Ramsey Winch HD-P8000 Installation and user guide

OPERATING, SERVICE AND
MAINTENANCE MANUAL
MODEL HD-P8000
PLANETARY WINCH
CAUTION: READ AND UNDERSTAND THIS MANUAL BEFORE
INSTALLATION AND OPERATION OF WINCH. SEE WARNINGS!

TABLE OF CONTENTS
INTRODUCTIONS ...........................................................................................1
WARRANTY INFORMATION ...........................................................................1
SPECIFICATIONS ...........................................................................................1
WARNINGS.......................................................................................................1
CABLE INSTALLATION ...................................................................................2
HYDRAULIC SYSTEM REQUIREMENTS .......................................................3
TYPICAL LAYOUT ...........................................................................................3
PERFORMANCE CHARTS ..............................................................................3
OPERATION ....................................................................................................4
MAINTENANCE ...............................................................................................4
TROUBLE SHOOTING GUIDE ........................................................................5
OVERHAUL INSTRUCTIONS ..........................................................................6-11
DIMENSIONAL DRAWINGS ............................................................................12-13
PARTS LIST AND PARTS DRAWINGS ...........................................................14-17
LIMITED WARRANTY ...................................................................BACK COVER

1
NOTE: The rated line pulls shown are for the winch only. Consult the wire rope manufacturer for wire rope ratings.
WARNINGS:
• A MOTOR SPOOL (OPEN CENTER) DIRECTIONAL CONTROL VALVE IS REQUIRED FOR BRAKE OPERATION.
• CLUTCH MUST BE FULLY ENGAGED BEFORE STARTING THE WINCH.
• DO NOT DISENGAGE CLUTCH UNDER LOAD.
• DO NOT LEAVE CLUTCH ENGAGED WHEN WINCH IS NOT IN USE.
• STAY OUT FROM UNDER AND AWAY FROM RAISED LOADS.
• STAND CLEAR OF CABLE WHILE PULLING. DO NOT TRY TO GUIDE CABLE.
• DO NOT EXCEED MAXIMUM LINE PULL RATINGS SHOWN IN TABLE.
• DO NOT USE WINCH TO LIFT, SUPPORT, OR OTHERWISE TRANSPORT PERSONNEL.
• A MINIMUM OF 5 WRAPS OF CABLE AROUND THE DRUM BARREL IS NECESSARY TO HOLD THE LOAD. CABLE CLAMP
(SETSCREW) IS NOT DESIGNED TO HOLD LOAD.
• IN CAR CARRIER APPLICATIONS, AFTER PULLING VEHICLE ON CARRIER, BE SURE TO SECURE VEHICLE TO CARRIER
BED. DO NOT MAINTAIN LOAD ON WINCH CABLE WHILE TRANSPORTING VEHICLE. DO NOT USE WINCH AS A TIEDOWN.
• WHEN PULLING A HEAVY LOAD PLACE A BLANKET, JACKET, OR TARPAULIN OVER THE CABLE FIVE OR SIX FEET FROM
THE HOOK.
• AVOID CONDITIONS WHERE LOAD SHIFTS OR JERKS OCCUR, AS THEY MAY INDICATE A DANGEROUS SITUATION.
Rated Line Pull (lbs.) …………………………………………………
…
8,000
(Kg.) …………………………………………………
…
3,620
Gear Reduction 5.1:1
HD-P8000 STD. ……..…....………. 82 lbs. (37.2 Kg)
HD-P8000 "Y" ………….………….. 76 lbs. (34.5 Kg)
12345
lbs. 8,000 6,800 5,900 5,200 4,700
Kg. 3,620 3,080 2,670 2,350 2,120
ft. 25 55 90 130 170
m 7 16 27 39 51
ft.15356085115
m 4 10 18 25 34
FPM5058677684
MPM 15.2 17.6 20.3 23.1 25.5
…………………………………………………………
…
Weight (without cable)
LAYER OF CABLE
*Rated line pull
per layer
HD-P8000 (STD.
DRUM)
* Line Speed (at
15 GPM)
HD-P8000 ("Y"
DRUM)
* Cable Capacity per Layer
PLEASE READ THIS MANUAL CAREFULLY
This manual contains useful ideas for obtaining the most efficient operation from your Ramsey Winch, and safety pro-
cedures one needs to know before operating a Ramsey Winch. Do not operate this winch until you have carefully read
and understand the "WARNING" and "OPERATION" sections of this manual.
WARRANTY INFORMATION
Ramsey Winches are designed and built to exacting specifications. Great care and skill go into every winch we make.
If the need should arise, warranty procedure is outlined on the back of your self-addressed postage paid warranty
card. Please read and fill out the enclosed warranty card and send it to Ramsey Winch Company. If you have any
problems with your winch, please follow instructions for prompt service on all warranty claims. Refer to back page for
limited warranty.
SPECIFICATIONS*

2
CABLE INSTALLATION
An “A” or “B” decal on the clutch end bearing indicates the spooling direction of the cable. Also, a letter “A” or “B” is
stamped in the end bearing on the clutch end indicating rotation direction. If the decal is damaged or unreadable,
contact Customer Service for additional instructions to determine proper direction. To reverse the rotation direc-
tion, exchange positions of the cartridge and plug shown below.
1. Unwind cable by rolling it out along the ground to prevent kinking. Securely wrap end of cable, opposite hook,
with plastic or similar tape to prevent fraying.
2. Insert the end of the cable through roller fairlead.
3. Place taped end of cable under tensioner plate and into hole in cable drum. Use the 3/8-16NC x 1/2” long hex
socket drive setscrew (included with drum assembly) to secure cable to drum.
4. Carefully run winch in the "reel-in" direction. Wind about 5 wraps of cable onto the drum and stop. Using a ham-
mer tap these five wraps tightly over against the cable anchor flange of the drum. Spool all the cable onto the
cable drum, taking care to form neatly wrapped layers.
After installing cable, check freespool operation. Disengage clutch and pull on cable at a walking speed. If cable
“birdnests”, loosen jam nut (item #20) and turn nylon setscrew (item #17) clockwise to increase drag on drum. If
cable pull is excessive, loosen nylon setscrew by turning counterclockwise. Tighten jam nut when proper setting is
obtained. CAUTION: OVER-TIGHTENING OF JAM NUT MAY STRIP NYLON SETSCREW.
(REEL IN) RAISE INLET
"A" ROTATION "B" ROTATION
CABLE DRUM
ROTATION DIRECTION CABLE DRUM ROTATION DIRECTION
CARTRIDGE
POSITION CARTRIDGE
POSITION
PLUG
POSITION
17
20
INSERT CABLE AS SHOWN FOR "A" ROTATION
OVERWOUND APPLICATION.
(UNDERWOUND APPLICATION REQUIRES CABLE TO
COME UNDER DRUM FROM OPPOSITE DIRECTION
AND INSERTED IN THIS SAME CABLE POCKET.)
INSERT CABLE AS SHOWN FOR "B" ROTATION
OVERWOUND APPLICATION.
(UNDERWOUND APPLICATION REQUIRES CABLE TO
COME UNDER DRUM FROM OPPOSITE DIRECTION
AND INSERTED IN THIS SAME CABLE POCKET.)
"B" ROTATION
DIRECTION
"A" ROTATION
DIRECTION
SETSCREW
NOTE: VIEW SHOWN WITHOUT
CABLE TENSIONER FOR CLARITY.
CABLE IN DIRECTION CABLE IN DIRECTION

3
HYDRAULIC SYSTEM REQUIREMENTS
Refer to the performance charts below to properly match your hydraulic system to the
winch performance. The charts consist of:
(1) Line Pull first layer (lb.) vs. Working Pressure (PSI)
(2) Line Speed, first layer (FPM) vs. flow (GPM)
SYSTEM REQUIREMENTS
MOTOR SPOOL (OPEN CENTER) CONTROL VALVE REQUIRED
2500 PSI RELIEF VALVE SETTING
15 GPM FLOW RATE
DO NOT EXCEED 20 GPM--MOTOR AND WINCH MAY BE DAMAGED
10 MICRON NOMINAL FILTRATION
PORT CONTROL
PUMP
(.75 I.D. MINIMUM)
LOW PRESSURE LINE
(.50 I.D. MINIMUM)
HIGH PRESSURE LINE
2500 PSI
15 GPM
RATED LOAD:
PRESSURE AT
MAX. FLOW &
(MOTOR SPOOL)
4 WAY VALVE
3 POSITION RELIEF
SYSTEM
A
PORT
BRAKE
MOTOR
WITH BRAKE RELEASE SHUTTLE TYPICAL LAYOUT
B
WORKING PRESSURE (PSI) AT 15 GPM
GALLONS PER MINUTE (GPM)
LINE PULL-FIRST LAYER (LB)
LINE SPEED-FIRST LAYER (FPM)
051015
10
20
30
40
0
0
1000
2000
3000
4000
5000
6000
7000
8000
1000 2000 2500
50
BASED ON 15.5 CU. IN. MOTOR
1500500
PERFORMANCE CHARTS

4
OPERATION
The best way to get acquainted with how your winch operates is to make test runs before you
actually use it. Plan your test in advance. Remember, you hear your winch as well as see it oper-
ate. Get to recognize the sounds of a light steady pull, a heavy pull, and sounds caused by load
jerking or shifting. Avoid conditions where load shifts or jerks occur, as they may indicate a dan-
gerous situation.
The uneven spooling of cable, while pulling the load, is not a problem, unless there is a cable
pileup on one end of the drum. If this happens, reverse the winch to relieve the load, and move
your anchor point further to the center of the vehicle. After the job is done you can unspool and
rewind for a neat lay of the cable.
When pulling a heavy load, place a blanket, jacket, and tarpaulin over the cable about five or six
feet behind the hook. In the event of a broken cable, this will slow the snap back of the cable and
could prevent serious injury.
The winch clutch allows rapid unspooling of the cable, from the cable drum, for hooking onto the
load. The clutch is operated by the clutch shifter lever or air shifter.
WARNING: DO NOT DISENGAGE CLUTCH UNDER LOAD!
MANUAL CLUTCH SHIFTER (Refer to dimensional drawing page 12):
TO DISENGAGE CLUTCH: Run the winch in the reverse (reel out) direction until the load is off
the cable. Pull handle out and rotate 90°. With handle in the DISENGAGED” position, cable may
now be free-spooled from the drum. TO ENGAGE CLUTCH: Pull handle out, rotate 90° and re-
lease handle. Run the winch in reverse until the clutch handle snaps fully into the “ENGAGED”
position. DO NOT attempt to pull a load unless the handle is fully at the “ENGAGED” position.
AIR CYLINDER CLUTCH SHIFTER (Refer to the dimensional drawing page 13):
TO DISENGAGE CLUTCH: Run the winch in the reverse (reel out) direction until load is off the
cable. Apply air pressure to the .125-27 NPT port: 80 PSI (min.)-150 PSI (max.). CAUTION:
PRESSURE MUST NOT EXCEED 150 PSI. TO ENGAGE CLUTCH: Remove air pressure from
the cylinder (a return spring engages the plunger). Run winch in reverse until the clutch engage-
ment indicator light (green light) is lit. To install light to the vehicle electrical system refer to the
Electrical Schematic on page 13.
MAINTENANCE
1. Inspect the cable for damage and lubricate frequently. If the cable becomes frayed with bro-
ken strands, replace immediately. Cable and hook assembly (100’ long cable) P/N 524118
may be purchased from a Ramsey distributor.
2. Check that the clutch is fully engaging. See OPERATION instructions, above, for the appro-
priate clutch shifter. FOR MANUAL CLUTCH ONLY: Monthly, disengage clutch, put several
drops of oil on the clutch handle shaft and work clutch handle IN and OUT several times to
lubricate inside the shifter assembly.
3. Check to see that the drum cable does not overrun (“birdnest”) when freespooling. Refer to
page 2 if it does.
4. Replace drum bushings and seals if seals begin to seep grease. Refer to the Overhaul In-
structions, pages 6-11. Add additional lubricant, Mobilith SHC 007, to gears and drum bear-
ings if required.

5
TROUBLESHOOTING GUIDE
CONDITIONS POSSIBLE CAUSE CORRECTION/ACTION
DRUM WILL NOT ROTATE AT NO
LOAD Winch not mounted squarely, causing end bearing to bind up Check mounting.
Gears damaged Inspect and replace damaged gears
DRUM WILL NOT ROTATE UNDER
LOAD Winch not mounted squarely, causing end bearing to bind up Check mounting.
Load greater than rated capacity of winch Refer to Specifications page 1 for line
pull rating.
Low hydraulic system pressure Check pressure. Refer to Hydraulic
Systems per-formance charts, page 3.
WINCH RUNS TOO SLOW Low hydraulic system flow rate Check flow rate. Refer to System
Requirements and Typical Layout,
page 3.
Motor worn out Replace motor
DRUM WILL NOT FREESPOOL Clutch not disengaged. Check Adjustment of Manual
Shifter, page 10. Check Operation, page 4.
Winch not mounted squarely, causing end bearing to bind
up Check mounting.
Side mounted bolts too long, causing binding of ring gear
(Item #32, page 14). Check bolt length. Bolt thread MUST
NOT engage threaded holes in sides of
end bearing more than the .50 inch
thread depth in the end bearing.
BRAKE WILL NOT HOLD Incorrect directional control valve (cylinder spool-closed
center) Use only a motor spool (open center) control valve.
LOAD DRIFTS Excessive Backpressure (100 PSI Max.) Check for restrictions in hydraulic
system. Refer to System Requirements
and Typical Layout, page 3.
CABLE BIRDNESTS WHEN CLUTCH
IS DISENGAGED Drag screw improperly adjusted Adjust nylon drag screw. Refer to
Cable Installation, page 2.
EXCESSIVE NOISE Hydraulic system flow too high Check flow rate. Refer to Typical
Layout page 3.
Drum in bind, winch not mounted squarely Check mounting.
DRUM CHATTERS IN “REEL IN”
DIRECTION Low hydraulic system flow rate Check flow rate. Refer to Typical
Layout page 3.
Low hydraulic system relief pressure setting Check relief valve setting.
OIL LEAKS FROM BREATHER VENT
UNDER MOTOR END BEARING Damaged brake o-rings, backup rings, or sealing surfaces Disassemble brake and inspect. See
Overhaul Instructions, pg. 7.

6
INSTRUCTIONS FOR OVERHAUL HD-P8000 SERIES WINCH
Take note of mounting configurations for proper mounting of parts during re-
assembly. Replace all gaskets, o-rings, and seals during re-assembly.
Disconnect tube (item #49) from elbow fittings (items #30) on bottom of end bearing
and counterbalance valve (item #50). Remove motor (item #34) from end bearing by
slowly unscrewing capscrews (items #22). CAUTION: MOTOR IS UNDER SPRING
PRESSURE.
Check breather vent (item #33). Make sure it is not clogged. If oil is leaking from vent,
check brake o-rings, backup rings, and sealing surfaces (see page 7).
Remove springs (items #48) from pockets and inspect for damage.
Replace gasket (item #31).
Remove coupling (item #29) from end bearing. Examine coupling for signs of wear, re-
place if necessary. If necessary, remove counterbalance valve from motor by removing
capscrews (items #16).
22
28
34
31
29
16
26
50
49
30 48

7
Remove retaining rings (items #46 and #47) with screwdriver.
Remove brake parts from end bearing. NOTE POSITION OF O-RINGS AND BACKUP
RINGS BEFORE REMOVAL. Examine brake discs (items #7) and stators (items #6) for
signs of wear, and replace if necessary.
Examine o-rings (items #35 and 36) and backup rings (items #38 and 40) in brake piston (item
#8), as well as o-ring (item #37) and backup ring (item #39) in backup brake piston (item #9)
for signs of wear. Remove o-rings and backup rings from grooves in brake piston or backup
brake piston and replace if necessary.
46
8
38 36
40
35
9
37 39
6
7
47

8
Remove nuts (item #66), washers (item #28), springs (item #60), and capscrews (item #55) from spring
tensioner. Spring tensioner may be left partially assembled when removing capscrews (item #65). Refer
to exploded views on pages 14 and 16 for all components. CAUTION: Both tensioner assembly and
mounting angle (item #3) will come off at the same time when mounting angle capscrews (item
#65) are removed. Slide motor end bearing (item #11) and drum (item #1) from gear housing end bear-
ing.
Remove input shaft (item #13) from end bearing. Inspect shaft and output sun gear (item #10) for dam-
age and replace if necessary. To remove the output sun gear, remove the snap rings (items #45) and
thrust washer (item #52) and pull off the end of the shaft.
Remove bushing (item #15) and o-ring (item #41) from motor end bearing. Place new, well-oiled o-ring
into groove inside of end bearing and press new bushing onto end bearing.
Remove seal (item #44) from gear housing end bearing
(item #12). Loosen nut (item #24) and remove nylon set-
screw (item #21). Remove ring gear from gear housing end
bearing, if necessary. Remove bushing (item #14) from end
bearing. Press new bushing into end bearing. Install ring
gear, then nylon setscrew and nut. Ring gear must be fully
seated in end bearing and slot in ring gear MUST NOT be
aligned with clutch shifter hole. Install new seal in end bear-
ing, with sharp edge of seal outward. 21 24
44
32
12
14
1
19
2
65
3
13
10 52
45
11
41
15
60
28
66
55

9
Generously apply grease (MOBILITH SHC 007) to teeth of ring gear (item #32), teeth of planet gears in
drum (item #1), and to bushing (item #14) in gear housing end bearing. Apply a small amount of grease to
base of bushing (item #15) on motor end bearing. Apply grease to teeth of output sun gear (item #10) and
input shaft (item #13).
Place end of shaft with output sun gear on it into drum (item #1). Rotate shaft to engage planet gears with
output sun gear. Place Gear End Bearing on Drum and engage planet gears with ring gear.
Assemble motor end bearing (item #11) to drum assembly and use mounting angle (item #2) and capscrews
(items #19) loosely to hold both end bearings together. Assemble mounting angle (item #3) and partial ten-
sioner assembly together with capscrews (item #65). CAUTION: Mounting angle capscrews are different
lengths! Ensure the correct capscrews are installed. Tighten capscrews to 55 ft-lbs (75 Nm). If neces-
sary, remove and replace the shifter assembly (manual, item #5, or air-cylinder, item #6), as follows:
MANUAL CLUTCH SHIFTER ASSEMBLY
Loosen setscrew (item #23) and jam nut, then unscrew shifter assembly (item #5). Be sure slot in ring gear
is not aligned with clutch shifter hole. Rotate drum, if necessary, to ensure hole and slot are not aligned.
Reinstall shifter assembly with plunger, jam nut, and handle positioned in gear housing as shown below.
Thread assembly (with handle engaged in cylinder slot) into the gear housing. Pull drum toward the gear
end bearing housing to remove play. Hold drum in position and continue threading the shifter assembly in
until the gap between the end of the handle and cylinder is 7/16 +0/ -1/16 inch and handle is in the horizontal
position (see below). Note: This gap will vary with drum endplay. With the drum pulled against the motor end
housing, the gap should be 3/8 inch.
Lightly tighten jam nut. Rotate drum until handle snaps fully into the engaged position. Pull handle out and
rotate 90°. Verify that drum can be rotated freely (at least one full revolution) with clutch shifter at the DIS-
ENGAGED position. Securely tighten jam nut while holding the handle. Tighten setscrew (item #23) se-
curely. Re-check clutch operation as described on page 4.
AIR CYLINDER SHIFTER ASSEMBLY
Loosen set screw (item #23) to remove shifter assembly (item #6). To reinstall, place 1 or 2 shims (items
#48) over plunger and thread shifter assembly into gear end housing. Add or remove shims to orient ports
for pneumatic connections. Ports should point down (below horizontal). Tighten setscrew. Check for clutch
operation as described on page 4.
51
43
12
23
5
20
48
6
CYLINDER
HANDLE (HORIZONTAL)
MANUAL CLUTCH ADJUSTMENT
MANUAL CLUTCH
SHIFTER
AIR-CYLINDER
CLUTCH SHIFTER
PLUNGER
JAM NUT

10
Set winch with gear housing end down on work surface.
Install well-oiled o-rings and backup rings into grooves on outside of brake piston and backup brake pis-
ton as shown in cross-section A-A below.
Piston, backup piston, brake discs and stators must be clean and free of grease and oil.
Insert brake discs (item #7) and stators (item #6) into gear end alternating, with stators first and last.
Insert backup brake piston (item #9) into motor end and insert brake piston (item #8) into it. Apply
even pressure on piston when installing.
Install retaining rings (item #46 and #47) into grooves in motor end housing.
7
6
39
37
9
35 40
36
38
8
46
A
A
SECTION A-A
89
38 36 37 39
35
40
MOTOR SIDE
DRUM SIDE
47

11
Insert springs (item #48) into pockets in back of brake piston. The two empty pockets should be on op-
posite sides.
Install roll pin (item #42) into new motor coupling below bottom of spline teeth. Insert motor cou-
pling (item #29), engaging it with the discs and the input shaft.
Place gasket (item #31) on mounting surface of motor (item #34). Slide motor shaft into coupling. Attach
motor to motor end bearing housing using (2) capscrews (item #22) and (2) lockwashers (item #28).
Evenly tighten to 49 ft-lbs. (66 Nm) torque.
Install the counterbalance valve (item #50) to the motor using (4) capscrews (item #16) and (4) lock-
washers (item #26). Tighten to 17 ft-lbs (23 Nm).
Securely connect fittings (item #30) to motor end housing and counterbalance valve, and connect tube
assembly (item #49) to fittings.
Apply at least 550 PSI hydraulic system pressure to brake and verify that brake releases (winch drum
will rotate).
Insert capscrews (item #55) through top plate and slotted
tensioner plate. Install springs (item #60), washers (item
#28), and secure with nylon lock nuts (item #66) to desired
cable tension. Springs require a small amount of compres-
sion before capscrews engage nylon lock nut threads. If it is
difficult to compress springs to engage capscrews with nylon
lock nut, loosen tensioner mounting bolts (item #65). Tighten
capscrews to 55 in-lb (75 Nm). Recommended spring com-
pression is 0.75” per spring. See figure at right.
Insert the end of the cable into the opening of the roller fair-
lead so that it passes under the tensioner plate and install
cable into the cable anchor.
Watch the tensioner as the cable is spooled onto the drum.
The tensioner must be free to move without obstruction to
function properly. If tensioner touches any surrounding
structure, correct the problem.
Refer to Cable Installation, page 2 for information on install-
ing the cable.
55
66
28
60
3
65
42
33
22
28
34
31
29
30
16
26
50
49
30 48

12
HD-P8000 MANUAL SHIFT

13
HD-P8000 AIR SHIFT

14
HD-P8000 MANUAL SHIFT
1
14
13
33
12
11
16
26
50
22
28 34
42
31
29 46
8
38 36
40
35
9
37 39
6
7
41
15
21
24 23
5
20
43 51
44
32
10
45
52
48
49
30
30
18
18
17
66
19
18
18
17
66
63
4
63
66
66 2
67
55
56
58
59
57
60
57
61
62
3
64
65 25
28
54
53
27
47

15
PARTS LIST - MANUAL SHIFT
Item No. Qty. Part No. Description Item No. Qty. Part No. Description
1 1 234204 DRUM ASSEMBLY 35 1 462067 O-RING PISTON-SM. 2 1 303120 ANGLE-MOUNTING, ROLLER SIDE 36 1 462068 O-RING PISTON-LG. 3 1 303119 ANGLE-MOUNTING, SPRING TENSIONER SIDE 37 1 462069 O-RING BACKUP PISTON 4 1 274015 ROLLER FRAME ASSEMBLY 38 1 462070 RING-BACKUP PISTON-LG 5 1 276048 SHIFTER ASSEMBLY 39 1 462071 RING-BACKUP BACKUP PISTON 6 6 330011 STATOR-BRAKE 40 1 462072 RING-BACKUP PISTON-SM 7 5 330012 DISC-BRAKE 41 1 462073 O-RING 8 1 330013 PISTON-BRAKE 42 1 470033 SPIROL PIN 9 1 330014 PISTON-BACKUP BRAKE 43 1 472052 PLUG
10 1 334174 GEAR-OUTPUT, SUN 44 1 486080 SEAL 11 1 338358 END BEARING-MOTOR 45 2 490003 SNAP RING 12 1 338327 GEAR HSG. END BEARING 46 1 490049 RING-INTERNAL RETAINING 13 1 357176 SHAFT-INPUT "Y" DRUM 47 1 490066 RING-INTERNAL RETAINING, SMALLEY # WHT-350 14 1 412085 BUSHING-DRUM 48 9 494124 SPRING-BRAKE 15 1 412109 BUSHING-DRUM, MOTOR END 49 1 509132 TUBE-BRAKE RELEASE (PORTS DOWN) 16 4 414159 CAPSCREW-5/16-18UNC X 2 1/2", HEX HEAD, ZINC, GR5 50 1 516041 VALVE-MOTOR CONTROL (A ROTATION) 17 2 414321 CAPSCREW-3/8-16NC X 1", HEX HEAD, BLACK, GR5, 51 1 518037 THRUST WASHER 18 6 414282 CAPSCREW-3/8-16NCX1 1/4LG,HXHD GR-5 52 1 518047 THRUST WASHER 19 4 414580 CAPSCREW-1/2-13NC X 1", HEX HEAD, ZINC, GR5 53 1 328164 COVER-GEAR HSG, HD-P10000 20 2 414854 SCREW-1/4-20NC X 1/2", ROUND HEAD, SLOTTED, ZINC 54 1 442212 GASKET-BRK HSG,.031THK.CORK NEOPREN 21 1 414926 SETSCREW-3/8-16NC X 1", SOCKET HEAD, NYLON 55 2 414519 CAPSCREW-1/2-13NCX4 1/2,HXHD,ZP,GR5 22 2 414954 CAPSCREW 1/2-13NC X 1/3/4 LG. SOCHD Z/P. 56 2 414577 CAPSCREW-1/2-13NC X4LG,HXHD,GR5,Z/P 23 1 416016 SETSCREW-1/4-20NC X 1/4", HEX SOCKET HEAD CUP 57 2 365072 TUBE-MOUNTING, SPRING TENSIONER,
24 1 418036 NUT-3/8-16 NC, HEX JAM, ZINC 58 1 350734 PLATE-SPRING TENSIONER MTG, RPH-15000 25 2 418069 NUT-1/2-13NC, HEX REG, ZINC 59 1 265106 WELDMENT-PIVOT PLATE, CABLE TENSIONER, Y DRUM 26 4 418163 LOCKWASHER-5/16 MED SECT, ZINC 60 2 494128 SPRING-TENSIONER, RPH-15000 27 4 414901 CAPSCREW-3/8-16NCX3/4LG HEX SOC HD 61 2 418223 WASHER-1/2 USS FLAT,ZINC PLATED 28 4 418218 LOCKWASHER-1/2 I.D. MED SECT, ZINC 62 2 418073 NUT-LOCK, 1/2-13NC, NYLON INSERT, ZP 29 1 431019 COUPLING-MOTOR 63 4 418177 LOCKWASHER-3/8 MED SECT,ZINC PLATED 30 2 432018 FITTING 64 1 303154 ANGLE-MOUNTING, CABLE TENSIONER, Y DRUM 31 1 442223 GASKET-MOTOR FLANGE 65 4 414578 CAPSCREW-1/2-13NCX1 1/4,HXHD,GR5,ZP 32 1 444084 GEAR-RING 66 6 418035 NUT-3/8-16NC HEX REG ZINC PLATED 33 1 456038 BREATHER VENT 67 1 243062 WELDMENT-MTG. CHANNEL, ROLLER SIDE, FOR NRC 34 1 458074 MOTOR-HYD.

16
HD-P8000 AIR SHIFT
15
16
1
3
5
35
13
14
48
6
19
28
55
24
30 36
44
33
31 50
52
10
40 38
42
37
11
39 41
8
9
43
17
23
27 25
47
34
12
49
56
54
32
32
12 18
58
58
29
29
58
20
57
57
2
22 58
20
57 57
67
60
62
63
61
64
61
65
66
4
68
53 26
30
51
59
7
21
46
43

17
PARTS LIST - AIR SHIFT
Item
No. Qty. Part No. Description Item No. Qty. Part No. Description
1 1 234204 DRUM ASSEMBLY 35 1 456038 BREATHER VENT 2 1 243062 WELDMENT-MTG. CHANNEL, ROLLER SIDE, FOR NRC 36 1 458074 MOTOR-HYD. 3 1 303120 ANGLE-MOUNTING, ROLLER SIDE 37 1 462067 O-RING PISTON-SM. 4 1 303119 ANGLE-MOUNTING, SPRING TENSIONER SIDE, 38 1 462068 O-RING PISTON-LG 5 1 274015 ROLLER FRAME ASSEMBLY 39 1 462069 O-RING BACKUP PISTON 6 1 276058 SHIFTER ASSEMBLY 40 1 462070 RING-BACKUP PISTON-LG 7 1 328164 COVER-GEAR HSG, HD-P10000 41 1 462071 RING-BACKUP BACKUP PISTON 8 6 330011 STATOR-BRAKE 42 1 462072 RING-BACKUP PISTON-SM 9 5 330012 DISC-BRAKE 43 1 462073 O-RING
10 1 330013 PISTON-BRAKE 44 1 470033 SPIROL PIN
11 1 330014 PISTON-BACKUP BRAKE 45 1 472052 PLUG-SAE O-RING,.562-18NF,6HP50NS
12 1 334174 GEAR-OUTPUT, SUN 46 1 518037 THRUST WASHER-TORRINGTON #TRA-1018
13 1 338358 END BEARING-MOTOR, MACHINED, HD-P8000 47 1 486080 SEAL-GH,MIKRON #RWH-675,MB-2590,RPH
14 1 338327 GEAR HSG. END BEARING 48 2 488007 SHIM
15 1 357176 SHAFT-INPUT "Y" DRUM 49 2 490003 SNAP RING
16 1 412085 BUSHING-DRUM 50 1 490049 RING-INTERNAL RETAINING
17 1 412109 BUSHING-DRUM, MOTOR END 51 1 490066 RING-INTERNAL RETAINING, SMALLEY # WHT-350
18 2 414036 CAPSCREW-1/4-20NC X 1/2", HEX HEAD, ZINC 52 9 494124 SPRING-BRAKE
19 4 414159 CAPSCREW-5/16-18UNC X 2 1/2", HEX HEAD, ZINC, GR5 53 4 414578 CAPSCREW-1/2-13NCX1 1/4,HXHD,GR5,ZP
20 2 414321 CAPSCREW-3/8-16NC X 1", HEX HEAD, BLACK, GR5 54 1 509132 TUBE-BRAKE RELEASE, BACK SIDE VALVE DOWN
21 4 414901 CAPSCREW-3/8-16NCX3/4LG HEX SOC HD 55 1 516041 VALVE-MOTOR CONTROL A ROTATION
22 4 414580 CAPSCREW-1/2-13NC X 1" HEX HEAD, ZINC, GR5 56 1 518047 THRUST WASHER
23 1 414926 SETSCREW-3/8-16NC X 1", SOCKET HEAD, NYLON 57 6 414282 CAPSCREW-3/8-16NCX1 1/4LG,HXHD GR-5
24 2 414954 CAPSCREW 1/2-13NC X 1/3/4 LG. SOCHD Z/P. 58 6 418035 NUT-3/8-16NC HEX REG ZINC PLATED
25 1 416016 SETSCREW-1/4-20NC X 1/4" HEX SOCKET HEAD CUP 59 1 442212 GASKET-BRK HSG,.031THK.CORK NEOPREN
26 2 418069 NUT-1/2-13NC HEX REG, ZINC 60 2 414577 CAPSCREW-1/2-13NC X4LG,HXHD,GR5,Z/P
27 1 418036 NUT-3/8-16 NC,HEX JAM,Z/P 61 2 365072 TUBE-MOUNTING, SPRING TENSIONER, RPH-15000
28 4 418163 LOCKWASHER-5/16 MED SECT, ZINC 62 1 350734 PLATE-SPRING TENSIONER MTG, RPH-15000
29 4 418177 LOCKWASHER-3/8 MED SECT,ZINC PLATED 63 1 265106 WELDMENT-PIVOT PLATE, CABLE TENSIONER, Y DRUM
30 4 418218 LOCKWASHER-1/2 ID MED SECT, ZINC 64 2 494128 SPRING-TENSIONER, RPH-15000
31 1 431019 COUPLING-MOTOR 65 2 418223 WASHER-1/2 USS FLAT,ZINC PLATED
32 2 432018 FITTING 66 2 418073 NUT-LOCK, 1/2-13NC, NYLON INSERT, ZP
33 1 442223 GASKET-MOTOR FLANGE 67 2 414519 CAPSCREW-1/2-13NCX4 1/2,HXHD,ZP,GR5
34 1 444084 GEAR-RING 68 1 303154 ANGLE-MOUNTING, CABLE TENSIONER, Y DRUM

18 914184-0309-B
LIMITED WARRANTY
RAMSEY WINCH warrants each new RAMSEY Winch to be free from defects in material and
workmanship for a period of one (1) year from date of purchase.
The obligation under this warranty, statutory or otherwise, is limited to the replacement or re-
pair at the Manufacturer's factory, or at a point designated by the Manufacturer, of such part
that shall appear to the Manufacturer, upon inspection of such part, to have been defective in
material or workmanship.
This warranty does not obligate RAMSEY WINCH to bear the cost of labor or transportation
charges in connection with the replacement or repair of defective parts, nor shall it apply to a
product upon which repair or alterations have been made, unless authorized by Manufacturer, or
for equipment misused, neglected or which has not been installed correctly.
RAMSEY WINCH shall in no event be liable for special or consequential damages.
RAMSEY WINCH makes no warranty in respect to accessories such as being subject to the
warranties of their respective manufacturers.
RAMSEY WINCH, whose policy is one of continuous improvement, reserves the right to im-
prove its products through changes in design or materials as it may deem desirable without be-
ing obligated to incorporate such changes in products of prior manufacture.
If field service at the request of the Buyer is rendered and the fault is found not to be with
RAMSEY WINCH's product, the Buyer shall pay the time and expense to the field representa-
tive. Bills for service, labor or other expenses that have been incurred by the Buyer without ap-
proval or authorization by RAMSEY WINCH will not be accepted
See warranty card for details.
RAMSEY WINCH COMPANY
PO BOX 581510
Tulsa OK 74158-1510
Telephone: [phone]
FAX: [phone]
Visit us at www.ramsey.com
