Rascal P327 User manual

Electric Mobility Euro Limited, Canal Way, Ilminster, Somerset TA19 9DL
Telephone: [phone] www.electricmobility.co.uk Issue 2 ver 1: 09/2017
WHITE OUT CE
Rascal Powerchair
Models P327 Mini /
P327 Mini SL
Owners Manual & Service Record
Model P327 Mini and P327 Mini SL

Electric Mobility Euro Ltd offers the Rascal P327
Mini Powerchair models for convenient indoor and
outdoor use. These mid-wheel drive Powerchairs
offer high manoeuvrability and comfort for people
with disabilities whom need a medium duty
Powerchair with a good range.
Provided that these Powerchairs are maintained
they should last for many years, and provide you
with freedom and independence.
Please read this manual thoroughly before using
your Powerchair. If you have any doubts about
warnings or instructions, ask your dealer for an
explanation. If at any time you feel you may not be
able to control the vehicle safely, do not drive,
but consult your dealer for a solution.
If you think your Powerchair may be damaged, do
not drive it but contact your dealer for advice.
We suggest that you keep this manual in a safe
place. It contains essential information on the
operation of your Powerchair and also includes the
maintenance records.
2
Notice
All Electric Mobility Vehicles are sold through
authorised dealers. Make sure your dealer
demonstrates all the features of the product
prior to, or when, it is delivered.
Warning!
This manual contains important safety notices.
Please take time to read and understand them.
Ignoring them may endanger you or others.
Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record
Model P327 Mini SL
Raised seat
(SL model only)

3
Contents Dealer Information 4
Features and Layout 4
Safety Information 5
Intended Use 5
Safety Information - General Warnings 6
Controls - Joystick Assembly 8
Controls - Driving Controls & Accelerator 9
Controls - Model P327 Mini SL only 10
Freewheel Device 11
Brakes 11
Armrest Adjustment 11
Joystick Controller Adjustment 12
Seat Back Folding / Adjustment 13
Headrest Adjustment 13
Swivel Seat 13
Seat Height Adjustment 13
Seat Removal 14
Footrest Adjustment 15
Transferring in and out of your Powerchair 15
Driving Your Vehicle 15
Driving Your Vehicle - Hazards 16
Transporting your Powerchair 17
Battery Charging 17
Battery Care 19
User Maintenance 19
Servicing & Maintenance 20
Additional Safety Information 20
Engineer’s Checklist 21
Troubleshooting Guide 22
Diagnostic Table 23
Frequently Asked Questions 24
Additional Information 24
Technical Information Regarding EMI 25
Technical Specification - P327 Mini 26
Technical Specification - P327 Mini SL 27
Service Log 28
Brochure Request 29
Notes 31

4
Dealer Information
For product information see serial number plate
under the joystick controller.)
Features and Layout
Photo shows the P327 Mini Powerchair. See the
specification for detailed weights and performance.
This is your contact number
for service and support
Dealer Stamp
Telephone:
Email:
Product Model Number
Serial Number
Date of Purchase
Owner
4. Solid tyres on
all four castors
3. Footrest
5. Adjustable armrest
7. Puncture-proof tyres
on drive wheels
6. Freewheel levers
1. On/off switch
and joystick control
forward/reverse
and turning
2. Charging point
Manufacturer: Electric Mobility Euro Limited
Canal Way, Ilminster, Somerset TA19 9DL
Company Registration in England No. 2419231
1
7
2
5
6
3
2
6
4
Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record

5
Safety Information
Read this manual thoroughly before driving
or operating the vehicle. This handbook is
applicable for both models.
If you have any doubt about the content of this
manual phone your dealer to resolve the problem.
Please read this manual, and ensure your
Powerchair is serviced regularly.
Book symbol: This symbol appears
on the product. Please read this
product manual before assembling or
operating the Powerchair.
Pinchpoint symbol: Wherever you
see this sign there is a nearby risk
of injury owing to a pinch or
crushing point.
Tip symbol: This sign indicates
advice on how to get the most from
your Powerchair.
© 2017 Electric Mobility Euro Ltd.
No liability is assumed with respect to the use of
any information contained in this publication. While
every precaution has been taken in the prepara-
tion of this publication Electric Mobility Euro Ltd.
assumes no responsibility for errors or omissions
nor is any liability assumed for damages resulting
from the use of information contained in this
publication. This publication, as well as the oper-
ational details described herein, is subject to change
without notice.
Intended use
of the vehicles
These vehicles is designed for use by adults with
a disability (up to the maximum recommended
weight – see Technical Specification) whom require
a manoeuvrable, compact, comfortable Powerchair
with a good range. Mid-wheel drive with punc-
ture-proof tyres makes the P327 Mini Powerchair
models capable, manoeuvrable indoor and outdoor
machines.
It should be noted that the P327 Mini SL differs
from the P327 Mini in that it features an electrically
driven seat lift. This model also has a footrest that
travels with the seat and does not feature a swivel
function.
The P327 Mini Powerchairs range is intended for
use in the home, for use in shopping precincts and
trips on paved or other smooth hard surfaces. Kerbs
should be avoided, but the P327 Mini Powerchairs
can mount kerbs and small obstacles up to that
specified in the Technical Specifications.
Users could endanger themselves and others if they
are not capable of driving their Powerchair safely.
Dealers will advise on the most suitable vehicle from
the Electric Mobility range, but it is up to users to
ensure that they have the manual dexterity to drive
the vehicle, adequate sight and hearing to perceive
danger in time, and can at all times operate the
Powerchair safely in the expected conditions. If in
doubt we suggest you consult a healthcare
professional or your nearest dealer for advice on
the most suitable Powerchair for your particular
condition. Users should also regularly assess their
ability to operate their vehicle safely.
These Powerchairs have relatively small front and
rear castor wheels and so should not be used on
uneven, pot-holed, rutted or slippery surfaces such
as grass and similar.
Within this manual there are
important safety notices. They are
clearly marked with the sign (left)
Make sure that you understand all
these notices. If you have any doubt,
contact your dealer.

6
Safety Information
General Warnings
Warning: The operation of Powerchairs can
endanger the life of the driver or third parties. Any
driver should always be fully capable of operating
this vehicle safely.
Warning: Sitting for long periods may increase the
chance of thromboses or pressure sores. Users
prone to such conditions are advised to take
medical advice.
Warning: These Powerchairs have been designed
and tested for drivers up to the maximum user
weight recorded in the Technical Specification. This
weight should never be exceeded.
Warning: Do not exceed the specification; do not
modify this Powerchair or use it other than as a
Powerchair.
Warning: Passengers, even children, should never
be carried.
Warning: Electromagnetic interference may affect
the performance of this Powerchair:
• Do not operate devices such as CB radios or
mobile phones while the vehicle is switched on.
• Avoid getting close to transmitter masts, such as
television and radio stations.
If your vehicle ever starts to operate by itself switch
it off and report this to your Dealer.
Warning: The operation of any Powerchair may
affect sensitive electronic circuits such as alarm
systems, garage door closing mechanisms, or auto-
matic doors in shops.
Driving
Before you drive refer also to “Driving Your
Vehicle” …later in this manual
Warning: Freewheel device Before getting on the
Powerchair, always check that both the freewheel
levers are in the “Drive” Position on both the motors.
When the levers are in the freewheel position there
is no braking and the Powerchair could run down a
slope and cause injury or even death.
NEVER SIT ON THE POWERCHAIR WHEN IN
FREEWHEEL.
Warning: Transferring On and Off Do not
attempt to get on or off your Powerchair unless it is
switched off, at rest, and on a stable, level surface.
Never get on or off on a hill.
Warning: Damage Before driving off check the
Powerchair for damage, particularly that which
might affect the controls, wheels and drive motors.
Warning: Footrest Before switching on your
Powerchair, always put the footrest down and place
your feet firmly on it. If you drive forward with your
feet still on the ground, your feet could become
trapped under the Powerchair and serious injury
could result. When getting on or off your Powerchair
we recommend putting the footrest in the vertical
position.
Warning: Armrests Do not use armrests as a
support when getting in or out of your Powerchair.
Make sure they are secure before you start off
otherwise you might fall out.
Warning: Seat Belt It is advisable to use your
seatbelt whenever you use your vehicle (not
supplied on all vehicles).
Warning: Battery Charge Before driving off always
check the battery indicator. If you are in any doubt,
ensure all the batteries are fully charged before
starting on a journey.
Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record

7
Warning: Castoring Be aware that, if you set off
when the castors are not straight, the initial move-
ment could be sideways.
Warning: Power Unless there is an emergency,
do not switch the power off when moving. The
Powerchair will stop very suddenly. Centre the
joystick and your Powerchair will come to a
controlled stop.
Warning: Slopes On steep slopes the Powerchair
could topple over. Always try to avoid crossing a
slope. If you have to cross a slope, take great care
to avoid tipping. Never make sharp turns on slopes.
Never drive on slippery or icy slopes. Never back
down a slope as your Powerchair could tip over
backwards. If you are not comfortable with the hill
gradient, consider an alternative route. See Driving
Your Vehicle – Hazards for more advice.
Warning: Kerbs You should try to avoid driving up
or down kerbs as this may cause the Powerchair
to topple. Use access ramps wherever possible.
Ensure that the backrest is upright before tackling
a slope or a kerb. Never attempt kerbs greater
than that in the Technical Specification. If you have
to climb or descend a low kerb, always tackle it
straight on. Lean forward when climbing a kerb and
back when descending a kerb. See Driving Your
Vehicle – Hazards for more advice.
Warning: Speed Turning at maximum speed might
cause the Powerchair to topple over. Always slow
down for turns. Always slow down when amongst
pedestrians and ensure you do not run into them.
Warning: Stopping If the Powerchair stops sud-
denly when turning, the Powerchair might topple.
Take care when turning.
Warning: Leaning Over Do not lean sideways, as
this could cause the Powerchair to topple.
Warning: Escalators Never drive this
Powerchair onto an escalator as this could result in
severe injury.
Warning: Driving in poor visibility Powerchairs
are not easily seen. Consider wearing a high visibility
jacket to warn others of your presence. Avoid driving
in bad weather conditions.
Warning: Roads The P327 Mini Powerchairs are
not for use on roads, apart from crossing roads at
designated places.
Warning: If the vehicle is left out in the sun,
surfaces could become extremely hot. Always try to
park the vehicle in the shade.
Warning: These Powerchairs are not suitable for use
as a seat for an occupant when in a motor vehicle.
Warning ! Entanglement Do not wear clothing or
carry items on the Powerchair that could become
entangled in wheels or other moving parts whilst
operating the Powerchair - severe injury may result.
Warning ! Ambient Operating Temperature
Range Do not use your Powerchair in temperatures
outside the range stated in the specifications
section of this manual. Driving in very hot or very
cold conditions can make driving more hazardous.
Warning: Reversing Always take particular care
when reversing the Powerchair as injury to other
people may occur if safe distances are not
maintained.
Warning: Seat Height (P327 Mini SL ) Do
not climb inclines or descend steeply with the
Powerchair seat in an elevated position.

Controls - Joystick
Assembly
Before driving your vehicle it is important to
familiarise yourself with the controls. Do not attempt
to drive the vehicle before reading the rest of this
Handbook.
Description of controls
1. Battery Indicator: These lights show the level
of charge in the batteries. When in the green lights
show the batteries are fully charged. When in the
yellow and red lights show the batteries need
recharging and when only the red lights show the
batteries urgently need recharging. Note: When the
vehicle is climbing an incline or starting off, the level
may drop momentarily; this is normal.
2. On Off Button: Switch the power on and off
using the power button. Remember to switch off
when not in use. Do not leave the power on when
not in use, especially when charging the vehicle.
Note that this switch can also be used to “lock” the
Powerchair to prevent it being used, or stolen. (see
unlocking and locking on page 9)
3. Maximum Speed Indicator: This shows what
speed setting has been selected by the controls 5
and 6. The more lights that show, the higher the
maximum speed. It is advisable to set the maximum
speed at the slowest setting until you are familiar
with controlling your P327 Mini Powerchair.
4. Horn: Press the button and the horn will sound.
Release and the horn will cease.
5/6. Speed Controls: (tortoise and hare) These
controls enable you to increase or decrease the
top speed of your Powerchair. When the speed
increase button hare (6) is pressed the maximum
speed the Powerchair can achieve is increased;
when the decrease button tortoise (5) is pressed
the maximum achievable speed is reduced. The
speed indicator shows a number of lamps to indi-
cate the maximum speed set. Set the maximum
speed to low until you are confident of driving your
Powerchair safely. Do not adjust the speed when
the vehicle is moving, but reset it when you are
stationary. If you become alarmed at your speed,
release the joystick and the vehicle will slow down
immediately.
7. Joystick: The more you move the joystick for-
ward, the faster you will go forwards. Move the joy-
stick back and you will go back. Move the joystick
to the right and you will turn to the right; move it to
the left and you will turn left.
8. Spanner icon/lamp: If there is a fault, this lamp
will repeatedly flash a given number of flashes. Use
the diagnostic table later in this manual to help your
dealer decode the particular fault.
Tip: If the lights (1) are flashing red, the batteries
must be recharged urgently.
Charging Point: The charging point is situated
beneath the joystick controller at the front. (Fig.1)
8
1
Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record
4
7
1
2
3
5 6

9
Controls - Driving
Controls/Accelerator
Joystick control - To operate, turn on
the On/Off button.
Firstly make sure your wrist is supported on the
armrests. If it is not supported, a jolt may cause a
movement of the joystick and an involuntary change
in direction or speed. Find an open level area with
no obstructions to practice controlling the vehicle
until you are confident that you can drive safely.
Note. The controls can be changed to the
other arm for customers with a left-hand bias.
Please contact your local dealer for information.
Going Forward or Backwards: Gently push the
joystick away from you and your Powerchair will
move forward, pull it backwards and it will move
backwards. Release pressure on the stick and the
vehicle will stop. The further you move the joystick
the faster you will go.
Turning Left or Right: Push the joystick to the
right and your Powerchair will move right, move the
joystick to the left and the Powerchair will go left.
Practice turning while in gentle forward motion to
familiarise yourself with driving the vehicle.
Braking: Whenever the joystick is in the central
position, the automatic brake will operate. Practice
stopping on level ground to ensure that you know
how quickly you can expect your Powerchair will
come to a stop.
Sleep Mode: With the power on, if you do not
operate the joystick for a while, then the controller
will go into “sleep mode” to preserve the batteries.
Any button press or joystick movement will re-acti-
vate the controller and you can then drive normally.
Joystick Disabling during Start-Up: To prevent
sudden unexpected movements, the joystick is
disabled during start-up. If the joystick is operated
when the power button is pressed, the lamps will
flash slowly. By centring the joystick this indication
will stop and the joystick will operate normally.
Tip: The controller has a diagnostic mode. The
“spanner” icon/lamp will flash to indicate that the
controller has detected an error or fault. If this hap-
pens refer to the diagnostic table at the back of this
manual, unless it is simply the result of the joystick
not being central at start up, which can be cleared
as above.
Locking Your Vehicle for Security: To prevent
unauthorised use the controller of your Powerchair
can be locked.
To Lock
• With the power on, press and hold the power
button for 4 seconds.
• The display will turn off immediately. After 2
seconds all LEDs will flash briefly and the horn will
sound a short beep.
• The Powerchair will then turn off.
To Unlock
• While locked, press the power button to turn on.
• All LEDs will flash briefly, then perform a slow
right-to-left countdown.
• Press the horn button twice before countdown is
completed (approximately 10 seconds).
• The current state-of-charge will then be displayed
and the controller may be operated normally.
If the user does not press the horn button twice
before the countdown is complete, the horn will
sound a short beep and the controller will turn
itself off. The unlock sequence must be completed
successfully before the controller will operate again
normally.
Ask your dealer to demonstrate all these functions
and make sure you can operate all the modes of the
controller before you take your vehicle home.

10 Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record
2
1
Controls - Model
P327 Mini SL only
Introduction
As referred to earlier in this manual, the SL or “seat
-lift version” of the P327 Mini features additional
functionality and controls to allow the user to elevate
their sitting position using the joystick module. (Fig 2)
Before attempting to raise or lower the seat, make
sure that the Powerchair is on level ground, not
moving and that freewheel mode is not engaged.
You should be sitting comfortably with your feet on
the footrests.
To raise the seat:
1. Press the seat actuator mode button (1) on the
joystick (circled in Fig.2). The Powerchair drive will
now be suspended.
2. Pull the joystick (arrowed in Fig.2) towards you
and the Powerchair seat will start to rise. When the
desired height is reached, release the joystick and
press the actuator mode button once again. Drive
will now be enabled. The maximum speed of the
Powerchair will be limited with the seat in a raised
position. This is to maintain stability performance.
See Fig.3 for the seat in its highest position.
To lower the seat:
1. Press the seat actuator mode button (1) on the
joystick (circled in Fig.2). The Powerchair drive will
now be suspended.
2. Push the joystick (arrowed in Fig,2) away from
you and the Powerchair seat will start to lower.
When the desired height is reached, release the
joystick and press the actuator mode button once
again. Drive will now be enabled. The maximum
speed of the Powerchair will be limited with the seat
in a raised position. This is to maintain stability per-
formance. The seat must be in the lowest position
to enable driving at full speed. See Fig.4 for the seat
in its lowest position.
If at anytime you wish to halt the raising or lowering
of the seat, simply allow the joystick to return to its
neutral position.
Warning! NEVER raise or lower the seat if
there any obstructions between the power-base
and the underside of the seat - there is a risk
of damage and or injury as a pinch point exists
between the seat and the mounting frame of the
power-base. Always check before actuating the
seat controls.
Warning! NEVER modify any of the controls
as this will not only invalidate guarantees, but
more importantly it may lead to serious injury.
3
4

11
Warning! If the freewheel devices are in
“freewheel” the braking is disabled. Never select
the freewheel devices if the Powerchair is on a
slope or could be pushed onto a slope.
NEVER leave one motor in Drive and the
other in Freewheel. You could damage your
Powerchair or cause injury.
Freewheel Device
When the vehicle is switched off the brakes are
automatically engaged. This is called “Failsafe
Braking”. Also, if the batteries are flat, the brakes
are applied. There may be occasions where you
may wish to move the vehicle without power. To
do this there is a Freewheel Device fitted on each
motor The Freewheel device allows the vehicle to be
pushed without power. To activate, first locate the
levers on the end of each drive motor. - See Fig.5.
• Make sure the power is switched off.
• Move both the levers into the freewheel position.
The vehicle can now be pushed in Freewheel. Note
that if the levers are too stiff to move a small move-
ment of the chair back or forward will make it easier
to operate the levers. Get your dealer to show you.
• Move both the levers to engage drive. The vehicle
is now braked. This is the normal operating position.
IF YOU ARE NOT COMPLETELY SURE OF THIS
FEATURE CONTACT YOUR DEALER BEFORE
OPERATING THE POWERCHAIR.
• Pull both levers UP to enable the vehicle to be
moved without power. Braking is disabled. NEVER
sit on the vehicle with the lever in this position.
• Push both levers DOWN This is the normal
operating position. The brakes are enabled, and
the vehicle can only operate with the lever in this
position.
Brakes
There are 2 braking systems. The first works with
the joystick. When the joystick is released the
Powerchair will automatically brake. When the
Powerchair stops the automatic brake will engage.
This will stop the vehicle rolling forward or back-
ward. When you start the brake will automatically
disengage.
If the battery should go flat the brakes automatically
engage. Note that even when freewheel is selected,
a secondary braking system is applied automatically
to limit the maximum speed. You may notice this
system when moving the Powerchair in freewheel.
Armrest adjustment
If you need help with any of these adjustments ask
you dealer to assist you.
Armrest Width Adjustment
If you require more room in the seat width loosen the
armrest width adjustment using an Allen key (Fig.6).
Slide the armrests in or out to suit, and tighten up
the Allen bolt, making sure that the armrests are
equidistant from the centre of the seat and secure.
5
6

12 Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record
Note: If you do remove the armrest completely,
make sure that the seat-belt (if fitted to your model)
is correctly installed on re-fitting of the armrest.
Armrest Height Adjustment
Loosen height adjustment knobs (One on each
armrest Fig.7), and raise or lower armrest so that it
is at a comfortable height. It may be better to have
someone else adjusting the armrest height while you
are sitting in the chair and making sure the armrests
are in a comfortable position before they are locked
in place. Finally tighten the knobs and ensure that
the armrests are secure.
Armrest Angle Adjustment
The armrest angle can be adjusted by flipping up
the armrest, and loosening the nut near the pivot
point (Fig.8). Then, using an Allen key turn the arm-
rest adjustment screw clockwise to lower the end of
the armrest or anticlockwise to raise it. Once satis-
fied, tighten the nut and lower the armrest.
Joystick Controller
Adjustment
The joystick controller position can be adjusted by
moving the joystick gently to the side and back. In
addition the joystick controller can be moved
forward and back by loosening the grub screw with
the Allen key provided (Fig.9), and setting to your
preferred position. Always ensure the grub screw
is secure and tight before using your Powerchair.
Ask your dealer if you wish to have the joystick on
the left hand armrest and they will make this change
for you.
7
Warning! NEVER drive with the armrest up
or with the armrest knob loose.
Warning! Do not use the armrest as a
support when getting in and out of your
Powerchair – Armrests are not designed to
fully support your weight.
Warning! Always check that the knobs are
tight and the armrests are secure before driving
the Powerchair.
8
9

Seat Back Folding and
Adjustment
The Seat Back can be folded down for transporting.
The seat back angle can be adjusted for comfort-
able sitting (Fig.10). The maximum reclining angle
is only for use when the chair is stationary, on a flat
surface with the power off. Note: If your Powerchair
is equipped with an optional attendant control
system or other rear of seat mounted accessory, it
may not be possible to recline beyond 105 degrees.
Headrest Adjustment
The headrest height can be adjusted by pressing in
the tab on the left hand collar and sliding the
headrest up or down (Fig.11). Make sure that the
collars have engaged into the headrest groves once
the adjustment has been made.
Swivel Seat (applies to
P327 Mini only)
This allows easy side access to the Powerchair
1. To operate, locate the release lever under the
seat (Fig.12).
2. Pull the lever up and the seat will release
allowing it to rotate.
3. Release the lever and the seat should lock
automatically, but always check it has.
Seat Height Adjustment
(applies to P327 Mini only)
You are advised to ask your dealer to set the seat
height in the most comfortable driving position.
13
10
11
12
Warning! Always return the seat to the
upright position before starting off. If the seat
back is tilted too far back, the risk of tipping
over backwards is increased, especially if
travelling up ramps, kerbs or hills.
Warning! Do not use this device if the vehicle
is on a slope. Always check the seat is locked
in the forward position before driving the vehicle.

14 Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record
Seat Removal - P327 Mini
Note: The seat on the P327 SL model can be
removed however there is no swivel lever to com-
press. It is suggested that the seat only be removed
for maintenance purposes by your dealer.
The seat can be removed for storage and to allow
for easier transportation of the power-chair. To
remove the seat follow the following procedure:
1. Disconnect the cable from the joystick by
pinching and pulling the grey grip (Fig.13).
2. Release the Velcro straps (Fig.14) securing
the joystick cable in place. (Retain these straps for
reassembly).
3. Raise the seat arms and/or fold the seat flat
to make lifting the seat away as easy as possible.
Remember that the seat is a heavy part and caution
to avoid a lifting injury must be taken. If in doubt
seek assistance.
4. Unlock the seat from the seat post by pulling/
compressing the seat swivel lever (Fig.15). The P327
SL model does not have a swivel lever to compress.
5. The seat can now be lifted away (Fig.16) from
the power-chair and stored safely.
Warning! Dismantling the power-chair
involves lifting and handling heavy parts.
Weights are given in the Technical Specification;
consider if you need help in handling parts
before you try to lift them. Your Powerchair
is not designed for unassisted loading into and
out of a car or similar vehicle. Specialist ramps
and hoists are available for transferring the
Powerchair into and out of a vehicle. Contact
your dealer for advice on how best to transport
your Powerchair in your particular vehicle.
Warning! Pinching or Crushing. Be careful
to avoid being pinched or having your hands
crushed when lifting or handling parts. Wear
gloves whenever possible. Special attention
should be paid when raising and lowering
armrests or rotating/handling the wheels when
dismantling or during re-assembly.
Warning! This vehicle is not suitable for use
as a seat for an occupant in a motor vehicle.
Warning! Do not attempt to lift the power
base/chassis un-assisted - back or other injury
may result!
13
15
16
14

15
Footrest Adjustment
For comfort and to achieve correct posture, the
footrest height and footrest angle can be adjusted.
Please ask your dealer to make these adjustments
to ensure your legs are in a comfortable position.
Transferring In And Out
Of Your Powerchair
If you feel at all uncertain about getting in or out of
your Powerchair, seek assistance.
Transferring into your Powerchair
• Ensure that the seat is in its lowest position (327
Mini SL model only).
• Make sure that your Powerchair is on a level
surface, and it is not in Freewheel.
• To make sure the brakes are engaged try and
push the Powerchair before getting in.
• Ensure that the controller is turned off before your
try to get into your Powerchair.
• We recommend moving the footplate to the
vertical position.
• With your back to the chair, steady yourself with
the armrests and lower yourself gently into the seat.
Do not put undue weight on the armrests!
Getting out of your Powerchair
Ensure that the seat is in its lowest position (327
Mini SL model only). When getting out be sure that
your Powerchair is on a level surface, is not in free-
wheel and the power is off before you try to get out.
Position your feet either side of the footplate and
raise the footplate to the vertical position before
getting off. If you feel uncertain about getting out,
get assistance.
Driving Your Vehicle
1. Before you set out, do check the weather
forecast. We suggest that you make sure you are
wearing suitable clothing, whether your journey is
long or short.
2. If you are taking medication check with your
doctor or physician that your ability to control the
vehicle will not be impaired and do not drink alcohol
and drive.
3. Only use the vehicle for the purpose its
intended for. Do not drive through water or on
slippery surfaces; do not transport more than one
person; do not tow other vehicles or carry excess
weight.
4. Before sitting in your Powerchair, check both
the freewheel levers are not in the Freewheel position
5. Check that the seat is locked in the forward
position and not free to rotate/swivel.
6. Check the battery charger is disconnected.
7. Check the backrest is upright
8. Ensure your feet are securely on the footrest.
9. Check you have adjusted the seat as
instructed in this manual – get comfortable and
secure your seat belt (Not fitted to all models).
10. Make sure the way ahead is clear.
11. Switch on the power. Check the battery level
indicator is in the green area.
12. Speed Control. Set the speed control to a
low setting.
13. Gently push the joystick in the direction you
wish to go. The vehicle will now move off. The further
you push the joystick the faster the vehicle will go.
14. To brake, return the joystick to the
neutral position. If you become unsure or feel
unsafe release the joystick immediately.
15. As you get accustomed to the power you can
increase the speed.
16. Switch off when not in use. To conserve your
batteries and prevent the vehicle accidentally moving,
always turn off the power when your Powerchair is
not in use.
Warning! Whether or not this is your first
mobility vehicle, please read these guidelines as
all vehicles differ. Failure to do this may cause
damage to you, a third party or the vehicle.

Driving Your Vehicle -
Hazards
Before driving the Powerchair you should be aware
that, under certain circumstances it could become
unstable and tip over. Your Powerchair has been
designed to operate on paved, even surfaces and
should not be used on rough, rutted, soft or slippery
terrain.
Getting on and off the Powerchair: When getting
on make sure that the vehicle is on level ground,
and not in freewheel mode. Ensure that the armrests
are secure. When getting off, park on level, stable
ground, and switch off the Powerchair before leaving
your seat. Make sure you get off the vehicle in a
safe area.
Seat Back Position: Always drive with the seat
back in an upright position.
Kerbs and Obstacles: Always try to avoid kerbs
and obstacles. Never ride up or down kerbs or
obstructions higher than that in the Technical
Specification Sheets. Use ramps wherever possible.
Always tackle obstacles head on. Never drive or
turn across a slope.
Hills & Slopes: Going Up Hill. Lean slightly
forward when going up. Remember that the seat
back should be in the upright position. Make sure
you have enough speed to climb the slope. Do not
stop or turn the vehicle around. If you have to
turn while climbing an incline, keep going until you
reach a level area. If you have to start on an incline,
lean forward and apply power slowly – do not start
and stop. If you are not comfortable about tackling a
gradient, consider an alternative route. Note: Always
check that the battery level is high; going up hill
takes a lot of energy. If the level drops too low the
vehicle will cut out leaving you stranded.
Hills & Slopes: Going Down Hill. Lean back in
the seat when going down, Turn the speed
control to low. If you are not comfortable about
tackling a gradient, consider an alternative route.
Try to avoid crossing slopes – always try to drive
straight up and down the slope NEVER BACK
DOWN A SLOPE!
For the seat lift model (327 Mini SL) always put
the seat in the lowest position before travelling up or
down a slope.
Turning: Always slow down before a turn; turning
at speed can cause the Powerchair to topple. Look
in the direction you are travelling – If there is a blind
corner sound the horn.
Turning Circle: So you can judge the turning
circle, practice manoeuvring your Powerchair. This
is important to avoid tipping off kerbs, and when
going into and out of lifts or entrances.
Bad Weather: If it is snowing or icy stay at home!
Remember that ice, snow and slippery surfaces
such as manhole covers, wet grass and drains could
affect braking and steering. Use caution at all times.
Shower Rooms or Washing: Never take your
Powerchair into a shower or steam room, and never
hose it down. Its sensitive electronics could
malfunction if they get wet or damp.
Tyres/Wheels: The castor and main drive wheels
are puncture proof. Should they become damaged,
they must be repaired or replaced by your dealer as
they are not user-serviceable.
Ambient Operating Temperature: Do not operate
your Powerchair outside of the ambient operating
temperature limits stated in the Technical
Specification.
16 Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record

17
Transporting Your
Powerchair
Contact your dealer for advice on how best to
transport your Powerchair in your vehicle. You
may prefer to use ramps rather than lifting the
components.
After Using Ramps to Unload Your Powerchair
• Position the Powerchair on level, solid ground
• Check parts for any sign of damage.
• Select power on and ensure that the battery level
indicator shows green. If not charge the Powerchair
before use.
• Check the freewheel levers are in the “drive”
position and not in the “freewheel”position
• Get on the Powerchair and test the operation of
the joystick, speed control and on off switch before
using the Powerchair to go anywhere. If there is any
malfunction, check that the joystick connection has
been correctly put together and locked. You are
now ready to drive the Powerchair away.
• Ensure that the seat is in its lowest position (327
Mini SL model only).
Battery Charging
Warning! Dismantling the Powerchair involves
lifting and handling heavy parts. Although your
Powerchair can be dismantled, we suggest that
you contact your dealer for advice on how best
to transport your Powerchair in your particular
vehicle. This may involve using ramps.
Warning! Pinching or Crushing. Be careful
to avoid being pinched or having your hands
crushed when lifting or handling parts. Wear
gloves whenever possible.
Warning! This Powerchair is not suitable for
use as a seat for an occupant in a motor vehicle.
Warning! When charging batteries NEVER
smoke or charge batteries in a place where
there are naked flames such as gas-fired heat-
ers as, under exceptional circumstances,
batteries may give off gases that could ignite
and explode. If the Powerchair has been
damaged, it is possible that the batteries have
been affected. In this case do not charge the
Powerchair and refer to your dealer for assist-
ance. Never charge the Powerchair outside as
the charger is not designed to get wet. If the
charger appears damaged in any way do not
use it and contact your dealer for a replacement.
Warning! Always charge in a dry, well
ventilated area.
Warning! It is strongly recommended that the
mains socket used for charging the Powerchair
is protected by a 30 m/A RCD (residual current
device). Many buildings have sockets protected
by a system based RCD. If you are in doubt
as to the level of protection in your charging
location then either purchase a plug in RCD or
consult a qualified electrician to verify that your
charging location mains sockets are protected.
Warning! If batteries are damaged or frozen
they could heat up during charging and in an
extreme case, explode.
Warning! Do not attempt to open the battery
enclosure, there are no user serviceable parts
inside. It may be necessary for some carriers
such as airlines to physically disconnect the
batteries for transit. If this is the case the
battery cover can be removed without the use
of tools once the seat has been removed. This
should only be done by appropriately skilled/
qualified personnel.

18 Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record
The charging socket is located below the front of the
joystick assembly (Fig.17). With the charger discon-
nected from the mains, push the charger plug into the
socket. When the vehicle is charged always remove
the plug.
The battery charger has a multi-coloured
charge status LED This lamp changes colour
depending on the status of the charger (Fig.18).
• The LED colours have the following meanings:
• Flashing red: Standby or fault – A fault exists if
the charger is connected to the mains power and
scooter but continues to flash. Standby state exists
if the charger is plugged into the mains but not into
the scooter charge port.
• Solid Red: Charging
• Solid Green: Fully charged
• No Light: Mains power is not connected to the
charger or the charger is faulty.
Tip: Always ensure that the lamp shows green
before switching off and disconnecting the charger
at the mains.
Note: the charger contains a fan and will emit a slight
humming noise when in use.
Connection Instructions
When you receive your vehicle the batteries are only
partially charged – always fully charge them before
use, preferably over-night.
1. Place your machine in an area that is dry and
well ventilated. Make sure a power point is nearby.
2. Check the vehicle is switched off and the
joystick power key off.
3. Check the mains switch is off. Never connect
or disconnect the charger from the Powerchair with
the mains on.
4. Connect the charger to the charging point..
5. Connect the mains plug and switch on.
6. The lamp illuminates red when the charger
is powered up and charging has started (this
lamp will flash red if there is a battery fault or
the charging plug has not been properly pushed
into the charging socket). The LED will show
green when the Powerchair batteries are fully charged.
7. Switch off the mains and remove the
charging plug from the Powerchair charging
socket when fully charged. Do not leave the
charger plugged in with the power off. This may
gradually discharge your batteries.
17
18

Battery Care
The batteries are the lifeblood of your vehicle. Their
characteristics can change depending on charging,
temperature, usage and other factors. Listed below
are guidelines to prolong battery life.
• After using your vehicle always charge it at the
end of the day - even after a short journey.
• If you do not use your vehicle for a prolonged
period, place it on charge once a week, overnight.
• Always use the correct charger with the correct
batteries.
• If the batteries have been flat for a long time
(about 2 months) it is recommended you contact
your dealer before charging:
• Do not charge the vehicle in the open – it may rain
and the battery charger is not waterproof.
• Keep the vehicle in a well-ventilated area and
away from any naked flame.
• Do not part-charge the batteries. Allow the
charger to complete its cycle for every battery fitted.
Batteries are expensive to replace – it is wise to
look after them. Batteries are heavy – make sure
you always lift them correctly.
User Maintenance
It is important for safety that you carry out the
following checks
Daily or Before Use
• Visually check the machine for damage.
• Visually check the tyres for damage.
• Check that the seat is secure.
• Check the armrests are secure and the knobs and
levers are tight.
• The battery should be fully charged.
• Check the operation of the brakes and if you have
any concerns, contact your dealer.
• Keep your vehicle clean by using a damp cloth and
soapy water – never use a hose or pressure washer
and never use solvent based cleaning agents.
Important – Possible faults
As you get used to your vehicle you will get a feel
for how it behaves. If something feels unusual, for
instance the vehicle does not accelerate or brake
smoothly; the vehicle tries to turn to one side, the
brakes are not holding on a slope or the controller
operates strangely, contact your dealer immediately
and explain to the engineer exactly what the
problem is.
Disposal
Contact your dealer for advice before you consider
disposing of your Powerchair. They will be aware
of the environmental regulations in force at the time
and will assist you to meet the applicable environ-
mental legislation.
19
Warning! If batteries are damaged or frozen
they could heat up when charging and, in an
extreme case, explode.
Warning! Never disconnect a battery or the
charger while the charger is connected to the
mains.
Warning! If one or both batteries are dam-
aged they could heat up when charging and, in
an extreme case, explode.
Notice
Your batteries are built-into the power-chair and
are not user-serviceable. Your dealer will replace
them when they are exhausted and dispose
of them in line with environmental regulations
applicable at the time.

20 Rascal P327 Mini / P327 Mini SL Powerchair Owner’s Manual & Service Record
Servicing and
Maintenance
1. This vehicle is designed for minimum
maintenance. However it is recommended that a
competent engineer service the vehicle at least
once a year. If the vehicle is used constantly we
recommend a twice yearly maintenance.
2. Ensure the engineer stamps the Service Log
(page 28) on completion for all servicing carried out
on this vehicle. Keep all receipts for servicing and
repairs with this handbook. This may add value
when selling the vehicle.
3. When the vehicle is due for its service make
sure you report any concerns you have,
preferably when you book the service (See points to
look out for below).
4. On completion of the service, always test
the vehicle before the engineer leaves and make
sure you are satisfied with the work carried out.
Points to look out for:
• Are there any strange noises from the wheels or
does the frame creak?
• Is the battery charging up correctly – is the “full”
charge green light on after charging?
• When turning, does the Powerchair respond
equally to left and right movements of the joystick ?
• Does the Powerchair stop smoothly when the
joystick is centred ?
• Does the Powerchair tend to pull to one side ?
• Does the speed control work ?
• Has anything come loose?
• Are there noises or rattles that were not there
before?
• Are there any signs of damage, corrosion or
cracking?
• Does the seat-lift function smoothly?
Additional Safety
Information
Carrying Weight on the Vehicle
Bags or Luggage: Never carry bags (unless they are
an approved accessory) behind the seat as this could
result in tipping over backwards. Only carry small
bags on your lap and ensure it does not prevent you
from controlling your vehicle.
Seat Arms: Do not carry or attach anything to the
seat arms. Anything attached to the seat arms could
affect stability, or interfere with the control of the
vehicle.
Other Precautions
Joystick: Do not touch the joystick when getting in
or out of your Powerchair; always make sure the
Powerchair is switched off.
Modifications: Unauthorised modifications could
result in injury or permanent damage. Such modifi-
cations will invalidate any guarantees.
Other Items: Only fit approved products or
accessories.
Child Safety
This product is designed to be operated by adults.
Children should not be allowed to tamper with the
controls or play on the vehicle. Do not carry children
as passengers. The product is designed for single
person use only. Keep all packaging well away from
children. They could be harmed.
