Model DL-ATG Operating Instructions P/N 889-4300-00
1
2
MODEL DL-ATG
TWO CHANNEL ANTI-TAILGATING LOOP DETECTOR
OPERATING INSTRUCTIONS
I General
The model designation indicates the number of lanes covered by each loop.
Model DL-ATG-x
1 = Single Lane
2 = Two Lane
The Model DL-ATG is a two channel detector designed to accurately count vehicles and identify their direction of travel over two
small inductive loops, even if they are tailgating. Please note that the Model DL-ATG has been specifically designed and tested to
count and/or identify passenger vehicles.
The Model DL-ATG accumulates directional vehicle counts that are displayed on the front panel Liquid Crystal Display (LCD). The
Model DL-ATG has 4 relay outputs; 2 for loop presence, 1 for counting in the AB direction, and 1 for counting in the BA direction.
Prior to initial operation, the Model DL-ATG detector must be calibrated. Connect the detector to an appropriately wired harness
and apply power. Follow the instructions outlined under Calibration on page 2 to calibrate the detector.
II Controls
i Push Buttons
A

B Count
When pressed the LCD screen displays the number of vehicles that have traveled over the loops in the AB direction. This
accumulator is capable of accumulating up to 99,999 directional counts. The display will show the hundreds, tens, and ones digits
until the accumulated count exceeds 999. At this point the display will alternate between the ten thousands and thousands digits and
the remaining three digits for hundreds, tens, and ones. Loss of power will not reset this number. The AB accumulator is indicated
by the symbol on the bottom of the LCD screen.
B

A Count
When pressed the LCD screen displays the number of vehicles that have traveled over the loops in the BA direction. This
accumulator is capable of accumulating up to 99,999 directional counts. The display will show the hundreds, tens, and ones digits
until the accumulated count exceeds 999. At this point the display will alternate between the ten thousands and thousands digits and
the remaining three digits for hundreds, tens, and ones. Loss of power will not reset this number. The BA accumulator is indicated
by the symbol on the bottom of the LCD screen.
Count Reset
When pressed, both AB and BA Count accumulators are reset to zero.
Loop Fail
When pressed, the LCD screen displays the count of past failures for each loop. The LCD will display the text “LOOP FAIL” and a
channel indicator icon for Channel A or for Channel B. These numbers reset to 0 for both channels on power down, or when
Detector Reset is pressed.
Diagnostics
When pressed the LCD screen continuously displays the Loop Inductance value L= in microhenries (µH). When a vehicle is detected
the LCD displays the percentage of inductance change -ΔL/L= value. When this feature is activated a single audible beep sounds for
vehicles traveling in the AB direction. A double audible beep sounds for vehicles in the BA direction. Pressing the Diagnostics
button again while viewing Diagnostics will toggle between Channel A and Channel B. This Diagnostic display will turn OFF after
15 minutes and return to the AB Count display.
Detector Reset
When pressed both channels are reset. Detector Reset will clear the loop fail accumulators, and any prior loop fail indication.
Detector Reset does not reset the count accumulators.
1
2
1
3510 E. Atlanta Ave.
Phoenix, AZ 85040 USA
Telephone: [phone]
Fax: [phone]
Website: www.editraffic.com
E-mail: [e-mail]

Model DL-ATG Operating Instructions P/N 889-4300-00
III Loop Orientation
i DL-ATG-1
The DL-ATG-1 version of the detector accurately counts directional vehicles in a single lane of traffic with loop spacing of 8 feet from
leading edge to leading edge. Loop spacing may vary from a minimum of 2 feet from leading edge to leading edge (overlapping by
six inches) to a maximum of 12 feet from leading edge to leading edge. Count accuracy at high speed (30 mph) decreases as you
approach the minimum and maximum loop spacing. Vehicles must span both loops to be counted.
Typical loop size is 2.5 feet x 6 feet. The loop size can vary from 2 feet to 4 feet in the direction of travel and 5 feet to 7 feet across
the lane. The loop should have three (3), four (4), or five (5) turns of wire. The detector operates most effectively when each channel
is connected to a single loop. Connecting multiple loops to a single channel is not recommended.
ii DL-ATG-2
The DL-ATG-2 version of the detector accurately counts directional vehicles in two lanes of traffic with loop spacing of 8 feet from
leading edge to leading edge. Loop spacing may vary from a minimum of 2 feet from leading edge to leading edge (overlapping by
0.5 feet) to a maximum of 12 feet from leading edge to leading edge. Count accuracy at high speed (30 mph) decreases as you
approach the minimum and maximum loop spacing. Vehicles must span both loops to be counted.
Typical loop size is 2.5 feet x 18 feet. The loop size can vary from 2 feet to 4 feet in the direction of travel and 12 feet to 24 feet
across the lane. The loop should have two (2), three (3), or four (4) turns of wire. The detector operates most effectively when each
channel is connected to a single loop. Connecting multiple loops to a single channel is not recommended.
IV Calibration
Calibrating the detector will automatically select the proper frequency and sensitivity for each channel. The detector ships from the
factory ready to be calibrated for first time use. Once power is applied and there are no loop failure indications, the LCD displays
CAL. To calibrate the detector, place the Reno A&E Calibration Loop (not included with the detector) on the ground at least two feet
away from the inductive loop. Slowly drag the calibration loop over the entire detection area of the inductive loops. The calibration is
finished when the calibration loop has been detected over both channels and there is no presence detected on the loops for
approximately five (5) seconds. Once the calibration process has successfully been completed, the display will revert from CAL to
Count AB. Please note that once the calibration process has been initiated there is no way to cancel the calibration procedure. To
enter into calibration mode after initial calibration, press and hold the Detector Reset button for 10 seconds until the LCD Display
reads CAL.
NOTE: Proper calibration is essential for accurate detection of tailgating vehicles. It is critical that vehicles do not pass over the
inductive loop while calibration is in progress.
V Loop Fail
Any time a channel failure occurs the LCD Display will indicate what type of failure has occurred on the channel. The LCD will
display L lo for low loop inductance and shorted loop situations or L hi for high loop inductance and open loop situations. When
there is a failure on both channels the display will toggle between the channels every 5 seconds displaying the fail status of each
channel. Upon failure, the presence Output Relay for that channel will enter into the Fail Safe Mode, indicating presence on that
channel. In addition to the LCD display indication, and the Presence Output Relay, the corresponding channel’s Presence LED will
flash three flashes per second. If the loop self-heals, the Presence Relay and LCD will resume normal operation while the LED will
continue to flash until the loop fail register is cleared by a Detector Reset or by cycling power.
VI Pin Connections
(Reno A&E Wiring Harness Model 804)
Pin
Wire Color
Function
A
White
Power, Neutral, 120 VAC
B
Gray/Black
BA Count, Relay Common
C
Black
Power, Line, 120 VAC
D
Brown
Channel A Loop Input
E
White/Brown
Channel A Loop Input
F
Red
Channel B Loop Input
G
White/Red
Channel B Loop Input
H
Green
Chassis Ground
J
Orange
No Connection
K
White/Orange
No Connection
L
Yellow
No Connection
M
White/Yellow
No Connection
N
White/Blue
Channel A Presence, Relay Normally Open
P
Blue
Channel A Presence, Relay Common
R
Violet
AB Count, Relay Common
S
White/Violet
AB Count, Relay Normally Open
T
Gray
Channel B Presence, Relay Common
U
White/Gray
Channel B Presence, Relay Normally Open
V
White/Black
BA Count, Relay Normally Open
NOTE:All pin connections listed above are with power applied, loop connected, and no vehicle detected.
To calibrate the detector, drag the calibration
loop slowly (5 seconds in each loop) through
both loops three times with CAL on.
Calibration Loop Start
Inductive Loops

Model DL-ATG Operating Instructions P/N 889-4300-00
