PENTA V24
QUICK USER MANUAL
RASHA PROFESSIONAL A/S

Rasha Professional A/S 1800 Rustin Ave., Riverside CA, 92507 | 951-654-3585
rashaprofessional .com | [email protected]
2
Edition Notes
Trademarks
Copyright
Notice
Manual Use
Document
Printing
Intended
Audience
Document
Revision
The Penta V24 , User Manual Rev. 1 covers the
description, safety precautions, installation,
programming, operation, and maintenance of the Penta
V24. Rasha released this edition of the Penta V24
User Manual in January 2016.
Rasha®is a registered trademark of RASHA
PROFESSIONAL A/S. (d/b/a RASHA®or Rasha).
The RASHA® logo in its entirety including the RASHA®
name and the Globe with Rings, and all other trademarks
in this manual pertaining to services, products, or
marketing statements are owned or licensed by
RASHA®. Any other product names, logos, brands,
company names, and other trademarks featured or
referred to within this document are the property of their
respective trademark holders.
RASHA owns the content of this User Manual in its
entirety, including but not limited to pictures, logos,
trademarks, and resources. © Copyright 2015 RASHA. All
rights reserved. Electronically published by Rasha in the
United States of America.
Rasha authorizes its customers to download and print this
manual for professional information purposes only. Rasha
expressly prohibits the usage, copy, storage, distribution,
modication, or printing of this manual or its content for
any other purpose without written consent from Rasha.
For better results, print this document in color, on letter
size paper (8.5 x 11 in), double-sided. If using A4 paper
(210 x 297 mm), congure your printer to scale the content
accordingly.
Any person in charge of installing, operating, and/or
maintaining this product should completely read through
the guide that shipped with the product, as well as this
manual, before installing, operating, or maintaining this
product.
The Penta V24 User Manual Rev. 1 supersedes all
previous versions of this manual. Discard any older
versions of this manual and replace with this version.
Go to www.rashaprofessional.com for the latest version.
Author Date Editor Date
Alex G. 14/09/18

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
3
1. Before You Begin................................. 4
What Is Included .................................. 4
Claims .................................................. 4
Manual Conventions ............................ 4
Symbols ............................................... 4
Safety Notes......................................... 5
Personal Safety.................................... 5
Mounting And Rigging .......................... 5
Power And Wiring................................. 5
Operation ............................................. 5
2. Introduction.......................................... 6
Description ........................................... 6
Features ............................................... 6
Overview .............................................. 7
Dimensions .......................................... 7
3. Setup..................................................... 8
AC Power ............................................. 8
AC Plug ................................................ 8
Fuse Replacement ............................... 8
Power Linking....................................... 8
DMX Linking......................................... 8
DMX Personalities................................ 8
Mounting .............................................. 9
Orientation............................................ 9
Rigging ................................................. 9
Procedure............................................ 9
4. Operation............................................ 10
Menu Map .......................................... 10
Control Panel Description .................. 11
Menu Intro .......................................... 11
Operations.......................................... 11
Parameter Value Settings .................. 12
Submenu............................................ 12
DMX addressing................................ 13
DMX channel modes......................... 13
Fixture Mode ..................................... 13
Show Mode ....................................... 13
Dimmer modes.................................. 13
Sound activation................................ 13
Microphone sensitivity....................... 14
Blackout ............................................ 14
LED display on/off ............................. 14
LED display inversion........................ 14
Custom made color effect ................. 14
Auto test ............................................ 15
Fixture time ....................................... 15
Firmware version............................... 15
Reset................................................. 15
5. Wireless Dmx..................................... 16
Channel 7........................................... 17
Channel 12......................................... 18
6. Technical Specications................... 20
Returns ............................................. 21
Contact Us ........................................ 22
Table of Contents

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
4
What Is
Included
• Rasha Penta V24
• Power Cord
• DMX Cable
• Quick reference guide
Claims
Carefully unpack the product immediately and check the
box to make sure all the parts are in the package are in
good condition. If the box or the contents (the product and
included accessories) appear damaged from shipping or
show signs of mishandling, notify the carrier immediately,
not Rasha. Failure to report damage to the carrier
immediately may Void your claim. In addition, keep the
box and contents for inspection.
For other issues, such as missing components or parts,
damage not related to shipping, or concealed damage, le
a claim with Rasha within 7 days of delivery.
Manual
Conventions
Convention Meaning
1–512 DMX value range in number
50/60 A set of mutually exclusive values in the text
<SET> A button on the product’s control panel
Settings A product function or a menu option
0-512 A sequence of menu options
1-10 A range of menu values from which to choose in a menu
Yes/No A set of two mutually exclusive menu options in a menu
ON A unique value to be entered or selected in a menu
Symbols
Symbols Meaning
The term “DMX” used throughout this manual refers to the DMX512 digital
data transmission protocol

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
5
Safety Notes
Read all the following Safety Notes before working with this product. These
notes include important information about the installation, usage, and
maintenance of this product. This product contains no user-serviceable
parts. Any reference to servicing in this User Manual will only apply to
properly trained Rasha certied technicians. Do not open the housing or
attempt any repairs. All applicable local codes and regulations apply to
proper installation of this product.
Personal
Safety
Avoid direct eye exposure to the light source while the product is on. Always
disconnect this product from its power source before servicing. Always
connect this product to a grounded circuit to avoid the risk of electrocution.
Do not touch this product’s housing during operation because it may be
very hot.
Rigging
This product is for indoor use only! To prevent risk of re or shock, do
not expose this product to rain or moisture. (IP20) CAUTION: When
transferring product from extreme temperature environments, (e.g. cold
truck to warm humid ballroom) condensation may form on the internal
electronics of the product. To avoid causing a failure, allow product
to fully acclimate to the surrounding environment before connecting it
to power. Mount this product in a location with adequate ventilation,
at least 20 in (50 cm) from adjacent surfaces. Make sure there are
n o  a m m a b l e m a t e r i a l s c l o s e t o t h i s p r o d u c t w h i l e i t i s o p e r a t i n g .
Always carry this product by the handles. Do not carry from the head.
When hanging this product, always secure to a fastening device using a
safety cable.
Power And
Wiring
Always make sure you are connecting this product to the proper voltage
in accordance with the specications in this manual or on the product’s
specication label. Never connect this product to a dimmer pack or
rheostat. Never disconnect this product by pulling or tugging on the power
cable.
Operation
Do not operate this product if you see damage to the housing, lenses,
or cables. Have the damaged parts replaced by an authorized technician
at once. To eliminate unnecessary wear and improve its lifespan, during
periods of non-use completely disconnect the product from power via
breaker or by unplugging it. Do not cover the ventilation slots when
operating to avoid internal overheating. Do not aim this product toward
the Sun. The lenses could concentrate the solar energy and cause internal
overheating. The maximum ambient temperature is 113 °F (45 °C). Do
not operate this product at a higher temperature. In case of a serious
operating problem, stop using this product immediately!
Use on Dimmer Auto Programs
Outdoor Use Auto-Ranging Power Supply
Sound-Activated Replaceable Fuse
DMX User-Serviceable
Master/Slave
The term “DMX” used throughout this manual refers to the DMX512 digital data
transmission protocol

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
6
Features • Built in DMX wireless
• Create rich colors and pastels with RGBAW color led chips
• Master/slave wirelessly linkable 2.4 GHz with other xtures for a
coordinated light show
• Create coordinated light shows by linking other xtures in master/slave
mode
• Set up and tear down in a fraction of the time by eliminating the need for
DMX or power cables
• Convenient wireless control using 2.4GHz
• Wireless control of sectional, eye-catching chase effects via DMX
• Access built-in, eye-catching automated and sound-active programs via
wireless DMX or master/slave mode
• Enhance light shows with adjustable electronic strobe and dimmer
effects
• Compact design easily ts inside sticks of truss or stand free.
• Custom color customization function
Description
Penta V24 up light is designed for the mobile entertainer, reducing the
hassle unnecessary cables. Penta V24 it has built in 2.4 GHZwireless
DMX receiver, static RED, GREEN, BLUE, AMBER and WHITE color,
with the ability to custom mix color. Penta V24 delivers stunning
RGBAW colors and nearly eliminate multicolored shadows. User can set
fixtures at any events, theater, bar, or any entertainment industry with the
ability to control up to 20 Fixtures* by DMX wireless.
INTRODUCTION

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
7
OVERVIEW

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
8
SETUP
Power Supply
Each Penta V24 has an auto-ranging power supply that works with an
input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the
power requirements for each Penta V24 refer to the label affixed to the
product. You can also refer to the Technical Specifications chart in this
manual. The listed current rating indicates the maximum current draw
during normal operation. For more information, you may download
Sizing Circuit Breakers from the Rasha website: www.
rashaprofessional.com

Always connect this product to a protected circuit with an appropriate
electrical ground to avoid the risk of electrocution or re. To eliminate
unnecessary wear and improve its lifespan, during periods of non-
use completely disconnect the product from power via breaker or by
unplugging it.
Never connect this product to a rheostat (variable resistor) or dimmer
circuit, even if the rheostat or dimmer channel serves only as a 0 to 100%
switch.
AC Plug
The Penta V24 comes with a power input cord terminated with an Edison
Connector (U.S. market). If the power input cord that came with your
product has no plug, or if you need to change the Edison plug, use the
table below to wire the new plug.
Fuse
Replacement
1. Disconnect this product from the power outlet.
2. Using a at-head screwdriver, lift the fuse holder cap from the housing.
3. Remove the blown fuse and replace with a another fuse of the same
type and rating (T 5 A).
4. press the fuse holder cap back in place and reconnect power.
Make sure to disconnect the product’s power cord before replacing a
blown fuse. Always replace the blown fuse with another of the same type
and rating
Power Linking
You can link 22 Fixtures @ 110V and 33 xtures @ 220V.
DMX
Personalities
• The Penta V24 uses a 3- or 5-pin DMX data connection for the 6 or 11
channel DMX personalities.
• Refer to the Introduction chapter for a brief description of each DMX
personality.
•Refer to the Operation chapter to learn how to configure the Penta V24
to work in these personalities.
• The DMX Values section provides you with detailed information regarding
the DMX personalities
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
If you are not familiar with or need more information about DMX standards, Master/Slave connectivity,
or the DMX cables needed to link this product to a DMX controller, download the DMX Handbook from
the Rasha website: www.rashaprofessional.com

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
9
Before mounting this product, read and follow the Safety Notes. For our
Rasha®Professional line of mounting clamps, go to
http://rashaprofessional.com/en/accesories
Orientation Always mount this product in a safe position and make sure there is
adequate room for ventilation, conguration, and maintenance
Rigging
Rasha recommends using the following general guidelines when mounting
this product.
• When selecting an installation location, consider easy access to
this product for operation, programming adjustments, and routine
maintenance.
• Make sure to mount this product away from any ammable material as
indicated in the Safety Notes.
• Never mount in places where rain, high humidity, extreme temperature
changes, or restricted ventilation may affect the product.
• If hanging this product, make sure that the mounting location can
support the product’s weight. See the Technical Specications for the
weight-bearing requirements of this product.
• When hanging this product, always secure to a fastening device using
a safety cable.
Procedures
The Penta V24 comes with a pre-installed mounting surface to which
you will be able to attach most of our clamps found at
www.rashaprofessional.com/en/accesories. Make sure the clamps are
capable of supporting the weight of this product. Use at least 1 mounting
point per product. In addition, use a safety cable to link the product to the
structure.
MOUNTING

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
10
MENU MAP
Addr 1-512
Chnd 6
11
sLND Slav
Nast
Sync
CliC
Shnd Colo 1-38
fade1-3
Flas 1-100
Auto 1-9
soun 1-6
Cust CC1-CC5
Dinn 1-3
Blnd on
off
led on
off
dIsp
test
Fhrs
Ver
Rest

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
11
1. Intro
The light panel diagram show as below, The Display support Display & operation just
like any analong menu in todays market, Touching the approprate buttons will set or
modify setting.
2. Operation
1. Operate light with touch or encoder button
2. Parameter value setting
Press MENU to navagate menu
•press <UP> or <DOWN> to scroll to correct setting. Touch <Enter> to enter sub
menu.
•Set and save value. Touch <ENTER> submenu.
3. Sub-Menu
• Select desired sub menu from main menu to enter corresponding sub menu shown
below. There is a of total 14 menu programs, includes class of parameter and
status:

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
12
Addr 1-512
Chnd 6
11
sLND Slav
Nast
Sync
CliC
SHND Colo 1-38
fade1-3
Flas 1-100
Auto 1-9
soun 1-6
Cust CC1-CC5
DINN 1-3
Blnd on
off
led on
off
dIsp
test
Fhrs
Ver
Rest
DMX ADDRESSING
To set the xture’s DMX address:
1. Select Addr and press the ENTER button.
2. Use the UP and DOWN buttons to select a DMX address.
3. Once the address has been selected, press the ENTER
button to set it display appears Addr (or, to return to a higher
level of the menu structure without any change press the
MENU or up button).
DMX CHANNEL MODES
1. 1. Select CHND and press the ENTER button.
2. Use the DOWN and UP buttons to select the 6CH or 11CH
DMX channel mode.
3. Once the desired mode is diplayed, press the ENTER button
to set it
FIXTURE MODE
1. Select SLND and press the ENTER button.
2. Use the DOWN and UP buttons to select the Slau or NAST
mode and Press Enter.
3. Once set SLND, display will show STBY after some seconds, if
choose NAST mode display will show chosed static option.
SHOW MODE
1. SH O=Random scenes and effects (requires sound activation
to be enabled).
2. COLO - Shows one of 38 preset colors with no scene
changes. Colors are with full range dimming.
(sound activation has no effect)
3. FADE - Color changes - fast (SP1) to slow (SP3).
(sound activation)
4. FLSH - Strobe speed- slow(1) to fast(255) -
(Colo mode activation and choose color to be enabled)
MENU UP DOWN ENTER
8. 8. 8. 8
ADDR
MENU UP DOWN ENTER
8. 8. 8. 8
CHND
MENU UP DOWN ENTER
8. 8. 8. 8
SLND
MENU UP DOWN ENTER
8. 8. 8. 8
SHND

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
13
DIMMER MODES
For DMX control, there are four possible settings for controlling
the rate of dimming.
DI 1 - LINEAR - The increase in light intensity appears to be
linear as DMX value is increased
DI 2 - SQUARE LAW - light intensity control is ner at low levels
and coarser at high levels.
DI 4 - INVERSE SQUARE LAW - light intensity control is coarser
at low levels and ner at high levels.
DI 4 - S-CURVE - light intensity control is ner at low levels and
high levels and coarser at medium levels.
To set the xture’s dimmer curve:
1. Select DINN and press the ENTER button to conrm. The present mode will blink on
the display.
2. Use the DOWN and UP buttons to select: DI I or DI 2 or DI 3 or DI 4
3. Once the mode has been selected, press the ENTER button to set it.
SOUND ACTIVATION
The xture has a built-in microphone that can be used to synchronize
its behavior to the beat of music. When the xture is not
connected to a DMX controller, and is running in Show Mode, it can be set to trigger
scene changesm (effects and color changes) in synch with music.
To turn on/off sound activation:
1. Select Soun and press the ENTER button.
2. Use the DOWN and UP buttons to select on OR Off.
3. Once the mode has been selected, press the ENTER button to
set it.
MENU UP DOWN ENTER
8. 8. 8. 8
DINN
Output Output Output Output
DMX % DMX % DMX % DMX %
Optically Linear Square Law Inverse Square Law S Curb
MENU UP DOWN ENTER
8. 8. 8. 8
SOUN

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
14
MICROPHONE SENSITIVITY
To adjust the sensitivity of the sound-activation microphone
1. Select SenS and press the ENTER button.
2. Use the DOWN and UP buttons to change the sound sense from 0 -100.
3. Once the level has been selected, press the ENTER button to set it (or, to
return to a higher level of the menu structure without any change press the
MENU button).
BLACKOUT
You can blackout the xture using the control menu:
1. Select BLND and press the ENTER button.
2. Use the DOWN and UP buttons to select YES or NO. Press
the ENTER button to set.
LED DISPLAY ON/OFF
To set the LED display to be on all the time, or to automatically switch off
after 10 seconds when not in use:
1. Select Led menu and press the ENTER button.
2.Use the DOWN and UP buttons to select the ON (LED on) or
OFF (LED off
when not in use). Press the ENTER button to set.
LED DISPLAY INVERSION
To invert the LED display:
1. Select DISP menu and press the ENTER button.
2. Use the DOWN and UP buttons to select the (normal display
orientation) or (invert display). Press the ENTER button to set
CUSTOM MADE COLOR EFFECT
Saved custom made color / project the saved custom made color
1. Select Cvst menu and press the ENTER button.
.2. Use the DOWN or UP buttons to choose (CUS1) or (CUS2) or
(CUS3) or (CUS4) or (CUS5)
then press the ENTER button to project saved custom color.
MENU UP DOWN ENTER
8. 8. 8. 8
BLND
MENU UP DOWN ENTER
8. 8. 8. 8
DISP
MENU UP DOWN ENTER
8. 8. 8. 8
Led
MENU UP DOWN ENTER
8. 8. 8. 8
CUST

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
15
AUTO TEST
To perform a complete test of all of the xture functions
1. Select Test and press the ENTER button. The xture will run a
self-test routine.
FIXTURE TIME
To display the xture’s operating hours counter:
1. Select Fhr5 and press the ENTER button. The display will
show thenumber of hours the unit has been run.
FIRMWARE VERSION
To display the xture’s installed rmware version number
1. Select Ver and press the ENTER button. The display will show
the version of software installed on the xture.
RESET
Reset the light as factory setting
1. Select rest and press the ENTER button. Display will show
STBY, all custom seting will back as defult setting.
MENU UP DOWN ENTER
8. 8. 8. 8
Test
MENU UP DOWN ENTER
8. 8. 8. 8
FHRS
MENU UP DOWN ENTER
8. 8. 8. 8
uer
MENU UP DOWN ENTER
8. 8. 8. 8
rest

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
16
1. Intro
Operating through an DMX controller gives the user the freedom to create their own
programs tailored to their own individual needs. Follow the directions below to set your
DMX Mode and address.
1. Before connecting to DMX controller, your xture has different DMX channel modes;
please select your desired DMX Channel mode by pressing the MENU button button,
then using the “Up” or “Down” buttons to scroll to CHND. Press ENTER to access
seconday menu. Select the desired channel and press ENTER to set the mode before
you address the xture.
2. After you have selected your mode, set the wireless DMX wireless reciever. The built-
in reciever must be addressed to the same frequency as your transmitter. Press the
ID code Selector Button (2) until the Wireless Signal LED color (3) matches both the
transmitter and your xture.
Note: If the transmission is successful the light and dmx controller (wireless transmitter)
the Green Led bulb in rear side of the light it will start to blip(means the successful in
transmission).
WIRELESS DMX
Figure 6
12 4 5
63 7 8
9 10
Rear Panel
1. Wireless Signal LED
2.ID code Selector Button
3. Battery Indicator
4. Alpha Led Display(4 digits)
5. Menu Button
6. DMX out port
7.DMX In Port
8. Power out port
9.Micro Phone/Sound Detector
10.Power in port
If working in 12 Channel mode make sure that the DMX faders 7 (dimmer)
and 8 (Strobe) are at full 255 and 1-6 are your colors.
If working in 6 Channel mode make sure that the DMX fader 6 is at full 255
and 1-5 are your colors.

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
17
DMX VALUES
6 CH Mode
Channel Value Description
CH1 0 No action
1-255 Red (Intensity 0 to 100%)
CH2 0 No action
1-255 Green (Intensity 0 to 100%)
CH3 0 No action
1-255 Blue (Intensity 0 to 100%)
CH4 0 No action
1-255 Amber(Intensity 0 to 100%)
CH5 0 No action
1-255 White (Intensity 0 to 100%) 5 0
CH6 0 No Action
1-255 Strobe speed 0-99
If working in 6 Channel mode make sure that DMX faders 6 are to at full
255 and 1-5 are your colors.

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
18
DMX VALUES
11 CH Mode
Channel Value Description
CH1 0 No action(blackout)
1 - 255 Red 0-100%
CH2 0 No action (blackout)
1 - 255 Green 0-100%
CH3 0 No action (blackout)
1 - 255 Blue 0-100%
CH4 0 No action (blackout)
1 - 255 Amber 0-100%
CH5 0 No action (blackout)
1 - 255 White 0-100%
CH6
0 - 7 Off
8 - 15 Color 1
16 - 23 Color 2
24 - 30 Color 3
31 - 38 Color 4
39 - 46 Color 5
47 - 54 Color 6
55 - 61 Color 7
62 - 69 Color 8
70 - 77 Color 9
78 - 85 Color 10
86 - 92 Color 11
93 - 100 Color 12
101 - 108 Color 13
109 - 116 Color 14
117 - 123 Color 15
124 - 131 Color 16
132 - 139 Color 17
140 - 147 Color 18

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
19
148 - 154 Color 19
155 - 162 Color 20
163 - 170 Color 21
171 - 178 Color 22
179 - 185 Color 23
186 - 193 Color 24
194 - 201 Color 25
202 - 209 Color 26
210 - 216 Color 27
217 - 224 Color 28
225 - 232 Color 29
233 - 240 Color 30
241 - 247 Color 31
248 - 255 Color 32
CH7 0 - 255 Master Dimmer Intencity 0-100%
CH8
Strobe
0 - 7 Off
16-131 Open
132-139 Strobe - slow-fast
140-181 Open
182-189 Pulse - fast close & slow open
190-231 Open
232-239 Pulse - slow close & fast open
240-247 Open
248-255 Random strobe
248 - 255 Open
CH9 0 - 255 RGBAW slow to fast ramdom color change
CH10 0 - 255 Auto color change slow to fast without
strobe
CH11 0 - 255 Auto color change with strobe along with
sound
If working in 11 Channel mode make sure that the DMX faders 7 (dimmer)
and 8 (Strobe) are at full 255 and 1-5 are your colors.

Rasha Professional 1800 Rustin Ave. Rivers
|
ide CA, 92507 |
m
951-654-3585
rashaprofessional .com [email protected]
20
SPECIFICATIONS
PHYSICAL
Weight : 4 kg (10.7 lbs.)
Dimensions 200 x 90 x 200 mm (7.8 x 2.3 x 7.8 in.)
DYNAMIC EFFECTS
Color mixing RGBAW+UV
Color selection 34 color presets
Electronic dimming 0-100%
Strobe and pulse effects Variable speed and action,
random strobe
Electronic shutter effect Instant open and blackout
OPTICS
Light source 24 x 15 W RGBAW LED Chips
LEDs Beam angle 25/40° Minimum
LED lifetime 50,000 hours (to >70% luminous output)*
LED Manufacturer’s gure obtained under manufacturer’s
test conditions
CONTROL AND PROGRAMMING
Control options DMX, stand-alone Sound active, Auto,
Static Mode,
DMX channels 6/11
Remote type Superior IR Technology
Stand-alone trigger options
Music trig, auto trig, Linkable
Standalone built-in shows
Random, preset colors, or variable fade
Settings, addressing and programming
Control panel with LED display
Sound activation Adjustable microphone sensitivity
DMX compliance
USITT DMX512 or DMX 512 Universal
Wireless DMX Transmitter compliance
Universal DMX 512 GHz with
7 group
CONSTRUCTION
Color Black/White
Protection rating IP20
INSTALLATION
Mounting Adjustable folding bracket,
Orientation Any
Location For indoor use only
APPROVALS
EU safety EN 60598-1, EN 60598-2-1, I EC/EN 60825-1
EU EMC EN 55103-1, EN 55103-2, EN 61000-3-2
Canadian safety (US model) CAN/CSA C.22.2 No.
250
CONNECTIONS
AC power in/thru American Power in socket
DMX data in/thru 3 or 5-pin locking XLR
Wireless DMX Receiver 2.4 GHz DMX Signal receiver
ELECTRICAL
AC power 100-240 V, 50/60 Hz
Power consumption 100 W
Fuse T 5 A
THERMAL
Maximum ambient temperature (Ta max.) 50°C(122°F)
Minimum ambient temperature (Ta min) 0°C (32°F)
Cooling 2 low noise fan
Heat control Aluminum Heating pan installed
ACCESSORIES (SOLD SEPARATELY)
Narrow beam angle kit (diffuser sheet)
P/N 892160
Medium beam angle kit (diffuser sheet) P/N 892161
Wide beam angle kit (diffuser sheet) P/N 892162
3M US Power cable P/N 890113
Safety eyebolt P/N 890110
3-pin male XLR connector 5M P/N 890103
6 in 1 power road case P/N 901306
12 in 1 road case P/N 901307
12 or above stackable road case P/N 901308
ORDERING INFORMATION
