Rascal Rhythm SL User manual

Rascal Rhythm SL
Powerchair
Owner’s Manual & Service Record
Electric Mobility Euro Limited, Canal Way, Ilminster, Somerset TA19 9DL
Telephone: [phone] www.electricmobility.co.uk
E. and 0.E. issue 1 04/2021
READ all safety warnings,
instructions, illustrations &
specifications provided with
this product BEFORE use.

Electric Mobility Euro Ltd offers the Rascal Rhythm
SL Powerchair for convenient indoor and outdoor
use. This Rhythm SL with Seat-Lift gives flexibility
to the user including a dual-directional drive with a
rotating seat giving you the option of Front-Wheel
Drive for superb manoeuvrability indoors*or Rear-
Wheel Drive for outdoors use.
Provided that the Powerchair is maintained and
operated in accordance with the instructions within
this manual it should last for many years providing
you with freedom and independence.
Rascal Rhythm SL Powerchair
Notice
All Electric Mobility Powerchairs are sold
through authorised dealers. Make sure the
dealer demonstrates all the features of the
product prior to, or when, it is delivered.
Please read this owner’s manual thoroughly before
usin
g the Powerchair. If you have any doubts about
warnings or instructions, ask the dealer for an
explanation. If at any time you feel that you may not
be able to control the Powerchair safely, do not
drive it, and consult the dealer for a solution. If you
think
the Powerchair may be damaged, do not drive
it and contact the dealer for advice.
Warning!
This manual contains important safety notices.
Please take time to read and understand them.
Ignoring them may endanger you or others.
We suggest that you keep this Owner’s Manual in a
safe place as it contains essential safety, operation,
and maintenance information for the Rascal Rhythm
SL Powerchair.
2
Rascal Rhythm SL Powerchairs Owner’s Manual and Service Record
FRONT-WHEEL DRIVE MODE
*Indoor Use Only
REAR-WHEEL DRIVE MODE

Contents
3
3
Dealer Information 4
Features & Layout 4
Safety Information 5
Intended Use of the Powerchair 5
Safety Information 6
Controls – Joystick Controller 8
Controls – Seat Lift 9
Seat Position – Front-Wheel Drive or Rear-Wheel Drive 10
Freewheel Device 11
Brakes 11
Armrest Adjustment 12
Seat Back Folding & Adjustment 12
Headrest Adjustment 12
Transferring In & Out of the Powerchair 13
Operation 13
Driving the Powerchair 14
Driving the Powerchair - Hazards 15
Transporting the Powerchair 16
Battery Charging 16
User Maintenance 18
Servicing & Maintenance 19
Diagnostic Table 20
Troubleshooting Guide 21
Additional Safety Information 22
Disposal 22
Frequently Asked Questions (FAQ) 22
Engineer’s Checklist 23
Additional Information 24
Technical Information regarding EMI 24
Technical Specifications 25
Service Log 26
Notes 27

Dealer Information
This is the contact number
for service and support
Dealer Stamp
Product Model
Serial Number
Date of Purchase
Owner
Telephone:
Email:
For product information see serial number plate
on the seat post under the seat.
Manufacturer: Electric Mobility Euro Limited
Canal Way, Ilminster, Somerset TA19 9DL
Company Registration in England No. 2419231
Features & Layout
Photo shows the Rascal Rhythm SL Powerchair.
See the Technical Specification for full details
1. Joystick Controller
2. Charging Point
3. Front Footrest
4. Fold-up / Adjustable
armrests
5. Solid Castor Tyres
6. Solid Tyres
7. Freewheel Levers
8. Rear Footrest
9. Headrest
4
Rascal Rhythm SL Powerchair Owner’s Manual & Service Record
1
2
4
5
7
8
6
3
7
9

Safety Information
Read this manual thoroughly before driving or
operating the Powerchair.
Intended Use of the
Powerchair
If you have any doubt about the content of this
manual then contact the dealer to resolve any
problem. Please read this manual thoroughly and
ensure the Powerchair is maintained regularly.
The Rascal Rhythm SL Powerchair is designed for
use by adults with a d
isability (up to the maximum
recommended weight - see
Technical
Specification
section of this manual) that require a
manoeuvrable, robust, comfortable Powerchair.
The Rascal Rhythm SL being capable outdoors in
Rear-
Wheel Drive mode as well as highly
manoeu
vrable for use in tight spaces indoors in
either Rear Wheel Drive or Front Wheel Drive
mode. The seat can be rotated easily to switch
between the Rear-Wheel Drive and Front-
Wheel
Drive modes.
The Rascal Rhythm SL powerchair also has a
125mm (5”) Seat Lift
capability for added flexibility
and convenience for the user.
Within this manual there are important
safety notices. They are clearly marked
with the sign (left) Make sure that you
understand all these
notices. If you
have any doubt, contact the dealer.
The Powerchair is intended for use indoors on hard
or smooth surfaces in both Front-
Wheel and Rear
Wheel Drive mode, and in Rear-
Wheel Drive
modes for outdoors use. Kerbs should be avoided,
but the Powerchair can mount kerbs and small
obstacles up to that as specified in the
Technical
Specification section.
Users could endanger themselves and or others if
they are not capable of driving the Powerchair
safely. Dealers will advise on the most suitable
Powerchair from the Electric Mobility Rascal range,
but it is the user’s responsibility to ensure that they
hav
e the manual dexterity to drive the Powerchair,
adequate sight and hearing to perceive danger in
time, and can at all times operate the Powerchair
safely in the expected conditions. If in doubt then
consult a healthcare professional and the nearest
dealer
for advice on the most suitable Powerchair
for the particular condition. Users should also
regularly assess their ability to operate their
Powerchair safely.
Book symbol: This symbol appears
on the product. Please read this
owner’s manual before assembling or
operating the Powerchair.
Pinchpoint symbol: Wherever you
see this sign there is a nearby risk of
injury owing to a pinch or crushing
point.
Tip symbol
: This sign indicates
advice on how to get the most from the
Powerchair.
The Rascal Rhythm SL Powerchair has relatively
small castor
wheels for good manoeuvrability so
they should not be used on uneven, pot-
holed or
rutted surfaces or slippery grassy areas.
© 2021 Electric Mobility Euro Ltd.
No liability is assumed with respect to the use of
any
information contained in this
publication. While every
precaution has been taken in the preparation of
this
publication Electric Mobility Euro Ltd.
assumes no
responsibility for errors or omissions nor is any
liability
assumed for damages resulting from the use
of
information contained in this publication.
This
publication, as well as the
operational details
described herein, is subject to change without notice.
5
Some of the functions of the Rhythm SL
Powerchair require the support of an attendant.
Both attendant and user are to read this guide
thoroughly before use.

Safety Information
General Warnings
Warning:
The operation of Powerchair can
endanger the life of the driver or
third parties. Any
driver should always be fully capable of operating
this Powerchair safely.
Warning: Freewheel Device/Mode. Before getting
on the Powerchair always check that the freewheel
levers are in the Drive position. When the freewheel
levers ar
e in the freewheel position, the main
brakes on the Powerchair will not function. Extra
care should be taken with the Powerchair when it is
in freewheel mode as it could move without
warning. Never sit on or try to ride the Powerchair
when it is in freewhe
el mode as serious injury or
death may result.
NEVER SIT ON THE POWERCHAIR WHEN IN
FREEWHEEL MODE.
Warning: Sitting for long periods may increase the
chance of thromboses or pressure sores.
Users
prone to such conditions are advised to take
medical advice.
Warning: Transferring On and Off. Do not
attempt to ge
t on or off the Powerchair unless it is
switched off, at rest, and on a stable, level surface.
Never get on or off on a hill or slope.
Warning: The Rascal Rhythm SL Powerchair has
been designed and tested for users with weights up
to those in the Technical Specification. This weight
should never be exceeded.
Warning: Damage. Before driving off, check the
Powerchair for damag
e, particularly that which
could affect the controls, wheels, freewheel
function and/ or drive motor.
Warning: Do not exceed the specification; do not
modify this Powerchair or use it other than as a
Powerchair.
Warning: Passengers, including children and
animals, should never be carried. Animals should
never be tethered to the Powerchair.
Warning: Footplates. Before switching on the
Powerchair, always make sure that the feet are
safely on the footplate. If you drive with the feet still
on the ground, they could become trapped under
the Powerchair an
d serious injury may result. Never
stand on the foot plate in motion. Do not carry
objects on the footplates as they may become lose
and become a hazard to safety.
ALWAYS STOW THE FOOTPLATE
VERTICALLY WHEN NOT IN USE
to prevent
damage and injury to others.
Warning: Electromagnetic interference may affect
the driving of this Powerchair:
•
Do not operate devices such as CB radios or
mobile phones while the Powerchair is switched
on.
•
Avoid getting close to transmitter masts, such as
television and radio stations.
If the P
owerchair ever starts to operate by itself
switch it off, cease using and report this incident to
the Dealer.
Warning: Armrests. Do not use the armrests as a
support when getting in or out of the Powerchair.
Make sure the armrests are lowered and secure
before you start off otherwise you may fall out.
Never drive without armrests fitted.
Warning: The operation of any Powerchair may
affect sensitive electronic circuits such as alarm
systems or automatic doors in shops.
Warning: Entanglement. Do not wear clothing or
carry items on the Powerchair that could becom
e
entangled in wheels or other moving parts whilst
operating the Powerchair. Severe injury may result.
Warning: Battery Charge Level. Before driving
off, always check the battery indicator. If you are in
any doubt, ensure all the batteries are fully charged
before starting on a journey. DO NOT
operate the
Powerchair with depleted batteries.
Driving
Before driving, refer to
Driving the
Powerchair
section in this manual.
Warning: Ambient Operating Temperature
Range.
Do not use the Powerchair in temperatures
outside the range stated in the technical
specifications section of this manual. Driving in very
hot, very cold or icy conditions, as can make driving
more hazardous.
6
Rascal Rhythm SL Powerchair Owner’s Manual & Service Record
Warning: Seat. Always drive the Powerchair with
the seat-back in upright position.

Warning: Castoring. Be aware that, if you set off
when the castor wheels are not straight, the initial
movement could be partially sideways.
Warning: Escalators. Never drive the Powerchair
onto an escalator as this could cause the
Powerchair to topple and result in severe injury.
Warning: Power. Unless there is an emergency,
do not switch the power off when moving. The
Powerchair may stop very sudde
nly. Release the
forward / reverse control and the Powerchair will
come to a controlled stop.
Warning: Roads. In the United Kingdom the
Rascal Rhythm SL is not designed or approved for
use on public roads, apart from crossi
ng roads at
designated places.
Warning: Slopes. On steep slopes the Powerchair
could topple over. Always try to avoid crossing a
slope. If crossing a slope is required then take great
care to avoid tipping. Never make sharp turns on
slopes. Never drive on slippery or icy slopes.
- consider an alternati
ve route to avoid turning on
slopes - see Driving the Powerchair – Hazards
for more advice.
Warning: Driving in Poor Visibility. Powerchairs
are not easily seen. Consider wearing a high
visibility jacket to warn others of the presence.
Warning: Carrying Items. Do not carry or attach
anything to the handlebars or controls as this could
affect the driving safety.
Warning: Kerbs. Always try to avoid driving up or
down kerbs as this may cause the Powerchair to
topple. Use access ramps wherever possible.
Never attempt to cl
imb or descend kerbs greater
than that noted in the Technical Specification
section. When in a situation to climb or descend a
low kerb, then always tackle it straight on. See
Driving the Powerchair – Hazards for more
advice.
Warning: Hot Surfaces. If the Powerchair is left
out in the sun, surfaces could become extremely
hot. Always try to park the Powerchair in the shade.
Warning: Seats in Motor Vehicles. This
Powerchair is
NOT SUITABLE FOR USE AS A
SEAT FOR A
N OCCUPANT WHEN IN A MOTOR
VEHICLE.
Warning: Speed. Turning at maximum speed
might cause the Powerchair to topple over. Always
slow down for turns.
Always slow down when
amongst pedestrians and ensure you do not run
into them.
Warning: Stopping. If the Powerchair stops
suddenly when turning, it might topple. Try not to
brake when turni
ng. Always take particular care
when turning.
The stopping distances on slopes
can be significantly greater than on level ground.
Warning: Reversing. Always take particular care
when
reversing the Powerchair as injury to other
people may occur if safe distances are not
maintained.
Warning: Leaning Over. Do not lean sideways, as
this could cause the Powerchair to topple.
7
Warning: Front-Wheel Drive Mode. This
Powerchair is to be used in Front-Wheel D
rive
mode indoors only.
Do not attempt to drive the
powerchair in Front-
Wheel Drive mode outside, on
roads, footpaths, or slopes or inclines greater
than 3°.
FRONT-WHEEL DRIVE FOR INDOORS
USE ONLY.
Warning: Seatbelts. It is advisable to secure the
seatbelt whenever seated in the powerchair, being
driving, operating seat lift or stationary.

Controls - Joystick
Controller
4. Horn: Press the button and the horn will sound.
Release and the horn will cease.
5/6. Speed Controls: These controls enable you to
increase or decrease the top speed of the
Powerchair. When the
speed increase button (6) is
pressed the maximum speed the powerchair can
achieve is increased; when the decrease button
(5)
is pressed the maximum achievable speed is
reduced. The speed indicator shows a number of
lamps to indicate the maximum speed set.
Set the
maximum speed to low until confident of driving the
Powerchair safely. Do not adjust the speed when
the vehicle is moving but reset it when you are
stationary. If you become alarmed at the speed,
release the joystick and the vehicle will slow down
immediately.
7. Joystick Lever: The more you move the joystick
forward, the faster you will go forwards. Move the
joystick back and you will go back. Move the joystick
to the right and you will turn to the right; move it to
the left and you will turn left.
Before operating the Rascal Rhythm SL it is
important to becoming fa
miliar with the controls.
The controls are as described (see Fig.1).
Warning!
Do not attempt to drive or operate the
Powerchair before reading the Owner’s Manual.
Description of controls
1. Battery Indicator:
These LED lights show the
level of charge in the batteries. The more lights that
are lit, the higher the charge level:
Red+Yellow+Green = Fully charged
Red+Yellow
= Part charged. Recharge when the
last yellow light is visible.
Red = depleted. Recharge immediately.
Note:
When the vehicle is climbing an incline or
starting off, the level may drop momentarily; this is
normal.
2. Ignition On / Off Button: Switch the power on
and off using the power button. Remember to
switch off when not in use. Do not leave the ignition
on when not in use, especially when charging the
vehicle.
3. Maximum Speed Indicator: This shows what
speed setting has been selected by the controls (
5)
and (6). The more lights that
show, the higher the
maximum speed. It is advisable to set the maximum
speed at the slowest setting until you are familiar
with controlling the Rascal Rhythm SL
8
7
1
2
3
4
5
6
8
8
8. Seat Actuator Mode. The Rascal Rhythm SL
features additional functionality and controls to
allow the user to elevate their sitting position using
the Joystick Controller. See Controls –
Seat Lift
section of this manual.
7
9
Rascal Rhythm SL Powerchair Owner’s Manual & Service Record
1

8
1
8
Controls – Seat Lift
To lower the seat:
1.
Press the seat actuator mode button (1) on the
joystick (see
Fig.2). The Powerchair drive will now
be suspended.
2. Push the joystick (arrowed in Fig.
2) away from
you and the Powerchair seat will start to lower.
When the desired height is reached, release the
joystick and press the actuator mode button once
again. Drive will now be enabled. The maximum
speed of the Powerchair will be limited with the seat
in a raised position. This is to maintain stability
performance. The seat must be in the lowest
position to enable driving at full speed - see Fig.5
Pg. 10 for the seat in its lowest position.
If at any time you wish to halt the raising or
lowering of the seat, simply allow the joystick to
return to its neutral position.
The Rascal Rhythm SL features additional
functionality and controls to allow the user to elevate
their sitting position using the Joystick Controller.
(see Fi
g.2)
Before attempting to raise or lower the seat, make
sure that the Powerchair is on level ground, not
moving and that
FREEWHEEL mode is not
engaged. User should be sitting comfortably with
feet on the footrest.
To raise the seat:
1. Press either of the seat actuator mode button (8
)
on the Joystick Assembly
(Fig.2). The Powerchair
drive function will now be suspended.
2. Pull the Joystick Lever (7) (
Fig.2) towards you
and the Powerchair seat will start to rise. When the
desired height is reached, release the J
oystick
Lever and press the Seat Actuator b
utton once
again (8). Drive function
will now be enabled. The
maximum speed of the Powerchair will be
limited
with the seat in a raised position. This is to maintain
stability performance. See (Fig.3)
for the seat in its
highest position.
Warning! NEVER raise or lower the seat if there
are any obstructions between the power-
base and
the underside of the seat - there is a risk
of
damage and or injury as a pinch point exists
between the seat and the mounting frame of the
power-base. Always ch
eck before actuating the
seat controls.
Warning! NEVER
modify any of the controls as
this will not only invalidate guarantees, but more
importantly it may lead to serious injury.
Warning! NEVER
attempt to rotate the seat
whilst operating the Seat Lift function.
Warning! NEVER attempt to use
the Seat Lift
function when in FREEWHEEL mode.
9
7
2
3

Seat Position –
Front-Wheel Drive or Rear-
Wheel Drive
10
The Rascal Rhythm SL features functionality to
allow the seat position to change the drive
orientation to FRONT
-WHEEL DRIVE to REAR
-
WHEEL DRIVE.
NEVER ROTATE THE SEAT WHILST SEATED
UNLESS
WITH THE HELP OF AN ATTENDANT.
Before attempting to rotate the seat, ensure sure
that:
1. The charger is not connected.
2. That the Powerchair is on level ground
3. Controls are switched-off.
4. FREEWHEEL MODE IS NOT ENGAGED.
5. Ensure Seat Back is in upright position (see
Seat
Back Adjustment section).
6. Both Footrests to be in the vert
ical position (see
Fig. 6)
Drive position can be changed by rotating the seat
1. Locate Seat Rotation Lever (see Fig.7) –
With
the powerchair in Rear-
Wheel Drive position (as
Fig. 4) and then raise and hold lever and then rotate
seat 180°clockwise to the Front-
Wheel Drive
position (see Fig,5)
2. Once Seat is locked in orientation then lower
required footrest at user feet keeping redundant
Footrest in the vertical position.
Warning!
NEVER switch-
on the powerchair with
the user
seated when not in the FRONT-
WHEEL
DRIVE OR REAR
-WHEEL DRIVE position.
REAR
-
WHEEL DRIVE
FRONT
-
WHEEL DRIVE
Rascal Rhythm SL Powerchair Owner’s Manual & Service Record
Warning! Never attempt drive with the seat
rotated at a side
-ways angle.
6
7
4
5
1

Freewheel Device
When the Rhythm SL is switched off with DRIVE
selected
on both DRIVE / FREEWHEEL Levers
then the Powerchair brakes are automatically
engaged. This is called “Failsafe Braking
”. Also, if
the batteries are fully discharged then the brakes
will still function. However there may be occasions
that there is a need
to move the vehicle without
power.
FREEWHEEL LEVERS ONLY TO BE
ENGAGED TO ‘FREEWHEEL’
BY AN
ATTENDANT OR ASSISTANT.
NEVER SIT ON THE POWERCHAIR IN
FREEWHEEL WITHOUT THE SUPPORT OF
AN ATTENDANT.
There are Freewheel Devices fitted on each motor.
The
Freewheel devices allow the vehicle to be
pushed without power. To activate, first locate the
levers on the top and rear of the rear cover (see
Fig.8).
1. Ensure the powerchair is switched-
off at the
Joystick Controller.
2. Rotate both levers through 90 de
grees to the
FREEWHEEL position (See Fig.9).
3. The Powerchair cannot be pushed by the
attendant in FREEWHEEL mode.
Warning! If the freewheel devices are in
“FREEWHEEL” the braking is disabled. NEVER
SELECT THE FREEWHEEL DEVICES IF THE
POWERCHAIR IS ON A SLOPE OR COULD BE
PUSHED ONTO A
SLOPE.
Warning
! NEVER
sit on the Powerchair without
both levers being in the DRIVE position
without
the support of an assistant or attendant.
Brakes
There are 2 braking systems. The first works with
the joystick. When the joystick is released the
Powerchair will automatically brake.
When the
Powerchair stops the automatic handbrake will
engage. This will stop the vehicle rolling forward or
backward. When you start the brake will
automatically disengage.
If the battery should go flat the brakes automatically
engage provided DRIVE is se
lected on the
Freewheel levers – see Freewheel Device
section
of this manual.
Note: that if the levers are too stiff to move a small
movement of the Powerchair back or forward will
make it easier to operate the le
vers. Request the
dealer to demonstrate this feature.
IF EITHER THE ATTENDANT OR USER ARE NOT
COMPLETELY SURE OF THIS FEATURE
CONTACT THE DEALER BEFORE OPERATING
THE POWERCHAIR.
Rotate BOTH levers in the opposite direction
towards the DRIVE position to engage drive. The
vehicle is n
ow braked automatically and ready to
drive. NEVER
sit on the Powerchair without both
levers being in the DRIVE position.
Check that both DRIVE levers are engaged by
attempting to push the powerchair to check brakes
are engaged.
Warning! NEVER leave one motor in DRIVE and
the other in FREEWHEEL. Could result in damage
to the Powerchair or cause injury.
11
REAR-WHEEL DRIVE MODE
9
8
1

8
Rascal Rhythm SL Powerchair Owner’s Manual & Service Record
Armrest Adjustment
Armrest
Width Adjustment
If the user requires more room in the seat width
loosen the armrest width adjustment using a
Hexagon socket key. The armrests can then be
adjusted in or out to suit. Would recommend this
only be undertaken by the Dealer or skilled
engineer.
Armre
st Height Adjustment
Loosen height adjustment knobs (One on each
armrest
– see Fig.9) by turning anti-
clockwise and
raise or lower armrest so that it is at a comfortable
height. It may be better to have the attendant adjust
the armrest height while you are
sitting in the chair
and making sure the armrests are in a comfortable
position before they are locked in place. Finally
tighten the knobs and ensure that the armrests are
secure.
Warning! Never drive with the armrest up or
with the armrest knob loose.
Seat Back Folding &
Adjustment
The seat back angle can be adjusted for
comfortable sitting
. The Seat Back can also
folded
down for transporting. Lift handle (see Fig. 10) and
then adjust position. The maximum reclining angle
is only for use when the chair is stationary, on a flat
surface with the power
-off.
12
Warning! Do not use the armrest as a support
when getting in and out of the Powerchair.
Armrests
are not designed to fully support user weight.
Warning! Always return the seat to the upright
position before driving or raising/lowering seat
. If
the seat back is tilted too far back, the risk of tipping
over backwards is increased, especially if travelling
up ramps, kerbs or hills.
Headrest Adjustment
The headrest height can be adjusted by pressing in
the tab on the left hand collar and sliding the
headrest up or down
(see Fig.11)
. Make sure that
the collars have engaged into the headrest groves
once the adjustment has been made.
9
10
11

Transferring In & Out of
the Powerchair
If you feel at all uncertain about getting in or out of
the Powerchair seek assistance with an attendant.
TRANSFERRING
IN TO THE POWERCHAIR
Ensure
that -
1. T
he Powerchair is on a level surface
, and it is
not in F
REEWHEEL mode.
2. T
he brakes are engaged -
try to push the
Powerchair
a little to verify that the brakes are
working.
3.
Seat Lift is at the lowest position
4.
Seat and locked in position
. Check the seat
cannot be rotated.
5. Joystick C
ontroller is switched off before
try
ing to get into the Powerchair
6. Footrests are in the Vertical position as would
obstruct access.
7. Armrests are down
and secured.
8. Sitting.
User to sit with back to the seat
, stabilise
with the armrests
if practical
and lower gently into
the seat. Do not put undue weight on the
Armrests.
TRANSFERRING
OUT OF
THE
POWERCHAIR
En
sure that -
1. T
he Powerchair is on a level surface
, and it is
not in F
REEWHEEL mode.
2. T
he brakes are engaged -
try to push the
Powerchair
a little to verify that the brakes are
working.
3.
Seat Lift is at the lowest position
4.
Seat and locked in position
. Check the seat
cannot be rotated.
5. Joystick C
ontroller is switched off before
trying
to get into the Powerchair.
6. Footrests are in the Vertical position as would
obstruct access.
13
7. Armrests are down
and secured.
8.
Exiting the Chair.
Position feet either side of the
raised footplate. Use the armrest
to take user weight
and
carefully attempt to stand and
do not put undue
weight on the
Armrests
If you feel uncertain about getting out, seek
assistance.
Operation
Before you set out, do check the weather forecast.
We suggest that you make sure you are wearing
suitable clothing, whether
the
journey is long or
short.
Remember that you can become wet and
cold. Suitable clothes should always be worn. A high
visibility jacket should be considered if you are in
poor visibility. Remember not to use the Powerchair
in poor light or darkness
If you are taking medication check with your
doctor or physician that your ability to control the
Powerchair
will not be impaired and do not drink
alcohol
and operate.
Only use the
Powerchair for the purpose
its
intended for. Do not drive through water or on
slippery
surfaces; do not transport more than
one
person;
do not tow other vehicles or carry
excess
weight.
1.
Before sitting in the Powerchair
, check both the
freewheel levers are not in the Freewheel
position
.
Only the attendant to operate the Freewheel
levers
.
2. Check the battery charger is disconnected.
3.
Check the backrest is upright.
4.
Ensure feet are securely on the footrest
and
redundant footrest is in the vertical position.
5.
Check you have adjusted the seat
as instructed
in this manual
– get comfortable and secure the seat
belt.
Warning! User or Attendant should NEVER
stand on either footplate at any time, being
stationary or whilst moving. The powerchair
could become unstable and lose control
resulting in injury.

Check-
•there is no damage to the
Powerchair
before use.
•All adjustment thumb-
wheels are fully
tightened.
•Any accessories are properly attached.
•User is c
apable of controlling the
Powerchair at all times.
•Seat is locked into the Front-
Wheel or
Rear Wheel drive position.
Kerbs and Obstacles: Try to avoid taking the
Powerchair over obstacles or kerbs. Tackle
obstacles head on.
Bad Weather: We suggest that it is better to stay at
home in bad weather. Remember that you can
become wet and cold. Suitable clothes should
always be worn. A high visibility jacket should be
considered if you are in poor visibility. Remember
not to use th
e Powerchair in poor light or darkness.
14
1. Ensure the way ahead is clear.
2. Switch on the power. Check the battery level
indicator is in the green area.
3. Speed Control. Set the speed control to a low
setting.
4. Gently push the joystick in the direction you
wish
to go. The vehicle will now moveoff.The
further
you
push the joystick the faster the vehicle will go.
5. To brake, return the joystick to the
neutral position.
If you become unsure or
feel
unsafe release the joystick immediately.
6. As you get accustomed to the power you can
increase the speed.
7. Switch Off when not in use. To conserve
batteries and prevent the vehicle
accidentally
moving, always turn off the power when the
Powerchair is not in use.).
Tip:
If you do leave the Powerchair switched on for
a prolonged period of time without using it, it will
enter a sleep mode to conserve power. To
reactivate the Powerchair, the On/Off key will need
to be turned to the “Off” position and then back to
the “On” position.
Driving the Powerchair
Warning! Read this before driving the
Powerchair! Whether
or not this is the first
mobility Powerchair, please read these
guidelines as all Powerchairs differ. Failure to do
this may cause damage to you, a third party or
the Powerchair.
Range. The Powerchair has a limited range.
Always ensure that the planne
d journey does not
exceed the maximum range in the
Technical
Specification
section and that the battery is fully
charged.
Rascal Rhythm SL Powerchair Owner’s Manual & Service Record
Range. Ensure you fully charge the Powerchair and
do not overestimate the range as many factors such
as user weight, weather and terrain can all af
fect
range performance.
Warning!
People or objects should never be
carried on the footplates at any time as could lead
to the Powerchair becoming unstable and a
hazard to others.
Warning! Be aware that when setting off if the
castors are not straight, the initial movement
could be sideways.
Operation (cont.)
6. Check both armrests are down
and at a
comfortable position.
7. Make sure the way ahead is clear.
8.
Switch on the power.
Check the battery level
indicator is in the green
area and fully charged.
9.
Switch off when not in use. To conserve
the
batteries
and prevent the vehicle
accidentally
moving, always turn off the power when the
Powerchair is not in
use.
Front-Wheel Drive. When in Front-Wheel drive
mode the maximum speed is reduced to 3 m.p.h. (5
km/h) as this is for use indoors only.
Raised Seat Lift. When the seat lift is raised, the
maximum speed is reduced to 1.4 m.p.h. (2.2 km/h).

15
Driving the Powerchair -
Hazards
Warning!
Before driving the Powerchair you
should be aware that, under certain
circumstances it could become unstable and tip
over. The Powerchair has been designed to
operate on hard, even surfaces and should not
be used on very rough or rutted terrain. Do not
exceed the maximum safe slope as specified in
the Technical Specifications section.
Immersion: Never enter large puddles or areas of
water where the depth and/or current is unknown.
Immersion or partial immersion of the Powerchair
may damage it and could leave you stranded.
Getting on and off the Powerchair: When getting
on make sure that the vehicle is on level ground,
and not in freewheel mode. Ensure that the
armrests are secure.
When getting off, park on
level, stable ground, and switch off the Powerchair
before leaving the seat. Make sure you get off the
vehicle in a safe area.
Seat Back Position: Always drive with the seat
back in an upright position.
Kerbs and Obstacles: Always try to avoid kerbs
and obstacles. Never ride up or down kerbs or
obstructions higher than that in the Technical
Specification section. Use ramps wher
ever
possible. Always tackle obstacles head on. Never
drive or turn across a slope.
Hills & Slopes: Going Up Hill. Lean slightly
forward when going up.
Remember that the seat
back should be in the upright position. Make su
re
you have enough speed to climb the slope.
Do not
stop or turn the vehicle around.
If you have to
turn while climbing an incline, keep going until
reaching a level area. If starting on an incline, lean
forward and apply power slowly –
do not start and
st
op. Consider an alternative route if not
comfortable about tackling a gradient.
Note: Always check that the battery level is high;
going uphill takes a lot of energy. If the level drops
too low the vehicle will cut out leaving the user
stranded.
Try to avoid crossing slopes – always try to drive
straight up and down the
slope NEVER BACK
DOWN A SLOPE!
Turning: Always slow down before a turn; turning
at speed can caus
e the Powerchair to topple. Look
in the direction you are travelling –
If there is a blind
corner sound the horn.
Turning Circle: So you can judge the turning
circle, practice manoeuvring the Powerchair. This
is important to avoid tipping off kerbs, and when
going into and out of lifts or entrances.
Bad Weather: If it is snowing or icy stay at home!
Remember that ice, snow and slippery surfaces
such as manhole covers, wet grass and drains
could affect braking and steering. Use caution at all
times.
Shower Rooms or Washing: Never take ther
Powerchair into a shower or steam room, and never
hose it down. Its sensitive electronics could
malfunction if they get wet or damp.
Tyres: Wheels: The Castor and Drive wheels have
solid tyres that will not puncture. Should
they
become damaged they should be replaced by the
dealer. Do not attempt to replace them yourself.
Seat Orientation: Only ever drive with the Seat in
the Front-Wheel Drive or Rear-
Wheel Drive
orientation. Never attempt to drive with the seat in
any other position (see Fig. 12)
Seat Raised: NEVER drive on slopes or go over
obstacles with the seat raised.
Footrest: Always stow the redundant footrest in the
vertical position when not in use. Never stand on
the footrests at any time.
12

Transporting the
Powerchair
Contact the
dealer for advice on how best to
transport the Powerchair in a
road vehicle. You may
prefer to use ramps rather than lifting the
components with hoist system.
Warning! Dismantling the Powerchair
involves the use of tools, lifting and handling
heavy parts. Weights are given in the Technical
Specification. Contact the dealer for advice on
how best to transport the Powerchair in the
vehicle. Only trained/qualified
persons to
disassemble the Powerchair.
Warning!
Pinching or Crushing. Be careful
to
avoid being pinched or having hands crushed
when lifting or handling parts. Wear gloves
whenever possible. Special attention should be
paid when raising and lowering armrests and
for
transportation in a road vehicle car or similar.
Warning!
The Rascal Rhythm SL Powerchair
NOT SUITABLE FOR USE AS A
SEAT FOR AN OCCUPANT IN A
ROAD VEHICLE
.
Warning! Do not stand the Powerchair up on
its ends or sides as it may become unstable and
topple causing an injury.
16
Warning!
When charging batteries
NEVER
smoke or charge batteries in a place where
there are naked flames such as gas-
fired
heaters as, under exceptional circumstances,
batteries may give off gases that could ignite
and explode. Always make sure that the battery
pack is not damaged. Never charge the
Powerchair battery pack outside as the charger
is not designed to get wet. If the charger or
battery pack appears damaged in any way then
do not use and contact the dealer.
Warning!
It is strongly recommended that
the
mains socket used for charging the Powerchair
is protected by a 30 m/A RCD (residual current
device). Many buildings have sockets protected
by a system based RCD. If you are in doubt as
to the level of protection in the charging location
then either p
urchase a plug in RCD or consult a
qualified electrician to verify that the charging
location mains sockets are protected.
Warning! Do not attempt to open the battery
box/enclosures, there are no user serviceable
parts inside. It may be necessary for so
me
carriers such as airlines to physically disconnect
the batteries for transit. If this is the case the
battery pack can simply be removed from the
Powerchair.
Warning!
When charging batteries
NEVER
connect or disconnect the charger from the
Powerchair while it is still connected to the
mains.
-
Remove the charger mains plug from the wall
socket having first switched the mains socket
off if a switch is provided.
Rascal Rhythm SL Powerchair Owner’s Manual & Service Record
4. Ensure Seat is set to the REAR
-
WHEEL DRIVE
position and Footplate down.
5. Power-
On and ensure that the battery level
indicator shows green
. If not charge the
Powerchair before use.
Get on the Powerchair and test the operation of the
joystick, speed control and on off switch before
using the Powerchair. If there is any malfunction,
check that the joystick connection has been
correctly put together and locked.
ALWAYS HAVE THE HELP OF AN
ASSISTANT OR ATTENDANT WHEN
TRANSPORTING OR PLACING WITHIN A
ROAD VEHICLE.
Following Transportation
:
1. Ensure that the Powerchair on level, solid
ground.
2. Attendant or Assistant to
Check the
Freewheel levers are in the “DRIVE” and not the
‘FREEWHEEL’ position.
3. Check Powerchair for any sign of damage.
Battery Charging

1517
Warning!
Never disconnect a battery /
charger
while the charger is connected to the mains.
Warning!If one or both batteries are damaged
or frozen they could heat up when char
ging and,
in an extreme case, explode.
3. Check the mains switch is off. Never connect
or disconnect the charger with the
mains switched
on.
4. Connect the charger to the charging point on
the battery pack.
5. Connect the mains plug and switch on.
6. The lamp illuminates green when the charger
is powered up,
(Fig.14) then red when it is
charging. The charger lamp changes to green
when
the battery pack is fully charged.
7. Switch off the mains and remove the plug
from the battery pack when fully charged.
Do
not leave the charger plugged in with the power off.
This will gradually discharge the battery.
The batteries are the lifeblood of the Powerchair.
Their characteristic
s can change depending on
charging, temperature, usage and other factors.
Listed below are guidelines to prolong battery life.
The charging socket is located below the front of the
joystick assembly (see Fig.13). With the charger
disconnected from the mains, push the charger plug
into the socket. When the powerchair is charged
always remove the plug.
The battery charger has a multi-coloured
charge status LED lamp. The lamp changes colour
depending on the status of the charger (See
Fig.14).
The LED colours have the following meanings:
• Flashing red: Standby or fault – A fault exists if
the charger is connected to the mains power and
scooter but continues to flash. Standby state exists
if the charger is plugged into the mains but not into
the scooter charge port.
• Solid Red: Charging
• Solid Green: Fully charged
• No Light: Mains power is not connected to the
charger or the charger is faulty.
Tip: Always ensure that the lamp shows green
before switching off and disconnecting the charger
at the mains.
Note: the charger contains a fan and will emit a
slight humming noise when in use.
Warning! Never connect any other accessory
apart from the approved charger into the
charging
(XLR) port/socket on the Powerchair battery
pack (Fig.13).
Connection Instructions
When you initially receive the
Powerchair the
batteries are only partially charged –
always fully
charge prior to use for a 12-14 hour period.
1. Place the Powerchair in an area that is dry
and well ventilated. Make sure a power point is
nearby.
2. Check the Powerchair is switched off and
the key removed.
Warning! Always charge in a dry, well
ventilated area.
Warning! Never use a different battery charger
to that supplied by the dealer. Damage or injury
may occur if you do!
14
Indicator
Lamp
13

1. After using the Powerchair always charge it at
the end of the day
even after a short journey.
2. If you plan not to use the Powerchair for a
prolonged amount of time, place
it on charge
once a week, for a 12 to 14 hour period.
3. Always use the correct charger with the
correct batteries as recommended by the dealer.
4. If the batteries have been flat for a long time
(about 2 months) it is recommended you contact
the dealer before charging.
5. Do not charge the Powerchair in the open /
out of doors –
it may rain and the battery charger
is not waterproof.
6. Keep the Powerchair in a well-ventilated area
and away from any naked flame.
7. Do not part charge the batteries. Allow the
charger to complete its cycle.
NOTE: Avoid storing the Powerchair in cold/damp
places. This will shorten battery life and may cause
deterioration in the structure. Batteries are
expensive to replace –
it is wise to look after them
and charge weekly when not in use.
18
Rascal Rhythm SL Powerchair Owner’s Manual & Service Record
Guidelines to Prolong Battery Life
User Maintenance
It is important for safety that you carry out the
following checks before use.
1. Visually check the Powerchair for damage.
2.
Visually check the tyres for inflation /
damage.
3. Check the steering moves freely.
4.
Check that the tiller is secure and that the
tiller thumb-wheel is tight.
5. Check that the seat is located correctly.
6. Check the armrests are secure.
7. The battery pack should be fully charged.
Tip: Keep the Powerchair clean by using a damp
cloth and soapy water
–
never use an excessive
amount of water, a hose or jet wash to clean the
Powerchair.
Warning! Important – Possible faults
After a short time operating the Powerchair will
become familiar to the user.
If a function of the Powerchair changes and does
not operate or function well, for instance the
Powerchair does not accelerate or brake
smoothly; the brakes are not holding on
a slope
or the steering feels different, then stop using the
Powerchair and contact the dealer immediately.
Explain to the engineer exactly the problem
or
concern.
Storage Conditions
We recommend storing the mobility Powerchair at
a temperature range of 15˚C (59˚F) to 19˚C (66˚F)
ensure a long service life of the product and
batteries. The allowable temperature range to store
the mobility Powerchair is
-40˚C(-
40˚F) up to 65˚C
(149˚F). The allowable temperature range to store
batteries is
-15˚C (-5˚F) up to 40˚C (104˚F).
fT

Servicing &
Maintenance
1. The Rascal Rhythm SL Powerchair
is
designed for minimal maintenance.
It is
recommended that the Powerchair
is serviced at
least once a y
ear, by an approved Electric Mobility
Dealer. If the Powerchair
is used constantly then we
recommend a twice yearly maintenance.
2. Ensure the engineer stamps the Service Log
(see Page 26
) on completion of all servicing. Keep
all receipts for
servicing and repairs with this
handbook. This may add value when selling the
Powerchair.
3. When the Powerchair is due for an annual
service make sure you report any concerns you
have, preferably when you book the service
(See
points to look out for below).
4. On completion of the service, always test the
Powerchair before the engineer
leaves and make
sure you are satisfied with the work carried out.
Points to look out for:
• Are there any strange noises from the wheels or
does the frame creak when going over rough
ground?
• Is the battery charged up correctly – is the “full”
charge green light on after charging?
• Is the steering tight or is it loose when t
urning? Is
there excessive play in the steering?
• Are the brakes effective?
•
Is there any damage to spigots or parts related to
disassembly?
• Has anything come loose?
Does the Powerchair perform as well as it did
when it was new?
• Are there noises or rattles that were not there
before?
• Are there any signs of damage, corrosion or
cracking?
19

Diagnostic Table
Powerchair controller provides diagnostic information by lamp indications on the Battery Level Indicator.
Individual lamps will flash to indicate a fault as below:
The battery needs charging or there is a bad connection
to the battery. Check the connections to the battery. If the connections are good, try charging the battery.
The left hand motor* has a bad connection. Check the connections to the left hand motor.
The left hand motor* has a short circuit to a battery connection. Contact the dealer.
The right hand motor* has a bad connection. Check the connections to the right hand motor.
The right hand motor* has a short circuit to a battery connection. Contact the dealer.
6 Bar - The wheelchair is being prevented from driving by an external signal. The exact cause will depend
on the type of wheelchair you have, one possibility is the battery charger is connected.
A joystick fault is indicated. Make sure that the joystick is in the centre position before switching on the control
system.
A possible control system fault is indicated. Make sure that all connections are secure.
The parking brakes have a bad connection. Check the parking brake and motor connections.
Make sure the control system connections are secure.
An excessive voltage has been applied to the control system.
This is usually caused by a poor battery connection. Check the battery connections.
23
A communication fault is indicated. Make sure that the joystick cable is securely connected and not damaged.
.
An Actuator trip is indicated. If more than one actuator is fitted, check which actuator is not working correctly.
Check the actuator wiring.
20
Rascal Rhythm SL Powerchair Owner’s Manual & Service Record
