RabbitCore RCM3000
C-Programmable Module with Ethernet
Getting Started Manual
019–0109 • 050131–E

RabbitCore RCM3000
Z-World, Inc.
2900 Spafford Street
Davis, California 95616-6800
USA
Telephone: [phone]
Fax: [phone]
www.zworld.com
Rabbit Semiconductor
2932 Spafford Street
Davis, California 95616-6800
USA
Telephone: [phone]
Fax: [phone]
www.rabbitsemiconductor.com
RabbitCore RCM3000 Getting Started Manual
Part Number 019-0109 • 050131–E• Printed in U.S.A.
©2002–2005 Z-World Inc. • All rights reserved.
Z-World reserves the right tomake changes and
improvements to its products without providing notice.
Trademarks
Rabbit and Rabbit 3000 are registered trademarks of Rabbit Semiconductor.
Z-World is a registered trademark of Z-World Inc.
RabbitCore is a trademark of Rabbit Semiconductor.
Dynamic C is a registered trademark of Z-World Inc.

Getting Started
Table of Contents
Chapter 1. Introduction & Overview 1
1.1 Rabbit 3000 Microprocessor................................................................................................................ 1
1.2 RCM3000 RabbitCore Modules .......................................................................................................... 2
1.2.1 Physical & Electrical Specifications ........................................................................................... 3
1.3 Development Software......................................................................................................................... 4
1.4 How to Use This Manual ..................................................................................................................... 4
1.4.1 Additional Product Information .................................................................................................. 4
1.4.2 Additional Reference Information .............................................................................................. 5
1.4.3 Using Online Documentation ...................................................................................................... 5
Chapter 2. Hardware Setup 7
2.1 Development Kit Contents................................................................................................................... 7
2.2 Prototyping Board................................................................................................................................ 8
2.2.1 Prototyping Board Features ......................................................................................................... 9
2.3 Development Hardware Connections ................................................................................................ 11
2.3.1 Attach Module to Prototyping Board ........................................................................................ 11
2.3.2 Connect Programming Cable .................................................................................................... 12
2.3.3 Connect Power .......................................................................................................................... 13
2.4 Run a Sample Program ...................................................................................................................... 14
2.4.1 Troubleshooting ........................................................................................................................ 14
2.5 Where Do I Go From Here?............................................................................................................... 15
2.5.1 Technical Support ..................................................................................................................... 15
Chapter 3. Software Installation & Overview 17
3.1 An Overview of Dynamic C .............................................................................................................. 17
3.2 Installing Dynamic C ......................................................................................................................... 18
3.3 Sample Programs ............................................................................................................................... 19
3.3.1 Serial Communication ............................................................................................................... 20
3.3.2 Other Sample Programs ............................................................................................................ 22
3.4 Upgrading Dynamic C....................................................................................................................... 22
3.4.1 Add-On Modules ....................................................................................................................... 22

RabbitCore RCM3000
Chapter 4. Using the TCP/IP Features 23
4.1 TCP/IP Connections........................................................................................................................... 23
4.2 TCP/IP Primer on IP Addresses.........................................................................................................25
4.3 IP Addresses Explained...................................................................................................................... 27
4.4 How IP Addresses are Used............................................................................................................... 28
4.5 Dynamically Assigned Internet Addresses ........................................................................................ 29
4.6 Placing Your Device on the Network ................................................................................................ 30
4.7 Running TCP/IP Sample Programs....................................................................................................31
4.8 How to Set IP Addresses in the Sample Programs.............................................................................32
4.9 How to Set Up Your Computer’s IP Address for Direct Connect.....................................................33
4.10 Run the PINGME.C Sample Program..............................................................................................34
4.11 Running More Sample Programs With Direct Connect................................................................... 34
4.12 Where Do I Go From Here?............................................................................................................. 35
Notice to Users 37
Index 39
Schematics 41

Getting Started 1
1. INTRODUCTION & OVERVIEW
The Rabbit 3000®is a modern 8-bit microprocessor that is the
central element of a complete and fully supported embedded
design system that includes development tools, software libraries,
core modules, sample designs, a parts store, and readily available
expert, human support.
This Development Kit has the essentials that you need to design
your own microprocessor-based system, and includes a complete
Dynamic C®software development system. This Development
Kit contains a powerful RabbitCore™ module (the RCM3010)
and Prototyping Board that will allow you to evaluate the Rabbit
3000 and to prototype circuits that interface to a Rabbit 3000
microprocessor. You will also be able to write and test software
for the RCM3000 series RabbitCore modules, including TCP/IP
applications.
1.1 Rabbit 3000 Microprocessor
The Rabbit 3000 microprocessor shares its instruction set and conceptual design with the
successful Rabbit 2000. The instruction set is based on the Z80/Z180, but has been
adapted to be C-friendly and to allow a megabyte of code space. Rabbit processors are fast
with compact code.
The Rabbit 3000 has an extensive array of on-chip peripherals including 6 serial ports, 56
parallel I/O pins, motion control interfaces, a time/date clock, glueless memory and I/O
interfacing, a slave interface, and in-circuit programming. Low-EMI features including a
clock spectrum spreader eliminate schedule-wrecking EMI problems.
Software development support is based on Z-World’s Dynamic C, and includes extensive
libraries for Internet connectivity.
Refer to the Rabbit 3000 Microprocessor User’s Manual for complete information on the
Rabbit 3000 microprocessor and complete specifications.

2RabbitCore RCM3000
1.2 RCM3000 RabbitCore Modules
Throughout this manual, the term RCM3000 refers to the complete series of RCM3000
RabbitCore modules unless other production models are referred to specifically.
The RCM3000 RabbitCore modules are designed for use on a customer-supplied mother-
board that supplies power and interfaces to real-world I/O devices. Their two 34-pin con-
nection headers provide 52 parallel user I/O lines, shared with five serial ports, along with
control lines. A sixth serial port and one additional I/O line are available on the program-
ming header.
A fully enabled slave port permits glueless master-slave interface with another Rabbit-
based system. The slave port may also be used with non-Rabbit systems, although addi-
tional logic may be required.
The RCM3000 is equipped with a 10/100-compatible Ethernet port with a 10Base-T inter-
face, 256K–512K flash memory and 128K–512K static RAM.
There are two production models in the RCM3000 series. If the standard models do not
serve your needs, other variations can be specified and ordered in production quantities.
Contact your Z-World®or Rabbit Semiconductor sales representative for details.
Table 1 below highlights the differences between the two models in the RCM3000 family.
NOTE: The RCM3010 is the RabbitCore module supplied with the Development Kit.
In addition, there is an RCM3100 series of RabbitCore modules that omits the RCM3000
series’ Ethernet connectivity, but offer a much smaller footprint, which is about one-half
that of the RCM3000 series.
The RabbitCore modules can be programed locally, remotely, or via a network using
appropriate interface hardware.
Table 1. RCM3000 Versions
Feature RCM3000 RCM3010
Microprocessor Rabbit 3000 running at 29.4 MHz
Flash Memory 512K 256K
Static RAM 512K 128K
Serial Ports
6 shared high-speed, CMOS-compatible ports:
6 are configurable as asynchronous serial ports;
4 are configurable as clocked serial ports (SPI);
2 are configurable as SDLC/HDLC serial ports;
1 asynchronous clocked serial port is dedicated
for programming

Getting Started 3
1.2.1 Physical & Electrical Specifications
Table 2 lists the basic specifications for the RCM3000.
NOTE: For complete product specifications, see Appendix A in the RabbitCore
RCM3000 User’s Manual.
The RCM3000 modules have two 34-pin headers to which cables can be connected, or
which can be plugged into matching sockets on a production device. The pinouts for these
connectors are shown in Figure 1 below.
Figure 1. RCM3000 Connector Pinout
Table 2. RCM3000 Specifications
Specification Data
Power Supply 3.15 – 3.45 V DC (145 mA at 29.5 MHz clock speed)
Size 1.85" x 2.65"” x 0.86" (47 mm × 67 mm × 22 mm)
Environmental 0°C to 70°C, 5–95% humidity, noncondensing
Note: These pinouts are as seen on
the Bottom Side of the module.
STATUS
PA6
PA4
PA2
PA0
PF2
PF0
PC1
PC3
PC5
PC7
PG1
PG3
PD5
PD3
PD7
n.c.
GND
PA7
PA5
PA3
PA1
PF3
PF1
PC0
PC2
PC4
PC6
PG0
PG2
PD4
PD2
PD6
n.c.
J1
/RES
PB2
PB4
PB6
PF4
PF6
PE7
PE5
PE3
PE0
PG6
PG4
/IORD
SMOD1
VRAM
+3.3V
n.c.
PB0
PB3
PB5
PB7
PF5
PF7
PE6
PE4
PE1
PG7
PG5
/IOWR
SMOD0
/RESET IN
VBAT EXT
GND
GND
J2
n.c. = not connected

4RabbitCore RCM3000
1.3 Development Software
The RCM3000 module uses the Dynamic C development environment for rapid creation
and debugging of runtime applications. Dynamic C provides a complete development
environment with integrated editor, compiler and source-level debugger. It interfaces
directly with the target system, eliminating the need for complex and unreliable in-circuit
emulators.
Dynamic C must be installed on a Windows workstation with at least one free serial USB
or COM port for communication with the target system.
NOTE: An RS-232/USB converter is required if you intend to use a USB port on your
computer. Z-World and Rabbit Semiconductor offer a suitable converter—more infor-
mation is available at www.rabbitsemiconductor.com, or you may telephone your
Z-World/Rabbit Semiconductor sales representative or authorized distributor.
See Chapter 3., “Software Installation & Overview.” for complete information on install-
ing Dynamic C.
NOTE: The RCM3000 module requires Dynamic C v7.25 or later for development. A
compatible version is included on the Development Kit CD-ROM.
1.4 How to Use This Manual
This Getting Started manual is intended to give users a quick but solid start with the
RCM3000 module. It does not contain detailed information on the module hardware capa-
bilities, the Dynamic C development environment, or the TCP/IP software support for the
integrated Ethernet port. Most users will want more detailed information on some or all of
these topics in order to put the RCM3000 module to effective use.
1.4.1 Additional Product Information
Detailed information about the RCM3000 will be found in the RabbitCore RCM3000
User’s Manual, provided on the accompanying CD-ROM in both HTML and Adobe PDF
format.
Some advanced users may choose to skip the rest of this introductory manual and proceed
directly with the detailed hardware and software information in the User’s Manual.
TIP: We recommend that anyone not thoroughly familiar with Z-World controllers at
least read through the rest of this manual to gain the necessary familiarity to make use
of the more advanced information.

Getting Started 5
1.4.2 Additional Reference Information
In addition to the product-specific information contained in the RabbitCore RCM3000
User’s Manual, several higher level reference manuals are provided in HTML and PDF
form on the accompanying CD-ROM. Advanced users will find these references valuable
in developing systems based on the RCM3000 module:
•Dynamic C User’s Manual
•Dynamic C Function Reference Manual
•An Introduction to TCP/IP
•Dynamic C TCP/IP User’s Manual
•Rabbit 3000 Microprocessor User’s Manual
1.4.3 Using Online Documentation
We provide the bulk of our user and reference documentation in two electronic formats,
HTML and Adobe PDF. We do this for several reasons.
We believe that providing all users with our complete library of product and reference
manuals is a useful convenience. However, printed manuals are expensive to print, stock
and ship. Rather than include and charge for manuals that every user may not want, or pro-
vide only product-specific manuals, we choose to provide our complete documentation
and reference library in electronic form with every development kit and with our Dynamic
C development environment.
NOTE: The most current version of Adobe Acrobat Reader can always be downloaded
from Adobe’s web site at http://www.adobe.com.
We recommend that you use version 4.0 or later.
Providing this documentation in electronic form saves an enormous amount of paper by
not printing copies of manuals that users don’t need.
Finding Online Documents
The online documentation is installed along with Dynamic C, and an icon for the docu-
mentation menu is placed on the workstation’s desktop. Double-click this icon to reach the
menu. If the icon is missing, create a new desktop icon that points to default.htm in the
docs folder, found in the Dynamic C installation folder.
The latest versions of all documents are always available for free, unregistered download
from our web sites as well.

6RabbitCore RCM3000
Printing Electronic Manuals
We recognize that many users prefer printed manuals for some uses. Users can easily print
all or parts of those manuals provided in electronic form. The following guidelines may be
helpful:
•Print from the Adobe PDF versions of the files, not the HTML versions.
•If your printer supports duplex printing, print pages double-sided.
•If you do not have a suitable printer or do not want to print the manual yourself, most
retail copy shops (e.g. Kinkos, AlphaGraphics, etc.) will print the manual from the PDF
file and bind it for a reasonable charge—about what we would have to charge for a
printed and bound manual.
