9370 Information System
Installation Manual -
Physical Planning

o
o
o
GA24-4031-0
File No. 9370-15
IBM 9370 Information System
Installation Manual -
Physical Planning
-~--
---.-
-- ---
---
- -. ---
--- ---
-----
-----,-

Federal Communications Commission
(FCC) Statement
Warning: This equipment generates,
uses, and can radiate radio frequency
energy and if not installed and used in
accordance with the instruction manual,
may cause interference to radio
communications. It has been tested and
found to comply with the limits for a
Class A computing device pursuant to
Subpart J of Part 15 of FCC Rules, which
are designed to provide reasonable
protection against such interference
when operated in a commercial
environment. Operation of this
equipment in a residential area is likely
to cause interference in which case the
user at his own expense will be required
to take whatever measures may be
required to correct the interference.
First Edition (October 1986)
Information in this manual is subject to change from time to
time. Changes will be reported in subsequent revisions or
through the System Library Subscription Service. (SLSS)
Any reference to an IBM program product in this document is
not intended to state or imply that only IBM's program product
may be used. Any functionally equivalent program may be used
instead.
It is possible that this material may contain reference to,'or
information about, IBM products (machines and programs),-
programming, or services that are not announced in your
country. Such references or information must not be construed
to mean that IBM intends to announce such IBM products,
programming, or services in your country.
Publications are not stocked at the address below. Make
requests for copies of IBM publications to your IBM
representative or to the IBM branch office serving your
locality.
Aform for reader's comments is at the back of this publication.
If the form has been removed, comments may be addressed to:
IBM Systems Technology Division
Product Publications Dept. K10
P.O. Box 6
Endicott, NY 13760
IBM may use or distribute any of the information you supply in
any way it believes appropriate without incurring any
obligation whatever.
© Copyright International Business Machines Corporation 1986
o
o

o
o
Who Should Read This Book
This book contains information necessary for you to
prepare the physical site and plan for installing the 9370
system. Become familiar with the contents of this manual
before beginning any installation planning.
«'tAW
How to Use This ,Book
This book has six chapters and four appendixes:
Chapter 1, "Introduction," provides general information
on site preparation and customer responsibility.
Chapter 2, "System Specifications," provides system
specifications, such as primary power and environmental
specifica tions.
Chapter 3, "Rack," explains the requirements for the rack
enclosure, including environmental and power
specifications, and limitations.
Chapter 4, "Unit Specifications," provides
three-dimensional views and specifications for system
units.
Chapter 5, "Cable Requirements," provides the
requirements for ordering system cables.
Chapter 6, "Remote Facility," provides a general
description of Remote Service and system requirements for
Remote Service.
Appendix A, "Specification Summary," provides a
specification and noise-emission level chart for the units
integrated in the system.
Appendix B, "Plugs and Receptacles," provides
illustrations of the required plugs and receptacles.
Appendix C, "Planning Checklist," provides a planning
checklist to prepare for installing the system.
Appendix D, "Physical Planning Templates," provides
plan views of the 9309 Rack Enclosure you can use to plan
the floor layout of the system.
III

What You Should Know
The system hardware consists of:
• The 9309 Rack Enclosure.
• The following IBM 9370 rack-mounted System/370
processors:
9373 Model 20
9375 Models 40 and 60
9377 Model 90.
•
Integrated input/output (I/O) controllers for:
Disk/Tape
Work stations
Telecommunications
Local area network.
• Direct access storage devices (DASD).
•
Magnetic tape drive units.
• System/370 block multiplexer channels.
If You Need More Information
IV
Depending on your system equipment, you may find the
following books helpful.
• IBM System/360, System/370, 4300 Processors,
Input/Output Equipment Installation Manual- Physical
Planning,
GC22~7064
• IBM Input/Output Equipment Reference Installation
Manual- Physical Planning: System/360, System/370,
and 4300 Processors, GC22-7069
• IBM General Information Manual Installation
Manual- Physical Planning, GC22-7072
• IBM Communications Terminals Installation
Manual-Physical Planning, GA27-3006
• IBM 3270 Information Display Station Installation
Manual-Physical Planning, GA27-2787
• IBM Multiuse Communications Loop Planning and
Installation Guide, GA27-3341
• Installation and Assembly of Coaxial Cable and
Accessories for Attachment to IBM Products, GA27-2805
c
o

1. Introduction ............................. 1-1
Your Responsibilities ................................ 1-3
Planning the Layout ................................ 1-3
Planning Checklist ................................. 1-5
Making the Layout ................................. 1-5
Storage and Shipping Environment ..................... 1-6
Electrical Power ................................... 1-7
Primary Computer Power Service .................... 1-7
8ranch Circuits .................................. 1-8
Grounding ..................................... 1-10
Computer Room Emergency Power-Off Controls ....... 1 -10
Lightning Protection ............................... 1-10
Convenience Outlets ............................... 1-11
Power Plugs and Receptacles
........................ 1-11
Additional Reference Material
........................ 1-11
2.
System Specifications ...................... 2-1
Primary Rack Power
................................ 2-2
Power Control Compartment (PCC) .................. 2-3
Power Phase Imbalance ........................... 2-6
Plugs and Receptacles: .... . . . . . . . . . . . . . . . . . . . . . .. 2-6
Cooling .......................................... 2-7
System Environmental Specifications ................... 2-7
3. Rack ................................... 3-1
Plan View
(Not to Scale) .......................... 3-3
Raised Floor Cutout ................................ 3-6
Rack Specifications ................................. 3-7
Limitations ....................................... 3-8
Requirements ................................... 3-8
Loading the Rack ............................... 3-11
4. Unit Specifications ........................ 4-1
IBM 9373, 9375, and 9377 Processors .................. 4-2
9373 Processor .................................. 4-2
9373 Processor Specifications ...................... 4-3
9375 Processor .................................. 4-4
9375 Processor Specifications ...................... 4-5
9377 Processor .................................. 4-6
9377 Processor Specifications ...................... 4- 7
I/O Card Unit ..................................... 4-8
I/O Card Unit Specifications ........................ 4-9
9332-400 DASD ................................. 4-10
9332-400 DASD Specifications .................... 4-11
9335-A01 DASD Controller ......................... 4-12
9335-A01 DASD Controller Specifications ............ 4-13
9335-801 DASD .................................. 4-14
9335-801 DASD ............................... 4-14
9335-801 DASD Specifications .................... 4-15
9347 Tape Unit ................................... 4-16
9347 Tape Unit Specifications ..................... 4-17
o Power Sequence and Control
........................ 4-18
Unit Specifications .............................. 4-19
v

5. Cable Requirements ...................... . 5-1
Cable Information ................................. . 5-2
Channel Cable Length ............................ . 5-2
Coaxial Cable Length ............................ . 5-2
Communication Cable Length ...................... . 5-3
Cable Schematic ................................ . 5-4
System Cabling ................................... . 5-6
6. Remote Facility .......................... . 6-1
General Information .......................... - ...... . 6-3
Communication Facilities ........................... . 6-4
Requirements .................................. . 6-4
Remote Facility ................................... . 6-6
External Interface Adapter (USA only) ............... . 6-6
Customer-Ordering Information For Remote Facility ..... . 6-8
Appendix A. Specification Summary ........... . A-1
Specification Summary Chart· ....................... . A-2
Acoustics (Noise-Emission Levels) ................... . A-3
Unit Noise-Emission Levels ......................... . A-4
Appendix B. Plugs and Receptacles ............ . B-1
Plugs/Receptacles for USA, AG, APG ................. .
8-2
Plugs and Receptacles for EM EA .................... .
Three-Phase Power Plug
......................... .
50- Hz Power Cord Style ......................... .
8-3
(;1
8-6
8-7
~
Appendix C. Planning Checklist ............... . C-1
Appendix O. Physical Planning Templates ........ 0-1
English Units ..................................... 0-1
Metric Units ..................................... 0-2
Template List ..................................... 0-3
Glossary X-1
Index ..................................... X-5
o
vi

r?q'rY'Tf;:'t:'t'~'T;,~'~~~<";0'''~:,",,'';'' ~..,,,.'?>,.,_,,,~=_~~_~v_ ~~7·'":':<-~~~~·''''' .«"~o<~" ~~'''::~wl ~".v' .. ~"'»>':~~w":"»:»,~,v,,,,~.:_.,,,~,«,= '«F" N~Y«'~=< "'''>'''' <' .'" '-:'-~'~":C= 'U.* <M" .... 0WY#~'::~"~~;[;:T:: ~:;~~.:'/;:;" ... »>'--: 77;,~::;·~t:· ':···v<,:,:·~
,;;~~~ :. ~ ':;;::' "':~':>':: >.;,,,
:;:1";::
:'~: r;:~
o
o
Fig No.
1-1.
2-l.
2-2.
2-3.
3-1.
3-2.
3-3.
3-4.
3-5.
3-6.
3-7.
3-8.
4-1.
4-2.
4-3.
4-4.
4-5.
4-6.
4-7.
4-8.
4-9.
5-1.
5-2.
5-3.
5-4.
5-5.
5-6.
6-1.
A-I.
A-2.
A-3.
B-l.
B-2.
B-3.
B-4.
B-5.
B-6.
D-l.
D-2.
Page No.
Power Distribution Systems .................. 1-9
Power Control Compartment Versions .......... 2-4
Power Control Compartments for EMEA ........ 2-5
System Environment Specifications ............ 2-7
Plan View Symbol Legend .................... 3-2
9309 Rack Enclosure Models 1 and 2 ............ 3-3
Plan View for Multiple Racks ................. 3-4
Weight Distribution/Service Clearance for Multiple
Racks .................................... 3-5
Required Service Clearance .................. 3-5
Positioning and Dimensions for the Floor Cutout .. 3-6
Center-of-Gravity for the Modell .............. 3-9
Center-of-Gravity for the Model 2 ............. 3-10
9373 Processor ............................. 4-2
9375 Processor ............................. 4-4
9377 Processor ............................. 4-6
I/O Card Unit (Features 5010 and 5020) .......... 4-8
9332 Model 400 DASD ...................... 4-10
9335-A01 DASD Controller .................. 4-12
9335-B01 DASD ........................... 4-14
9347 Tape Unit ........................... 4-16
Power Sequence and Control Unit (Feature 6001). 4-18
Cable Schematic ........................... 5-4
Channel Cabling Chart ...................... 5-6
Cables to the 9370 Processor .................. 5-7
Control Unit-to-Channel Cabling .............. 5-9
Cables for Asynchronous Protocol Adapter ...... 5-10
Cables for Multi-Protocol Adapter ............ 5-11
Remote Facility Configuration ................ 6-6
Unit Specification Summary .................. A-2
Noise Emission Levels ....................... A-4
Power-Emission Level for Sample Configurations .. A-5
Plugs and Receptacles for USA and AG, APG ..... B-2
Plug and Connector/Receptacle for USA, AG, and
A/PG' .................................... B-3
EMEA Plugs for Single-Phase Power (3 kVA) ..... B-5
EMEA 200 -240 Single-Phase Power Plug (5 kVA) . B-5
Three-Phase Power Plug (for 15 Amps) .......... B-6
Power Cord Style (50-Hz Reference) ............ B-7
Physical Planning Template (English) .......... D-l
Physical Planning Template (Metric) ........... D-2
VII

b B
0
CD
CJ c:
IJ
~
§=
:::::
==:
-==:
0
t:J
:::=
en
[J
~
~
~
~
ac=:ss
-
~
C
Q
----------- ~
---
IBM 9370 Information System in Model 1 and Model 2 Racks
c"
viii

Your Responsibilities ................................ 1-3
Planning the Layout ................................ 1-3
Planning Checklist ................................. 1-5
Making the Layout ................................. 1-5
Storage and Shipping Environment ..................... 1-6
Electrical Power ................................... 1-7
Primary Computer Power Service .................... 1-7
Branch Circuits .................................. 1-8
Grounding ..................................... 1-10
Computer Room Emergency Power-Off Controls ....... 1-10
Lightning Protection ............................... 1 -10
Convenience Outlets ....... ;....................... 1-11
Power Plugs and Receptacles
........................ 1-11
Additional Reference Material ........................ 1-11
o
o
1-1

''':- >, ,,"- -< ,.~ "
; .. <:..,,,,,
1-2
,>
';' , i.~. "
, ;-~,;"" ~ "
~,:.: <'.).'".':;:.- ~.':< '::~:<>.,.-. ,.,;
The 9370 system includes the 9370 Processors, which are
air-cooled, compatible with System/370, and reside in the
IBM 9309 Rack Enclosure (for clarity, rack will be used in
the rest of this book). There are four versions of the 9370
Processor.
• 9373 Model 20
• 9375 Models 40 and 60
• 9377
Model 90.
These processors use microcode-driven input/output (I/O)
controllers (residing on logic cards) to attach I/O units.
Some of the highlights of the 9370 system include:
• Rack-mounted I/O units
Direct access storage units
Tape units
• An integrated DASD/Tape Controller
• ASystem/370 Block Multiplexer Channel, which
allows you to use System/370 channel-attached devices
• A Work Station Subsystem Controller (uses 3270-type
terminals)
•
Four communication subsystems, which allow you to
communicate over synchronous and asynchronous
lines
• Local Area Network subsystem.
o

o
o
Your Responsibilities
Site preparation for the system is your responsibility.
This book can help you prepare for installing and
expanding your system. Although you are responsible for
this activity, you may need help from IBM, consultants,
contractors, or vendors to complete the tasks.
The primary task of the site planner is to identify the
physical space and system layout requirements for the
equipment. Appendix D, "Physical Planning Templates,"
supplies paper cutouts of the rack to help plan the layout.
[Plastic templates in English (GX24-4046) and metric
(GX24-4047) units are available.]
Site preparation includes:
• Adhering to the planning schedules.
• Preparing the physical location of the units (floor
planning).
o Obtaining, installing, and maintaining coaxial cables
for work stations or the IBM cabling system.
o Inspecting the site to insure that each unit will fit
through doorways and passageways.
• Arranging for installation of any communication
facilities (common carrier, postal telephone and
telegraph, or private) and connecting the system to
these facilities.
• Performing similar planning functions for IBM
input/output (I/O) devices that you plan to attach to
the processor.
Planning the Layout
Operational requirements determine where you place
system components. Some considerations include:
• Flow of work and personnel within the area
• Location of planned safety equipment
• Necessity for maintaining service clearances for all
system units .
1-3

Planning the Layout (Continued)
1-4
• Priority of channel-attached devices
• Space limitations, such as floor-loading capacity,
location of columns, and provisions for growth
• The length of the cables connecting the units in the
system
• Visual access required between a control unit and at
least one of its associated I/O devices
• Work space and aisles.
You may need to prepare and analyze several layouts
before choosing the final layout. If you plan to install the
equipment in two or more stages, prepare a separate
layout for each stage. Consider channel priority
assignments and cable lengths for each stage.
To make a layout, you need an accurate drawing of the
proposed area. For a precise layout, use the paper
templates in Appendix D or order clear plastic templates
(English GA24-4046, metric GA24-4047). The templates
show the required space for weight distribution and
clearances for the operator, service personnel, and test
equipment. Templates also show the radii of swinging
gates and covers, and the location of casters and frame
entry/exit cutouts for cables.
Note: You may overlap clearances shown on the
templates if you maintain the larger clearance. The gate
swing of an auxiliary unit must not interfere with the
gate swing of its corresponding control unit.
Place the equipment so that the lengths of the connecting
cables do not exceed the maximum limits; these limits may
vary. Refer to the device specification pages and cable
schematics for the appropriate limits.
o
o

o
o
Planning Checklist
The planning checklist (Appendix C, "Planning
Checklist") provides a suggested schedule. Your site
preparation may not require all of the suggested steps, or
you may require some additional steps. Be sure you allow
enough time to complete the necessary steps before your
system arrives.
Making the Layout
The prepared layout must be accurate and drawn to scale.
If necessary, IBM uses the layout to determine the
appropriate cable lengths [EMEA (IBM Europe/Middle
East/Africa) has fixed length cables.] Be sure to include
the following items, and any other unique considerations,
on the layout:
• Service clearances required for each unit.
• Location of:
Power receptacles
Air conditioning equipment and controls
File cabinets, desks, and other office equipment
Room emergency power-off controls
All entran"ces, exits, windows, and columns or
pillars.
• The number of:
Control units assigned to each channel
The number of input/output units attached to each
control unit.
Special tasks that you must do for a raised-floor
environment include:
• Showing the location of any obstruction that Inay
affect cable routing.
1-5

;,lhf'ritJifdctitin';
~ -:;-., ," "., :,«,." -,'( <> "'\ " ~.",
h <' "~:~~L:;_L:~t~L;:~~2'~~~i:: .:~~~<~~ .. :: ~:::;~~:t.,,:':~~.::sv>.:?::_ b.~'A lMx~<;,":;~~~~ij::~,~,c'::9 "',,, ~
Making the Layout (Continued)
• Showing the height of the raised-floor above the base
floor.
Note: The raised-floor height should be between 155
millimeters
(6 inches) and 460 millimeters (18
inches).
This height should accommodate piping
and power distribution. The minimum raised-floor
height for the 9370 system, with the System/370
channel feature, is 155 millimeters (6 inches).
However, the
height should also have a minimum of
an additional 115 millimeters (4.5 inches) to ensure
you can run cables and connectors over and under
obstacles.
When a raised-floor
panel is cut for cable entry or
air register, additional panel support may be
required to restore
structural integrity. See
Figure 3-6 on page 3-6 for the recommended floor
cutout
dimensions and placement.
Tasks that you must do for a non-raised-floor
environment include:
• Showing the planned placement of cables for minimum
obstruction.
• Showing the amount of additional cable required, if
the cable route is indirectly between units (such as
along walls or suspended).
• Deciding if you need cable guards or ramps to ensure
personnel and equipment safety.
Always review the final layout to ensure that cable
lengths do not exceed limitations and that all devices
have proper clearances. Notify IBM immediately of any
layout changes that·affect cable lengths.
Storage and Shipping Environment
1-6
IBM designs its units to operate in a controlled
temperature and relative humidity range, and (even when
stored or in shipment) they require some environmental
control. If you store the unit outside the specified limits,
permanent damage can result.
c
o

o
o
Warning: Do not store a unit in a room that has
chemicals that can cause corrosion damage. See
"System Environmental Specifications" on page 2-7,
and individual specifications in Chapter 4.
When removing a unit for shipment or storage, use the
blocks, braces, and preparation procedures found in the
Packaging Bill of Material. This is a protective package
designed uniquely for each unit, and is available from any
IBM Branch Office.
Ship the units through a household goods carrier (padded
van), with appropriate strapping and padding to avoid
transi t damage.
6;.. ,,'#@::Wr'1'" iN ~)5.·t,,*5N • ·.,.,; ... 31
Electrical Power
Primary Computer Power Service
For maximum reliability, the computer power panel
should connect to feeders that do not serve other loads.
Connect electrical noise-producing devices, such as
accounting equipment, card punches, typewriters, and
calculators to panels separate from those feeding the
computer units.
1-7

Electrical Power (Continued)
Branch Circuits
1-8
The branch circuit panel for the computer should be in a
convenient, well-lighted area of the computer room.
Protect the individual branch circuits on the panel with
circuit breakers properly rated according to the
manufacturer's specifications and applicable codes. Label
each circuit breaker to identify the branch circuit it
controls. The power requirements for I/O equipment are
on the unit specification pages in:
• IBM Input/Output Equipment Installation
Manual- Physical Planning for System/360,
System/370,
and 4300 Processors, GC22-7064.
• IBM Input/Output Equipment Reference Installation
Manual- Physical Planning for System/360,
System/370,
and 4300 Processors, GC22-7069.
The grounding wire of the branch circuit must have
insulation and be equal in size to the neutral and phase
conductors.
Terminate branch circuits as close as possible to the unit
they supply-within 3 meters (10 feet). Run branch
circuits in either rigid or nonrigid metallic conduit (or in
compliance with local or national standards). The conduit
system should be continuous, uninterrupted, and
connected to the building or transformer ground; see
Figure I-Ion page 1-9.
o
c
o

o
o
Incoming three-phase
power from service
entrance or derived
system, appropriate
over-current protection
and
suitable ground.
Neutral
0--
0----
Ground 0---
Service
Entrance
Ground
or
Suitable
Building Legend:
Ground
--- Phase Wires and Neutral
208/240V
---Insulated Green Wire Ground
Figure 1-1. Power Distribution Systems
Remotely Operated
Power Service
.4""'=c-.t--+--+- Main
Ci rcuit Breakers of
Appropriate Size
Grounding
Terminal Bar
(Bonded to
Enclosure)
Customer-supplied
receptacles/connectors
in accordance with
local codes.
~Branch
Circuits
* For loads
requiring a
neutral. attach
computer/data
processing
equipment only.
1-9

Electrical Power (Continued)
Grounding
A machine must be properly grounded. It is recommended
that an insulated green wire ground, the same size as the
phase wire, be installed between the branch circuit panel
and the receptacle. For some small machines such as
terminals, a continuous metallic conduit is adequate for
grounding.
To ensure proper grounding, a licensed electrician should
check the grounding and receptacles for conformance with
the country electrical codes.
For personnel safety, the ground must have sufficiently
low impedance to limit the voltage to ground and to
operate the circuit protective devices if a phase-to-frame
short occurs. For example, the ground path shall not
exceed 1 ohm for 120-volt, 20-ampere branch circuit
devices.
Computer Room Emergency Power-Off Controls
As a safety precaution, provide room emergency power-off
controls for disconnecting the main service wiring that
supplies the computer equipment. Install these controls at
a convenient place for the operator and next to the main
. exit doors of the' room.
Follow national and local electrical codes.
Lightning Protection
1-10
You should install lightning protection devices when:
• An over!J.ead power service supplies the primary power
• The utility company installs lightning protectors on
the primary power source
• The area is subject to electrical storms or
equivalent-type power surges.
o

o
o
Convenience Outlets
You are responsible for selecting and installing lightning
protection devices.
Install a suitable number of convenience outlets in the
computer room and the service representative area for use
by building maintenance personnel and service
representatives. Convenience outlets should be on the
lighting or other building circuits, not on the computer
power panel or feeder. Do not use the service convenience
outlets on IBM units for any purpose Qther than normal
servicing.
h,iF t·!G'@ ,tJ a·ee
i4
Wi £&9
Power Plugs and Receptacles
All power attachment cable plugs have approval for use
wi th the 9370 system and meet the relevant testing
laboratory or country/test-house standards. All power
cords have the appropriate plugs according to the ship
destination of the system.
Note: See Appendix B, "Plugs and Receptacles," for types
of power cord plugs and receptacles.
'~·!fRi "?"§if. P!S¥t,;*, B'*, &* ··P{¥igPie+
i
Additional Reference Material
For more information about domestic standards on site
preparation refer to:
o National Fire Protection Association (NFPA) Standard
No. 75, Protection of Electronic Computer/Data
Processing Equipment (or applicable local or national
equivalent)
o IBM General Information Manual, Installation
Manual-Physical Planning, GC22-7072.
Some of the topics in the IBM General Installation
Manual- Physical Planning that you may consider
reviewing for proper site preparation include:
o Environmental Considerations
o Acoustics
o Electromagnetic Compatibility
• Lighting
1-11
