R&S SMCVB-K167 User manual

R&S®SMCVB-K167
DVB-S
User Manual
User Manual
Version 02
1179105802
(;Ý:È2)

This document describes the following software option:
●R&S®SMCVB-K167
1434.3954.02
This manual describes firmware version FW 4.70.176.xx and later of the R&S®SMCV100B.
© 2020 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1179.1058.02 | Version 02 | R&S®SMCVB-K167
The following abbreviations are used throughout this manual: R&S®SMCVB is abbreviated as R&S SMCVB

Contents
R&S®SMCVB-K167
3User Manual 1179.1058.02 ─ 02
Contents
1 Preface.................................................................................................... 5
1.1 About this Manual......................................................................................................... 5
1.2 Documentation Overview............................................................................................. 6
1.2.1 Getting Started Manual................................................................................................... 6
1.2.2 User Manuals and Help...................................................................................................6
1.2.3 Service Manual............................................................................................................... 6
1.2.4 Instrument Security Procedures......................................................................................7
1.2.5 Printed Safety Instructions.............................................................................................. 7
1.2.6 Data Sheets and Brochures............................................................................................ 7
1.2.7 Release Notes and Open Source Acknowledgment (OSA)............................................ 7
1.2.8 Application Notes, Application Cards, White Papers, etc................................................7
2 Welcome to the DVB-S / DVB-S2 Option..............................................8
2.1 Accessing the DVB-S / DVB-S2 Dialog....................................................................... 8
2.2 Scope............................................................................................................................. 9
2.3 Notes on Screenshots.................................................................................................. 9
3 About the DVB-S / DVB-S2 Option..................................................... 10
3.1 Required Options........................................................................................................ 10
4 DVB-S Configuration and Settings..................................................... 11
4.1 General Settings..........................................................................................................11
4.2 Input Signal Settings.................................................................................................. 12
4.2.1 General Settings........................................................................................................... 13
4.2.2 Info................................................................................................................................ 16
4.2.3 Test Signal Settings.......................................................................................................17
4.2.4 IP Channnel x Settings..................................................................................................19
4.3 Coding Settings...........................................................................................................22
4.4 Special Settings.......................................................................................................... 24
4.5 Global Connector Settings.........................................................................................25
4.6 TS Player......................................................................................................................25
4.6.1 TS Player Settings........................................................................................................ 26
4.6.2 Player Output................................................................................................................ 29

Contents
R&S®SMCVB-K167
4User Manual 1179.1058.02 ─ 02
4.6.2.1 General......................................................................................................................... 29
4.6.2.2 Stuffing.......................................................................................................................... 31
4.6.3 Seamless Loop Settings............................................................................................... 32
4.7 Local IP Data Network Settings................................................................................. 34
5 Performing DVB-S / DVB-S2 Signal Generation Tasks.....................37
5.1 Configuring the Input Signal......................................................................................37
5.1.1 How to Apply an External IP Input Signal..................................................................... 37
5.1.2 How to Apply an External TS Input Signal.................................................................... 40
5.1.3 How to Generate an Internal TS Signal........................................................................ 41
5.2 Monitoring the Input Signal........................................................................................41
5.2.1 How to Monitor External IP Input Data..........................................................................42
5.2.2 How to Monitor an External TS Input Signal................................................................. 42
5.2.3 How to Monitor an Internal TS Player Signal................................................................ 43
6 Remote-Control Commands............................................................... 44
6.1 General Commands.................................................................................................... 45
6.2 Input Signal Commands............................................................................................. 46
6.2.1 General Commands...................................................................................................... 46
6.2.2 Info Commands.............................................................................................................48
6.2.3 Test Signal Commands................................................................................................. 49
6.2.4 IP Subsystem................................................................................................................ 51
6.3 Coding Commands..................................................................................................... 54
6.4 Special Commands..................................................................................................... 55
6.5 TSGen Subsystem...................................................................................................... 56
6.6 BCIP Subsystem......................................................................................................... 63
Glossary: Abbreviations......................................................................67
Glossary: Specifications..................................................................... 69
List of Commands................................................................................70
Index......................................................................................................72

Preface
R&S®SMCVB-K167
5User Manual 1179.1058.02 ─ 02
1 Preface
1.1 About this Manual
This user manual provides all the information specific to the DVB-S / DVB-S2 option
R&S SMCVB-K167. All general instrument functions and settings common to all appli-
cations and operating modes are described in the main R&S SMCV100B user manual.
The main focus in this manual is on the provided settings and the tasks required to
generate a signal. The following topics are included:
●Welcome to the DVB-S / DVB-S2 option R&S SMCVB-K167
Introduction to and getting familiar with the option
●About the DVB-S / DVB-S2
Background information on basic terms and principles in the context of the signal
generation
●DVB-S / DVB-S2 Configuration and Settings
A concise description of all functions and settings available to configure signal gen-
eration with their corresponding remote control command
●How to Generate a Signal with the DVB-S / DVB-S2 Option
The basic procedure to perform signal generation tasks and step-by-step instruc-
tions for more complex tasks or alternative methods
As well as detailed examples to guide you through typical signal generation sce-
narios and allow you to try out the application immediately
●Remote Control Commands
Remote commands required to configure and perform signal generation in a
remote environment, sorted by tasks
(Commands required to set up the instrument or to perform common tasks on the
instrument are provided in the main R&S SMCV100B user manual)
Programming examples demonstrate the use of many commands and can usually
be executed directly for test purposes
●List of remote commands
Alphabetical list of all remote commands described in the manual
●Index
Contents and scope
This description assumes R&S SMCV100B equipped with all available options.
Depending on your model and the installed options, some of the functions may not be
available on your instrument.
Notes on screenshots
When describing the functions of the product, we use sample screenshots. These
screenshots are meant to illustrate as much as possible of the provided functions and
possible interdependencies between parameters. The shown values may not represent
realistic usage scenarios.
About this Manual

Preface
R&S®SMCVB-K167
6User Manual 1179.1058.02 ─ 02
The screenshots usually show a fully equipped product, that is: with all options instal-
led. Thus, some functions shown in the screenshots may not be available in your par-
ticular product configuration.
1.2 Documentation Overview
This section provides an overview of the R&S SMCV100B user documentation. Unless
specified otherwise, you find the documents on the R&S SMCV100B product page at:
www.rohde-schwarz.com/manual/smcv100b
1.2.1 Getting Started Manual
Introduces the R&S SMCV100B and describes how to set up and start working with the
product. Includes basic operations, typical measurement examples, and general infor-
mation, e.g. safety instructions, etc. A printed version is delivered with the instrument.
1.2.2 User Manuals and Help
Separate manuals for the base unit and the software options are provided for down-
load:
●Base unit manual
Contains the description of all instrument modes and functions. It also provides an
introduction to remote control, a complete description of the remote control com-
mands with programming examples, and information on maintenance, instrument
interfaces and error messages. Includes the contents of the getting started manual.
●Software option manual
Contains the description of the specific functions of an option. Basic information on
operating the R&S SMCV100B is not included.
The contents of the user manuals are available as help in the R&S SMCV100B. The
help offers quick, context-sensitive access to the complete information for the base unit
and the software options.
All user manuals are also available for download or for immediate display on the Inter-
net.
1.2.3 Service Manual
Describes the performance test for checking the rated specifications, module replace-
ment and repair, firmware update, troubleshooting and fault elimination, and contains
mechanical drawings and spare part lists.
The service manual is available for registered users on the global Rohde & Schwarz
information system (GLORIS):
Documentation Overview

Preface
R&S®SMCVB-K167
7User Manual 1179.1058.02 ─ 02
https://gloris.rohde-schwarz.com
1.2.4 Instrument Security Procedures
Deals with security issues when working with the R&S SMCV100B in secure areas. It
is available for download on the Internet.
1.2.5 Printed Safety Instructions
Provides safety information in many languages. The printed document is delivered with
the product.
1.2.6 Data Sheets and Brochures
The data sheet contains the technical specifications of the R&S SMCV100B. It also
lists the options and their order numbers and optional accessories.
The brochure provides an overview of the instrument and deals with the specific char-
acteristics.
See www.rohde-schwarz.com/brochure-datasheet/smcv100b
1.2.7 Release Notes and Open Source Acknowledgment (OSA)
The release notes list new features, improvements and known issues of the current
firmware version, and describe the firmware installation.
The open-source acknowledgment document provides verbatim license texts of the
used open source software.
See www.rohde-schwarz.com/firmware/smcv100b
1.2.8 Application Notes, Application Cards, White Papers, etc.
These documents deal with special applications or background information on particu-
lar topics.
See www.rohde-schwarz.com/application/smcv100b
Documentation Overview

Welcome to the DVB-S / DVB-S2 Option
R&S®SMCVB-K167
8User Manual 1179.1058.02 ─ 02
2 Welcome to the DVB-S / DVB-S2 Option
The R&S SMCVB-K167 is a firmware application that adds functionality to generate
signals in accordance with the DVB-S / DVB-S2 digital standards.
The R&S SMCVB-K167 option features:
●DVB-S signal generation
●Basic DVB-S2 signal generation
This user manual contains a description of the functionality that the application pro-
vides, including remote control operation.
All functions not discussed in this manual are the same as in the base unit and are
described in the R&S SMCV100B user manual. The latest version is available at:
www.rohde-schwarz.com/manual/SMCV100B
Installation
You can find detailed installation instructions in the delivery of the option or in the
R&S SMCV100B service manual.
2.1 Accessing the DVB-S / DVB-S2 Dialog
To open the dialog with DVB-S / DVB-S2 settings
► In the block diagram of the R&S SMCV100B, select "Baseband > DVB-S / DVB-
S2".
A dialog box opens that displays the provided general settings.
The signal generation is not started immediately. To start signal generation with the
default settings, select "State > On".
Accessing the DVB-S / DVB-S2 Dialog

Welcome to the DVB-S / DVB-S2 Option
R&S®SMCVB-K167
9User Manual 1179.1058.02 ─ 02
2.2 Scope
Tasks (in manual or remote operation) that are also performed in the base unit in the
same way are not described here.
In particular, it includes:
●Managing settings and data lists, like storing and loading settings, creating and
accessing data lists, or accessing files in a particular directory.
●Information on regular trigger, marker and clock signals and filter settings, if appro-
priate.
●General instrument configuration, such as checking the system configuration, con-
figuring networks and remote operation
●Using the common status registers
For a description of such tasks, see the R&S SMCV100B user manual.
2.3 Notes on Screenshots
When describing the functions of the product, we use sample screenshots. These
screenshots are meant to illustrate as many as possible of the provided functions and
possible interdependencies between parameters. The shown values may not represent
realistic usage scenarios.
The screenshots usually show a fully equipped product, that is: with all options instal-
led. Thus, some functions shown in the screenshots may not be available in your par-
ticular product configuration.
Notes on Screenshots

About the DVB-S / DVB-S2 Option
R&S®SMCVB-K167
10User Manual 1179.1058.02 ─ 02
3 About the DVB-S / DVB-S2 Option
DVB-S and DVB-DSNG are DVB standards for satellite services. DSNG is the abbrevi-
ation for digital news gathering.
DVB-S complies with specification EN 300 421.
DVB-DSNG complies with specification EN 301 210.
3.1 Required Options
The equipment layout for generating DVB-S / DVB-S2 signals includes:
●Base unit
●Option Enable Broadcast Standard (R&S SMCVB-K519)
●Option DVB-S / DVB-S2 (R&S SMCVB-K167)
Required Options

DVB-S Configuration and Settings
R&S®SMCVB-K167
11User Manual 1179.1058.02 ─ 02
4 DVB-S Configuration and Settings
Access:
► Select "Baseband > DVB-S".
This section provides an overview on the DVB-S / DVB-S2 settings.
The remote commands required to define these settings are described in Chapter 6,
"Remote-Control Commands", on page 44.
Settings:
●General Settings......................................................................................................11
●Input Signal Settings............................................................................................... 12
●Coding Settings.......................................................................................................22
●Special Settings...................................................................................................... 24
●Global Connector Settings...................................................................................... 25
●TS Player................................................................................................................ 25
●Local IP Data Network Settings.............................................................................. 34
4.1 General Settings
Access:
► Select "Baseband > DVB-S".
The tab provides functionality for calling default settings, save and recall settings.
Settings:
State.............................................................................................................................. 11
Set To Default................................................................................................................12
Save/Recall................................................................................................................... 12
State
Activates the standard and deactivates all the other digital standards and digital modu-
lation modes in the same path.
Remote command:
[:SOURce<hw>]:BB:DVBS:STATe on page 45
General Settings

DVB-S Configuration and Settings
R&S®SMCVB-K167
12User Manual 1179.1058.02 ─ 02
Set To Default
Calls the default settings. The values of the main parameters are listed in the following
table.
Parameter Value
State Not affected by the "Set to Default"
Remote command:
[:SOURce<hw>]:BB:DVBS:PRESet on page 45
Save/Recall
Accesses the "Save/Recall" dialog, that is the standard instrument function for saving
and recalling the complete dialog-related settings in a file. The provided navigation
possibilities in the dialog are self-explanatory.
The filename and the directory, in that the settings are stored, are user-definable; the
file extension is however predefined.
See also, chapter "File and Data Management" in the R&S SMCV100B user manual.
Remote command:
[:SOURce<hw>]:BB:DVBS:SETTing:CATalog? on page 45
[:SOURce<hw>]:BB:DVBS:SETTing:LOAD on page 46
[:SOURce<hw>]:BB:DVBS:SETTing:STORe on page 46
[:SOURce<hw>]:BB:DVBS:SETTing:DELete on page 45
4.2 Input Signal Settings
Access:
► Select "Baseband > DVB-S / DVB-S2 > Input Signal".
The dialog provides access to settings necessary to configure the input signal.
Input signal tasks
The settings allow you to perform the following tasks:
●Selecting an MPEG TS source
●Displaying information about the selected MPEG TS (e.g. data rate)
●Configuring the internal MPEG TS test packets or internal IP test packets
How to: Chapter 5.1, "Configuring the Input Signal", on page 37.
Input Signal Settings

DVB-S Configuration and Settings
R&S®SMCVB-K167
13User Manual 1179.1058.02 ─ 02
Common input signal settings
The setting of the following parameters is used for all broadcast standards.
●"Source"
●"Input/Input Type"
●"IP TS Channel"
Settings:
●General Settings..................................................................................................... 13
●Info.......................................................................................................................... 16
●Test Signal Settings.................................................................................................17
●IP Channnel x Settings............................................................................................19
4.2.1 General Settings
Access:
► Select "Input Signal > General".
The tab provides general settings necessary to configure the input signal.
Settings:
Source...........................................................................................................................13
Input.............................................................................................................................. 14
Input Format..................................................................................................................14
IP TS Channel...............................................................................................................14
Stuffing.......................................................................................................................... 15
Test Signal.....................................................................................................................15
Source
Sets the modulation source for the input signal.
Input Signal Settings

DVB-S Configuration and Settings
R&S®SMCVB-K167
14User Manual 1179.1058.02 ─ 02
"External" Uses a transport stream, that is input at the "TS IN"/"IP Data" inter-
face.
For more information about connecting to the interfaces, see also:
●"TS IN" interface: Section "Configuring the Global Connectors" in
the R&S SMCV100B user manual.
●"IP Data" interface: Chapter 4.7, "Local IP Data Network Set-
tings", on page 34.
Uses an internal transport stream with TS packet data played from a
file. The player requires no option.
Playing encrypted files with extension _c requires a stream library
option R&S SMCVB-KSx.
See also:
●Chapter 4.6, "TS Player", on page 25
●Supported TS player file types
"Test Signal" Uses an internal test signal as specified in Chapter 4.2.3, "Test Signal
Settings", on page 17.
Remote command:
[:SOURce<hw>]:BB:DVBS:SOURce on page 47
Input
Requires "Source > External".
Sets the external input interface.
"TS IN" Input for serial transport stream data. The signal is input at the "User
1" connector.
"IP" Input for IP-based transport stream data (TSoverIP). The signal is
input at the "IP Data" connector.
Remote command:
[:SOURce<hw>]:BB:DVBS:INPut on page 47
Input Format
Requires "Input > TS IN".
Sets the format of the input signal.
"ASI" ASI format
"SMPTE 310" SMPTE 310 format
Remote command:
[:SOURce<hw>]:BB:DVBS:INPut:FORMat on page 47
IP TS Channel
Requires "Input > IP".
Selects the IP-based transport stream (TS) channel. You can select 1 out of 4 IP TS
channels as input at the "IP Data" interface.
To configure a particular channel, see Chapter 4.2.4, "IP Channnel x Settings",
on page 19.
Remote command:
[:SOURce<hw>]:BB:DVBS:INPut:TSCHannel on page 47
Input Signal Settings

DVB-S Configuration and Settings
R&S®SMCVB-K167
15User Manual 1179.1058.02 ─ 02
Stuffing
Requires "Source > External/TS Player".
Activates stuffing.
"On" The installed input interface provides the transport stream data rate
required for the current modulation parameters (regardless of the
input data rate of the external transport stream).
"Off" The data rate of the transport stream source must match the data
rate required for the current modulation parameters.
The value equals the "Max. Useful Data Rate" on page 16.
Remote command:
[:SOURce<hw>]:BB:DVBS:STUFfing on page 47
Test Signal
Requires "Source > Test Signal".
Defines the test signal data.
The data consists of test TS packets.
"Test TS Packet"
Standardized packet data used as modulation data in the transport
stream. To configure the packet structure, select the side tab "Test
Signal > Test TS Packet".
See also " Test TS Packet" on page 18.
"PRBS before Conv. Enc."
Pure pseudo-random bit sequence (PRBS) data used as modulation
data with no packet structure. The sequence is inserted before the
convolutional encoder. PRBS data conforms with ITU-T O.151 speci-
fication.
To configure the PRBS type, select the side tab "Test Signal >
PRBS". See also "PRBS" on page 18.
Remote command:
[:SOURce<hw>]:BB:DVBS:TESTsignal on page 49
Input Signal Settings

DVB-S Configuration and Settings
R&S®SMCVB-K167
16User Manual 1179.1058.02 ─ 02
4.2.2 Info
Access:
► Select "Input Signal > Info".
The tab displays the information on the input signal.
Settings:
Packet Length............................................................................................................... 16
Max. Useful Data Rate.................................................................................................. 16
Measured Data Rate..................................................................................................... 17
Useful Data Rate...........................................................................................................17
Packet Length
Requires "Source > External".
Displays the packet length of the external transport stream in bytes.
If the packet length does not match the specified length, the output signal is erroneous.
"Packet Length > Invalid" is displayed.
"188" 188 byte packets specified for serial input ("Input > TS IN") and paral-
lel input ("Input > IP").
"204" 204 byte packets specified for serial input and parallel input.
"Invalid" Packet length does not match the specified length.
Remote command:
[:SOURce<hw>]:BB:DVBS:PACKetlength? on page 48
Max. Useful Data Rate
Requires "Source > External/TS Player".
Displays the maximum data rate, that is derived from the current modulation parameter
settings.
The value is the optimal value at the TS input interface, that is necessary for the modu-
lator.
If "Stuffing > On", the value indicates the maximum useful data rate, that is allowed in
the transport stream.
Input Signal Settings

DVB-S Configuration and Settings
R&S®SMCVB-K167
17User Manual 1179.1058.02 ─ 02
If "Stuffing > Off", the value indicates the transport stream input data rate that is
required for the transport stream.
Remote command:
[:SOURce<hw>]:BB:DVBS:USEFul[:RATE]:MAX? on page 48
Measured Data Rate
Requires "Source > External".
Displays the measured value of the data rate rmeas of one of the following:
●External transport stream including null packets input at "User 1" connector
●External transport stream including null packets input at "IP Data/LAN" connector
(TSoverIP)
The value rmeas equals the sum of useful data rate ruseful and the rate of null packets r0:
If "Stuffing > Off", ensure that the measured data rate equals the maximum useful data
rate (rmeas = rmax. useful).
Remote command:
[:SOURce<hw>]:BB:DVBS[:INPut]:DATarate? on page 49
Useful Data Rate
Requires "Source > External/TS Player".
Displays the data rate of useful data ruseful of the external transport stream. The data
rate is measured at the input of the installed input interface.
Remote command:
[:SOURce<hw>]:BB:DVBS:USEFul[:RATE]? on page 48
4.2.3 Test Signal Settings
Access:
► Select "Input Signal > Test Signal".
The tab provides settings necessary to configure the input test signal.
Input Signal Settings

DVB-S Configuration and Settings
R&S®SMCVB-K167
18User Manual 1179.1058.02 ─ 02
Settings:
Test TS Packet.............................................................................................................. 18
PID Test Packet.............................................................................................................18
PID (Hex)...................................................................................................................... 18
Payload Test/Stuff......................................................................................................... 18
PRBS............................................................................................................................ 18
Test TS Packet
Specifies the structure of the test transport stream packet that is fed to the modulator.
"Head/184 Payload"
A sync byte (0x47) followed by three header bytes and 184 payload
bytes.
"Sync/187 Payload"
A sync byte (0x47) followed by 187 payload bytes.
Remote command:
[:SOURce<hw>]:BB:DVBS:TSPacket on page 49
PID Test Packet
If a header is present in the test packet ("Test TS Packet > Head/184 Payload"), you
can specify a fixed or variable packet identifier (PID).
"Null" The header of the test transport stream packets has a fixed setting of
null packet header 1FFF (hex).
"Variable" Uses the header value defined with PID (Hex).
Remote command:
[:SOURce<hw>]:BB:DVBS:PIDTestpack on page 50
PID (Hex)
Sets the PID.
If "PID Test Packet > Null", "PID (Hex) = 1FFF" is fixed.
If "PID Test Packet > Variable", you can edit the value.
Remote command:
[:SOURce<hw>]:BB:DVBS:PID on page 50
Payload Test/Stuff.
Defines the payload area content of the TS packet.
You can select PRBS or exclusively data in hexadecimal format as payload.
For "Source > Test Signal", the packet is a test packet.
For "Stuffing > On", the packet is a null packet. Null packets are inserted into the exter-
nal transport stream to adapt the stream data rate. See also " Measured Data Rate"
on page 17.
Remote command:
[:SOURce<hw>]:BB:DVBS:PAYLoad on page 50
PRBS
Sets the length of the PRBS sequence.
Input Signal Settings

DVB-S Configuration and Settings
R&S®SMCVB-K167
19User Manual 1179.1058.02 ─ 02
You can select a PRBS 15 or a PRBS 23 sequence as specified by ITU-T O.151.
Remote command:
[:SOURce<hw>]:BB:DVBS:PRBS on page 50
4.2.4 IP Channnel x Settings
Access:
1. Select "Input Signal > General".
2. Select "Source > External"
3. Select "Input > IP"
4. Select "Input Signal > IP Channel x"
The tab provides settings necessary to configure IP channel x.
You can configure settings for 4 IP channels x = 1 to 4 individually, see also "Input
Signal > General > IP TS Channel".
IP channel settings affect input IP data of the local IP data network. The settings are
independent from the used broadcast standard configuration.
Saving/recalling a certain IP channel or local IP data network configuration is not possi-
ble via the broadcast standard-specific functionality.
Use the global save/recall functionality instead, see section "Saving and Recalling
Instrument Settings" in the R&S SMCV100B user manual.
The table below shows the availability of the tab in the broadcast standard configura-
tion.
Input Signal Settings

DVB-S Configuration and Settings
R&S®SMCVB-K167
20User Manual 1179.1058.02 ─ 02
Table 4-1: IP channel configuration support in broadcast standards
Baseband standard "IP Channel x" Baseband standard "IP Channel x"
"ATSC/ATSC-M/H" Yes "T-DMB/DAB" Yes
"ATSC 3.0" No "DVB-S" Yes
"DTMB" Yes "DVB-S2" Yes
"DVB-T" Yes "DRM" No
"DVB-T2" Yes "Audio AM" No
"ISDB-T" Yes "Audio FM" No
See also:
●Chapter 5.1.1, "How to Apply an External IP Input Signal", on page 37
●Chapter 4.7, "Local IP Data Network Settings", on page 34
Requirements
At your IP source, set the "transport stream packets per internet protocol packet" (TP
per IP) parameter as follows:
●If TP packet length = 188 bytes: Set TP per IP to 7 or 6.
●If TP packet length = 204/208 bytes: Set TP per IP to 6.
We recommend that youFurthermore, we recommend that you use a separate LAN
infrastructure to stream the transport streams via IP to the IP connector of the base-
band board. We recommend that you avoid TS packet losses during IP transmission.
Settings:
Input IP..........................................................................................................................20
Alias.............................................................................................................................. 20
Type.............................................................................................................................. 21
Multicast Address..........................................................................................................21
Port................................................................................................................................21
IGMPv3 Source Address...............................................................................................21
Ping Source Address.................................................................................................... 21
Ping Result....................................................................................................................21
Local IP Data Network.................................................................................................. 22
Input IP
Activates/deactivates the IP input.
Remote command:
[:SOURce<hw>]:BB:INPut:IP<ch>[:STATe] on page 52
Alias
Sets a unique name for the IP connection.
The definition of a name is optional but facilitates identification in the measurement
views. The name input fits maximum 16 characters in ASCII format.
Input Signal Settings
