Radio Shack PRO ENCORE! PG 202 User manual

Cat. No. 17-7021
OWNER’S MANUAL
PRO ENCORE!
PG 202 Numeric Pager
Please read before using this pager.
TM
17-7021.fm Page 1 Wednesday, July 21, 1999 5:13 PM

2
INTRODUCTION
Your Radio Shack Pro Encore PG 202 Numeric Pager
lets you keep in touch with family and friends every-
where you go (in the PageMart coverage area you
choose) and is easy to operate. It can store up to 16
20-digit messages in memory, and you can protect im-
portant messages so you do not accidentally erase
them.
Be sure you thoroughly read these instructions to en-
sure that you fully understand how to use your pager.
©1995 Tandy Corporation.
All Rights Reserved.
PRO ENCORE! is a trademark of Motorola, Inc.
Radio Shack is a registered trademark
used by Tandy Corporation.
17-7021.fm Page 2 Wednesday, July 21, 1999 5:13 PM

3
INSTALLING THE BATTERY
Your pager requires one AAA battery.For the best per-
formance, we recommend an alkaline battery, such as
Radio Shack Cat. No. 23-555.
1. Slide the battery compartment lock up and slide
the battery door in the direction of the arrow. The
pager’s door hinges open. If you accidentally lift it
so far that it pops off of the pager, simply snap it
back into place.
2. Insert the battery’s positive end first, as indicated
by the polarity symbol (+) marked outside the
compartment.
17-7021.fm Page 3 Wednesday, July 21, 1999 5:13 PM

4
3. Close the battery door and slide the battery com-
partment lock down to secure it.
Notes:
• To conserve battery power, turn the pager off
when you are not using it.
• The battery should provide about 850 to 950
hours of continuous use.
A low battery alert sounds and the pager displays LO
CELL when the battery’s power is low. When this oc-
curs, replace the battery.
Notes:
• To save battery power, all pager alerts change to
2 seconds in length when battery power is low.
• When you replace the battery, the pager keeps all
messages and the time and date.
17-7021.fm Page 4 Wednesday, July 21, 1999 5:13 PM

5
OPERATION
A LOOK AT YOUR PAGER
— turns the pager on/off, lets you read messages
and select the displayed function.
— press once to light the screen; press again to re-
set to the standby screen.
— scrolls through menus.
Display
17-7021.fm Page 5 Wednesday, July 21, 1999 5:13 PM

6
TURNING ON THE PAGER
Press to turn on your pager. Your pager alerts with
either a tone or vibration.
TURNING OFF THE PAGER
Repeatedly press until the pager displays PAgEr
OFF?. Press to turn off the pager. Previously re-
ceived messages are not erased. However if you are
paged while the pager is off, you do not receive the
page.
17-7021.fm Page 6 Wednesday, July 21, 1999 5:13 PM

7
SELECTING AUDIBLE/SILENT
ALERT
From the date/time display, press until the pager
displays either SILENT? or AUdIO?.
• If the pager displays SILENT?, it is set to sound
an alert tone. Press to make your pager
vibrate when it receives a page.
• If the pager displays AUdIO?, it is set to vibrate.
Press to make your pager sound an alert tone
when it receives a page.
Set your pager to the silent mode when you are in
meetings, church, or the theater, to avoid disturbing
others with the tone. The silent feature is also handy if
you are at a concert or in any noisy environment where
it might be difficult to hear the tone.
17-7021.fm Page 7 Wednesday, July 21, 1999 5:13 PM

8
ALERT TONES
Your pager has five different alert tones. If you select-
ed the audible alert, follow these steps to select an
alert tone.
1. Repeatedly press until the pager displays
SET ALErT?.
2. Press . The pager sounds the currently
selected alert tone.
3. Repeatedly press until the pager sounds the
alert tone you want.
4. Press .
17-7021.fm Page 8 Wednesday, July 21, 1999 5:13 PM

9
SETTING THE TIME
You must set the time so the pager can time stamp
your messages.
1. Repeatedly press until the pager displays
SET TIME?.
2. Press . The hour digits flash. Within 8 seconds,
repeatedly press to set the hour.
3. Press . The first minute digit flashes. Within 8
seconds, repeatedly press to set the first
minute digit.
4. Press . The second minute digit flashes. Within
8 seconds, repeatedly press to set the sec-
ond minute digit.
17-7021.fm Page 9 Wednesday, July 21, 1999 5:13 PM

10
5. Press .
Aor Pflashes in the display. Within 8
seconds, press to set the time of day to AM
or PM.
6. Press twice. The pager displays the time and
date.
SETTING THE DATE
1. Repeatedly press until the pager displays
SET dATE?.
2. Press . The month flashes. Within 8 seconds,
repeatedly press to set the month.
3. Press . The day flashes. Within 8 seconds,
repeatedly press to set the day.
4. Press twice. The pager displays the time and
date.
