Radioddity DB25-D Service manual

© Radioddity 2023 page 1 of 252
V3.0, September 23rd, 2023
Extended Manual for
DB25-D, DB40-D & GD-88

Radioddity Extended manual for Radioddity DB25-D, DB40-D & GD-88 v3.0
© Radioddity 2023 page 2 of 252
Please note that some of the features described within this Extended Manual are
available in digital mode whereas other features are available in analog mode
only. Besides that, not all radios do have the very same features. Our flagship
radio, the Radioddity DB40-D does come with the most features. In order to easy
identify those differences, we do use the following icons throughout this manual:
Described functionality is only available for digital DMR channels
Described functionality is only available for analog channels
The described function/feature is only available for the
Radioddity DB25-D.
The described function/feature is only available for the
Radioddity DB40-D.
The described function/feature is only available for the
Radioddity GD-88.

Radioddity Extended manual for Radioddity DB25-D, DB40-D & GD-88 v3.0
© Radioddity 2023 page 3 of 252
