Rae UltraRAE 3000 User manual

Using the
UltraRAE 3000

UltraRAE 3000
UltraRAE 3000
Lamp Range Resolution
10.6 eV 50 ppb to 10,000 ppm (VOC mode) 50 ppb
9.8 eV 50 ppb to 200 ppm, for benzene and butadiene;
50 ppb to 5,000 ppm (VOC mode)
50 ppb
11.7 eV 50 ppb to 2,000 ppm (VOC mode) 50 ppb

Agenda
• User Interface
• Turning on the UltraRAE 3000
• Recommended daily start-up procedure
• Hygiene mode & displays
• Alarm signals
• Programming mode
• Charging station

User Interface
• User Interface:
– [Y/+] tests alarms
– [N/-]
– [MODE] (on)
– Flashlight on/off key
Display
MODE key
Flashlight
on/off key
LEDs and flashlight

Control Buttons
• [Y/+] always controls left-hand response & increases
numerical values
• [N/-] controls right-hand response & moves to next digit
• [MODE] controls center & returns to previous menu

Start-up: Turning On
• Press and hold [MODE]
• When display appears,
release [MODE] key
• Instrument performs self-
test
• Final display shows and
unit is ready for zero
calibration

Start-up: Programmable Zero Calibration
• Unit performs Zero calibration after warm-up
• “apply zero gas…”
• If in fresh air, the UltraRAE can be calibrated, or
a Zeroing kit with charcoal tube can be used

Test Pump
• To ensure that there are no leaks,
periodically test the seals.
• With the UltraRAE 3000 running, place
your finger over the end of the inlet probe.
• The alarm should sound and the pump-
stall icon should flash on the display.
• This indicates that all seals are good. Stop
the alarm by pressing [Y/+].

Test Pump
• If the pump does not alarm or show the
stalled-pump icon, then check that all inlet
parts are tight and inspect the O-ring for
damage (replace it if necessary).
• After inspection and/or replacing, test
again.
• If there is still no alarm, send instrument in
for pump service.

Start-up: Programmable Zero calibration
