Radio Shack SYSTEM 2100 User manual

Cat. No. 43-982
OWNER’S MANUAL
Please read before using this equipment.
System 2100
2-Line Caller ID
with 64-Call Memory
43-982.fm Page 1 Monday, August 16, 1999 5:01 PM

2
This symbol is intended to alert you to the presence of
uninsulated dangerous voltage within the product’s en-
closure that might be of sufficient magnitude to consti-
tute a risk of electric shock. Do not open the product’s
case.
This symbol is intended to informyou thatimportant op-
erating and maintenance instructions are included in the
literature accompanying this product.
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER-SERVICE-
ABLE PARTS INSIDE. REFER SERVIC-
ING TO QUALIFIED PERSONNEL.
WARNING: To reduce the risk of fire
or shock hazard, do not expose this
product to rain or moisture.
CAUTION !
!
© 1997 Tandy Corporation.
All Rights Reserved.
RadioShack is a registered trademark used by Tandy Corporation.
43-982.fm Page 2 Monday, August 16, 1999 5:01 PM

3
FEATURES
Your RadioShack System 2100 2-Line Caller ID with 64-Call
Memory is the latest in telephone technology, providing Call-
er ID information for two phone lines. When you subscribe to
Caller ID service, the telephone company sends the caller’s
name and telephone number (if available), the date, and the
time of the call between the first and second rings. The Sys-
tem 2100 stores and displays up to 64 Caller ID records per
phone line, which have either a number or a name, or both.
The system’s callback feature lets you dial a caller’s number
with the press of a single button. Its other features include:
Easy Installation — so you can quickly begin to see Caller
ID information.
New Call Counter — displays the number of new calls you
have received.
READ/DELETE Button — lets you delete Caller ID records
one at a time or all at once.
Large Display — makes it easy to see the Caller ID infor-
mation for up to two phone lines and the current time and
date as provided to Caller ID service subscribers by your lo-
cal telephone company.
Message Waiting Display — appears when you have re-
ceived a voice mail message (if you subscribe to a message
waiting service from your local phone company).
43-982.fm Page 3 Monday, August 16, 1999 5:01 PM

4
Trilingual Messages — lets you set the system to display
messages in English, French, or Spanish.
REVIEW Buttons — let you easily scroll through all records
in Caller ID memory.
Mounting Options — you can place the system on a desk,
shelf, or table, or mount it on a wall.
This system has been tested and found to comply with all
applicable UL and FCC standards.
Notes:
• To use this system, you must be in an area where Call-
er ID service is available, and you must subscribe to the
service.
• Your System 2100 displays name only, number only, or
both name and number, depending upon the informa-
tion provided by the phone company.
We recommend you record your System 2100’s serial num-
ber here. The number is on the system’s bottom panel.
Serial Number:
43-982.fm Page 4 Monday, August 16, 1999 5:01 PM

5
FCC INFORMATION
We have designed your System 2100 to conform to federal
regulations, and you can connect it to most telephone lines.
However, each system (and each device, such as a tele-
phone or answering machine) that you connect to the tele-
phone line draws power from the line. We refer to this power
draw as the device’s
ringer equivalence number or REN.
The REN is shown on a label on the bottom of the system.
If you use more than one telephone or other device on the
line, add up all of the RENs. If the total is more than five,
your telephone might not ring. In rural areas, a total REN of
three might impair ringer operation. If ringer operation is im-
paired, remove a device from the line.
Your system complies with Part 68 of
FCC Rules . You must,
upon request, provide the FCC registration number and the
REN to your telephone company. Both numbers are shown
on the bottom of the system.
Note: You must not connect the system to:
• Coin-operated systems
• Party-line systems
• Most electronic key telephone systems
43-982.fm Page 5 Monday, August 16, 1999 5:01 PM

6
In the unlikely event that your system causes problems on
the phone line, the phone company can temporarily discon-
tinue your service. If this happens, the phone company at-
tempts to notify you in advance. If advance notice is not
practical, the phone company notifies you as soon as possi-
ble and advises you of your right to file a complaint with the
FCC.
Also, the phone company can make changes to its lines,
equipment, operations, or procedures that could affect the
operationofthissystem. Thetelephone company notifiesyou
of these changes in advance, so you can take the necessary
steps to prevent interruption of your telephone service.
This system complies with the limits for a Class B digital de-
vice as specified in Part 15 of
FCC Rules . These limits pro-
videreasonable protection against radio andTV interference
in a residential area. However, your system might cause TV
or radio interference even when it is operating properly. To
eliminate interference, you can try one or more of the follow-
ing corrective measures.
• Reorient or relocate the receiving antenna
• Increase the distance between the System 2100 and
the radio or TV
Consult your local RadioShack store if the problem contin-
ues.
43-982.fm Page 6 Monday, August 16, 1999 5:01 PM

7
CONTENTS
Preparation ....................................................................... 8
Installing Batteries/Setup ............................................ 8
Connecting the System ............................................ 12
Connecting to the Phone Line ........................... 12
Connecting to an Answering Machine ............... 15
Mounting the System ................................................ 16
Operation ........................................................................ 18
Receiving Calls ......................................................... 18
Reviewing Call Records ........................................... 19
Displayed Call Information ................................ 21
Deleting Call Records ............................................... 22
Deleting a Single Call ........................................ 22
Deleting All Calls ............................................... 22
Using Callback .......................................................... 23
Care and Maintenance ................................................... 25
Lightning ................................................................... 26
43-982.fm Page 7 Monday, August 16, 1999 5:01 PM

8
PREPARATION
INSTALLING BATTERIES/SETUP
You need eight AAA batteries (not supplied) to power the
system. For the longest operation and best performance, we
recommend alkaline batteries, such as RadioShack Cat. No.
23-558.
Cautions:
• Use only fresh batteries of the required size and recom-
mended type.
• Do not mix old and new batteries, different types of bat-
teries (standard, alkaline, or rechargeable), or re-
chargeable batteries of different capacities.
Follow these steps to install batteries and select the display
language, area code, year, day, date, and time.
Note: To change any of the settings (for example, area code
or year), you must start from Step 1.
1. Unplug the system from the phone line.
2. Set L1/L2 on the side of the system to L2.
43-982.fm Page 8 Monday, August 16, 1999 5:01 PM

9
3. Use a Phillips screwdriver to remove the battery com-
partment screw on the bottom of the system and lift off
the cover.
4. Put the fresh batteries in the compartment as indicated
by the polarity symbols (+ and –) marked inside.
5. Replace the cover and tighten the screw. Reconnect
the phone line.
6. Turn the system over so you can see the display. After
you install batteries, the system displays TWIN640
REV 1.6 (information about the system’s software),
SET LANGUAGE, then ENGLISH (the default display
language).
7. To select another language, repeatedly press within
2 minutes. The display cycles through FRENCH,
SPANISH, and ENGLISH.
Note: If you do not press any key within 2 minutes, the
system automatically selects English.
8. Press to store the selected language. 000 and SET
AREA CODE appear. The first 0flashes.
9. Within 2 minutes, repeatedly press until the first digit
of your area code appears, then press to enter the
digit. The second 0flashes.
Repeat this step to set the second and third digits of
your area code.
43-982.fm Page 9 Monday, August 16, 1999 5:01 PM

10
Notes:
• If you make a mistake while setting the area code,
press READ/DELETE. The cursor moves to the first
digit of the area code. Repeat this step to reset the
area code.
• If you do not press any key within 2 minutes, the ar-
ea code is automatically set to 000.
10. Press to store the area code. 1997 SET YEAR ap-
pears. The 1flashes.
11. Repeatedly press until the desired first digit appears,
then press to store the digit. The second digit of the
year flashes.
Repeat this step to set the second, third, and fourth dig-
its.
Note: The correct date and time are automatically set
when the system receives its first call, but you can man-
ually set the date and time by following Steps 12–20.
12. Press to store the year. SET DATE 1/01 appears.
The month digit flashes.
13. Repeatedly press until the desired digit appears,
then press . The date’s first digit flashes.
14. Repeatedly press until the desired digit appears,
then press . The date’s second digit flashes.
43-982.fm Page 10 Monday, August 16, 1999 5:01 PM

11
15. Repeatedly press until the desired second date digit
appears, then press . SET DAY appears, then ----
----.
16. Repeatedly press to select the day of the week, then
press .
12:00AM SET TIME appears. 12 flashes.
17. Repeatedly press until the desired hour appears,
then press . The minute’s first digit flashes.
18. Repeatedly press until the desired digit appears,
then press . The second minute digit flashes.
19. Repeatedly press until the desired digit appears,
then press . AM flashes.
20. To change to PM, press .
21. Press to store the information.
When the battery low indicator ( ) appears or the display
dims, replace the batteries.
Cautions:
• Always remove old or weak batteries; batteries can leak
chemicals that can destroy electronic parts.
• Dispose of old batteries promptly and properly.
43-982.fm Page 11 Monday, August 16, 1999 5:01 PM

12
CONNECTING THE SYSTEM
Connecting to the Phone Line
The System 2100 connects to your phone and phone line
using four modular telephone line connectors. If your phone
line does not have a modular jacks, you can update the wir-
ing yourself using adapters available at your local Ra-
dioShack store. Or, you can have the telephone company
update your telephone wiring for you.
Notes:
• If you connect the system to only one phone line, the
system displays Caller ID information for only that line.
• The USOC number of the jack to be installed is RJ11C
(for a single-line phone jack) or RJ14C (for a two-line
phone jack).
The following illustrations show the possible connections,
depending on your telephone and phone line setup:
43-982.fm Page 12 Monday, August 16, 1999 5:01 PM

13
For a Two-Line Phone and a Two-Line Phone Jack
For a Two-Line Phone and Two Single-Line Phone
Jacks
43-982.fm Page 13 Monday, August 16, 1999 5:01 PM

14
For a Single-Line Phone and a Two-Line Phone Jack
For Two Single-Line Phones and a Two-Line Phone
Jack
43-982.fm Page 14 Monday, August 16, 1999 5:01 PM

15
For Two Single-Line Phones and Two Single-Line
Phone Jacks
Connecting to an Answering Machine
You can connect an answering machine to your System
2100 to answer calls for either or both phone lines.
Note: After connecting the answering machine, set it to an-
swer after at least two rings.
For both lines or Line 1 only
43-982.fm Page 15 Monday, August 16, 1999 5:01 PM

16
For Line 2 only
MOUNTING THE SYSTEM
You can place the System 2100 directly on a desk, shelf, or
table, or mount it on a wall using the supplied mounting
bracket and screws.
Follow these steps to mount the system on a wall.
1. Select a location near the phone line jack(s) and mark
mounting screw locations 43/16 inches (106 mm) apart
on the wall, side-by-side.
2. Drill two 1/8-inch holes in the wall at the marked loca-
tions.
Note: For extra support, use the supplied wall anchors.
3. Thread a screw into each hole until the head extends 1/8
inch from the wall.
43-982.fm Page 16 Monday, August 16, 1999 5:01 PM

17
4. Use a Phillips screwdriver to remove the battery com-
partment screw on the bottom of the system and lift off
the cover. Take care not to remove the batteries.
5. Rotate the cover 180° and reattach it.
6. Align the two screws with the keyholes on the bottom of
the system. Slide the system down onto the screws to
secure it to the wall.
43-982.fm Page 17 Monday, August 16, 1999 5:01 PM

18
OPERATION
RECEIVING CALLS
Caller ID is a service provided by your telephone company.
When you subscribe to this service, the telephone company
sends the caller’s telephone number (and name, if available)
and the call’s date and time between the first and second
rings. The system receives and displays this information for
each call and updates the display with the current date and
time. The display also shows if caller information is not avail-
able or if the number is blocked by the sender (see “Dis-
played Call Information” on Page 21).
CALL flashes during a new incoming call, the LINE indicator
flashes, and the call record shows for 20 seconds, then the
number of new calls and NEW CALL appear. The LINE indi-
cator shows which line the call came in on and flashes until
you review a call (see “Reviewing Call Records” on
Page 19).
Note: If you have a phone that has a hold feature, we do not
recommend using hold for very long. The Caller ID informa-
tion sent by the phone company might disconnect a caller
on hold if a new call comes in.
If you have voice-mail message waiting (if you subscribe to
the telephone company’s message waiting service), NEW
CALL and MESSAGE WAITING appear on the display.
MESSAGE WAITING remains on the display until you re-
trieve the message.
43-982.fm Page 18 Monday, August 16, 1999 5:01 PM

19
In some areas, callers have the option of blocking the send-
ing of their Caller ID information. When a caller has blocked
Caller ID, the system displays PRIVATE CALL instead of
the call information.
REVIEWING CALL RECORDS
Each time you receive a call, your system saves a call
record in memory that you can review later, even while you
are on the phone. Your system saves up to 64 call records
for each connected phone line, then (for subsequent calls) it
replaces the oldest call record with each new one.
A stored call record includes:
• Call number (order the call is received)
• Time and date of the call
• Caller’s telephone number (if available)
• Caller’s name (if available)
Note: The display shows up to 10 digits of the phone num-
ber. If the incoming phone number is longer than 10 digits,
the display shows only the last 10 digits.
43-982.fm Page 19 Monday, August 16, 1999 5:01 PM

20
To review the call information, set L1/L2 to the line you want
to review. Repeatedly press REVIEW to see the most re-
cent call records or REVIEW to see older call records.
Notes:
•-- END -- appears after the last call record.
• When reviewing call records or using any other func-
tion, the system returns to the current date and time
about 20 seconds after you last press a key.
43-982.fm Page 20 Monday, August 16, 1999 5:01 PM
