RIIM overview
The RIIM network consists of these key elements
The IPM module
oThe IPM module can be configured as root (border router), mesh router or leaf node.
As a root node it acts as the base of the mesh network. It can connect to an external
network via ethernet or custom user application on other interfaces such as UART
As a router node, it will be able to transport packets in the RIIM mesh network
As a leaf node, it is not able to transport packets to other nodes except its parent. This
mode uses the least amount of energy.
oAll modes supports customer ICI applications and external connections. Applications use the
same RIIM Software Development Kit (SDK) for all node types.
- The RIIM SDK
oSoftware development kit with application frameworks and tools for creating and uploading
end network configuration and customer applications to the RC1882CEF-IPM
- The RIIM Border router, a complete router that is based on the RC1882CEF-IPM module that
connects the RIIM network to the Internet.
Below is an illustration of the different elements and the documentation available
Figure 1. RIIM network –system and documentation overview
Sub 1 GHz
Mesh
IEEE 802.15.4g/e
IPv6
UDP
CoAP
Ethernet
RC1882-IPM Data sheet
RIIM SDK
RIIM SDK User Manual
RIIM SDK Quick Start Guide
RIIM SDK API reference
RIIM Border Router Data sheet
Network:
- Internet or local network
RIIM User Manual
RC1880-GPR
IPM module
RC1880-GPR
IPM module
RC1880-GPR
IPM module
RC1880-GPR
IPM module
Mesh router
RIIM DEVELOPMENT KIT(DK)
RC1882-RIIM-DK Development Kit User Manual

Page 4of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
Development Kit Introduction
The Development Kit (DK) is designed to make it easy for the user to evaluate the RIIM network and to run
preloaded application or to make a user specific application with minimal time and effort.
This document covers the following kits.
Your Development Kit contains the following items:
Figure 2. Sensor board(left) and development board(middle) and border router board(right)
Kit contents
Item
Number of
articles
Preloaded firmware
Sensor board w/RC1882CEF-IPM module
Development board w/RC1882CEF-IPM module
1
1
Sensor read example
Wireless router example
Border router board w/RC1882CEF-IPM module
Antenna, 50quarter-wave monopole, SMA male connector
1
3
Border router example
USB cable (micro)
USB cable (USB-C)
2
2
This User Manual describes how to use the Development Kit and provides detailed documentation for the Sensor
board and Development board

Page 5of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
Quick Start
The development kit is programmed with an out-of-the box application that allow the user to make wireless
connection and see data coming through the network. The example code pre-loaded on the development kit is
also included in the RIIM SDK.
Sensor Board
Preloaded with an application that automatically joins the network, read on-board
temp/humidity sensor SHT35 and sends data as JSON objects to the border-router-
board.
Development board
Preloaded with a router application that will operate as a mesh device and forward
message. Device auto joins the network.
Border router board
Preloaded with application that starts the network as root node. Packets received to this
device is sent on UART.
Step-by-step setup
Mount antenna on all three boards. (angled antenna on border router board)
Power up the Border router board
Connect PC to console input and open a terminal program to monitor this port (Putty, LookRS232,
Teraterm, YAT etc). Baud rate 115200, 8N1, no flow control.
Power up the Development Board through USB micro connector (Can be powered from PC)
Power up the Sensor Board through USB micro connector (Can be powered from PC)
Observe data being received at border router board though terminal program.

Page 6of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
Figure 3. Log from Border Router Board startup and packet reception(YAT)
Further development
Start making your own custom application
oRead a different sensor
oUse other channels or output power level
oAdd new timer events
oMake events based on button
oMake smart solution by adding intelligence processing on IPM module
oSend downlink messages from gateway to end node
The possibilities are infinite. Details for making your own application can be found in RIIM SDK Quick Start,
RIIM SDK User Manual and RIIM SDK API reference.
The rest of the document goes through the HW in the kit in detail, to allow further development and prototyping
with the kit.

Page 7of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
Border Router Board Introduction
The border router board contains an Ethernet (RJ45) connector, USB connector, USB to serial converter, LEDs,
voltage regulator, power switch and programming/debug connector. All I/O signals are routed to holes at the
edge suitable for 2.54 mm pitch pin headers.
Figure 4: RC1882CEF-IPM Border Router Board
Functional button
LED2
RF Module
USB power
USB for Console, Debug,
FW upgrade
RESET button
Ethernet connector
RF connector
Power on LED
LED1

Page 8of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
Block Diagram
JTAG/
cJTAG
USB to UART
P2s
SMA
P1
USB
Button:
RESET
FUNCTIONAL
P8: JTAG
Programming
Connector
USB
Power LED
RF
3V3OUT
Radiocrafts
Module
UART
P5-P6: 2*10 pins I/O connection, pitch 2.54mm
I/O
LEDs
Figure 5. Block schematic RC1882CEF-IPM-BR
LDO 1 A
P4
USB
power
USB
Ethernet
MAC/PHY
SPI
RJ45
ethernet

Page 9of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
I/O connection
All pins to the module are available through standard pin rows using a pitch distance of 100 mil (2.54 mm).
These pins are connected to 2 x 10 pins holes named P5 to P6. The table below gives an overview of the
edge connectors and their logical signals. Details on the RC1882 pinning can be found in [7].
I/O connection
Connector
PIN
Signal
RC1882 PIN
Note
P5
1
INT
35
2
SPI_MISO
31
3
SPI_MOSI
32
4
SPI_CLK
33
5
SPI_CS
36
6
RESET_ETH
34
7
DIO_9
38
No functional use. Option for debug
8
DIO_10
39
No functional use. Option for debug
9
DIO_11
40
No functional use. Option for debug
10
GND
P6
1
ADC_2
11
2
ADC_1
10
3
SCL
9
4
SDA
8
5
DIO_18
4
6
VCC
27
3.3 V regulated power
7
RXD
6
8
TXD
7
9
Not connected
10
GND

Page 10 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00

Page 11 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
Development Board Introduction
The development board contains an USB connector, USB to serial converter, LEDs, voltage regulator, power
switch and programming/debug connector. All I/O signals are routed to holes at the edge suitable for 2.54 mm
pitch pin headers.
Figure 6: RC1882 Development Board
Antenna connector
sub 1GHz
Module article
number
USB power LED
User LEDs
P1: USB micro
connector
RESET button
Power switch
IO for connector to
external devices
(IPM)
IO for connector to
external devices
(IPM)

Page 12 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
Block Diagram
JTAG/
cJTAG
USB to UA
RT
Regulator
3.3V / 50 mA
P3
SMA
P1
USB
Buttons:
RESET
P8: JTAG
Programming
Connector
USB
VBUS (5V/100mA)
USB
LEDs
RF
Sub
1G
Hz
3V3OUT
Radiocrafts
Module
UART
P4-P7: 4*10 pins I/O connection, pitch 2.54mm
I/O
LEDs
Power
on
switch
Figure 7. Block schematic RC1882CEF-IPM-DB

Page 13 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
I/O connection
All pins to the module are available through standard pin rows using a pitch distance of 100 mil (2.54 mm).
These pins are connected to 4 x 10 pins holes named P4 to P7. The table below gives an overview of the
edge connectors and their logical signals. Details on the RC188x pinning can be found in [7].
I/O connection
Connector
PIN
Signal
RC188x PIN
Note
P4
1
GND
2
RX/TX
25
Not used
3
RESET
26
4
DIO_1
30
5
DIO_2
31
6
DIO_3
32
7
DIO_4
33
8
DIO_5
34
9
DIO_6
35
10
DIO_7
36
P5
1
DIO_8
37
2
DIO_9
38
3
DIO_10
39
4
DIO_11
40
5
DIO_12
41
6
DIO_13
42
7
DIO_14
2
8
DIO_15
3
9
DIO_18
4
10
GND
P6
1
GND
2
DIO_19
5
TXD output (Connected to USB FTDI chip)
3
DIO_20
6
RXD input (Connected to USB FTDI chip)
4
VCC_EXTERN
27
Via EMI bead to RC188X
5
DIO_21
8
6
DIO_22
9
7
DIO_23
10
8
DIO_24
11
9
TMSC
12
10
TCKC
13
P7
1
DIO_16/TDO
14
2
DIO_17/TDI
15
3
DIO_25
16
4
DIO_26
17
5
DIO_27
18
6
DIO_28
19
Not connected for RC1885. Module pin 19-21 are RF port
for 2.4 GHz.
7
DIO_29
20
8
DIO_30
21
9
Not connected
10
GND

Page 14 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
Sensor Board Introduction
The Sensor Board includes the module to be evaluated. In addition it contains other circuitry needed for powering
and communication to the module. All I/O signals are routed to holes at the edge suitable for 2.54 mm pitch pin
headers for easy monitoring and control externally.
The board includes 6 different sensors and a controllable LED to demonstrate GPIO control options.
Sensor
Manufacturer
Sensor Type
SHT35
Sensirion
Precision Temperature and Humidity Sensor
HDC2010
Texas Instruments
Low Power Temperature and Humidity Sensor
BME680
Bosch Sensortech
Environmental sensor
ALS-PT-315C
Everlight
Analogue Light Sensor
SL353LT
Honeywell
Hall detector
LIS3DE
ST
Accelerometer
Figure 8: Sensor Board
Antenna connector
sub 1GHz
Radiocrafts
Module
Power LED
LED/GPIO
P1: USB TO PC
RESET
BUTTON
Connector holes
P4/P5
Connector holes
P6/P7
Power selection
P13: USB power

Page 15 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
Block Diagram Sensor Board
USB to UA
RT
Regulator
3.3V / 50 mA
P3
SMA
P1
USB
Buttons:
RESET
P14 :Programming
Connector
USB
VBUS (5V/100mA)
POWER
LED
RF Sub
1GHz
3V3OUT
Radiocrafts
Module
UART
P4-P7: 4*10 pins I/O connection, pitch 2.54mm
I/O
LEDs
Power
Selector
Figure 9. Block schematic Sensor board
P1 USB
Power
LDO
HDC2010
SHT35
BME680
I2C
Light
sensor
ADC
LIS3DE
SPI
HALL
Sensor
I/O

Page 16 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
Powering the Sensor Board
The sensor board can be power in several different ways, thus giving flexibility and ease of use.
Power source
Jumper position/RED
Comment
USB power 1A
VCC - VCC_EXT
Make sure to use a USB power source
capable of 1 A. A PC does normally not offer
that high current
Extern Volt 4-11 V
/9V battery
VCC - VCC_EXT
Connect through pin holes at edge. Here a
9V battery can also be connected.
NB: Using VCC > 6V, continuous
transmission test mode cannot be used.
Battery 3.0/3.6V
VCC - OFF/BAT
Battery can be connected
USB PC
VCC –VCC_PC
The sensor board is setup with a green power on LED, D1. This draws 2 mA and is always on. In case of
using the sensor board for battery operated proof of concept, this LED need to be removed to ensure low
power consumption
Controlling and Configuring Sensor Board
The sensor module can be controlled and configured through UART. For ease of use the UART is connected
through a UART-to-USB bridge from FTDI and to a micro USB contact.
By connecting a computer to this USB connector on the sensor board, a terminal emulator program can be
used to communication with the module. There is also a config button on the board to easily put the module in
configuration mode. See datasheets Error! Reference source not found. and user manual for details on
ommunication via UART.

Page 17 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
I/O Connection
All pins to the module are available through standard pin rows using a pitch distance of 100 mils (2.54 mm).
These pins are connected to 4 x 10 pins holes named P4 to P7. The table below gives an overview of the
edge connectors and their logical signals. Details on the pinning can be found in module datasheet.
I/O connection
Connector
PIN
Signal
Module (Sensor
board)
Module
PIN
Note
P4
1
GND
2
VCC
Not used
3
RESET
4
Not used
Internally connected –Do not use
5
GPIO8
34
6
GPIO7
35
7
GPIO6
36
8
GPIO5
37
9
SPI_MISO
31
10
SPI_MOSI
32
P5
1
SPI_CLK
33
2
GPIO4
38
3
GPIO3 (SPI_CS)
39
4
GPIO2 (HALL_OUT)
40
5
GPIO1 (DRDY)
41
6
GPIO0 (LED_1)
42
7
CTS
2
8
RTS
3
9
VCC_4_11V
Not connected to module
10
GND
P6
1
GND
2
BSL
4
3
TXD
5
TXD output (Connected to USB FTDI chip)
4
RXD
6
RXD input (Connected to USB FTDI chip)
5
VCC
27
Via EMI bead to module
6
SDA
8
7
SCL
9
8
ADC0
(LIGHT_OUT_ANALOG)
10
9
ADC1
11
10
TMSC
12
JTAG programming interface. Do not use.
P7
1
TCKC
13
2
TDO
14
3
TDI
15
4
SENS_1
16
Reserved for future use.
5
SENS_2
17
6
SENS_3
18
7
PA_CTR
19
8
PA_CTR
20
9
PA_CTR
21
10
GND

Page 18 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
I/O Silkscreen (revision 1.0)
On revision 1.0 of the sensor board there are some inaccuracies in the silkscreen print.
GPIO numbering is wrong and ADC1 marking is missing. Marking of RXD/TXD are offset.
See below
ADC1
ADC0
0
1
2

Page 19 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
SHT35 Temperature and Humidity Sensor
SHT35 is the next generation of Sensirion’s temperature and humidity sensors. It has a typical accuracy of ±
1.5 %RH and ± 0.1 °C. It connected to sensor module by I2C and is setup with I2C address 0x44.
HDC2010 Low Power Temperature and Humidity Sensor
The HDC2010 is an integrated humidity and temperature sensor from Texas Instruments, with very low power
consumption and in an ultra-compact package. I has an accuracy of ± 2 %RH and ± 0.2 °C. It connected to
sensor module by I2C and is setup with I2C address 0x40.
The data ready pin is connected to the GPIO-2 of the sensor module.
BME680 Environmental sensor(revision 1.0 only)
BME680 is an integrated environmental sensor developed specifically for mobile applications and wearables
where size and low power consumption are key requirements. The sensor reads is a 4-in-1 sensor that
measure gas, humidity, pressure and temperature. It connected to sensor module by I2C and is setup with I2C
address 0x76.
ALS-PT-315C, Analogue Light Sensor
The ALS-PT-315C is light sensor that gives an analogue output based on the illuminance (Lux). The output is
connected to the analogue input of the sensor module. On the sensor board this sensor is always on.

Page 20 of 27
USER MANUAL RC1882-RIIM-DK DEVELOPMENT KIT
2019 Radiocrafts AS
User Manual RC1882-RIIM-DK Development Kit Rev. 1.00
SL353LT Hall Detector
The SL353LT is a state-of-the art hall detector that enable magnetic detection. It has a very low power
consumption of 1.8 uA in average for 2.8V operation. The output of the hall detector is connected to GPIO-3
on the sensor module.
LIS3DE Accelerometer
The LIS3DE is an ultra-low-power high-performance 3-axis linear accelerometer belonging to the “nano”
family, with digital I2C/SPI serial interface standard output. The device features ultra-low-power
operational modes that allow advanced power saving and smart embedded functions.
It is connected to the sensor module via the SPI and GPIO-4 is the chip select pin.
Blue LED
There is a blue LED on the board (D2) that is connected to GPIO-1 of the sensor module. This is used to
demonstrate the GPIO output control capabilities of the sensor module.
