Pro2 Air Filter Installation Instruction
Pro2 Air Filter Installation instruction
STEP 1: Loose the Back Cover
Remove the screws marked in red in the following images.
Keep the screws in green.
STEP 2: Remove the Fixing Screws of the Filter System
Hold the filter system with one hand and remove the 4 fixing screws marked in red from the back
cover with the other hand.

WWW.RAISE3D.COM
AMERICA ·ASIA · EUROPE
Pro2 Air Filter Installation Instruction
STEP 3: Take the System Apart
Separate the filter system into 4 parts: fan, filter cartridge and 2 brackets.
STEP 4: Replace the Filter Cartridge
Take the origin filter cartridge out and install the new filter cartridge.
Face the black honeycomb side of the cartridge to the no label side of the fan. Install the 2 brackets to fix
the filter cartridge and the fan.

WWW.RAISE3D.COM
AMERICA ·ASIA · EUROPE
Pro2 Air Filter Installation Instruction
STEP 5: Install the Filter System
Hold the filter system with one hand and install the 4 fixing screws with the other hand.
Face the tiny arrow on label of the fan upward. Watch out the fan cable.
将后板上的螺丝装回，完成更换滤芯。
STEP 6: Fix the Back Cover
Install the fixing screws of the back cover.
