Racelogic Performance Box Touch V2 User manual

03 Screen Layout – Performance Box Touch V2
As the name suggests, you can control Performance Box Touch by using its capacitive touch screen.
Generally, the different areas of the screen contain the following:
• Top of the screen – indicative status information
• Centre of the screen – mode and settings information (navigate by pressing the forward and back arrows or by
swiping left or right)
• Bottom of the screen – function buttons
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/Performance_Box_Touch/Performance_Box_Touch_V2/
User_Guide_%E2%80%93_Performance_Box_Touch_V2/03_Screen_Layout_%E2%80%93_Performance_Box_Touch_V2
1

LEDs
The Performance Box Touch has 4 LEDs above the display. These can flash in different colours and different frequency
patterns depending on the process being performed. You can learn more about the behaviour of the LEDs on
Performance Box Touch here.
Logging Status
The red Record Icon will show when the unit is logging
data to the SD card.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/Performance_Box_Touch/Performance_Box_Touch_V2/
User_Guide_%E2%80%93_Performance_Box_Touch_V2/03_Screen_Layout_%E2%80%93_Performance_Box_Touch_V2
2

If the icon appears white after you have initiated logging,
it means that the unit is primed for logging and is in the
process of synchronising the internal real-time clock
(RTC) to GPS time. The logging will not start until
this synchronisation process is complete.
IMPORTANT
Do not remove the SD card when the Record Icon is red. You may lose data or damage the SD card if you
remove it while the unit is logging.
SD Status
The SD Card Icon displays the status of the recording
media. When an SD card has been inserted and has
free space, the icon will be green.By tapping on the
icon when it is green, you can manually start or stop the
data logging and override the Configured Logging
Strategy.
If the unit cannot detect an SD card or the media is full
or corrupted, the icon will be red.
Satellite Status
The Satellite Icon illustrates whether the unit has a valid
satellite lock.
When a lock is acquired, this icon will be solid green.
If there is no satellite lock, the icon will flash red.
Display Mode
This header shows which Display Mode is currently selected.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/Performance_Box_Touch/Performance_Box_Touch_V2/
User_Guide_%E2%80%93_Performance_Box_Touch_V2/03_Screen_Layout_%E2%80%93_Performance_Box_Touch_V2
3

Battery Status
If you are using the separate battery to power Performance Box Touch, the Battery status icon is there to keep you
informed of the charge currently available in the battery. You can read more about the battery status here.
Mode Data
This area will contain information that relates to the currently selected Display Mode.
Settings Button
The Settings Button will open a Settings area, which
contains menus for Display Mode settings,
General settings, Diagnostic Settings and Time
settings.
The Display Mode settings shown on the Settings
screen depend on which mode has been selected. You
can find information about the settings for each mode in
the specific mode areas.
Screenshot Button
By pressing the Screenshot Button you can save a full
image of what is currently shown on the screen. This
screenshot will be saved to the inserted SD card as a
1.5 MB bitmap image, orientated at 90° to the original
screen image and with the prefix 'screenshot'.
The LEDs will illuminate yellow in sequence from left to
right to display the progress of writing to the SD
card. When the screen capture is
complete, Performance Box Touch will emit an audible
confirmation notification. If the screenshot could not be
saved, for example, no SD card is inserted or the card is
full, the SD Card Icon at the top of the screen will flash
3 times and Performance Box Touch will emit an audible
error notification.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/Performance_Box_Touch/Performance_Box_Touch_V2/
User_Guide_%E2%80%93_Performance_Box_Touch_V2/03_Screen_Layout_%E2%80%93_Performance_Box_Touch_V2
4

IMPORTANT
NEVER remove the SD card while a screenshot is
captured and saved as it could cause the unit to
crash!
Results Button
You can view the test results history by
selecting the Results button at the bottom of the
current test screen.
These test results will be displayed until you choose a
new test type or you press the Reset Button.
Mode Button
The Mode Button lets you choose between the 4
Display Modes available.
Reset Button
Depending on which screen you are on, the Reset
Button will reset mode results and/or history. When
pressed, the LEDs will briefly flash green twice and the
unit will emit an audible confirmation notification. If you
press the Reset button while in Lap Timing Mode, you
will see a cancel timeout screen giving you the
opportunity to cancel the reset within 5 seconds by
pressing anywhere on the screen.
Forward/Back Arrow Buttons
You can use the
Forward and Back arrow buttons to
navigate through the Display
Mode and Settings screens.
Alternatively, you can also swipe left
or right on the screen when these
buttons are visible.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/Performance_Box_Touch/Performance_Box_Touch_V2/
User_Guide_%E2%80%93_Performance_Box_Touch_V2/03_Screen_Layout_%E2%80%93_Performance_Box_Touch_V2
5

Exit Button
You can use the Exit button to return to the previous
menu or page.
