Rauckman Utility Products METERPULLER M-001 Owner's manual

METERPULLER®
OWNER/OPERATOR MANUAL
Carefully read, understand and follow the
warnings and instructions provided in this
manual, and keep it in a safe place for future
reference. Failure to do so can result in
accident, severe personal injury or death.
WARNING
If there are any questions regarding these or any of our other ne products, please
contact us at www.rauckmanutility.com or call us at 618-234-0001 from 8-5 CST.
www.rauckmanutility.com

www.rauckmanutility.com Doc. No. RUPMP3235A2
RAUCKMAN UTILITY PRODUCTS • METERPULLER® OWNER/OPERATOR MANUAL
ELECTROCUTION HAZARD
Avoid Personal Injury or Death. Do not use this tool
until you have completely read the owner’s manual.
Also see www.rauckmanutility.com
for safety information.
WARNING
I. Preliminary
1. The safety of the tool and of the work site are the responsibility of the worker
and his supervisors, who are the only individuals who can evaluate whether it
is safe to work.
II. General Instructions
1. All workers are required to wear proper Personal Protection Equipment (PPE),
to be identied and provided by the Employer or otherwise mandated by appli-
cable Regulations.
2. PPE shall be used at all times, without exception.
3. All workers must be trained and determined to be qualied on the use of
the tools, on accident risks, safety devices, accident prevention procedures
and applicable regulations. The qualied worker is dened as one who
demonstrates skills and knowledge related to the construction and operation
of electric equipment and installations and has received safety training to
identify the hazards and reduce the associated risk.
4. Never allow bystanders near the work area.
5. Immediately alert your superviser of any hazardous conditions or irregularities
which could result in an accident, even if the chance of an accident is slim.
6. In the event of any unforseen, unanticipated or unexpected situation or occur-
rence of any type during work, immediately stop work and evacuate the area.
Notify appropriate supervising personnel.
7. Electrical shock can result if the user fails to maintain a safe and proper Min-
imum Approach Distance (MAD) as mandated by OSHA, local regulators, or
employer work rules, whichever is greatest.
8. Tools should not be laid on the ground because of possible moisture contami-
nation or wetting.
III. Before Each Use
1. If any defect, contamination, or other issue is noted which could possibly
adversely affect mechanical integrity of the tool, DO NOT USE THE TOOL.

www.rauckmanutility.com Doc. No. RUPMP3235A3
RAUCKMAN UTILITY PRODUCTS • METERPULLER® OWNER/OPERATOR MANUAL
The Rauckman Utility Products
METERPULLER® makes the task of
installing and removing electric meters
easier and safer. It reduces potential
injuries by encapsulating the meter and
giving the worker a solid handle for re-
moval and installation of these devices.
Made in the
USA, it is
constructed of a durable polycarbon-
ate material with chrome plated clips
that hold the meter in place. It fea-
tures a solid hand barrier, and vent
holes located close to the engage-
ment clips to divert hot gas.
The amber colored M-001 is de-
signed for residential meters and will
t “A” base meters, single phase ring
type meters and single phase ringless meters.
The M-002A is orange and will work on residential meters, and
commercial poly-phase ring type and ringless meters.
M-001 M-002A

www.rauckmanutility.com Doc. No. RUPMP3235A4
RAUCKMAN UTILITY PRODUCTS • METERPULLER® OWNER/OPERATOR MANUAL
USING THE RAUCKMAN
METERPULLER®
Inspect and clear the work area around
the meter of any items or
debris that may conict with the
operation.
Secure and inspect the appropriate
Personal Protective Equipment (PPE)
per your company safety rules. (See
page 2 for more information). This may
include the arc ash protective clothing,
hard hat, face shield/glasses and rubber
gloves with leather protectors. Your
company work rules and practices must
be followed at all times when using this
product.
The Rauckman METERPULLER® is a
tool to ease the removal and installation
of electric meters, both residential
and commercial. It is not, nor should
it be considered to be part of the PPE
required to complete this task.
Carefully inspect the Rauckman
METERPULLER® before each use. Any
tool must be removed from service
immediately for repair or replacement.
that exhibits conditions such as;
-Cracked or damaged polycarbonate
material
-Loose or bent engagement clips
-Loose handle or plugged vent holes

www.rauckmanutility.com Doc. No. RUPMP3235A5
RAUCKMAN UTILITY PRODUCTS • METERPULLER® OWNER/OPERATOR MANUAL
METER REMOVAL USING
THE RAUCKMAN UTILILITY
PRODUCTS M-001/M-002A
Slide the METERPULLER® over the
meter, and push into place until the
clips snap over the meter’s metal band,
or the bottom of the meter.
Caution: If you are unable to
secure the METERPULLER® with the
clips engaged, do not proceed to the
next step.
Once the METERPULLER® is
secure on the meter, rock the meter up
and down slightly to loosen the con-
nections. Do not use any side to side
motion as this may damage the con-
nections or the base.
When the meter is loose, simply tilt it
down to break the top contact and pull
it away from the base in one smooth
motion.
Using the M-002A is essentially the
same, only additional care must be
taken due to higher amperages and
heavier connections.
If the meter is so equipped with a by-
pass lever it should be placed into the
open position.

www.rauckmanutility.com Doc. No. RUPMP3235A6
RAUCKMAN UTILITY PRODUCTS • METERPULLER® OWNER/OPERATOR MANUAL
METER INSTALLATION USING
THE RAUCKMAN UTILITY
PRODUCTS M-001/M-002A
Snap the meter into the device. Verify
the clips are over the base of the meter
and it is secure in the device.
Carefully align the meter to the contacts,
then push the bottom into the base and
tilt the meter up to engage the contacts
in one smooth motion.
Verify the meter is correctly aligned and
fully engaged into the meter base.
Use of the M-002A is essentially the
same as the M-001.
After verifying the correct alignment and
installation of the meter simply push the
clips in to release the meter from the
unit and carefully remove the METER-
PULLER® from the meter.
When removing the Rauckman
METERPULLER®, be careful not to
either damage the meter or alter
the alignment.

www.rauckmanutility.com Doc. No. RUPMP3235A7
RAUCKMAN UTILITY PRODUCTS • METERPULLER® OWNER/OPERATOR MANUAL
OPTIONAL ARC SHIELD
The MPS-002A Arc Shield
is a polycarbonate disc that
is sold separately and may
be installed on either M-001
or M-002A Meterpullers®. It
keeps the hands away from
the meter base and offers pro-
tection for the body and hands
in a ash event.
INSTALLING THE ARC SHIELD
- Place the Arc Shield on top of the
METERPULLER®, inserting the ring
on top of the Meterpuller into the slot
under the Arc Shield.
- Use the two holes in the disc to mark
the placement of the bolt holes.
- Use a ¼” bit to drill the two holes.
- Insert the nylon bolts from inside the
METERPULLER®, and nger tighten
the wing nuts
The operation of the M-001 and M-002A
is unchanged with the addition of the
MPS-002A Arc Shield.
