ApplianceStor 70v2
Performance Storage Server
User Manual
Version 1.3 April 2020

Copyright Notice
All rights, including copyright, in the content of this manual are owned or controlled by RASILIENT and
protected by copyright. No part of this document may be photocopied, reproduced,
or translated into
another language without the prior written consent of RASILIENT Systems, Inc.
Trademarks
All product names or brands mentioned herein are the trademarks of RASILIENT, its subsidiaries or other
respective owners.
Disclaimer
This manual provides information regarding set-up and installation of the product herein. Nothing
herein may be construed as granting any right or license relating to any intellectual property rights of this
manual or product. Unless otherwise provided inthe Purchase and Sale Agreement for this product,
manufacturer and distributor of this product will not be liable whatsoever relating tothe distribution
and/or use of this product. In addition, manufacturer and distributor of this product hereby specifically
disclaim any express or implied warranties of merchantability, fitness for a particular purpose, or
non-infringement of third party rights in connection with this product.
Manufacturerofthis producthastherighttochangespecificationsandproductdescriptions at any time
without notice

Table of Contents
Conventions............................................................ 5
Safety Symbols .................................................................................. 5
Safety Precautions.............................................................................. 6
Regulatory and Integration Information ............... 8
Product Safety Compliance ................................................................ 8
Product EMC Compliance................................................................... 8
Power Cords ..................................................................................... 10
Introduction .......................................................... 12
Audience Assumptions ..................................................................... 12
About This Guide .............................................................................. 12
Product Introduction.......................................................................... 12
Simple............................................................................................... 12
Powerful............................................................................................ 12
Reliable............................................................................................. 13
Right Size ......................................................................................... 13
Open ................................................................................................. 13
Optimized.......................................................................................... 13
Easy.................................................................................................. 13
Expandable....................................................................................... 13
System Specification......................................................................... 14
System Layout...................................................... 16
Front panel........................................................................................ 16
Front Panel LEDs.............................................................................. 16
Rear Panel........................................................................................ 17
LAN Port LEDs.................................................................................. 17
Internal.............................................................................................. 18
Before You Begin.................................................. 19
Gather information ............................................................................ 19
Packing Checklist.............................................................................. 19
Hardware Installation........................................... 21
Tool-less Friction Rail Kit................................................................... 21
Installing the tool-less rack rail........................................................... 21

Rail kit dimensions ............................................................................ 24
Protective Film .................................................................................. 24
Disk drives ........................................................................................ 25
Redundant power supplymodule ...................................................... 27
Tables
Table 1: Safety Compliance .......................................................................................................................... 8
Table 2: European Union Compliance .......................................................................................................... 9
Table 3: Manual Organization ..................................................................................................................... 12
Table 4: Packing Check List........................................................................................................................ 19

Conventions
Safety Symbols
Safety Precautions
Regulatory and Integration Information
About This Manual

Conventions
To make sure that you perform certain tasks properly, take note of the following symbols used throughout
this manual.
Safety Symbols
The following symbols are placed on some components of the system to alert the user to potential
hazards,
WARNING: Electric Shock Hazard – To reduce risk of injury from electric shock hazards,
do not open this component.
WARNING: Contains no user or field serviceable parts – To reduce the risk of injury
from electric shock hazards, do not open this component.
WARNING: Hot Surface or Component - To reduce risk of injury from a hot
component; allow the surface to cool before touching.
WARNING: Insert Network Interface Only - Any receptacle (e.g. RJ45) marked with
this symbol indicates a network interface connection. To reduce the risk of electric shock,
fire or damage to equipment, do not plug telephone or telecommunications connectors
into this receptacle.
WARNING: This symbol, on power supplies or systems, indicates that the equipment
is supplied by multiple sources of power. To reduce the risk of injury from electric shock,
remove all power cords to completely power down the system.
WARNING: This symbol indicates that the component exceeds the recommended
weight for one individual to handle safely. To reduce the risk of personal injury or damage
to the equipment, observe local occupational health and safety requirements and
guidelines for manual material handling.

Safety Precautions
Technician Notes
Only authorized technicians should attempt to repair this equipment.
Before installing this system, carefully read all the manuals included with the system.
All repair procedures allow only module replacement. Because of the complexity of the individual boards
and sub-assembles, no one should attempt to make repairs at the component level or make modifications
to any printed wiring board. Improper repairs can create a safety hazard.
To reduce the risk of personal injury from electric shock and hazardous energy levels, do not exceed the
level of repairs specified in these procedures.
The system is designed to be electrically grounded. To ensure proper operation, plug the AC power cord
into a properly grounded AC outlet only.
Electrostatic Discharge Precautions
Electrostatic discharge (ESD) can damage static sensitive devices or micro circuitry. Proper packaging
and grounding techniques are required to prevent damage.
Keep electrostatic-sensitive parts in their containers until they arrive at a static free work area.
Use a wrist strap connected to the work surface as well as properly grounded tools and equipment
Keep the area free of nonconductive materials such as ordinary plastic tools and foam packing.
Avoid touching pins, leads, or circuitry.
Always place drives with printed circuit board (PCB) assembly-side down.
Grasp cards and boards by the edges. Hold drives by the frame. Avoid touchingthe solder joints or pins.
If you need to lay the device down while it is out of the antistatic bag, lay it on the antistatic bag. Before
picking it up again, touch the antistatic bag and the metal frame of the system unit at the same time.
Rack Warnings
If you plan to rack mount the AS70v2, follow the rack manufacturer’s safety instructions.
Install the enclosure only in a rack that has been properly secured in an area with suitable environmental
conditions.
Have someone assist you during physical installation.

To properly ventilate the system, you must provide at least 7.6 cm of clearance at the front and back of
the system.
To reduce the risk of personal injury or damage to equipment, always ensure that the rack is adequately
stabilized prior to extending a component outside the rack. A rack may become unstable if more than one
component is extended. Extend only one at a time.
Do not stand or step on any components in the rack.
If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack
environment may be greater than room ambient. Therefore, consideration should be given to installing the
equipment in an environment compatible with the maximum ambient temperature (Tma) specified by the
manufacturer.
Do not overload the AC power supply branch circuit that provides power to the rack. Observe extension
cable and power strip ratings. Ensure that the total ampere rating of all equipment plugged into the
extension cable or power strip does not exceed 80 percent of the ampere ratings limit for the extension
cable or power strip.
System Warnings
Avoid dust, humidity, and extreme temperatures; place the system on a stable surface.
To reduce the risk of personal injury from hot surfaces, allow the hot-plug disk modules and other system
modules to cool before touching them.
To reduce the risk of electric shock or damage to the equipment, do not disable the power cord grounding
plug. The grounding plug is an important safety feature.
Ensure the power cord is inserted into a grounded electrical outlet that is easily accessible at all times.
Unplug the power cord from the power supply module to shut off power to the equipment
Protect the storage system from power fluctuations and temporary power interruptions with a regulating
uninterruptible power supply (UPS). This device protects the hardware from damage caused by power
surges and voltage spikes and keeps the system operational during a power failure.
The storage system must always be operated with all hot plug modules installed or slot covers in place to
ensure proper cooling.
Route power cords so that they will not be walked on or pinched by items placed upon or against them.
Pay particular attention to the plug, electrical outlet, and the point where the cords exit from the product.

Regulatory and Integration Information
Regulatory Compliance Identification Numbers
For the purpose of regulatory compliance certifications and identification, this system is assigned a serial
number. This system serial number can be found on the product label, along with the required approval
markings and information. When requesting certification information for this product, always refer to this
serial number. This serial number should not be confused with the marketing name or model number.
Product Safety Compliance
This system complies with the following safety requirements:
Table 1: Safety Compliance
IEC 60950-1
Safety of Information Technology Equipment
EN 60950-1
Safety of Information Technology Equipment Including Electrical Business
Equipment, European Committee for Electro-technical Standardization (CENELEC)
UL 60950-1
Safety of Information Technology Equipment
Worldwide Safety approvals can be supplied upon request. Please contact your sales representative for
approvals.
Product EMC Compliance
This product has been tested and verified to comply with the following electromagnetic compatibility
(EMC) regulations.
Federal Communications Commission (FCC) Notice
Part 15 of the Federal Communications Commission (FCC) Rules and Regulations has established Radio
Frequency (RF) emission limits to provide an interference-free radio frequency spectrum. Many electronic
devices, including computers, generate RF energy incidental to their intended function and are, therefore,
covered by these rules. These rules place computers and related peripheral devices into two classes, A
and B, depending upon their intended installation.
Class A devices are those that may reasonably be expected to be installed in a business or commercial
environment. Class B devices are those that may reasonably be expected to be installed in a residential
environment (for example, personal computers). The FCC requires devices in both classes to bear a label
indicating the interference potential of the device, as well as additional operating instructions for the user.
The rating label on the device shows which class (A or B) the equipment falls into. Class A devices do not
have an FCC logo or FCC ID on the label. Class B devices have an FCC logo or FCC ID on the label.
Once the class of the device is determined, refer to the following corresponding statement.
Class A Equipment

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference, in which case the user will be required to correct
the interference at personal expense.
Declaration of Conformity for Products Marked with the FCC Logo—United States Only This device
complies with Part 15 of the FCC Rules Operation and is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
For questions regarding your product, please contact your sales representative.
To identify this product, refer to the Part, Series, or Model number found on the product.
European Union Notice
Products with the CE Marking comply with both the EMC Directive (2014/30/EU) issued by the
Commission of the European Community.
Compliance with these directives implies conformity to the following European Norms (items in brackets
are the equivalent international standards):
Table 2: European Union Compliance
EN55032
Electromagnetic Interference
EN55024 (IEC61000-4-2,3,4,5,6,8,11)
Electromagnetic Immunity
EN61000-3-2 (IEC61000-3-2)
Power Line Harmonics
EN60950
Product Safety
Canadian Notice (Avis Canadien)
Class A Equipment: ICES-003
Japanese Notice

Taiwanese Notice
Power Cords
The power cord set included in the system meets the requirements for use in the country where the
system was purchased. If this system is to be used in another country, contact your sales representative
to purchase a power cord that is approved for use in that country.
The power cord must be rated for the product and for the voltage and current marked on the product's
electrical ratings label. The voltage and current rating of the cord should be greater than the voltage and
current rating marked on the product. In addition, the cross-sectional area of the wires must be a
minimum of 1.00mm² or 18AWG, and the length of the cords must be between 1.8m (6 feet) and 3.6m (12
feet). If you have questions about the type of power cord to use, contact your sales representative.
The following statement applies only to rack-installed products that are GS-Marked:
This equipment is not intended for use at workplaces with visual display units, in accordance with §2 of
the German ordinance for workplaces with visual display units."

Audience Assumptions
About This Guide
Product Introduction
System
Specifications
Chapter 1
Introduction
Chapter 1
Introduction

Introduction
Audience Assumptions
This manual assumes that you are a service technician or network administrator familiar with computer
hardware, data storage and network administration terminology and tasks.
About This Guide
This user guide provides step by step instructions on how to install, use and maintain the ApplianceStor
70v2 Storage Server. This manual is generally organized as follows:
Table 3: Manual Organization
Introduction
General introduction to the AS70V2and its components.
Preparation
What you need to do before you start.
Installation
Detailed description of each hardware module and instructions for
installation and removal.
Configuration
Initializing your system, setting up your system on a network,configuring
your storage,and connecting hosts.
Operation
Ongoing usage and maintenance information provided in a reference
format and organized by major system component.
Product Introduction
The AS70V2 is a 1U 4 drive high performance videosurveillance storage server appliance. The AS70V2
integrates VMS and storage in a simple to use, high-performance video surveillance storage
solution. It is optimized for Video Surveillance applications and delivers the performance
required for the most demanding megapixel installations.
Simple
The ApplianceStor 70v2 integrates VMS (Video Management Software) and storage into a simple to use, high
performance video surveillance storage server solution. This eliminates the cost of the VMS server,
significantly
reduces cabling and the nightmare of integrating VMS, OS, commodity server and storage,
while significantly reduces the overall solution cost. Guaranteed performance with all major VMS
solutions
prequalified on the AS70V2. It is easy to install and maintain. The AS70V2 is ultimate in simplicity
while
significantly reduces CAPEX and OPEX cost.
Powerful
The AS70V2 is a powerful server and storage system, built around high performance Intel® Xeon®
processors and fast DDR4 memory. The AS70V2 offers high performance and bandwidth connectivity to meet
the most demanding megapixel camera applications. The base AS70V2 model unmatched LAN connectivity
with 4 GbE ports and an addition port that is dedicated to management
for a total of 5GbE LAN ports. With
the AS70V2 Video Surveillance Appliance un-matched LAN connectivity and its impressive power it can

meet of the most demanding megapixel cameras deployments.
It has the performance and reliability for the
most demanding deployments.
Reliable
Disk drive failure is the number one cause of lost video storage and downtime. We provide advanced RAID 5
technologies which eliminates the loss of video due to a disk failure. Disk drives are hot swappable without
interruption in service or loss of data. The AS70V2 only uses ECC RAM and it guarantees that video being
stored read and move within is always correct. It uses a parity bit to accomplish the data protection. Most NVRs
and DVRs are not protected to this level and with these products crucial video can be lost. The AS70V2 gives
peace of mind that the video is always reliably being stored.
Right Size
Designed for smaller MegaPixel deployments; it is provided with each drive capacities to 14 TB versions. The
AS70V2 matches the perfect storage capacity with exceptional performance to ensure optimal, cost
effective and dependable video storage. If expansion is required the AS70V2 can be used in conjunction
the PS5000 allowing
capacity to grow beyond Petabytes.
Open
Purpose-built open platform to integrate Video Management Software, and Video Analytic Software
Providers. All major supported Video Analytic Software providers are prequalified. More are continually
added to ensure the widest possible certification coverage.
Optimized
The ApplianceStor 70v2 is optimized for the Video Surveillance applications and market place. It provides the
performance and capacity for the most demanding megapixel installations.
Easy
AS70V2 provides effortless installation, management and administration. All administration functions
assume
technicians with basic to no storage knowledge. Once racked, setup time should be 15 minutes or less.
Expandable
Additional RAM can be also be added and this will allow up to 64GB RAM to be used

System Specification
Core Technology
CPU Type
Xeon® E-2134
Socket
LGA1151
Core Logic
Intel® C242 Chipset
Memory size
up to 64GB
Memory type
DDR4 2400 ECC UDIMM
Expansion
Expansion Slot :
2 (not available for user)
Slot Type:
1xPCI
-E x16 slot(Gen3 X8 Link)(Full-Height/Half-
Length)
1 xPCI
-E x8 slot (Gen3 X8 Link)(Full-Height/Half-
Length)
Storage:
HDD Bays
4 x Hot-swap 3.5"
Drive support
up to 14TB SATAIII
RAID
0, 1, 5, 10
Removable Storage
1x Slim-type Optical DVD-RW
Networking
Data
4 x GbE
Management
1 x GbE
Video
Graphic
Aspeed AST2500 with 32MB VRAM
On Board I/O
1 x External Serial Port

2 x USB 3.1 ports and 4x 3.0
USB port, (Front x 2, Rear x 4)
1 x VGA port
Management Solution
Remote KVM
-iKVM for KVM-over-IP support
ASWM Enterprise
Compliance
Safety
US/Canada (UL1950-CSA950)
Europe (CE, EN55022
EMI
US (FCC, CFR47 Part 15, Class A)
Europe (CE, EN55022 & EN55024)
Physical
Characteristics
Dimensions (in./mm)
24.2" x 17.5" x 1.7" 380 x 430 x 43.4
Weight
33lbs./6.5Kg
Power
1+1 Redundant 450W 80 PLUS Gold Power Supply
Voltage
100-127/200-240Vac, 5.5A/3A (for each inlet), 50-60Hz
Watts
450
Operating Environment
Operation temperature
10
~ 35 degrees Celsius
Non operation
temperature
-
40 ~ 70 degrees Celsius
Humidity:
20% ~ 90% ( Non condensing)

System Layout
Front panel
The AS70V2 displays a simple yet stylish front panel with easily accessible features. The power and reset
buttons, LED indicators, and USB
port are located on the front panel.
Figure 1: Front Panel
Front Panel LEDs
LED
Icon
Display status
Description
Power LED ON System power ON
HDD Access LED
OFF
Blinking
No activity
Read/write data into the HDD
Message LED
OFF
ON
Systemis normal; no incoming event
Ahardwaremonitoreventis indicated
Location LED
OFF
ON
Normal status
Location switch is pressed
(Press the location switchagain to turn off)
LAN LEDs
OFF
Blinking
ON
No LAN connection
LANis transmitting or receiving data
LAN connection is present
Turn off thesystempowerand detachthe powersupplybeforeremovingorreplacing anysystem component.

Rear Panel
The rear panel includes the expansion slots,system power sockets,and rear fans. The I/O shields with
openings for the
rear panel connectorsonthemotherboard are also placed in therear panel.
Figure 2: Rear Panel
LAN Port LEDs

Internal
The AS70V2 server includes the basic components as shown.
Turn off the system power and detach the power supply before removing replacing any system
component.
WARNING HAZARDOUS MOVING PARTS KEEP FINGERS AND OTHER BODY PARTS AWAY

Before You Begin
Thoroughly research and establish an installation and configuration plan for your specific network
environment. You should also plan how you want to configure your storage.
Gather information
The system has the ability to be set with one or multiple IP addresses. The simple online configuration
procedures will allow you to set-up your system on your network using these IP addresses. Be sure to
ask your network administrator to provide you with sufficient IP addresses for your planned configuration.
Your administrator should provide the following information so that you can properly configure your
system on your network:
IP Address(s)
Gateway address
Net mask address
DNS server information.
Packing Checklist
Make sure you have all the components that shipped with your system. If any item is damaged or
missing, please contact your sales representative for a replacement. The AS70V2 is shipped with the
following:
Check your system package for the following items:
Table 4: Packing Check List
Model Name
AS 70v2
Chassis:
AS70v2 1U Rack mount
Chassis Component:
2 x 450W Power Supplies
4 x Hot-swap 3.5" HDD trays (with or without drives
depending upon configuration)
2 x AC Power Cords
1 x Rail Kit
Chapter 2
Before You Begin
