Rademacher Fernotron programming centre User manual

Operating Instructions

Fernotron Programming Centre

Article No. 2411

VBD 369-3-GB (06.09)

iDear customer ...

These instructions...

CE mark and conformity

...describe how to operate the Fernotron Programming Centre.

Please read this manual completely and observe all of the safety instructions

before commencing with the installation.

Please keep this manual in a safe place and include them with the device in the

event it changes owners.

The warranty becomes null and void in the event of any damage or loss caused

by failure to observe these operating and safety instructions. We accept no liability

for any consequential losses or damage resulting from non-observance of these

instructions.

This Fernotron Programming Centre (art. no. 2411) complies with the requirements

of the applicable European and national directives. The conformity has been certified

and the corresponding declarations and documentation are on file at the

manufacturer’s premises.

In purchasing this Fernotron Programming Centre you have decided on a quality

product manufactured by Rademacher. We would like to thank you for your

confidence.

The new Fernotron Programming Centre has been designed in an effort to combine

the latest technology with the greatest possible ease of operation. You will find that

the simple menu navigation makes operation appreciably easier. With

uncompromising quality requirements and after an extensive test series phase, we

are now proud to present you with this innovative product.

All the highly qualified staff at RADEMACHER

stand behind it.

iGeneral view

Display

Key, see page 63

Receiver

button

Group

button

STOP

Stop button/

data trans-

mission

button

OK button /

Auto/Manu

Down

button

Battery compart-

ment on the rear

iKey to symbols

Proper use

ADVICE

Improper use

This concerns your safety.

Please pay particular attention to and carefully follow all

instructions with this symbol.

This heading indicates information that is important to the pro-

per functioning of the motor.

Use the Fernotron

Programming

Centre ...

... and the components of the Fernotron system (receiver modules,

radio-controlled solar light sensor, transmitter button, etc.) only

for remote operation of:

◆Roller shutters

◆Venetian blinds

◆Electrical consumers (e.g. lighting)

Operating

conditions ◆The Fernotron system may only be operated with and installed

in systems and devices in which transmitter or receiver faults

do not present any danger to persons or property or for

which these hazards are removed by the use of other safety

equipment.

◆Use the Programming Centre only in dry rooms.

Never use the

Fernotron

Programming

Centre ...

...for remote operation of devices and equipment with increased

safety requirements or increased risk of accident. Additional safety

equipment is required to do so. Please observe the relevant legal

regulations for setting up such systems.

iContent

General view .................................. 3

Key to symbols ................................ 4

Proper use / improper use ............... 4

Overview of the Fernotron system..... 6

Functional description ...................... 8

Function overview ........................... 9

Important advice before

adjusting the settings ..................... 10

Group and receiver names (table) .. 13

Your notes/allocation table ............ 14

First steps with the

Programming Centre ..................... 16

Calling up commissioning assistant . 17

Basic principle of menu navigation . 21

Menu list ....................................... 22

Activating and deactivating

automatic operation ...................... 23

Changing the standard

switching times for UP/DOWN ...... 27

Weekly timer ................................. 28

- Setting the weekly timer .............. 29

Autom. sunlight protection mode .... 31

- Activating/deactivating the

automatic sunlight mode ............. 32

Automatic dusk mode

with astro function ......................... 33

Activating/deactivating

automatic dusk mode ..................... 34

Switching the automatic random

operation on or off ........................ 35

Transmitting time/date to receiver .. 36

Setting and transmitting

time / date to receiver ................... 37

Data transmission .......................... 38

Registration with:

- a receiver using the SET button .... 40

- a Fernotron radio-controlled

tubular motor with radio code ..... 42

Switching the button lock on or off . 44

Expert mode ................................. 45

- Calling up expert mode ............... 46

- Commissioning assistant .............. 47

- Selecting group names and/or

receiver names ........................... 47

- Activating SET function

of a receiver ............................... 47

- Entering radio code for a

Fernotron radio-controlled

tubular motor ............................. 48

- Setting of end positions ............... 50

- Setting the sun position ............... 50

- Changing the direction of rotation 51

- Entering postcode/time zone

for astro function ........................ 51

- Entering maximum number

of groups ................................... 51

- Defining the maximum number of

receivers per group .................... 52

- Automatic summer/winter

time changeover ......................... 52

- Selecting the language ................ 52

- Switching the automatic

button lock on/off ....................... 53

- Setting the contrast ..................... 53

- Indication of DFC

reception quality ......................... 53

- Switching DCF radio clock

on/off ........................................ 54

- Setting light function per group .... 54

- Setting the SU/WI

transmission time ........................ 54

- Setting the moving text velocity .... 55

- Switching automatic

data transmission on and off ....... 55

Deleting settings ............................ 56

Manual operation.......................... 57

Technical data ............................... 58

Time zone table ............................. 59

Warranty conditions ...................... 61

Quick user guide ........................... 62

Display overview ........................... 63

Factory settings ............................. 63

... is a radio-based system to control roller shutters and electrical

consumers (e.g. lighting). It consists of various transmitters and

receivers which allow you to adapt the system flexibly to your

requirements.

Overview of Fernotron system

The Fernotron system

Group formation With the Fernotron system you can combine and control a

maximum of 49 receivers in 7 groups (7 groups with 7 receivers

each).

iOverview of Fernotron system

DEVICES

Runs programme

controled

Directly performs

radio command

TRANSMITTER

Sends your

programme data

Sends

radio command

Article no.

2405

Standard

Program-

ming Centre

2411

Comfort

Program-

ming Centre

2430

Transmitter

button

2440

Radio-

controled

solar light

sensor

2427

Signal

amplifier

(not

switchable

manually)

RECEIVER

Saves the

programm data

Responds directly

to radio command

Article no.

2420

Receiver

surface-

mouned

2421

Receiver

recessed

version

2422

Receiver

with local

switch

function

2423

Receiver with

sensor switch

function

2425

Receiver/

light switch

2426

Receiver/

plug-in

switching

device

Controlling roller

shutters using

Rademacher tubular

motors

It is also possible to

control other brands of

tubular motors but not

however to set the end

positions using

Fernotron.

Controlling all light

sources and

electric devices

P = Programme-controlled M = Manual control

iFunctional description

The Programming

Centre ... is the input unit of the Fernotron system. You can use it to enter

the desired functions of the the Fernotron system (e.g. automatic

switching times) and to transmit these by radio to the desired

receiver or to the desired group.

All settings/input is saved permanently in the Programming

Centre.

Presettings save work Carry out all settings first (set up switching times/function and

groups) with the Programming Centre before transmitting the

settings by radio to the desired receiver.

Manual operation In addition you can manually remotely operate individual tubular

motors or devices, or tubular motors or devices which have been

combined into groups (a maximum of 7 groups with a maximum

of 7 receivers), at any time.

Programming Centre

with the receiver

To enable your settings or manual switching commands to be

transmitted, the Programming Centre must be registered once with

each receiver (see page 40).

Functions The settings/function which you can perform with the aid of the

Programming Centre can be divided into the following types:

◆General functions

◆Group functions

◆Individual functions

◆Special functions (see expert mode)

General functions General functions are functions and settings which refer to the

overall Fernotron system.

Group functions You can combine a maximum of 7 receivers in one group. The

previously set group functions then apply for all receivers or devices

of this group at the same time (e.g. in order to close all roller

shutters on the ground floor at 21.00).

Individual functions Individual functions are used to individually set a receiver (e.g. to

activate the automatic sunlight protection mode in order to open

an awning).

Special functions There are various special functions available in expert mode (E)

(menu items) to facilitate taking the Fernotron system into operation

and adapting it to individual requirements.

Most settings are not compulsory and only require to be carried

out once for the basic setting procedure (e.g. enter the postcode).

iFunction overview

General functions

- Setting the current time (only if there is no DCF reception)

- Transmitting the time to the receiver

- Setting the postcode for the dusk programme

- Setting the number of receivers and groups

- Setting the receiver and group names

Group functions (apply for a maximum of 7 groups of not more than 7

receivers each)

- Manual operation of all roller shutters or devices in a group

- Set standard switching time for UP (▲) and DOWN (▼)

- Activate/deactivate the weekly timer, including:

- weekdays/weekend programme

- individual days programme

Individual functions (apply for each of the maximum of 49 receivers)

- Manual operation of individual roller shutters or devices

- AUTO/MANU switchover

- Automatic sunlight protection mode

- Automatic dusk operation (with astro function)

- Setting of the time delay for the dusk programme

- Automatic random operation

- Registration with the receiver

- Transmit data (e.g. switching times)

Special functions in expert mode

- Commissioning assistant

- End position setting (only for Rademacher electronic tubular motors)

- Reversing the direction of rotation of a tubular motor

- Change the language

- Automatic SU/WI time changeover

- Other special functions, see page 45

iImportant advice before adjusting the settings

Settings

Initial operation

Two situations can be distinguished in which you adjust settings:

◆Initial operation/installation of a Fernotron system for the

first time.

◆Subsequent changes/settings made to an existing Fernotron

system.

Please proceed as follows:

Preliminary thoughts:

Fill in the table on page 14 with the allocation of the receivers

(including the names and number) and the desired settings.

ADVICE Please refer to page 13 for a table of the names

suggested and preset by the manufacturer.

Call up and carry out the commissioning assistant (see page 17)

Basic settings via menu navigation with standard switching times

including allocation of the names and numbers of the groups

and receivers.

ADVICE This will make you familiar with the setting principle.

Other settings enabling individual adaptation

◆Setting the weekly timer

◆Activating and setting the automatic sunlight protection mode

etc.

Registration of the Programming Centre and data transmission

◆To enable your settings or manual switching commands

to become active you must first register the Programming

Centre once with each Fernotron receiver (see page 40).

The allocation and all settings (including the time etc.) will

also be transmitted to each individual receiver at the same

time.

iImportant advice before adjusting the settings

Subsequent

changes

Please proceed as follows:

Preliminary thoughts:

Which settings are to be changed?

Record any changes in the table on page 14.

Set the Programming Centre

Call up and set the functions in the menu e.g.:

◆Set standard switching times or weekly timer

◆Set the automatic sunlight protection mode/dusk mode etc.

Data transmission

◆Select the desired receiver in the group

◆Transmission of the allocation and all settings

(including time etc.) to each individual receiver.

iImportant advice before adjusting the settings

Allocation of names

Initial operation

Subsequent

changes ...

Example

Using the

same names

Numbering receivers

consecutively

You can allocate a name/a device number to each group and

each receiver (see page 47/pt. 2).

If you use the commissioning assistant (see page 17) you will be

automatically requested to select and enter the group and receiver

names.

...are possible at any time.

You can use names several times. To distinguish between receivers

with the same name, each receiver is given a different receiver

number.

In the living room there are 5 windows, and all 5 windows should

open and close at the same time.

You wish to allocate the name „living room“ for the group and

for all receivers. This means that all receivers must be given a

consecutive number.

Group Name* Number

Group 1 Living room A

- Receiver 1 Living room 1

- Receiver 2 Living room 2

- Receiver 3 Living room 3

* The group and receiver name always appears at the top

of the display.

Group/receiver name

in moving text

Group number Receiver number

iGroup and receiver names

Select the corresponding cipher code for the group and receiver

names in expert mode (see page 47/no. 2). This table shows you

the factory settings with the corresponding code.

Setting code

or name

Code Name

53 DEVICE 1

54 DEVICE 2

55 DEVICE 3

56 DEVICE 4

57 DEVICE 5

58 DEVICE 6

59 DEVICET 7

60 GROUP 1

61 GROUP 2

62 GROUP 3

63 GROUP 4

64 GROUP 5

65 GROUP 6

66 GROUP 7

67 RESERVE

68 RESERVE

69 RESERVE

70 RESERVE

Code Name

26 KITCHEN

27 LAMP

28 FAN

29 AWNING

30 MEDIA ROOM

31 MOTOR

32 NORTH

33 FIRST FLOOR

34 EAST

35 PUMP

36 ROLLER SHUTTER

37 BEDROOM

38 STANDARD LAMP

39 SOUTH

40 PATIO

41 W.C.

42 STAIRWELL

43 CURTAIN

44 STORE

45 ENTRANCE HALL

46 WAITING ROOM

47 LADIES

48 GENTS

49 CRAFT ROOM

50 WORKSHOP

51 WEST

52 LIVING ROOM

Code Name

0 WITHOUT NAME

1 STORE ROOM

2 STUDY

3 BATHROOM

4 TREATMENT ROOM

5 LIBRARY

6 UTILITY ROOM

7 OFFICE

8 TOP FLOOR

9 CEILING LIGHT

10 ENTRANCE

11 PARENTS’-

BEDROOM

12 GROUND FLOOR

13 DINING ROOM

14 STOREY

15 TV ROOM

16 CORRIDOR

17 FOYER

18 CLOAKROOM W.C.

19 SPARE ROOM

20 GARDEN

21 HOBBY ROOM

22 VENETIAN BLIND

23 FIRESIDE LOUNGE

24 BASEMENT

25 CHILD’S BEDROOM

iYour notes / allocation table (master copy)

1 ...................... 2 ....................... 3 .......................

Receiver

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

Group

▲ ......... ▼ ...........

............. ...............

Standard pr.

Wp. Mon - Fri

Wp. Sat - Sun

Mon.

Tues.

Wed.

Thurs.

Fri.

Sat.

Sun.

▲ ......... ▼ ...........

............. ...............

▲ ......... ▼ ...........

............. ...............

Receiver

7씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

Individual days

programme

iYour notes / allocation table (master copy)

4 ...................... 5 ....................... 6 .......................

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲씲씲

씲씲

씲

Code/Name:............

.................................

씲씲

씲

7......................

씲씲

씲

Code/Name:...........

................................

씲씲

씲

씲씲

씲

Code/Name:...........

................................

씲씲

씲

씲씲

씲

Code/Name:...........

................................

씲씲

씲

씲씲

씲

Code/Name:...........

................................

씲씲

씲

씲씲

씲

Code/Name:...........

................................

씲씲

씲

씲씲

씲

Code/Name:...........

................................

씲씲

씲

씲씲

씲

Code/Name:...........

................................

씲씲

씲

▲ ......... ▼ ...........

............. ...............

▲ ......... ▼ ...........

............. ...............

▲ ......... ▼ ...........

............. ...............

▲ ......... ▼ ...........

............. ...............

Buttons Indication in the display

iFirst steps with the Programming Centre

Insert batteries,

see page 58

The quality of reception of the

DCF signal is displayed. The

radio clock symbol flashes.

Automatic settings when

a DCF signal is

received

2.a

2.b

1 or 2 lines

3 lines

No DCF reception or weak DCF

reception (1 to 2 lines in the

display).

Confirm and automatically pro-

ceed with setting clock time and

date, see page 37.

Good DCF reception (3 lines in

the display).

Confirm and automatically pro-

ceed with displaying the current

weekday, date and clock time

(normal display).

ADVICE

It can take up to 5 minutes until a

radio signal is received.

The radio clock symbol

flashes:

◆if no DCF signal is received

◆after a two-week loss of the

DCF signal

◆Date

◆Time

◆Weekday

We assume that you have not yet set up any groups or made any

settings.

With the aid of the commissioning assistant all important basic

settings will be requested automatically in succession.

Initial operation

Calling up the commissioning assistant

Menu navigation

Buttons Indication in the display

Open the menu1.

Press for

approx.

2 sec.

/Select expert mode (E)

The menu item flashes.

Open expert mode

It is important that you press the

buttons in the correct order:

+ 2.

Confirm the commissioning

assistant

Insert the postcode/time zone

and confirm

see automatic dusk mode, page 33

01 to 99 = Postcode in

Germany

(the first two

figures)

100 to 255 = Various Euro-

pean cities, see

table on page

Buttons Indication in the display

iCalling up the commissioning assistant

Enter and confirm the number

of groups

ADVICE

You can set up a maximum of 7

groups.

7.a

10.

Enter and confirm the number

of receivers for group 1

ADVICE

You can set up a maximum of 7

groups.

Repeat point (7) for all groups

Select a name for each group

(see page 13) and confirm

After each confirmation the next

group will follow automatically.

Select a name for each receiver

(see page 13) and confirm

ADVICE

After each confirmation the next

receiver will follow automatically. If

there are 7 groups with 7 receivers

each then you will have to perform

this procedure 49 times.

Enter and confirm standard

switching times for UP (▲▲

▲▲

▲) and

DOWN (▼▼

▼▼

▼) for each group.

1. Set the hours and proceed with

O.K.

2. Set the minutes and proceed

with O.K.

Buttons Indication in the display

iCalling up the commissioning assistant

After the last setting the function

data transmission and the win-

dow „Press Stop button“ will

appear briefly

11.

12. Press SET at

the receiver

13.

STOP

14.

Activate the SET function of the

first Fernotron receiver (see ope-

rating instructions for the recei-

ver)

You can register the Programming

Centre with the receiver within 60

seconds.

tre with the receiver and begin

data transmission

Data transmission will take approx.

5 seconds, during which a count-

down from 5 down to 1 will be

shown in the display.

The receiver confirms the successful

data trans-mission by briefly

switching on the connected motor

or light.

If there is no confirmation then press

the STOP button again.

Confirm the data transmission

By pressing the OK button the data

transmission for the next receiver

will automatically be proposed.

ADVICE

Alternatively you can also select the

next receiver with the G and E

button or with the UP (▲) and

DOWN (▼) button.

Buttons Indication in the display

iCalling up the commissioning assistant

15. Proceed with the data trans-

mission for the next receiver

and all other receivers as shown

in the steps 12 to 14.

16.

SET /

STOP

Press for

4 sec.

After the data transmission to

the last receiver, return to the

normal display.

ADVICE

Abort initial operation

By pressing the menu button the

initial operation procedure will be

aborted and the normal display will

appear.

ADVICE

If you wish to abort the data trans-

mission, then proceed as follows:

Abort data transmission

By pressing the UP (▼) / DOWN

(▼) button several times, you will

obtain the function „Abort“.

By confirming with OK the normal

display will appear again.

This manual suits for next models

Table of contents

Other RADEMACHER Remote Control manuals

RADEMACHER

RADEMACHER DuoFern User manual

RADEMACHER

RADEMACHER DuoFern User manual

RADEMACHER

RADEMACHER Rollotron Pro Comfort User manual

RADEMACHER

RADEMACHER RolloTron Comfort DuoFern User manual

Popular Remote Control manuals by other brands

Foyum

Foyum TY-R1 manual

Harman Kardon

Harman Kardon RCP 2 owner's manual

Samsung

Samsung MR-EH01 user manual

One Forall

One Forall URC 7880 Simple setup guide

FUTABA

FUTABA 3PM instruction manual

IRIS Net

IRIS Net RCM-810 Engineeiring data

Toshiba

Toshiba RBC-AXU33UPB-E installation manual

Eaton

Eaton HMIVU07CUNBE instruction sheet

Flipsky

Flipsky VX2 product manual

Sony

Sony RCP-750 Operation manual

FUTABA

FUTABA 3PJ Super instruction manual

Firstech

Firstech UM-FT-2W4B-LED Quick start card

Tactic

Tactic TTX410 manual

Pegler Yorkshire

Pegler Yorkshire Terrier Handbook

Hitachi

Hitachi SPX-WKT3 instruction manual

Bose

Bose Cinemate Code List

AT&T

AT&T U-verse TV Using

Motorola

Motorola R331 Specification sheet

RADEMACHER Fernotron Programming Centre User manual

Popular Remote Control manuals by other brands
