Radwin TERRABRIDGE User manual

INSTALLATIONGUIDE
Cat.No/Rev.
TERRABRIDGE
Rel.y.z
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 1‐1
TableofContents
Chapter1:Introduction
1.1ScopeofthisDocument ...................................................................................................... 1‐1
1.2Overview ............................................................................................................................. 1‐1
1.3BasicWorkingModel .......................................................................................................... 1‐1
1.4MainFeatures ..................................................................................................................... 1‐1
1.5MechanicalSpecifications ................................................................................................... 1‐2
Chapter2:InstallationSteps
2.1PrepareLaptop.................................................................................................................... 2‐2
2.2ConnectLaptoptoRadioUnit ............................................................................................. 2‐2
2.3UpdateConnectivityParametersofRadioUnit .................................................................. 2‐3
2.4PrepareItemstobeInstalled .............................................................................................. 2‐3
2.5PrepareTools ...................................................................................................................... 2‐4
2.6PrepareRailroadCar ........................................................................................................... 2‐4
2.7PreparePoE......................................................................................................................... 2‐5
2.8MountUnit.......................................................................................................................... 2‐6
2.8.1WithouttheBasePlate ............................................................................................... 2‐6
2.8.2WiththeBasePlate..................................................................................................... 2‐9
2.9GroundUnit....................................................................................................................... 2‐11
2.9.1WiththeBasePlate................................................................................................... 2‐12
2.9.2WithouttheBasePlate ............................................................................................. 2‐12
2.10ConnectRadio ................................................................................................................. 2‐12
2.11CheckConnectivitytoRadio............................................................................................ 2‐13
2.12VerifyLink........................................................................................................................ 2‐13
AppendixA:CertifiedAntennas
A.1ForDeploymentinUS/Canada............................................................................................ A‐1
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuide Releasey.z 1‐1
Chapter1:Introduction
1.1ScopeofthisDocument
ThisdocumentshowshowtoinstallandconfiguretheTerraBridgeradiounits.
1.2Overview
TerraBridgeisamillimeter‐waveradiounitthatprovidesupto1.5Gbpsaggregatedwireless
connectivitybetweenrailroadcars.TheproductenablesGbpsEthernetnetworkthroughout
thetrain,seamlesslysupportingdynamicchangesinthetrainconsist.
TheunitcomplieswithoutdoorspecIP‐69K.Itissmallandlightweight,whichallowsittobe
mountedoutofthewayinconvenientlocations.
1.3BasicWorkingModel
Showtwotraincars,withtwoTerraBridgesoneach.
ShowhoweachTerraBridgeisconnectedtothenetworkandpowerfromwithinthetrain
car.
MentiontheGUI.
1.4MainFeatures
Radiobasedon802.11adstandardinmm‐wavesunlicensedband
Capacityofupto1.5Gbpsaggregated
Spectrum:mmWave/60GHz
Throughput:1.5Gbps
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuide Releasey.z 1‐2
MechanicalSpecifications Introduction
Delay:1‐3msec
Power:PoEGbEinterface,802.3af
Connector:M‐12X‐codedconnector
Environmental:IP69(highpressurewaterjetat80degC)
Railwaystandards:EN50155,EN50121andEN61373,IEC60571
Antenna:Integratedinsidetheradiounit
1.5MechanicalSpecifications
ShowamechanicaldrawingincludingthelocationsofthescrewsandtheM12X(PoE)
connection
Size(HxWxD):12x12x2.25cm
Weight
OperatingTemperature
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐1
InstallationSteps InstallationSteps
Chapter2:InstallationSteps
Toinstallandestablishabasicconnectionwitharadiounit,carryoutthestepsshownbelow.
Printoutthislist,andplaceacheckmarknexttoacompletedtask.
Table2‐1:InstallationCheck‐List
Step Action Page Done?
Beforedeployingatinstallationsite
1. PrepareLaptop page 2‐2
2. ConnectLaptoptoRadioUnit page 2‐2
3. UpdateConnectivityParametersofRadioUnit Page 2‐3
4. PrepareItemstobeInstalled Page 2‐3
5. PrepareTools Page 2‐4
Installation
6. PrepareRailroadCar Page 2‐4
7. PreparePoE Page 2‐5
8. MountUnit Page 2‐6
9. GroundUnit Page 2‐11
10. ConnectRadio Page 2‐12
Commissioning
11. CheckConnectivitytoRadio Page 2‐13
12. VerifyLink Page 2‐13
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐2
PrepareLaptop InstallationSteps
2.1PrepareLaptop
ConfigureIPaddressandsubnetmaskoflaptopasfollows:
•ControlPanel‐>NetworkandInternet‐>NetworkandSharingCenter‐>Change
Adaptersettings‐>clickonNetworkInterfaceCardname
•Properties‐>SelectInternetProtocolVersion4(TCP/IPv4)‐>Properties‐>setIPaddress
to10.0.0.100andSubnetmaskto255.255.255.0
2.2ConnectLaptoptoRadioUnit
ConnectPoEtopower,connectthelaptop’sethernetporttotheIN(orLAN)socketonthe
PoE,thenconnecttheOUT(orPoE)socketonthePoEtotheM‐12Xportontheradiounit.
MakesureyouareusingtheappropriatePoEforyourspecificradiounit.
Connectinglaptoptoaradiounit
RadioUnit
Power
PoE
CAT‐5ecable
Out
In
CAT‐5ecablewith
M‐12Xcodedconnector
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐3
UpdateConnectivityParametersofRadioUnit InstallationSteps
Connectto‐>Inputsocket(notlabeled)
Figure2‐1:Laptop/networkport:TerraBridgeradiounit
2.3UpdateConnectivityParametersof
RadioUnit
MakesureyouhaveGoogleChromeorMicrosoftEdgeinstalled
Logontothedeviceviawebbrowser–http://10.0.0.130/(defaultIP)
Entertheusername–root
Enterthepassword–admin
Youwillbeprompttochangetheusernameandpasswordforthefirst‐timelogin
Under“Setting”“NetworkSettings”configurethedeviceIP(DHCP/Static)
Under“Settings”“System”configuredeviceNTPserverIP
Addafewscreenshere
2.4PrepareItemstobeInstalled
•Radiounit(includingmountingplate)
•Screwsandbolts
Inputsocket
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐4
PrepareTools InstallationSteps
•PoE(ifused),includingethernetcablewithM12Xconnector
•Ethernetcables
•Groundingcable(10AWG)
2.5PrepareTools
•Crimpingtool
•Spanner/wrench13mm(1/2”)
•Cableties
•DrillandappropriatebitstomakeholesforPoEandbolts
2.6PrepareRailroadCar
1. Determinewhereonthecarstheunitswillbefastened.
•Itisrequiredthatyouchooseaspecificlocationandkeepthatlocationforallcarsthat
willreceivetheTerraBridge.
•Werecommendusingtwounitsoneachcar(seeFigure 2‐2,Twounitsoneachcar).
•Theunitsmustbeoppositeeachother.
Figure2‐2:Twounitsoneachcar
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐5
PreparePoE InstallationSteps
Figure2‐3:Viewfromabove
Figure2‐4:Viewfromtheside
2.7PreparePoE
YoucanuseaRADWIN‐suppliedPoEunit,orthepowersupplyonthecarfulfillingthe
followingcriteria:
PoEGbEinterface,802.3af.
Opposite
Opposite
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐6
MountUnit InstallationSteps
2.8MountUnit
Youcanmounttheunitwiththebaseplateorwithoutthebaseplate.
2.8.1WithouttheBasePlate
1. NotewhereonthetraincaryouhavedeterminedtoinstalltheTerraBridgeunit.
2. UsingthescrewsfromthebodyoftheTerraBridgeunit,installthemfromtheinternalside
ofthewall:
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐7
WithouttheBasePlate InstallationSteps
3. Insertscrews(internalsideofwallshown):
4. DrillholeforPoEconnection:
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐8
WithouttheBasePlate InstallationSteps
5. Fastenunittoscrewsonwall:
6. ConnectPoEcableandground(internalsideofwallshown):
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐9
WiththeBasePlate InstallationSteps
2.8.2WiththeBasePlate
1. Connectbaseplateandexternalsealinggaskettounit.
2. NotewhereonthetraincaryouhavedeterminedtoinstalltheTerraBridgeunit.
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐10
WiththeBasePlate InstallationSteps
3. Drillholesforscrews:
4. DrillholeforPoEconnection:
5. Fastenunittoscrewsonwall:
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐11
GroundUnit InstallationSteps
6. ConnectPoEcableandground(interioroftrainwallshown):
2.9GroundUnit
Connecta10AWGcabletooneofthemountingscrewsontheplate,oroneoftheinner
screws.Thisdependsonifyouareusingthebaseplateornot.
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐12
WiththeBasePlate InstallationSteps
2.9.1WiththeBasePlate
2.9.2WithouttheBasePlate
2.10ConnectRadio
Connectspecialcablethatwesupply,withPoEoron‐boardsupply.
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. 2‐13
CheckConnectivitytoRadio InstallationSteps
2.11CheckConnectivitytoRadio
Pingtheinstalledunit.
Showfigure
2.12VerifyLink
I’mnotsureweneedthis,butit’sinthePPpresentation,soI’maddingithere.
Installseconddevicebyrepeatingstep1‐2
MakesurenottousethesameIP(forexample–10.0.0.131)
Oncethedeviceisconfigured,facethe2devicesoneanother(distance30cm‐50cm)
ConnectyourPCtotheunitviaaPoE,eitherdirectly,orviayourlocalnetwork
Pingfromdevice1todevice2toconfirmconnectivity
Logintobothdevices(webUI)toverifylinkstatusfromthe“Dashboard”tab
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. Releasey.z A‐1
AppendixA:Certified
Antennas
A.1ForDeploymentinUS/Canada
TerraBridgebearsthefollowingFCC/ICIDsonthelabel,refertothetablebelow:
FCCID:Q3K‐TRBR600G
IC:5100A‐TRBR600G
TerraBridgemustbeinstalledsoastoprovideaminimumseparationdistancefrom
bystandersasspecifiedinthetablebelow:
TableA‐1:FrequencyBand60GHz
Gain(dBi) EIRP(dBm) Min.SafeDistance
(cm)
19 27.0 20
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. B‐1
RegulatoryCompliance
GeneralNote
ThissystemhasachievedTypeApprovalinvariouscountriesaroundtheworld.Thismeans
thatthesystemhasbeentestedagainstvariouslocaltechnicalregulationsandfoundto
comply.Thefrequencybandsinwhichthesystemoperatesmaybe“unlicensed”andinthese
bands,thesystemcanbeusedprovideditdoesnotcauseinterference.
Forinformationontherestrictionsonputtingthedeviceintoservicepleasecontactyour
nationaltelecommunicationauthorities.
FCC/ISED‐Compliance
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable
protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipment
generates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedin
accordancewiththeinstructions,maycauseharmfulinterferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.If
thisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcan
bedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrect
theinterferencebyoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe
receiverisconnected.
Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Changesormodificationstothisequipmentnotexpresslyapprovedbythepartyresponsible
forcompliancecouldvoidtheuser'sauthoritytooperatetheequipment.
Thisdevicecontainslicence‐exempttransmitter(s)/receiver(s)thatcomplywithInnovation,
ScienceandEconomicDevelopmentCanada'slicence‐exemptRSS(s).Operationissubjectto
thefollowingtwoconditions:
1. Thisdevicemaynotcauseinterference.
2. Thisdevicemustacceptanyinterference,includinginterferencethatmaycause
undesiredoperationofthedevice.
L'émetteur/récepteurexemptdelicencecontenudansleprésentappareilestconformeaux
CNRd'Innovation,SciencesetDéveloppementéconomiqueCanadaapplicablesauxappareils
radioexemptsdelicence.L'exploitationestautoriséeauxdeuxconditionssuivantes:
1. L'appareilnedoitpasproduiredebrouillage;
FOR REGULATORY USES ONLY

TerraBridgeInstallationGuideCat.No/Rev. B‐2
2. L'appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesilebrouillage
estsusceptibled'encompromettrelefonctionnement.
RFExposure
Forthesafetyofthegeneralpublicitisrecommendedtokeepaminimumsafedistancefrom
radiatingantennasaccordingtoTableA‐1.
Pourlasécuritédugrandpublic,ilestrecommandéderespecterunedistancedesécurité
minimaleparrapportauxantennesrayonnantes,conformémentautableauTableA‐1.
IndoorUnitscomplywithpart15oftheFCCrules.Operationissubjecttothefollowingtwo
conditions:
(1)Thesedevicesmaynotcauseharmfulinterference.
(2)Thesedevicesmustacceptanyinterferencereceived,includinginterferencethatmay
causeundesiredoperation.
OutdoorunitsandantennasshouldbeinstalledONLYbyexperienced
installationprofessionalswhoarefamiliarwithlocalbuildingandsafety
codesand,whereverapplicable,arelicensedbytheappropriate
governmentregulatoryauthorities.Failuretodosomayvoidtheproduct
warrantyandmayexposetheenduserortheserviceprovidertolegaland
financialliabilities.Resellersordistributorsofthisequipmentarenot
liableforinjury,damageorviolationofregulationsassociatedwiththe
installationofoutdoorunitsorantennas.Theinstallershouldconfigure
theoutputpowerlevelofantennasaccordingtocountryregulationsand
antennatype.
Lesunitésextérieuresetlesantennesdoiventêtreinstallées
UNIQUEMENTpardeslesprofessionnelsdel'installationquiconnaissent
lebâtimentetlasécuritélocauxcodeset,lecaséchéant,sontautorisés
parlesautoritéscompétentesautoritésderéglementation
gouvernementales.Nepaslefairepeutannulerleproduitgarantieetpeut
exposerl'utilisateurfinaloulefournisseurdeservicesàdespassifs
financiers.Lesrevendeursoudistributeursdecetéquipementnesontpas
responsabledesblessures,desdommagesoudelaviolationdela
réglementationinstallationd'unitésextérieuresoud'antennes.
L'installateurdoitconfigurerleniveaudepuissancedesortiedesantennes
selonlesréglementationsdupaysettyped'antenne.
•WhereOutdoorunitsareconfigurablebysoftwaretoTxpowerval‐
uesotherthanthoseforwhichtheproductiscertified,itisthe
responsibilityoftheProfessionalInstallertorestricttheTxpowerto
thecertifiedlimits.
•Thisproductwastestedwithspecialaccessories‐indoorunit(IDUor
PoE),FTPCAT‐5eshieldedcablewithsealinggasket,16AWGground‐
ingcable‐whichmustbeusedwiththeunittoinsurecompliance.
FOR REGULATORY USES ONLY
