Rachio 8ZULW Specification sheet

SMART SPRINKLER CONTROLLER
GENERATION 2
Let’s get started.

What’s in the box.
Faceplate Generation 2
4 Screws with Anchors Power Adapter

What you’ll need.
The Rachio Smart Sprinkler Controller, Generation 2, is designed for
indoor installation. If outdoor installation is required, you’ll need our
weather-resistant enclosure. Learn more at rachio.com/outdoors.
Wi-Fi Access
(2.4 GHz only)
Phillips
Screwdriver
Hammer
(Drywall Installs)
Drill and Drill Bit
(Drywall Installs)
Smartphone
or Tablet
Need some help?

Need some help?
Check out our Help Center.
support.rachio.com
Give us a call.
1 [phone]
Not sure what to do with your old controller?
We’ll recycle it for free! Visit rachio.com/recycle.

Out with the old!
Test your old system to ensure everything works
properly. Photograph the wiring inside your existing
controller to reference during installation. Remove
your old controller from the wall.
STEP 1
Need some help?
Test
Sprinklers
Photograph
Wiring
Remove
Controller

Mark screw locations.
Use the Mounting Template at the end of this guide
to mark where you want to install your Generation 2.
For Drywall Installation:
Drill holes at marked locations for the anchors. Use
a 3/16 inch bit to drill through the drywall, then use
a hammer to gently tap each anchor into place.
STEP 2

In with the new!
Remove the faceplate of the Generation 2. Mount
your new controller by screwing it onto the wall
using the provided screws.
STEP 3

Mounting Template
Ensure the lower holes are level, and use a
pencil to mark the center of each hole.
Make sure your wires have enough
slack to reach the drill icon above!

Tear here to detach the mounting template.

While referencing the photo of your previous
wiring, insert the wires into the appropriate
terminals. Things not matching up? Visit
rachio.com/wiring for tips on advanced wiring.
Connect your wires.
STEP 4
BEST PRACTICE: WIRING
Insert screwdriver tip into the
rectangular wire terminal.
Press in until the rectangular terminal
is flush with the gray terminal bar or
you feel a click.
Insert your wire, then release the
rectangular terminal.
Tug the wire to make sure it is secure!

Sensor Wires (Optional)
You are able to connect up to
two rain or flow sensors to your
controller using the “S1,” “S2,”
and “SC” and “SP” terminals.
For more information, visit
rachio.com/sensors.
Master Valve
Not all systems have a master
valve. Master valve wires are often
labeled “M,” “MV,” or “Pump.” If
you have a master valve, wire it
into the “M” terminal.
MS1-2 SC SP
Common Wires
Common wires are often labeled
“C” or “Com.” You can insert them
into any of the “C” terminals.
Zone Wires
Zone wires correspond to your
landscape’s zones. Insert them
into the numbered terminals.
1-16C
Insert the power connector into the power jack located at
the bottom right of the wiring bay. Then, plug the power
adapter into the outlet.

Create an account.
Find the Rachio app on the Apple App Store, on
Google Play, or by visiting rachio.com/download.
Once the app is installed, create your account.
STEP 5

Connect to Wi-Fi.
Open the Rachio app and
select “Add Controller.”
The app will guide you
through this process.
Once your controller is
online, all four blue lights
will be solid. You can now
replace the faceplate.
Don’t forget!
If you run into any issues during
connection, the question mark support
icon in the app can provide contextual
help throughout the process!
STEP 6

Complete setup on the app.
Now that the controller is online, use the Rachio
app to customize your zones and create a schedule.
STEP 7

Congrats, you did it!
Want to learn more about what you can do with
your new Generation 2?
Control your
system remotely.
Integrate your
smart home.
Optimize your
waterings.
Visit rachio.com/more.

Manual Controls
Zones can be run directly from the controller, if needed.
Use the up and down arrows to highlight a zone on the
controller’s lights, then press the select button.
SELECTED ZONE SELECT BUTTON
