Rapid RKR 200/3 E User manual

Translation of the original operation manual GB, Stand 08 / 2018
nRKR 200/3 E RKR 200/3 EA
nRKR 200/2 E RKR 200/2 EA
nRKR 200/2 E-2 RKR 200/2 E-G
nRKR 200/2 E-2G RKR 80/5 E
nRKR 50/2 E
nKRP E
RKR 200/3E RKR 200/2E RKR 200/2E-2
RKR 50/2 E
RKR 200/2 E-G RKR 50/5 E
RKR 200/2 E- 2G RKR 80/5 E
i
Weiterentwicklung im Sinne des Fortschrittes behalten wir uns vor. - Technical Modifications are subject to change. - Details techniques subject à modification sans avis préalable
O P T I M I Z E S W O R K R O U T I N E S E N V I R O N M E N T A L L Y E F F E C T I V E S E C U R E

[phone]
2
Operation Manual
1. Kindly observe: This operation manual contains all necessary information. Please read carefully to avoid
damages and faults. All rapid pieces of equipment are checked carefully before delivery for their perfect composition
and function. In case of improper use all rights to claim under guarantee are void.
Kindly keep this operation manual within reach together with the piece of equipment.
2. Technical Data:
Model: dim. L/W/H weight. loading barrel size Ref.-no.
capacity dim.
RKR 200/3 E 800x 550x 300 17 kg 30 kg 200 ltr. max. 70 001
RKR 200/3 EA 800x 550x 300 17 kg 30 kg 200 ltr. max. 70 016
RKR 200/2 E 800x 550x 300 23 kg 30 kg 200 ltr. max. 70 003
RKR 200/2 EA 800x 550x 300 23 kg 30 kg 200 ltr. max. 70 014
RKR 200/2 E-2 1150x 670x 1250 37 kg 150 kg 200 ltr. max. 70 005
RKR 60/5 E 580x 480x 1150 30 kg 30 kg 50 ltr. max. D380, H600 70 007
RKR 80/5 E 800x 710x 1150 32 kg 30 kg 50 ltr. max. D380, H600 70 017
RKR 50/2 E 580x 480x 1050 28 kg 30 kg 50 ltr. max. D380, H600 70 023
Pump: connection 230 V, 50 Hz, 45 W, insulation class IP 54
sound level 59 dB(A) within 1 m distance
immersion depth delivery rate barrel size
KRP 630 E 600 mm ca. 4 l /min 200 l barrel with lid-bung-hole
KRP 330 E 300 mm ca. 4 l /min 200 l barrel with jacket-bung-hole
3. Installation
Within an area of 5m around the unit, open fire, other ignition sources i.e. smoking, grinding and winding is not
allowed. The area has to be marked correspondingly. Take care for sufficient ventilation.
4. Assembling
4.1Barrel model RKR 200/3 E, RKR 200/3 EA
Open faucet hole of the barrel. Put the cleaning pan onto the barrel in that way that the reflux nipple extend into
the 3/4” orifice, but do not cover the 2” orifice. Screw the pan to the barrel.
Proceed with 4.4 and 4.5
4.2Floor-mounted model RKR 200/2 E, RKR 200/2 EA, RKR 200/2 E-2
Plug the standpipes into the corresponding sleeves of the bottom of pan and secure with the screws. Fix the
cross-ties between the standpipes with screws. Open faucet hole of the barrel and push the barrel underneath so
that the reflux hose gets without buckling into the 3/4” orifice and the 2” orifice remains uncovered.
Proceed with 4.4 and 4.5
4.3Movable model RKR 60/5 E, RKR 80/5 E
Open the faucet hole of the barrel. Put the barrel into the cleaner so that the reflux hose gets without buckling into
the 3/4” orifice and the 2” orifice remains uncovered.
Proceed with 4.4 and 4.5
4.4With the attached screws please fix the single parts of the splash guard wall together and then to the grating
according to drawing. Put the edge protections on the open edges of the splash guard and the pan.
4.5Plug the pump tubing into the 2” orifice of the barrel, push the hose for the brush through the hole of the rear wall
and slip on the brush. Place the foot switch in a suitable position in front of the cleaner and connect the cleaner to
a 230V power socket by using the plug.

side wall
rear wall
side wall
grating
side wall
rear wall
side wall
grating
5. Operation
5.1 Only solvents with a flash point above 55°C (formerly VbF-dangerous class AIII) are permitted to
be used.
5.2 By operating the foot switch the pump delivers the solvent through the brush. With the brush the
parts can be treated in the desired manor. The peeled off dust particles flow back into the barrel
together with the solvent and concentrate in the lower part of the barrel.
That’s why the pump draws in always clean liquid.
5.3 When operating the small parts cleaner all local laws and directives have to be strictly observed.
5.4 In case alkaline solvents are used the pump tubing must be of stainless steel.
6. Servicing and maintenance
6.1 The machine itself is maintenance-free, but should be cleaned if necessary and checked for
possible damages especially of the hoses. Defect hoses should immediately been replaced by
original hoses.
6.2 From time to time the bolted joints have to be checked and if necessary tightened.
6.3 Depending on the application and period of use the solvent will be sooner or later contaminated
and must be replaced. Used solvent has to be given to your supplier or to an authorized waste
management enterprise upon receipt of proof of delivery.
7. Safety instructions
7.1 Only solvents with a flash point over 55°C, anciently VbF dangerous class AIII, my be used.
7.2 The “Regulations for installations for the cleaning of workpieces with solvents” issued by local
authorities have to be strictly observed.
7.3 Installation can only be carried out off-site of fire-break and explosion endangering areas and
only in sufficiently naturally ventilated rooms.
7.4 Within an area of 5m open fire and other sparkling sources are forbidden.
7.5 Only set up the cleaner on smooth and levelled surface.
7.6 Load the cleaner that way that the stability is secured.
7.7 The cleaner must stand on a collecting pan.
7.8 The security data sheets of solvent producer must strictly be observed.
7.9 Introducing of easily inflammable liquids i.e. petrol is permitted.
7.10Only CFC-free solvents are allowed.
7.11Spoiled solvents have to be immediately removed and disposed professionally.
7.12It has to be taken care that no solvent infiltrate soil or sewer system.
7.13Wear protective clothing, glasses gloves.
7.14Only return used solvent to your dealer or authorized waste management enterprise upon receipt
of proof of delivery.
[phone]
3

4
[phone]
Fax : [phone] •
inf o @ ra p i d- g r oup . de
Rap i d G r o up G mbH •B ahn h ofs t r aß e 53 - 5 5•64 5 60 R ied s tad t •Tel e fon : +49 (61 5 8 ) 9 2 98 0 - 0•
www . r ap i d -g r o up. d e•
8. Health Precautions
Only use solvents for which no labelling is required according to the Ordinance on Hazardous Substances (for
more information contact local environmental authorities) such as
Rapid-cold cleaning agent RFX or Rapid-cold cleaning agent ELX
examples for also utilisable solvents
Cold degreaser WBC 16 of Bisterfeld
Industrial degreaser 274 of Chesterton
Cold cleaning agent Eskapon S 186 of Haug Chemie GmbH
Hebrosol of Hebro Chemie GmbH
Hebrosol75 of Hebro Chemie GmbH
9. Liability and Warranty
9.1 All rapid pieces of equipment are checked carefully before delivery for their perfect composition and
function.
9.2 Read this operation manual carefully before operating this cleaner.
9.3 In case of improper use of this cleaner, poor maintenance, using not compliant spare or attached parts or
not appropriate solvents all liabilities and right to claim under guarantee are void.
9.4 Rapid is also not liable in case of use the cleaner not according to the regulations or ignoring the security
precautions.
9.5 Technical modifications are subjects to change without announcement.
