RAMTONS RM/391 User manual

BLENDER
INSTRUCTION MANUAL
MODEL: RM/391
Read this manual thoroughly before using and save it for future reference

1
IMPORTANT SAFEGUARDS
When using electrical appliance. Basic safety precautions should always
be followed including the following:
1. Read all instructions.
2. Before using check that the voltage power corresponds to the one
shown on the appliance nameplate.
3. Do not let cord hang over edge of table or counter.
4. Do not operate any appliance with a damage cord or plug or after the
appliance malfunction or has been damaged in any manner. Return
the appliance to the nearest authorized service facility for examination,
repair or adjustment.
5. If the supply cord is damaged，it must be replaced by the manufacture
or its service agent or a similarly quality person in order to avoid a
hazard .
6. Close supervision is necessary when any appliance is used by or
near children.
7. Avoid contacting moving parts.
8. Blades are sharp, so handle carefully.
9. Never use hot liquids or run the appliance empty.
10. The use of accessory not recommended or sold by the manufacturer
may cause fire，electric shock or injury。
11. The appliance can not be used for blending or chopping hard and dry
substance, otherwise the blade could be blunted. But it can be used
for blending ice cube.
12. Unplug from outlet when not in use, before putting on or taking off
parts, and before cleaning.
13. To protect against risk of electrical shock do not put unit in water or
other liquid.
14. Be sure blending cover are accurately put in place before operating
appliance
15. Keep hands and utensils out of container while blending to reduce the
risk of severe injury to persons or damage to the blender. A scraper
may be used but must be used only when the blender is not running.
16. To reduce the risk of injury, never place cutter-assembly blades on
base without jar or bowl properly attached.
17. The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
18. This appliance is not intended for used by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliances by a person

2
responsible for their safety.
19. Children should be supervised to ensure that they do not play with the
appliance.
20. Do not immerse the Motor Unit into water or other liquids.
21. Crushing ice or blending viscous food at the highest speed.
22. Do not use outdoors.
23. Save these instructions.
HOUSEHOLD USE ONLY
KNOW YOUR BLENDER

3
BEFORE THE FIRST USE
Check that all parts are complete and not damaged. Choose the
appropriate attachment to perform your desired task. The blender
attachment is suitable for blending fruits or vegetables or crushing ice,
while the coffee grinder attachment for grinding coffee.while the grinder
attachment for grinding the cayennes or garlics. Clean the attachment
according to the section “CLEANING AND MAINTENANCE”.
WARNING: The blade is sharp, handle with great care and ensure
that unplug the appliance from outlet before assembling and
removing parts.
BLENDER OPERATIO
1. Lay the motor unit on the flat horizontal surface and make sure it is
unplugged.
2. Place the Jar on the Motor Unit, let the triangle almost align with the
word “UNLOCK” on jar base and then turn the jar clockwise until the
triangle aligns with the word “LOCK”, a click will be heard when
locked into position properly. Please see Fig.1.
NOTE: There is a safety interlock device at the bottom of jar, if the jar
is not assembled in place, the blender will not operate.
3. Open the jar cover by turning anticlockwise and place it on the
surface.Peel or core the fruits or vegetables and then cut it into small
pieces, then put them into the jar. Usually certain amount of purified
water has to be added to facilitate the smooth running of appliance.
The amount of mixture should not exceed the max level as indicated
on the jar, nor sit lower the min level. The best proportion of the fruits
or vegetables and water is 2:3.When blending light liquids do not
fill above the 1250ml mark indicated on the blender jug to avoid
overspill from the jug brim。

4
NOTE: The blender is not applicable for beating egg white, mashing
potatoes, mixing dough, extracting juice from fruit and vegetable.
4. Replace jar cover on the jar and turn it by clockwise.
NOTE: There is a safety interlock device at the side of jar cover, if
the jar cover is not assembled in place, the blender will not operate.
5. You may add ingredient into the jar through the center opening of jar
cover during operation, then replace measuring cup if necessary. Let
the tabs of measuring cup aligns with the grooves of jar cover, put
down and turn the measuring cup by anti-clockwise until it in place.
6. Ensure the Speed Selector to “0” Position,then plug into power
outlet and set Speed Selector to your desired setting. You can set
Speed Selector to the “M” position if want to accelerate the process
of blending. The detailed information is shown in below fig. 2
NOTE: Make sure the jar cover is placed in position completely
before operating, and never open the jar cover during operation.
1
M
2
3
4
5
0
Pulse
To start pulsing, hold the
knob to this position
To stop pulsing, release
the knob
Stop
To stop the appliance at any time
set the knob to this position
Lowest
Highest
7. Do not operate for more than 3 minutes per time, at least 10 minutes
rest time must be maintained between two continuous cycles, let the
unit cool to room temperature before performing next operation cycle.
Fig. 2

5
8. Turn the Speed Selector to “0” Position once the mixture has been
blended to your desired consistency.
9. Turn the jar by anti-clockwise and remove it from the motor unit,
carefully take down the jar cover, then pour and serve.
COFFEE GRINDER OPERATION
1. Lay the motor unit on the flat horizontal surface
and make sure it is unplugged.
2. Fill the grinding bowl with proper coffee bean,
then assemble the grinding blade assembly and
grinding bowl together. Please see Fig.6
NOTE: The quantity of coffee bean the grinding
bowl allows to grind is Max 60g.
3. Place the grinder attachment on the motor unit,
let the triangle almost aligns with the word
“UNLOCK” on bowl base then turn the bowl
clockwise until the triangle aligns with the word
“LOCK”, a click will be heard when locked into
position properly. Please see Fig. 7
NOTE: There is a safety interlock device at the
bottom of bowl, if the bowl is not assembled in
place, the grinder will not operate.
4. Ensure the Speed Selector to “0” Position,
then plug into power outlet.
5. Select the desired speed setting, the appliance
will start grinding. During grinding, you can
tweak the Pulse button without releasing it if
want to accelerate the process of grinding.
6. Turn the Speed Selector to “0” Position once
the coffee has been ground to your desired
result.
7. Disconnect from power supply once finished.
Disassemble the grinder attachment from the
unit, keep the grinding bowl downward and turn it by anticlockwise
(see fig.8), then empty the bowl and serve.
8. Do not run the appliance for more than 1 minutes per time, at least 10
minutes rest time must be maintained between two continuous cycles,
let the unit cool to room temperature before performing next operation
cycle.

6
GRINDER OPERATION
9. Lay the motor unit on the flat horizontal surface
and make sure it is unplugged.
10. Fill the grinding bowl with proper cayennes or
garlics, then assemble the grinding blade
assembly and grinding bowl together. Please
see Fig.6
NOTE: The quantity of cayennes or garlics the
grinding bowl allows to grind is Max 60g.
11. Place the grinder attachment on the motor unit,
let the triangle almost aligns with the word
“UNLOCK” on bowl base then turn the bowl
clockwise until the triangle aligns with the word
“LOCK”, a click will be heard when locked into
position properly. Please see Fig. 7
NOTE: There is a safety interlock device at the
bottom of bowl, if the bowl is not assembled in
place, the grinder will not operate.
12. Ensure the Speed Selector to “0” Position,
then plug into power outlet.
13. Select the desired speed setting, the appliance
will start grinding. During grinding, you can
tweak the Mwithout releasing it if want to
accelerate the process of grinding.
14. Turn the Speed Selector to “0” Position once
the coffee has been ground to your desired
result.
15. Disconnect from power supply once finished.
Disassemble the grinder attachment from the unit, keep the grinding
bowl downward and turn it by anticlockwise (see fig.8), then empty
the bowl and serve.
16. Do not run the appliance for more than 1 minutes per time, at least 10
minutes rest time must be maintained between two continuous cycles,
let the unit cool to room temperature before performing next operation
cycle.

7
WARNING:
1. Never operate the appliance continuously for more than 3 minutes per
time.
2. Blades are very sharp. Handle with care.
3. Do not operate without the jar or bowl cover in place.
4. Do not disassemble the jar or bowl from the jar base or bowl base in
general condition.
CLEANING AND MAINTENANCE
Make sure to disconnect appliance from power supply before cleaning
For blender
The Auto Clean function can clean the blender easily and rapidly in
complete safety.
1. Pour a little warm soapy water into the Jar and turn the Speed
Selector to “M” position for a few seconds.
2. Remove the Jar and rinse under running water.
3. Dismantle all detachable parts.Disassemble the Jar from the motor
unit and rinse it under running water, then detach the blade assembly
from the jar assembly, take the blade assembly out, finally remove the
jar base seal ring (see fig.6). In addition, detach the measure cup
from the jar cover. Rinse the jar, blade, jar base, jar cover and
measure cup under running water.
4. Wipe the outer surface of motor unit with a damp cloth

8
NOTE: Do not use abrasive cleanser and never immerse it in water
for cleaning
5. Dry all parts and then assemble them. The method of assembling
blender attachment just is in opposite of its detaching sequence.
NOTE: If any problem has been encountered during using, never
disassemble the Motor Unit by yourself. There are no user
serviceable parts inside. Only contact the authorized service facility
for examination and repair.
For grinder or coffee grinder
1. Detach the bowl base from the grinding blade assembly.
NOTE: While detaching, only grasp the unsharp part of grinding
blade or wear glove to prevent any injuries.
2. Immerse the blade, bowl base and grinding bowl into warm soapy
water for cleaning, and then rinse them under running water.
3. Wipe the outer surface with damp cloth.
NOTE: Never immerse the motor unit into water for cleaning.
4. Dry all parts thoroughly and assemble them in position.
ENVIRONMENT FRIENDLY DISPOSAL
You can help protect the environment!
Please remember to respect the local regulations: hand
in the non-working electrical equipments to an
appropriate waste disposal centre.
