User Guide
DiNET DAN-TX2
2-Channel Dante Network Transmitter
Radial Engineering Ltd.
1588 Kebet Way, Port Coquitlam
British Columbia, Canada, V3C 5M5
Tel: 604-942-1001 • Fax: 604-942-1010
Email: [email protected]
Radial®DAN-TX2™User Guide
Table of Contents Page
Overview.......................................................................................1
Features ................................................................................... 2-3
Getting Started .............................................................................4
Using with Unbalanced Signals....................................................5
Using with Professional Line Level Equipment.............................6
Block Diagram ..............................................................................7
Specications ...............................................................................9
Warranty .......................................................................Back cover
Thank you for purchasing the Radial DiNET DAN-TX2. The DAN-
TX2 is a high-resolution stereo direct box designed to connect
to a Dante™ enabled Ethernet network and seamlessly convert
analog audio to a digital format compatible with Dante. This
makes it ideal for connecting consumer line-level devices such
as laptops, tablets or CD players, or professional balanced line-
level equipment directly to a Dante network for easy routing and
distribution to other devices.
This manual covers the setup and operation of the DAN-TX2
in various applications. Please take a few minutes to read
through and familiarize yourself with the DAN-TX2 features
and functions. If you have any questions that are not covered
in this manual, please consult the FAQ section on our website.
This is where we post the latest updates. If you still do not
nd what you are looking for, feel free to send us an email at
order.
True to the Music
®
Radial Engineering Ltd. DAN-TX2
1
OVERVIEW
The DiNET DAN-TX2 is an analog to digital converter that is designed
to take the signal from both consumer and professional line-level audio
sources and transmit them over an existing Dante or AES67-enabled
network.
The DAN-TX2 is equipped with a variety of connection options to make
it easy to connect with any type of audio equipment. The included stereo
3.5mm, RCA and XLR/TRS combo connectors are wired in parallel to
allow for immediate hookup of laptops, tablets, smartphones, consumer
audio devices, broadcast and professional audio equipment without the
need for adapter cables.
The inputs of the DAN-TX2 are processed using high quality 24 bit/96kHz
analog-to-digital converters, providing two channels of Dante digital
outputs over a single Ethernet connector, and allowing easy integration
of analog audio devices with an existing Dante network.
The DAN-TX2 is easy to use, with no setup required on the device itself.
It is completely congured by Dante Controller, which manages digital
audio routing across the Dante network. Dante Controller is a software
application by Audinate™ that allows the user to manage all Dante-
enabled devices across a network. Use Dante Controller to route audio
from the DAN-TX2 to ny number of destinations on the network. Simply
connect the DAN-TX2 to the network and it will automatically appear as
an available transmit device within Dante Controller.
The DAN-TX2 will initially have the name “DiNET-TX2-xxxxxx”, where
the last 6 digits will be the unique media access control address (MAC
address) of your DAN-TX2. As this can be changed to a user-generated
name using Dante Controller, we recommend writing down the MAC
address of your unit in the space provided below for future reference.
Record your DAN-TX2 MAC address here:
DiNET-TX2-__________________
Dante Controller can be downloaded for free at www.audinate.com. For
latest rmware for the DAN-TX2 please visit www.radialeng.com.
Dante Network
Cat 5e / Cat6
Radial Engineering Ltd. DAN-TX2
True to the Music
®
2
FEATURES
1 7 82 3 4 5 6
1. 3.5MM INPUT:Stereo TRS input for use with laptops, tablets and
smartphones. Wired in parallel with the XLR and RCA inputs.
2. PAD: Engages a -18dB input pad for high output line-level sources.
3. TRIM: Adjustable trim control to set input levels, with unity gain at
12 o’clock. Provides -10dB of cut or +10dB of gain at the min/max
settings.
4. LINK: When engaged, the TRIM and PAD controls for Channel-1
become the master controls for stereo operation.
5. SIG/CLIP LEDS: Will illuminate when input signal is present or
clipping is detected on each input channel.
6. SYNC LEDS: Red LED is illuminated when unit is powered. Green
LED will illuminate once connected to an Ethernet network. Flashing
green LED indicates that the DAN-TX2 is in master clock mode,
solid green LED indicates that it is in slave mode.
7. SYS LEDS: Red LED illuminates when power is rst applied, green
LED illuminates once Dante processor becomes active.
8. +15V LED: Will illuminate when the DAN-TX2 is connected to the
included DC power adaptor.
9. POE LED: Will illuminate when the DAN-TX2 is receiving Power
over Ethernet (PoE).
9
True to the Music
®
Radial Engineering Ltd. DAN-TX2
3
10 12 13 16
11
10. POWER: 15VDC connection for use with included Radial power
adapter when PoE is not available.
11. CABLE CLAMP: Used to secure the power supply cable to prevent
accidental disconnection.
12. ETHERNET PORT: Connects to the Dante network using a
standard CAT5e or CAT6 Ethernet cable. This port delivers the
digital audio signal to the network and powers the DAN-TX2 when
Power over Ethernet (PoE) is available.
13. ETHERCON COMPATIBLE CONNECTION: Locking connector
prevents accidental disconnection or damage to RJ45 connectors
when used with Neutrik etherCON cable connector carriers.
14. RCA AUX INPUTS: Provided for connection from CD/DVD players
and other consumer-level playback devices. Wired in parallel with
the XLR/TRS and 3.5mm inputs.
15. XLR/TRS COMBO INPUTS: Balanced inputs for connection to
professional audio playback sources.
16. NON SLIP PAD: Provides electrical & mechanical isolation and
keeps the unit from sliding around.
14 15
Radial Engineering Ltd. DAN-TX2
True to the Music
®
4
Dante Network
GETTING STARTED
Before making any connections, always ensure your ampliers or
speakers are either turned down or turned o in order to protect sensitive
components from damage due to loud transients that can occur when
plugging in or turning on various components.
POWERING THE DAN-TX2
PoE
Power for the DAN-TX2 can be provided
via Power over Ethernet (PoE) from a PoE-
capable network switch or a separate PoE
injector. Once power is available, the side
panel PoE LED indicator will illuminate and
the DAN-TX2 will be ready to use.
Power Supply
The included 15VDC power supply is provided
for use when PoE is not available. Once you
have connected the DAN-TX2 to the Ethernet
switch, plug in the power supply. The +15VDC
LED will illuminate and the DAN-TX2 will be
ready to use.
ETHERNET CONNECTION
The DAN-TX2 connects to an Ethernet switch using a standard CAT5e
or CAT6 cable. Once the Ethernet switch is connected to a computer
running the Dante Controller software, the DAN-TX2 will appear as an
available transmit device.
As a backup option, the DAN-TX2 is designed to be able to have both
PoE and the 15VDC adaptor connected at the same time. If one fails, the
other will maintain power without interruption.
True to the Music
®
Radial Engineering Ltd. DAN-TX2
5
DAN-TX2 WITH UNBALANCED CONSUMER AUDIO
When using the DAN-TX2 with consumer audio devices, typically either
the RCA connectors or the mini 3.5mm connector will be used, however,
the XLR/TRS inputs can also be employed. The DAN-TX2 will accept
consumer line level signals such as those from a CD/DVD player, laptop,
tablet, or smartphone. The TRIM control can be used to ne tune the level,
and the PAD can be engaged should further attenuation be required.
When connecting to stereo input sources, engage the LINK switch to
allow the TRIM and PAD on Channel-1 to aect both left and right signals
equally, providing you with the ability to adjust the levels of both channels
using just one control without altering the stereo balance.
Only one set of inputs should be used at a time, as they will all sum
together to the left and right Dante outputs over Ethernet. To connect
more than one device at a time to the Dante network, use multiple
DAN-TX2 units.
Dante Network
Link
Radial Engineering Ltd. DAN-TX2
True to the Music
®
6
DAN-TX2 WITH PROFESSIONAL LINE-LEVEL EQUIPMENT
The balanced XLR/TRS combo inputs on the DAN-TX2 are designed to
be used with professional audio and broadcast equipment such as mixing
consoles and recording interfaces, with the ability to handle extremely hot
signal levels of up to +28dBu. TRIM controls for each channel have +/-
10dB of gain to accomodate for a wide range of input levels, along with
-18dB pad switches for extremely hot signals. When the TRIM control
is set to 12 o’clock and the PAD is engaged, +18dBu = 0dBFS. Without
the PAD engaged 0dBu = 0dBFS. As with the unbalanced inputs, when
connecting to stereo input sources engage the LINK switch to allow the
PAD and TRIM on Channel-1 to aect both inputs equally.
Dante Network
MOUNTING THE DAN-TX2 IN A RACK
The DAN-TX2 can be mounted in standard 19” equipment racks using
the optional SA Series Rack Adaptor kit (Part # R800 9422). This 1 RU
adaptor allows you to mount one or two DAN-TX2 receivers in a single
rack space.
Audio connections for PA system and recording systems use
balanced XLR cables up to 100 meters (300’).
True to the Music
®
Radial Engineering Ltd. DAN-TX2
7
Audio connections for PA system and recording systems use
balanced XLR cables up to 100 meters (300’).
Radial Engineering Ltd. DAN-TX2
True to the Music
®
8
True to the Music
®
Radial Engineering Ltd. DAN-TX2
SPECIFICATIONS*
* Subject to change without notice.
9
Note: This device has been tested and found to comply with the limits for a Class
A digital device, according to Part 15 of the FCC Rules and EN55022. These
limits are designed to provide reasonable protection against harmful
interference when the device is operated in a commercial environment.
This device generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the user manual, may
cause harmful interference to radio communications. Operation of this device in a
residential area is likely to cause harmful interference, in which case the user will
be required to correct the interference at their own expense.
Audio Circuit Type: ............................................................. High current balanced active input device
Number of Channels:.......................................................... 2
Sample Rate:...................................................................... 44.1kHz, 48kHz, 88.2kHz, and 96kHz
Bit Depth:............................................................................ 24 bit
Frequency Response: ........................................................ 20Hz-20kHz
Idle Channel Noise: ............................................................ -108dB
Dynamic Range:................................................................. >103dB
Channel Separation:........................................................... >85dB
Maximum Input:.................................................................. +28dBu
Equivalent Input Noise:....................................................... -98dB
Total Harmonic Distortion + Noise: ..................................... 0.008% @ -6dBfs
IMD:.................................................................................... 0.0017% -10dBfs
Balanced Input Impedance:................................................ 40kOhm
Unbalanced Input Impedance:............................................ 20kOhm
Power Consumption: .......................................................... 1.25W
Features
Input Connectors: ............................................................... 2x XLR/TRS combo, 3.5mm TRS, 2x RCA
Output Connectors: ............................................................ RJ45 Ethernet with locking etherCON
LED Indicators:................................................................... SYNC, SYS, +15V, and PoE
Pad: .................................................................................... -18dB
General
Power: ................................................................................ 15VDC 400mA (included) or PoE
Power Over Ethernet (PoE):............................................... Class 1 IEEE 802.3af
FCC Approval: .................................................................... Meets FCC Part 15B Class A
Construction: ...................................................................... 14-gauge steel
Finish:................................................................................. Durable powder coat
Size (L x W x D):................................................................. 4.5” x 2” x 6” (121 x 6 x 147mm)
Warranty: ............................................................................ Radial 3-year, transferable
®
www.radialeng.com
THREE YEAR TRANSFERABLE LIMITED WARRANTY
RADIAL ENGINEERING LTD. (“Radial”) warrants this product to be free from defects in
material and workmanship and will remedy any such defects free of charge according
to the terms of this warranty. Radial will repair or replace (at its option) any defective
component(s) of this product (excluding nish and wear and tear on components under
normal use) for a period of three (3) years from the original date of purchase. In the event
that a particular product is no longer available, Radial reserves the right to replace the
product with a similar product of equal or greater value. In the unlikely event that a defect
RA number (Return Authorization number) before the 3 year warranty period expires.
The product must be returned prepaid in the original shipping container (or equivalent)
to Radial or to an authorized Radial repair centre and you must assume the risk of loss
or damage. A copy of the original invoice showing date of purchase and the dealer name
must accompany any request for work to be performed under this limited and transferable
warranty. This warranty shall not apply if the product has been damaged due to abuse,
misuse, misapplication, accident or as a result of service or modication by any other than
an authorized Radial repair center.
THERE ARE NO EXPRESSED WARRANTIES OTHER THAN THOSE ON THE FACE
HEREOF AND DESCRIBED ABOVE. NO WARRANTIES WHETHER EXPRESSED
OR IMPLIED, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL EXTEND
BEYOND THE RESPECTIVE WARRANTY PERIOD DESCRIBED ABOVE OF THREE
YEARS. RADIAL SHALL NOT BE RESPONSIBLE OR LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSS ARISING FROM THE USE
OF THIS PRODUCT. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS, WHICH MAY VARY DEPENDING ON WHERE
YOU LIVE AND WHERE THE PRODUCT WAS PURCHASED.
Radial®DAN-TX2 User Guide - Part #: R870 1047 00 / 11-2018
Copyright 2018 Radial Engineering Ltd. All rights reserved.
Specications and appearance subject to change without notice.
Radial Engineering Ltd.
1588 Kebet Way, Port Coquitlam, British Columbia, V3C 5M5
To meet the requirements of California Proposition 65, it is our responsibility to inform you of the following:
WARNING: This product contains chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
Please take proper care when handling and consult local government regulations before discarding.
Table of contents
Other Radial Engineering Transmitter manuals
