RAMTONS RM/368 User manual

STAND BLENDER
INSTRUCTION MANUAL
MODEL: RM/368
Read this booklet thoroughly before using and save it for future reference

2
IMPORTANT SAFEGUARDS
When using this electrical appliance, basic safety precautions
should always be followed, including the following:
1. Read all instructions.
2. Before using check that the voltage indicated on the product
corresponds with the voltage of your electrical outlet.
3. Do not let cord hang on hot surface or over edge of table or
counter.
4. Do not operate any appliance with a damaged cord or plug or
after the appliance malfunction or has been damaged in any
manner. Return the appliance to the nearest authorized service
facility for examination, repair or adjustment.
5. If the supply cord is damaged ，it must be replaced by the
manufacturer or its service agent or a similarly qualified person
in order to avoid a hazard.
6. Close supervision is necessary when any appliance is used by
or near children.
7. Avoid contacting the moving parts.
8. Keep hands and utensils out of container while blending to
reduce the risk of severe injury to persons or damage to the
blender.A scraper may be used but must be used only when the
blender is not running.
9. The use of attachments not recommended or sold by
manufacturer may cause fire, electric shock or injury.
10. Unplug from outlet when not in use, before putting on or

3
taking off parts, and before cleaning. To disconnect, turn any
control to “off”, then remove plug from wall outlet by grasping
the plug, not the cord.
11.To reduce the risk of injury, never place blade assembly on
motor unit without the jar properly attached.
12. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliances by a person responsible for their safety.
13. Children should be supervised to ensure that they do not
play with the appliance.
14. Do not leave the machine on unattended.
15. When removing the blender from the motor unit, wait until the
blades have completely stopped.
16. Always operate blender with cover in place.
17. Always use the appliance on a secure, dry level surface.
18. Never place this appliance on or near a hot gas or an electric
burner or where it could touch a heated appliance.
19. Do not use outdoors.
20. Do not use appliance for other than its intended use.

4
Fig.1
HOUSEHOLD USE ONLY
KNOW YOUR BLEANDER
Measure cu
p
Li
p
Ja
r
Blade assembl
y
Seal rin
g
Blade Base
Moto
r
unit
S
p
ee
d
knob

5
Fig.2
SPEED KNOB
HOW TO USE
Before initial use
1. Before first use, unpack the appliance and place all parts on a
horizontal surface.
2. The jar assembly (including the measure cup, lid, seal ring 1, jar,
seal ring 2 , blade assembly and jar base) has already been
assembled into the motor unit. Disassemble to wash all detachable
parts except the motor unit. Refer to the latter chapter CARE AND
CLEANING.
S blade assemboy
bowl Lid
Bowl
CHOPPER_BOWL

6
Fig.5
3. Once all pieces have been cleaned and dry thoroughly, reassemble.
1) Invert the jar onto a level surface, holding the jar handle, put the the
seal ring 2 and blade assembly onto the jar base bottom and secure the
blade assembly by turning it anti-clockwise until tight（See Fig.3）
2) Reposition the jar assembly with its opening upwards. Wrap the seal
ring 1 around the lid bottom and put the lid onto the jar assembly. Place
the measure cup exactly into the lid by fitting the small projection on the
both sides of the cup into the slots of the lid and turning the cup
clockwise until tight. （See Fig.4）
3) Finally, place the assembled jar onto the motor unit by aligning the
strip on the assembled jar bottom. (See Fig.5）
CAUSION: Jar and jar base is now secure. Do not try to twist the jar
and jar base onto motor unit
Fig.3 Fig.4

7
How to use
1. Peeled or cored the fruit or vegetables and then cut it into small
dices.
2. Place the food to be blended into the jar（See Fig.6）. Usually,
certain amount of purified water has to be added to facilitate the
smooth running of appliance. The proportion of the food and water is
2:3.The amount of mixture should not exceed the max level as
indicated on the jar.
RECIPE
FOOD TYPE SPEC WEIGHT SPEED
Carrot (apple,
pear etc. )
Cut into
15mm*15mm*15mmm
Carrot: 600g
Water: 900g High speed
Note: never use boiling liquids or run the appliance empty.
3. Put the lid on the jar. Be sure the measuring cup is in place.
4. Plug the power cord into a standard wall outlet.
5. Turn the speed knob to the appropriate speed setting for your task.
6. For quick or delicate blending tasks, turn the speed knob to P
position and hold for a few seconds and then release, the knob will
reset to O position automatically. Operate several times until the
consistence you want is obtained
7. If you want to add ingredients while the blender is working, remove
the measuring cup and place through the lid opening. （See Fig.7）
8. When crushing ice or hard food, keep one hand firmly on the lid.

8
9. When the consistence you desire is obtained, turn the knob to O
position.
Note: 1) For each use, the consecutive operation time should not
exceed 3 minutes. at least 10 minutes rest time must be
maintained between two continuous cycles, let the unit cool to
room temperature before performing next operation cycle.
2) If you want to stop the machine during operation, turn the knob
to O position anytime.
Important operating tips
10.Fill the grinding bowl with proper bean (such as coffee bean), then
assemble the grinding blade assembly and grinding bowl together.
Please see.
NOTE:
1. Do not run the appliance for more than 3 minutes per time, and only
wait until the unit is cooled to room temperature before performing
next operation cycles.
2. The quantity of bean to be allowed to grind by the grinding bowl is
Max 35g, and the finished time is about 30s.
3. Then place the prepared chopping food into the bowl.The food must
be cut into small size firstly(such as 2cm*2cm*6cm for beef).
4. The appliance allows you to chop the maximum quantity of beef or
Fig.6 Fig.7
Before blending, add
food to be blended
into the jar.
During blending, add the
ingredient through the lid
opening.

9
meat is 150g. Select the highest speed and operate for 40S。
zFor best circulation of food that are to be blended with some liquid,
pour the liquid into the jar first, then add solids.
zSome of the tasks that cannot be performed efficiently with a
blender are: beating egg whites, whipping cream, mashing potatoes,
grinding meat, mixing dough, extracting juice from fruit and
vegetable
zThe following items should never be placed in the unit as they may
cause damage: bones, large pieces of solid, frozen food, or tough
foods such as turnips.
zTo crush ice, add up to 6 ice cubes. If more ice is needed, remove
the cup and add cubes one by one through the lid opening.
CARE AND CLEANING
This product contains no user serviceable parts. Refer service to
qualified service personnel.
1. Before cleaning, unplug the blender.
2. Always wash immediately after use for easier cleaning. Don’t let food
dry on the jar assembly as this will make cleaning difficult.
3. Pour a little warm soapy water into the jar and turn the knob to P
position for a few seconds. And then empty the jar.
4. Dismantle all detachable parts. Lift the jar assembly off the motor
unit, To detach the blade assembly by turning it clockwise from the
jar base bottom , and remove the seal ring 2 and blade assembly
(see fig.8). In addition, detach the jar cover seal ring 1 from the jar

10
cover.
5. Rinse the measure cup, lid, seal ring 1, jar, seal ring 2 and blade
assembly by hands or in a dishwasher and then dry. They are
dishwasher safe components, but the temperature setting shall not
exceed 70℃.
6. Brush the blade clean using warm soapy water, then rinse
thoroughly under the tap. Don’t touch the sharp blades, handle
carefully. Don’t immerse the blade assembly in water. Leave to
dry upside down away from children.
7. Wipe the motor unit with a damp cloth and dry thoroughly. Remove
the stubborn spots by rubbing with non-abrasive cleaner. If liquids
spill into the motor unit; first unplug the unit, then wipe with a damp
cloth and dry thoroughly.
CAUSION：
1) Do not immerse the motor unit in liquid to prevent the risk of
electric shock.
2) Do not use rough scouring pads or cleansers on parts or
finish.
Fig.8

11
ENVIRONMENT FRIENDLY DISPOSAL
You can help protect the environment!
Please remember to respect the local
regulations: hand in the non-working
electrical equipments to an appropriate
waste disposal centre.
