Radio Shack Projection Clock Radio 12-591 User manual

12-591
User’s Guide
Daytime/Nighttime • Atomic-Controlled
Projection Clock Radio
Thank you for purchasing your Projection
Clock Radio from RadioShack. Please
read this user’s guide before installing,
setting up, and using your new
Projection Clock Radio.

2
Contents
Important Safety Instructions..............................................................................3
Package contents ......................................................................................................... 5
Features......................................................................................................................... 5
Setup ..................................................................................................................6
Power Your Radio..........................................................................................................6
Setting Time ................................................................................................................ 10
Setting Alarms ............................................................................................................. 11
Using the alarm ....................................................................................................... 11
Operation.........................................................................................................12
Tune to a Frequency....................................................................................................12
Preset Memory ............................................................................................................ 12
Find a Preset Station............................................................................................... 13
Sleep Timer ................................................................................................................. 13
Connecting Auxiliary Audio Equipment......................................................................13
Using the Projector......................................................................................................14
Additional Information .....................................................................................15
Specifications............................................................................................................... 15
FCC Information .......................................................................................................... 16
Limited Warranty ......................................................................................................... 17

3
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Unplug this product from the wall outlet before cleaning. Do not liquid cleaners or aerosol cleaners. Clean
only with dry cloth.
WARNING: To reduce the risk
of re or shock hazard, do not
expose this product to rain or
moisture.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER
OR BACK. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
PERSONNEL.
The lightning symbol is intended to alert you to the presence of
uninsulated, dangerous voltage within this product’s enclosure
that might be of sufcient magnitude to constitute a risk of electric
shock. Do not open the product’s case.
The exclamation symbol is intended to inform you that important
operating and maintenance instructions are included in the literature
accompanying this product.
CAUTION
!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
!

4
6. Do not use this product near water. The apparatus shall not be exposed to dripping or splashing and that
no objects filled with liquids, such as vases, shall be placed on apparatus.
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
8. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from tip-over.
9. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product
and to protect if from overheating. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
10. This product is equipped with a polarized AC line plug (a plug having one blade wider than the other).
This plug will fit in the power outlet only one way. This is a safety feature. If you cannot insert the plug fully
into the outlet, try reversing the plug. If the plug still doesn’t fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized plug. If you need an extension cord,
use a polarized cord.
11. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
12. The mains plug of the apparatus should not be obstructed OR should be easily accessed during intended
use.
13. To completely disconnect the power input, the mains plug of apparatus shall be disconnected from the
mains. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Only use attachments/accessories specified by the manufacturer.
15.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
16. The rating plate is located on the bottom of the apparatus.

5
Setup
Package contents
• Radio
• User’s Guide
• Quick Start
Features
• Projects time on the ceiling or wall
• Automatically adjusts the brightness of the beam based on ambient lighting
conditions
• Time synchronizes with the U.S. government’s atomic clock, sets itself, and stays
accurate
• Dual alarms with snooze function
• AM/FM radio with six memory presets

6
Setup
Setup
Power Your Radio
Connect the AC plug to a standard wall outlet.
Install batteries for backup power. In the event of a
power interruption, the backup batteries will retain
your radio presets, the clock and alarm times in
the memory only (normal clock, display and radio
operation excluded):
1. Remove the battery cover.
2. Insert 2 AAA batteries (not supplied) matching
the polarity symbols (+ and –) marked inside.
3. Replace the battery cover.
bBattery Notes:
• Dispose of batteries promptly and properly. Do not burn or bury them.
• Do not expose batteries to excessive sunlight, fire or heat.
• Use only fresh batteries of the required size and type.
• Do not mix old and new batteries, different types of batteries (alkaline, or
rechargeable), or rechargeable batteries of different capacities.
AA
A
AAA

7
Setup
PROJECTOR HI/MED/
AUTO/OFF
• Turn projector on/off
• Select brightness level
LOCK TIME/DATE
Slide to TIME/DATE to set
time manually. Slide to LOCK
to save.
12/24
Select 12 or 24 hour format.
TIME ZONE
Select your time zone.
RESET
Restore to factory settings
and clear all time and radio
presets.
DST AUTO/OFF
Turn daylight savings on/off.
Projection Focus
Adjust the image focus.
Image Rotate
Adjust the
projection angle.

8
Setup
WAVE
Hold down about 10 seconds
to turn on/off the atomic clock
function. Press to search for the
atomic clock signal, e flashes.
SET
Set time and alarm.

Change settings.
+ VOLUME –
Adjust volume.
M 1/ M 2
Turn on or stop alarm 1 or alarm 2.
Light sensor
Helps to detect light levels to automatically
adjust projector brightness. See page 14,
Using the projector.

9
Setup
G
Turn on/off the radio.
FM/AM/AUX
Select the desired frequency.
SLEEP
Select a sleep timer in 60, 30, 15 minute
increments.
MEMORY
• Hold down to store frequencies.
• Press to recall the saved frequencies.
SNOOZE/LIGHT
• Stop the alarm for 10 minutes when
the alarm sounds.
• Briefly turn on the backlight /projector
image.
• Press and hold for 3 seconds to
change backlight brightness level.
AUX ⅛”(3.5mm) jack
Connect auxiliary audio equipment.

10
Setup
• If you do not plan to use the radio for a long time, remove the batteries.
Batteries can leak chemicals that can damage electronic parts.
Setting Time
Your clock attempts to synchronize with the atomic time signal
automatically when you first turn it on and whenever you press RESET.
The reception icon eflashes while it is searching for a signal.
After your clock displays the time, set the TIME ZONE switch to the
local zone (Eastern, Central, Mountain, or Pacific).
If the clock does not find the atomic time signal or when you are out of
the local zone, set the time manually:
1. Slide LOCK TIME/DATE to TIME/DATE.
2. The current time flashes. Press or to select the time or
hold down or to quick search in 10 minute increments.
3. Press SET to confirm and enter calendar mode. The month flashes.
4. Press or to select the month.
5. Press SET. The day flashes.
6. Press or to select the date.
RESET

11
Setup
7. Press SET to confirm. The year flashes.
8. Press or to select the year.
9. Press SET to confirm and slide LOCK TIME/DATE to LOCK to save the setting.
Setting Alarms
1. Hold down SET until the time display of ALARM 1 flashes.
2. Press or to select the alarm time, then press SET.
3. Press or to wake by (alarm) or (radio AM/ FM band). The icon of
the selected mode flashes.
4. Press SET; the time display of ALARM 2 flashes. Follow Steps 2 and 3 to set
alarm time and wake mode, or press SET to skip.
5. Press SET to save all alarm settings and
go back to the regular clock display.
Using the Alarm
• To activate the alarm, press to release the
1or 2button. The corresponding
alarm time and alarm mode appears on
the display.

12
Operation
• To deactivate the alarm, press the 1or 2button down. The corresponding
alarm time and alarm mode disappear.
Operation
Press G to turn on the radio. The last frequency appears.
Tune the Radio
1. Press FM/AM/AUX to toggle between FM, AM and auxiliary input.
2. To manually find a frequency, press or until the desired frequency sounds.
To auto scan a frequency, hold down or for about 5 seconds, the radio will
search for a broadcast automatically and stop when a strong signal is received.
Preset Memory
You can store up to six stations in the preset memory.
1. Hold MEMORY. The first preset station ( ) appears.
2. Press FM/AM/AUX to select the desired band and press or to select the
desired frequency.

13
Operation
3. Press MEMORY to store the frequency and select the next preset frequency.
4. Repeat step 2–3 to store other preset frequencies.
Find a Preset Station
1. Press MEMORY to recall the previous used memory frequency.
2. Press MEMORY again to go to the next preset frequency.
Sleep Timer
You can set your radio to turn off automatically after a predetermined period.
Repeatedly press SLEEP to select 60, 30, or 15 minutes. Select OFF to turn off the
sleep timer. SLEEP flashes during the sleep timer count down.
Connecting Auxiliary Audio Equipment
You can use your radio as an amplifier by connecting other audio equipment such
as an MP3 or CD player.
1. Use an Æ“ (3.5mm) plug cable (not supplied) to connect the audio equipment
to the AUX jack on the radio.
2. Press FM/AM/AUX until AU appears.

14
Operation
3. Adjust the sound control on your device.
4. Press POWER to turn off the radio.
Using the Projector
Project the current time, date, or radio frequency on a wall or ceiling, and rotate
the projection +/- 90 degrees.
• AUTO – The projection brightness changes according to the ambient brightness.
In order for auto light detection to work properly, make sure you do not cover or
obstruct the light sensor (see page 8.)
• OFF – When projection is OFF, press LIGHT/SNOOZE to briefly project the
image, it lights about 10 seconds.
• HI – High brightness.
• MED – Medium brightness.
• Image Rotate – Rotate the image to the desired angle.
• Projection Focus – Adjust the image until a clear projection appears on a wall
or ceiling.

15
Additional Info
Additional Information
Specifications
Power supply................................................................................................................... 120V AC
Output power .................................................................................................................. 200 mW
FM Frequency ............................................................................87.5 – 107.9 MHz, 200 kHz step
AM Frequency................................................................................. 530 – 1700 kHz, 10 kHz step
Size (L x W x H)............................................................... 4.9 x 3.1 x 5.8 in (12.5 x 7.8 x 14.7 cm)
Weight ............................................................................................................... 17.64 oz. (0.8 kg)
Specifications are subject to change and improvement without notice. Actual product may vary from the
images found in this document.

16
Additional Info
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult your local RadioShack store or an experienced radio/TV technician for help.
If you cannot eliminate the interference, the FCC requires that you stop using your equipment. Changes or
modifications not expressly approved by RadioShack may cause interference and void the user’s authority
to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device
does not cause harmful interference.

17
Additional Info
Limited Warranty
RadioShack warrants this product against defects in materials and workmanship under normal use by the
original purchaser for ninety (90) days after the date of purchase from a RadioShack-owned store or an
authorized RadioShack franchisee or dealer. RADIOSHACK MAKES NO OTHER EXPRESS WARRANTIES.
This warranty does not cover: (a) damage or failure caused by or attributable to abuse, misuse, failure to
follow instructions, improper installation or maintenance, alteration, accident, Acts of God (such as floods
or lightning), or excess voltage or current; (b) improper or incorrectly performed repairs by persons who
are not a RadioShack Authorized Service Facility; (c) consumables such as fuses or batteries; (d) ordinary
wear and tear or cosmetic damage; (e) transportation, shipping or insurance costs; (f) costs of product
removal, installation, set-up service, adjustment or reinstallation; and (g) claims by persons other than the
original purchaser.
Should a problem occur that is covered by this warranty, take the product and the RadioShack sales
receipt as proof of purchase date to any RadioShack store in the U.S. RadioShack will, at its option,
unless otherwise provided by law: (a) repair the product without charge for parts and labor; (b) replace
the product with the same or a comparable product; or (c) refund the purchase price. All replaced parts
and products, and products on which a refund is made, become the property of RadioShack. New or
reconditioned parts and products may be used in the performance of warranty service. Repaired or
replaced parts and products are warranted for the remainder of the original warranty period. You will be
charged for repair or replacement of the product made after the expiration of the warranty period.
RADIOSHACK EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS NOT STATED IN THIS
LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW, INCLUDING
THE IMPLIED WARRANTY OF MERCHANTABILITY AND, IF APPLICABLE, THE IMPLIED WARRANTY
OF FITNESS FOR A PARTICULAR PURPOSE, SHALL EXPIRE ON THE EXPIRATION OF THE STATED
WARRANTY PERIOD.
EXCEPT AS DESCRIBED ABOVE, RADIOSHACK SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO
THE PURCHASER OF THE PRODUCT OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY

18
Additional Info
LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE
PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED
TO, ANY DAMAGES RESULTING FROM INCONVENIENCE AND ANY LOSS OF TIME, DATA, PROPERTY,
REVENUE, OR PROFIT AND ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES,
EVEN IF RADIOSHACK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some States do not allow limitations on how long an implied warranty lasts or the exclusion or limitation
of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
You may contact RadioShack at:
RadioShack Customer Relations
300 RadioShack Circle, Fort Worth, TX 76102 04/08
www.RadioShack.com

19
Additional Info

Printed
in China
06A09
12-591
©2009. RadioShack Corporation. All rights reserved.
RadioShack and RadioShack.com are trademarks used by RadioShack Corporation.
Protect the environment by recycling used electronics. Go to
E-CyclingCentral.com to find an electronic recycling center near you.
