RapidSignage RS-200 User manual
RapidSignage - Rapid Digital Signage Deployments
www.rapidsignage.com
RS-200 Configuration
Direct Connect:
1. Connect the provided power adapter into the DC in (4).
2. Connect Ethernet cable to the computer and to LAN port (7).
3. Connect a HDMI cable to HDMI port (5) to an Videowall. (if two monitors are used, then
connect a DisplayPort cable to Display port (6) and second monitor)
4. Configure your computer system’s network settings to:
a. IP address (TCP/IPv4): 192.168.100.2
b. Subnet mask: 255.255.255.0
5. Open your browser (Google Chrome is recommended) and connect to the RS-200:
c. Default URL: http://192.168.100.1
d. Default login: admin
e. Default password: admin
RapidSignage - Rapid Digital Signage Deployments
www.rapidsignage.com
With DHCP networking:
If you want the RS-200 connect to a DHCP network, you need to directly connect with RS-200 first
and change the networking setting of the RS-200:
1. Click SystemConfig on the main page of RS-200, then click Network config Tab.
2. Double-click textbox of DHCP and make sure DHCP is turned on, then Click Apply.
3. Click Power tab, and click Reboot button to reboot the RS-200.
4. After reboot, the RS-200 IP address will be displayed on the boot screen.
Example:
Change the RS-200 into the diagram below:
AP / Router / Switch
