Reset Tool (lamps only)
The Rapid Reset process must be done by a
professional electrician qualified by RAB. Reach out
to your RAB sales manager to request a Rapid Reset
Tool. The tool simply needs to be placed directly on
the small Lightcloud Blue logo on the device for 2s
or until the lamp/luminaire flashes 3x, then resets to
100% brightness at the default CCT.
Electrical
Power Factor:
≥0.9
Dimmable:
Yes via the Lightcloud Blue mobile app and devices.
This lamp will not operate properly when connected
to a standard (incandescent) dimmer or dimming
control.
Input Voltage:
RGBW A19 Lamp: 120V
Nano: 3V
Remote: 3V
Operating Frequency:
RGBW A19 Lamp: 60Hz
Nano: DC
Remote: DC
Input Current @ 120V (mA):
75mA (lamps only)
Operating Temperature:
-4°F to 113°F (-20°C to 45°C)
Flicker:
<30%
Battery Type:
Remote: CR2032 (included)
Battery Lifespan:
2-years
LED Characteristics
Color Temperature:
Tunable White 2700K - 6500K 16+ million colors
(lamps only)
Color Accuracy (CRI):
>90 CRI
R9 Value:
>0
Color Consistency:
<4-step MacAdam Ellipse binning to achieve
consistent fixture-to-fixture color
Construction
Mounting:
Nano: Plugs into any compatible USB Type A port
Remote: Includes backplate, faceplate and mounting
screws to replace a single gang wall box or to be
installed on any flat surface.
Base Type:
RGBW A19 Lamp: E26
Nano: USB Type A
Finish:
White
Shape:
RGBW lamps: A19
Nano: Rectangular Cube
Remote: Rectangle
Enclosure Material:
RGBW A19 Lamps: Plastic
Nano: Plastic
Remote: Plastic
Lens Finish:
Frosted
Compliance
Listings:
UL Listed
Environment:
Suitable for use in dry and damp environments
T20 Compliant:
Can be used to conform with the requirements of
California Title 20
California Title 24 JA8 Compliant:
No
FCC:
Complies with Part 15B of the FCC Rules
Technical Specifications (continued)
Other
Warranty:
RAB warrants that our LED products will be free from
defects in materials and workmanship for a period of
three (3) years from the date of delivery to the end
user, including coverage of light output, color
stability, driver performance and fixture finish. RAB's
warranty is subject to all terms and conditions found
at rablighting.com/warranty.

A19-9-E26-9RGB-SS-2P-2/LCB
Need help? Tech help line: [phone] Email: [email protected] Website: www.rablighting.com
Copyright © 2023 RAB Lighting All Rights Reserved Note: Specifications are subject to change at any time without notice
Page 3 of 4
Note:
All values are typical (tolerance +/- 10%)
Buy American Act Compliance:
RAB values USA manufacturing! Upon request, RAB
may be able to manufacture this product to be
compliant with the Buy American Act (BAA). Please
contact customer service to request a quote for the
product to be made BAA compliant.
Case and Pallet Dimensions
QTY LENGTH (in) WIDTH (in) HEIGHT (in)
CASE 6 20 8.74 7.95
PALLET 270 48 40 43.31
Dimension
Features
Replacement for legacy incandescent and halogen lamps
Perfect introduction to Lightcloud Blue
Direct Connect to the Lightcloud Blue mobile app via Bluetooth, no Gateway or
Hub required
Use mobile device to configure features for On/Off Control, Dim Level, Color
Temperature, Schedules, Scenes, SmartShift and more
Choose between 16+ million colors to fit any mood
Tunable White 2200 - 6500K with smooth transition between color
temperatures
Enable SmartShift circadian lighting to get back your body back in sync
Ordering Matrix
Family Wattage Base Type CRI/Color Temp SmartShift Kit
A19 – 9 – E26 – 9RGB – SS – 2P–2/LCB
9 = 9W E26 = Edison Base 9RGB = 90 CRI, Color Tuning 16+ million
colors Tunable White 2200K-6500K
SS = SmartShift 2P–2/LCB = A19, Nano, Remote
