RAM K5UR120ML-AM1G Series Parts list manual

MODEL K5UR120ML-XX-AM1G
UTILITY AND MANLIFTER
AIR WINCH

Table of Contents Continued
4.0 Operating Instructions
4.1 Operator Start Up
4.2 Shutdown
5.0 Preventive Maintenance
5.1 Introduction
5.2 Maintenance Plan
5.2.1 Lubrication Schedule
5.2.2 Cleaning
5.2.3 Cable and Hoses
5.2.4 In Field Load Brake Adjustment
6.0 Component Removal/Replacement
Appendices
Personnel Rating Performance Characteristics
Utility Rating Performance Characteristics
RAM Winch & Hoist Parts Information
Invader General Assembly Drawing
Drum Guard Drawing
Invader Winch Assembly Bill of Material
Invader Exploded View Figures 1 through 5
Invader Manual Brake Bill of Material
Invader Auto Brake Bill of Material
Invader Manual & Auto Brake Bill of Material
Invader Recommended Spares
K5U Air Motor Parts Listing
K5U Air Motor Assembly Drawing
Power Wheel Service Manual Model 9
Double Reduction Wheel Drive Service Manual

1.0 General Information
1.1 User Responsibility and Safety Precautions
MODEL IDENTIFICATION
The exact model number of your winch is located on the RAM winch nameplate permanently
mounted on the winch. The RAM model number identification chart located on the inside of the
front cover of this manual explains the model number codes for the various features provided on
your winch.
This equipment will perform in conformity with the description thereof, contained in this
manual, its accompanying labels and/or inserts when it is installed, operated, maintained and
repaired according to the instructions provided. This equipment must be checked periodically.
Deficient equipment should not be used. Parts that are broken, missing, plainly worn, distorted
or contaminated should be replaced immediately. Should such repair or replacement become
necessary, we recommend that a telephone or written request for service be made to RAM
Winch & Hoist.
This equipment or any of its parts should not be altered without prior written approval of RAM
Winch & Hoist. The user of this equipment shall have the sole responsibility for any
malfunction that results from improper use, faulty maintenance, damage, improper repairs or
alterations made by anyone other than RAM Winch & Hoist.
1.2 Introduction
1.2.1 Purpose
The purpose of this manual is to provide operating instructions and maintenance procedures for
your RAM Winch & Hoist Air Winch.
1.2.2 Model Number, Serial Number and Options
This manual covers the winch built by RAM Winch & Hoist for your particular unit. The model
and serial numbers are listed on the nameplate attached to the unit.
1.2.3 Warranty
See standard warranty certificate.
1.3 Equipment Description
1.3.1 Capabilities and Limitations
The winch is an air, planetary driven cable-handling unit with manual release and auto release
band brakes, designed for use in the marine or industrial environment.
