Randell 2021F User manual

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Upright Reach-In Double Glass Door Freezer models 2021F
Randell Series 2000 Upright are built for years of efficient, high
performance service. The top mounted, expansion valve refrig-
eration system offers the highest, most consistent performance
available while maximizing usable interior space.
model 2021F shown
CABINET EXTERIOR: Cabinet body is constructed of all metal,
inside & out. The top, bottom, & back are galvanized steel. Front
and sides are available in finishes as listed above. Doors and
louver are removable without tools. Unit on 6" casters, front two
are locking.
CABINET INTERIOR: Interior of cabinet is fully coved to meet
N.S.F. standard #7. The interior walls, ceiling and door liner are
available in either stainless steel or anodized aluminum as listed
above. Foamed in place, CFC free urethane insulation. Snap-in
A.B.S. breaker strips allow access to condensate heater wires.
DOORS: Glass front with either anodized aluminum or stainless
steel liner,mounted on heavy duty cam lift hinges with automatic
light switch, heavy duty chrome handle, cylinder door lock.
REFRIGERATION: Top mounted condensing unit and evaporator
coil, expansion valve system with pressure control, factory
tested and balanced to maintain (0˚ F. to -5˚ F.) average interior
temperature utilizing CFC free 404a refrigerant. Evaporator coil
is coated to resist corrosion. Unit supplied with master on/off
switch and 8' cord and plug. Access to service points without
tools is standard. Provided with full automatic coil defrost with
programmable timer and safety switches.
Standard Features Continued:
• C.F.C. Free R-404a Refrigerant
• Efficient Hot Gas Condensate Evaporator
• Full Automatic Coil Defrost With Programable Timer and Safety Switches
• 8' Cord & Plug
• Main Power Supply Switch
• Self-Closing Cam Lift Hinges with 120˚ Open Feature (Lifetime Warranty)
• Automatic Interior Light on door
• 6" Casters - Factory Mounted (Front two Locking)
• Cylinder Door Locks
• Fully Coved Interior Meeting N.S.F. Standard #7
• Polyurethane Insulation
• Condensate Heaters Around All Door Openings
• 3 Baked Epoxy Coated Wire Shelves Per Section
With Stainless Steel Support Clips (Adjustable every 1")
• Snap-In Magnetic Door Gaskets
Description:
Specifications:
Randell Upright, Page 8
Revised 07/07
Standard Features:
• Expansion Valve
• Digital Control
• Exterior LED Temperature Display
• Top mounted Compressor & Evaporator Coil
Standard Series Louver: Stainless steel.
Exterior Sides: Anodized aluminum. Interior: Anodized aluminum
E Series (Add Suffix “E”) Cabinet interior, exterior sides
and fronts stainless steel.
Finishes:
Universal Tray Slides (set of two) Qty. Sets
1/2 Doors Qty. Location
6" Legs
Extra Interior Shelves Qty.
(maximum of (23) or (20) additional on 1.5" centers-leaves 1" clear)
Finished Back
Export Voltage(s) Specify Voltage
Prison Package
Options & Accessories:
Refrigeration Type (Add Suffix “R”):
Remote
0°F to -5°F 60°F to 180°F0°F to -5°F
some models
available
for -10°F
applications,
consult
factory

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
Models 2021F
SELF-CONTAINED SINGLE SECTION FREEZERS
*Based on 90˚ ambient and -10˚ evaporator.
Model
2021F solid door
L
55”
D
33 1/2"
H
81.25”
Doors
2
HP
2/3
Volt
115/60/1
Amps
15.4
NEMA
5-20P
BTU Rating
3520*
Ship Wt.
620
Cu./Ft.
46.08
Shelves
6
Shelves Sq. Ft.
26
FOR REMOTE MODELS
Use same specifications as self-contained models except for:
Model No. Rec. H.P. Rec. BTU/Hr. Amp. Ship Wt.
2021FR solid door 3/4 3520 9 570
Note: All remote Upright come standard on 6" legs in lieu of casters.
TRAYSLIDE CAPACITIES
Universal Pan Slides .... Model....RIUNIVPS - set of two.
For 12 x 20 food pans or 18 x 26 sheet pans.
Maximum capacity of 12" x 20" food pans per full height section:
(6) 6" deep pans, (8) 4" deep pans, (18) 2" deep pans.
Maximum capacity of 18" x 26" sheet pans with 2" spacing is (22).
115V/60Hz/1Ph
15.4 Amps
JUNCTION BOX
9' LONG CORD SET
DT DEFROST TIMER
(NEMA 5-20P)
OC CONDENSATE DRAIN 1/2"
EH EVAPORATOR HOUSING
J
CONDENSATE
HOT GAS
EVAPORATOR
3520 BTU/Hr
2/3hp COMPRESSOR
MODEL # 2020F
LEGEND FOR
HP
INDUSTRIESCOMPANY
JJUNCTION BOX
115V/60Hz/1Ph
CONDENSATE
HOT GAS
EVAPORATOR
OC CONDENSATE DRAIN 1/2"
DT DEFROST TIMER
EH EVAPORATOR HOUSING
9' LONG CORD SET
15.4 Amps
(NEMA 5-20P)
4180 BTU/Hr
3/4hp COMPRESSOR
R404A REFRIGERANT
MODEL # 2021F
LEGEND FOR
HP
INDUSTRIESCOMPANY
EH
DT
OC
HP
J
26.5"
31.25"
DIGITAL
CONTROL
J
EH
DT
HP
OC
26.25"
31.25"
55" 33.5"
81"
55" 33.5"
81"
LIGHT SWITCH
DIGITAL
CONTROL
MODEL # 2021F
MODEL #2020F
58.25"
