Randell RanSpec 64335 User manual

1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
RanSpec Remote Worktop Freezer models 64000
Description:
Remote freezer base with 16 gauge reinforced stainless steel
top, and integral backsplash with 45˚ return. Stainless steel
doors on concealed hinges. CFC free, R-404a refrigeration
system. Condensing unit and controls not provided. Evaporator
blower coil with expansion valve supplied and installed. Unit
with automatic defrost system, and heated door frames. 6" high
adjustable and movable legs.
Standard Features:
• Available under one piece top with other modular
equipment up to 16' in length
• 6" high legs—adjustable and movable
• Foamed in place “CFC free” urethane insulation
• Refrigeration system utilizes “CFC free” R- 404a
refrigerant, expansion valve for fast recovery, and
digital control for field adjustability and solenoid value
• Automatic coil defrost system
• 45˚ integral stainless backsplash is standard. 90˚
stainless backsplash is optional.
• Front breathing louver design allows sealing to wall &
curb mounting without special requirements
• Precise temperature settings, LED temperature readout
• Filter dryer installed on liquid line
Specifications:
Options & Accessories:
Stainless Steel Ends
Stainless Steel Back
Casters in lieu of legs
Flat Top with no backsplash
CABINET EXTERIOR: Top to be one piece of die-formed 16 gauge
stainless steel with 2 1/2" nosing. Backsplash to be coved
cornered, with 45˚ return at top and overall height of 6 3/4".
Ends at top fitted with recessed heavy duty steel bars for field
bolting units together, producing a hairline seam. Exterior body
to be corrosion resistant steel. Door opening frame to be ABS
and contain magnetic strip for positive sealing of gaskets and
heater elements to prevent gasket freezing. Back-up element
installed. Work surface to be at 36" work height. Legs to be 6"
high stainless steel with adjustable bullet foot. Legs mounted to
full length channel frame assembly which is integrally welded
to bottom of body assembly. Legs can be moved left to right to
avoid floor obstacles during installation.
CABINET INTERIOR: Base interior to be ABS thermoplastic at
ends only. Stainless steel interior liner to be coved cornered to
form bottom, back and top. One baked enamel finished shelf
provided behind each door. Unit insulation to be CFC free foamed
in place urethane.
DOORS: Door fronts to be 22 gauge stainless steel with 16 gauge
stainless steel handles, magnetic gaskets, ABS door liner and
foamed in place insulation. Hinges are concealed, all stainless
steel with bronze pivot pin in nylon bushing.
REFRIGERATION: Refrigerant to be specified by customer
(Specification based on R-404a refrigerant). Interior fitted with
Randell evaporator blower coil for cooling base. Expansion valve
and refrigeration lines provided and installed for connection at
unit rear. Blower coil fitted with expansion valve for fast recovery
and automatic defrost heater system with digital control and
safety switches. Condensing unit not provided. Unit totally
prewired to junction box for 115V operation.
Shown with optional finished end.
Randell RanSpec, Page 24
PP SPEC0139 Rev. A
Revised 08/07
model 64335 64338 64341 64352 64358 64364 64382

1055 Mendell Davis Drive, Jackson, MS 39272, 888-994-7636, unifiedbrands.net
Information contained in this document is known to be current and accurate at the time
of printing/creation. Unified Brands recommends referencing our product line websites,
unifiedbrands.net, for the most updated product information and specifications.
64000 Series
.25" LIQUID, .375" SUCTION
CONDENSATE DRAIN 1/2 "
PVC 8-1/2" AFF.
EVAPORATOR COIL
& DEFROST CONTROL
115V-60Hz-1Ph
AFF. = ABOVE FIXED FLOOR
LEGEND
R134A REFRIG.
LOCATION
DIGITAL TEMP.
JUNCTION BOX
R-22 REFRIG.
R404 REFRIG.
CHOOSE ONE:
LINE 8.5" AFF
OC
OR
J
33"
36"
42.75"
OR
OC
J
6"
COIL
PANEL
27"FREEZER 27"FREEZER
64"
24"FREEZER
PANEL
COIL
24"FREEZER
58"
PANEL
COIL
21"FREEZER21"FREEZER
52"
27"FREEZER
COIL
PANEL
41"
COIL
PANEL
24"FREEZER
38"
21"FREEZER
COIL
PANEL
35"
24"FREEZER 24"FREEZER24"FREEZER
PANEL
COIL
82"
Component
SECTION VIEW
64000 SERIES REMOTE FREEZERS WITH STAINLESS STEEL TOPS
Length
35" 38" 41" 52" 58" 64" 82"
Model 33" Deep 64335 64338 64341 64352 64358 64364 64382
# of Doors
(1) 21"
+ 8" coil hsg.
+ 6" mech. hsg.
(1) 24"
+ 8" coil hsg.
+ 6" mech. hsg.
(1) 27"
+ 8" coil hsg.
+ 6" mech. hsg.
(2) 21"
+ 4" mullion
+ 6" mech. hsg.
(2) 24"
+ 4" mullion
+ 6" mech. hsg.
(2) 27"
+ 4" mullion
+ 6" mech. hsg.
(3) 24"
+ 4" mullion
+ 6" mech. hsg.
Storage Cu. Ft.
(33” Deep) 5.86 6.84 7.81 11.39 13.35 15.30 21.16
Storage Cu. Ft.
(29” Deep) 4.92 5.74 6.56 9.57 11.21 12.85 17.77
Recommended*
H.P./Refrigerant 1/3hp/404a 1/3hp/404a 1/3hp/404a 1/2hp/404a 1/2hp/404a 1/2hp/404a 3/4hp/404a
Volt/Cycle/
Phase 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1 115/60/1
Amps 6 6 6 6 6 6 6
Ship Wt. - lbs. 355 370 385 445 475 505 700
BTU Design Load 956 1015 1064 1536 1635 1734 2321
Evap. BTU 160 160 160 160 160 160 160
* BTU loads shown are based on 100°F ambient with 30% added for usage and product loading. Final system selection should consider usage requirements and
combined loads. Recommended HP reflects Randell HP applied to self-contained (single) unit of equal storage capacity. Increasing HP may be appropriate in some
remote applications.
