Rain soft Airmaster dfs User manual

06/09

2080 E. Lunt Ave. Elk Grove Village, IL 60007

P one: 1-800-860-7638 • Fax: 1-847-437-5539

To find your local RainSoft dealer visit www.rainsoft.com

Portable Room Air Cleaner

o w n e r ’s m a n u a l

Please Note:

Your RainSoft®Airmaster DFS Advanced Air Purifier has been carefully packaged to avoid damage in shipping

and storage. Retain this packaging.

Please inspect your unit to insure that you receive the product free of any visible signs of damage. If you detect

any damage, you should file a claim with the shipping company or carrier within 15 days of receipt.

The RainSoft®Airmaster DFS Advanced Air Purifier is designed for “plug and play” operation and comes

complete, ready for use. Simply follow the instructions for set up contained in this ownerʼs manual.

To receive maximum benefit from the RainSoft®Airmaster DFS Air Cleaner, we recommend replacing the DFS

main filter every 12 to 16 months and the multi-stage filter every 12 months.

mportant Safety Precautions

Please read all instructions before operating our air purifier. Basic precautions should alwa s be observed

when using electric appliances to reduce the risk of fire, shock and injur .

Observe the following general precautions to insure effective, safe and trouble-free operation of your

RainSoft®Airmaster DFS Air Cleaner.

Warning: This air purifier must be plugged into a 120 Volt, AC earth

grounded outlet. Do not use this air purifier with a wall outlet

adapter. Do not operate this air purifier with an extension cord.

1. Plug the unit D RECTLY into an earth grounded standard 120 volt, AC electrical outlet. Insert the plug into

the outlet fully. The plug is a polarized line plug (one blade is wider than the other) and can only be inserted

one way as a safety feature.

2. Place the unit on a flat and level surface to allow continuous airflow to the bottom intake and out the

top outlet grill.

3. Always unplug the air purifier before moving it, opening the top lid, changing the main filter, changing

the multi-stage filter or before cleaning. (Clean only with a dry, non-static cloth.)

4. Do not place any foreign objects inside the unit because electric shock and injury could result.

5. Do not use the unit if any part is missing or damaged in any way.

6. Do not run power cord under carpeting or near heaters, registers, radiators, stoves or fireplaces.

To avoid a tripping hazard, keep the power cord away from traffic areas.

7. Never operate the air purifier in areas where combustible gases or vapors are present or any other

flammable materials.

8. Never immerse the unit in water or other liquids, spray the air purifier with liquids or clean the air

purifier under running water.

5 Year Limited Warranty

RainSoft Division of Aquion Water Treatment and Air Products, believing its

AIRMASTER DFS SYSTEM

to be of exceptional quality, hereby warrants said equipment to its first purchaser at retail as follows:

Full 5 year warranty on all parts

This warranty begins at the time the equipment is first connected for use, and is contingent upon the return of a signed owner's registration card.

This warranty does not require replacement of the entire unit. If the equipment does not perform properly, you should request service from the dealer

that sold you the equipment. If you are not satisfied, you should notify our Customer Service Manager. If we are not able to arrange local servicing,

you should send the defective part(s) (or, if you prefer, send the entire unit,) directly to the manufacturer, freight prepaid, with proof of purchase and

a copy of this warranty. The defective part(s) (or entire unit) will either be repaired or new RainSoft part(s) furnished, for a nominal charge to cover

labor, handling, packing and the increase, if any, in the retail price of the part(s) since the date of purchase. Genuine RainSoft parts must be used.

Failure to use genuine RainSoft parts will void the warranty and certifications.

This warranty does not include labor charges, filters or replacement filters, and does not cover installation, transportation, or any other claims or torts.

Some states do not allow the exclusion or limitation of incidental or consequential damages, so parts of the above limitation or exclusion may not apply

to you.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. ou also have implied warranty rights.

In the event of a problem with warranty service or performance, you may be able to go to a small claims court, a State court, or a Federal District Court.

This warranty is void if equipment is not installed and operated according to instructions. It does not apply to damage caused by abuse, accident,

neglect, freezing, fire, or other abnormal conditions beyond the company’s control. This warranty is void on any part from which the manufacturing

date has been removed or made illegible.

Benefits will be provided by various types of RainSoft equipment when installed and operated according to the manufacturer's recommendations.

Operational, maintenance and replacement requirements are essential for the product to perform as advertised. All claims are based on the best

available information at the time of printing. Manufacturer makes no representations as to the suitability of this equipment for a particular application.

Buyer relies entirely on the Dealer's recommendations in the purchase of this equipment.

Independent RainSoft Dealers may include, together with your RainSoft product, a product or component that is not manufactured by RainSoft or

their parent company, AWTP, LLC. Any non-RainSoft product may be covered by the manufacturer of that product, and is not covered by the

RainSoft warranty. AWTP, LLC does not warrant that your RainSoft product and the non-RainSoft product will perform properly when used

together, and assumes no liability therefore.

RainSoft Division of Aquion Water Treatment Products

2080 East Lunt Avenue

Elk Grove Village, Illinois 60007 USA

5 2

Unit will not turn ON • Is the unit plugged into a “working”

120 Volt, AC, earth grounded outlet?

• Is the unitʼs top cover in place, and

snapped shut?

• Is the ain Filter locked in place,

with the ain Filter locking handles

facing toward the center of the unit?

Unit is ON, but no speed change • Call RainSoft®Airmaster Customer Service.

ain Filter light is OUT • Replace ain Filter.

• ain Filter has reached its contaminant holding capacity.

Bio onitor light is out • Call RainSoft®Airmaster Customer Service.

• Dust has accumulated on the electric grid.

• Unplug the systems and remove the main filter.

Use a Q-tip with denatured alcohol to clean the

wires then reassemble.

RainSoft®Airmaster DFS offers a five-year limited warranty on all consumer products.

1) Retain proof of purchase and the original box and packaging materials.

2) ail Warranty Registration Card within 10 days of date of original purchase.

1) Fax Warranty Registration Card within 10 days of date of original purchase, fax 1-847-437-5539.

2) To make a product claim, call 1-800-860-7638 to obtain a warranty claim number.

Product Registration:

RainSoft®Airmaster DFS makes this Five (5) Year Limited Warranty (“Limited Warranty”) ONLY to the original

retail purchaser who completes the enclosed Warranty Registration Card within ten (10) days of purchase

and faxes it to: 1-847-437-5539; or mail it to: RainSoft®Airmaster DFS 2080 E. Lunt Ave., Elk Grove Village,

IL 60007

Trouble Shooting Guide:

Symptom Check / Remedy mportant Safety Precautions (continued)

9. The air purifier is designed for indoors, do not use this air purifier outdoors.

10. Do not operate this unit with a damaged cord or plug, or after the unit malfunctions or has been

damaged in any manner. Contact your local RainSoft dealer for servicing instructions. To find your local

dealer, visit www.rainsoft.com.

11. This unit is designed for residential use only. Do not use in industrial or severe

commercial applications.

12. A short power supply cord is provided to reduce the risk resulting from becoming entangled in or

tripping over a long cord. Do not use extension cords with this unit.

WARNING: To prevent fire or shock hazard, do not expose this unit to rain or moisture.

Electronic Control Panel -

• Service Light - indicates when unit requires service

• Bio- ontior Light - shows DFS germ killing zone is working at peak efficiency

• Convenient three speed control

• Low speed - ULTRA quiet air flow mode

GERM K LL NG ZONE!

• 98-100% of viruses

• 98-100% of bacteria

• 94-100% of mold & fungi

100% Sealed Filtration -

All incoming air is treated

in the 100% sealed filter chamber.

DFS Filter - Better than 99.99%

particle capture at 0.3 microns.

4 x the particle reduction as a

similar sized HEPA filter.

Traps micro-organisms for

germicidal exposure.

Dual Air ntake Blower -

Drives a consistent volume of air

and provides quiet operation.

360˚ air entry design -Allows

placement anywhere ensuring all room

air is treated.

6-Stage Filter -

•Poly Propylene Mesh:

Large particle collector

of dust, hair, and lint.

•Anti-Microbial: Reduces

bacteria growth in filter.

•Carbon Pellets: VOC/Gas

Adsorbent

•Potassium Permanganate:

VOC/Gas Adsorbent

•Anti-Microbial: Reduces

bacteria growth in filter.

•Poly Propylene Mesh: Large particle

collector of dust, hair, and lint.

System is making a clicking or

popping sound.

3 4

Where to Place the Air Purifier:

The RainSoft®Airmaster DFS Air Cleaner is designed as a portable floor model. Place the air purifier anywhere

in the room; being careful not to block air from “entering” the intake grill, or “exiting” the top grill cover.

Do not place the air purifier where drapes or other objects block airflow. For best performance, it is recommended

to place the air purifier at least two (2) feet from walls and other obstructions.

Air Cleaner Operation:

After removing the protective plastic from the unit – plug the unit into a standard 120 volt earth grounded AC

circuit. The control panel lights should be illuminated as follows:

Main Filter - green light is ON

Bio Monitor - green light is ON

The RainSoft®Airmaster DFS indicator light system is an all “green” system.

When the unit is operating properly, both indicator lights will be “green”.

Main Filter Light:

When the ain Filter is operating at full efficiency, the green light is always ON. When the light goes OFF, this is

your indication to “service” the ain Filter. The average life expectancy of the ain Filter is 12 to 16 months. See

ain Filter replacement instructions.

Bio Monitor Light:

Green light ON indicates that airborne micro-organisms are continuously being destroyed in the DFS Filtration

System. If the light goes OFF, micro-organism

destruction has been interrupted. Immediately turn off the unit and unplug it from the outlet. Call RainSoft

customer service at 1-800-860-7638 for servicing instructions.

Cleaning the Unit:

Before cleaning the unit, shut the air purifier OFF and unplug it from the outlet. Clean exterior surfaces only with a

soft cloth dampened with water. Do not use abrasive cleansers. Do not spray the unit with any liquid cleaner. Wipe

the intake grill weekly with a clean, dry non-static cloth.

Cleaning the Permanent Polyester Mesh Filter:

Clean the Permanent Polyester esh Filter by simply placing the unit on itʼs side and wipe clean.

Ordering Replacement Filters:

To order a replacement filter, contact your local RainSoft dealer. To locate a dealer visit www.rainsoft.com or call 1-

800-860-7638.

To Change Reversible Multi-Stage Filtration:

Carbon-Zeolite AND Dual Pre-Filtration Tray

DFS Main Filter nstallation nstructions:

When the green ain Filter indicator light goes OFF, it is time to service the DFS

ain Filter. The average life expectancy of the ain Filter is 12 to 16 months.

CAUT ON: Turn the air purifier off and unplug from power outlet.

1. To access DFS ain Filter,

place fingertips under side

recesses of black cover, gently

pull outward and lift cover

to remove. (Fig. A) Separate

lid from the air purifier.

2. To release ain Filter, move

both gray handles 90° toward

front of air purifier. (Fig. B)

A B C

3. To remove DFS ain Filter, lift

filter from the internal chamber.

(Fig. C) Before installing the

new Main Filter, make sure

the filter seal “O” ring is

seated properly in the “O”

ring channel.

1. Turn the air purifier off and unplug from power outlet. To change/vacuum Carbon Filter, open back panel (Fig. F) remove

panel and set it down. Pull out carbon tray (Fig. G) and replace every 12 months. If you have a high level of particulates in

your home and/or animal hair you can easily vacuum the pre-filters between filter changes, which are located on the underside

of the carbon tray (Fig. H). Simply vacuum the carbon tray pre-filter. Then turn the tray over and reinsert into filter draw. This

procedure can be repeated as necessary. However, it is highly recommended that this entire filter be replaced annually. Reattach

the back panel. Your unit is now ready for use.

FGH

4. To load DFS ain Filter, align

hole in filter tab with brass pin.

Press filter down as shown.

(Fig. D). To lock filter in place,

move both gray handles in 90°

toward the center of the filter.

5. To replace the lid, align the 2

vertical tabs, on the inside of

the lid, with the slots in the top

of the machine. Push down

gently and snap shut. Plug air

purifier into power outlet and

turn on.

NOTE: The proper filter

must be used and

loaded correctly or air

purifier will not turn on.

CAUT ON: Do not force

handles, they should

move freely. If not,

realign the filter.

Main Filter Part #:

65132

Multi-Stage Filter Part #:

65131

3 4

Where to Place the Air Purifier:

The RainSoft®Airmaster DFS Air Cleaner is designed as a portable floor model. Place the air purifier anywhere

in the room; being careful not to block air from “entering” the intake grill, or “exiting” the top grill cover.

Do not place the air purifier where drapes or other objects block airflow. For best performance, it is recommended

to place the air purifier at least two (2) feet from walls and other obstructions.

Air Cleaner Operation:

After removing the protective plastic from the unit – plug the unit into a standard 120 volt earth grounded AC

circuit. The control panel lights should be illuminated as follows:

Main Filter - green light is ON

Bio Monitor - green light is ON

The RainSoft®Airmaster DFS indicator light system is an all “green” system.

When the unit is operating properly, both indicator lights will be “green”.

Main Filter Light:

When the ain Filter is operating at full efficiency, the green light is always ON. When the light goes OFF, this is

your indication to “service” the ain Filter. The average life expectancy of the ain Filter is 12 to 16 months. See

ain Filter replacement instructions.

Bio Monitor Light:

Green light ON indicates that airborne micro-organisms are continuously being destroyed in the DFS Filtration

System. If the light goes OFF, micro-organism

destruction has been interrupted. Immediately turn off the unit and unplug it from the outlet. Call RainSoft

customer service at 1-800-860-7638 for servicing instructions.

Cleaning the Unit:

Before cleaning the unit, shut the air purifier OFF and unplug it from the outlet. Clean exterior surfaces only with a

soft cloth dampened with water. Do not use abrasive cleansers. Do not spray the unit with any liquid cleaner. Wipe

the intake grill weekly with a clean, dry non-static cloth.

Cleaning the Permanent Polyester Mesh Filter:

Clean the Permanent Polyester esh Filter by simply placing the unit on itʼs side and wipe clean.

Ordering Replacement Filters:

To order a replacement filter, contact your local RainSoft dealer. To locate a dealer visit www.rainsoft.com or call 1-

800-860-7638.

To Change Reversible Multi-Stage Filtration:

Carbon-Zeolite AND Dual Pre-Filtration Tray

DFS Main Filter nstallation nstructions:

When the green ain Filter indicator light goes OFF, it is time to service the DFS

ain Filter. The average life expectancy of the ain Filter is 12 to 16 months.

CAUT ON: Turn the air purifier off and unplug from power outlet.

1. To access DFS ain Filter,

place fingertips under side

recesses of black cover, gently

pull outward and lift cover

to remove. (Fig. A) Separate

lid from the air purifier.

2. To release ain Filter, move

both gray handles 90° toward

front of air purifier. (Fig. B)

A B C

3. To remove DFS ain Filter, lift

filter from the internal chamber.

(Fig. C) Before installing the

new Main Filter, make sure

the filter seal “O” ring is

seated properly in the “O”

ring channel.

1. Turn the air purifier off and unplug from power outlet. To change/vacuum Carbon Filter, open back panel (Fig. F) remove

panel and set it down. Pull out carbon tray (Fig. G) and replace every 12 months. If you have a high level of particulates in

your home and/or animal hair you can easily vacuum the pre-filters between filter changes, which are located on the underside

of the carbon tray (Fig. H). Simply vacuum the carbon tray pre-filter. Then turn the tray over and reinsert into filter draw. This

procedure can be repeated as necessary. However, it is highly recommended that this entire filter be replaced annually. Reattach

the back panel. Your unit is now ready for use.

FGH

4. To load DFS ain Filter, align

hole in filter tab with brass pin.

Press filter down as shown.

(Fig. D). To lock filter in place,

move both gray handles in 90°

toward the center of the filter.

5. To replace the lid, align the 2

vertical tabs, on the inside of

the lid, with the slots in the top

of the machine. Push down

gently and snap shut. Plug air

purifier into power outlet and

turn on.

NOTE: The proper filter

must be used and

loaded correctly or air

purifier will not turn on.

CAUT ON: Do not force

handles, they should

move freely. If not,

realign the filter.

Main Filter Part #:

65132

Multi-Stage Filter Part #:

65131

5 2

Unit will not turn ON • Is the unit plugged into a “working”

120 Volt, AC, earth grounded outlet?

• Is the unitʼs top cover in place, and

snapped shut?

• Is the ain Filter locked in place,

with the ain Filter locking handles

facing toward the center of the unit?

Unit is ON, but no speed change • Call RainSoft®Airmaster Customer Service.

ain Filter light is OUT • Replace ain Filter.

• ain Filter has reached its contaminant holding capacity.

Bio onitor light is out • Call RainSoft®Airmaster Customer Service.

• Dust has accumulated on the electric grid.

• Unplug the systems and remove the main filter.

Use a Q-tip with denatured alcohol to clean the

wires then reassemble.

RainSoft®Airmaster DFS offers a five-year limited warranty on all consumer products.

1) Retain proof of purchase and the original box and packaging materials.

2) ail Warranty Registration Card within 10 days of date of original purchase.

1) Fax Warranty Registration Card within 10 days of date of original purchase, fax 1-847-437-5539.

2) To make a product claim, call 1-800-860-7638 to obtain a warranty claim number.

Product Registration:

RainSoft®Airmaster DFS makes this Five (5) Year Limited Warranty (“Limited Warranty”) ONLY to the original

retail purchaser who completes the enclosed Warranty Registration Card within ten (10) days of purchase

and faxes it to: 1-847-437-5539; or mail it to: RainSoft®Airmaster DFS 2080 E. Lunt Ave., Elk Grove Village,

IL 60007

Trouble Shooting Guide:

Symptom Check / Remedy mportant Safety Precautions (continued)

9. The air purifier is designed for indoors, do not use this air purifier outdoors.

10. Do not operate this unit with a damaged cord or plug, or after the unit malfunctions or has been

damaged in any manner. Contact your local RainSoft dealer for servicing instructions. To find your local

dealer, visit www.rainsoft.com.

11. This unit is designed for residential use only. Do not use in industrial or severe

commercial applications.

12. A short power supply cord is provided to reduce the risk resulting from becoming entangled in or

tripping over a long cord. Do not use extension cords with this unit.

WARNING: To prevent fire or shock hazard, do not expose this unit to rain or moisture.

Electronic Control Panel -

• Service Light - indicates when unit requires service

• Bio- ontior Light - shows DFS germ killing zone is working at peak efficiency

• Convenient three speed control

• Low speed - ULTRA quiet air flow mode

GERM K LL NG ZONE!

• 98-100% of viruses

• 98-100% of bacteria

• 94-100% of mold & fungi

100% Sealed Filtration -

All incoming air is treated

in the 100% sealed filter chamber.

DFS Filter - Better than 99.99%

particle capture at 0.3 microns.

4 x the particle reduction as a

similar sized HEPA filter.

Traps micro-organisms for

germicidal exposure.

Dual Air ntake Blower -

Drives a consistent volume of air

and provides quiet operation.

360˚ air entry design -Allows

placement anywhere ensuring all room

air is treated.

6-Stage Filter -

•Poly Propylene Mesh:

Large particle collector

of dust, hair, and lint.

•Anti-Microbial: Reduces

bacteria growth in filter.

•Carbon Pellets: VOC/Gas

Adsorbent

•Potassium Permanganate:

VOC/Gas Adsorbent

•Anti-Microbial: Reduces

bacteria growth in filter.

•Poly Propylene Mesh: Large particle

collector of dust, hair, and lint.

System is making a clicking or

popping sound.
